IEI Technology IMBA-C2060 User manual

IMBA-C2060 ATX Motherboard
Page i
User Manual
MODEL:
IMBA-C2060
A
TX LGA1155 Motherboard for Intel® Core™ i3 Quad/Dual Core
CPU, Intel® C206 Chipset, DDR3, VGA/DVI/HDMI,
Dual Intel® PCIe GbE, Intel® AMT 7.0 Support, Two USB 3.0
Ports, Five COM Ports, Two SATA 6Gb/s Ports and RoHS
Rev. 2.01 – 23 April, 2014

IMBA-C2060 ATX Motherboard
Page ii
Revision
Date Version Changes
23 April, 2014 2.01 Modified
Table 3-24: LAN Pinouts
9 December, 2013 2.00 Updated for R20 version
9 November, 2012 1.03 Added Appendix F: Intel® Matrix Storage Manager
9 September, 2011 1.02 Modified Section4.3.1: AT/ATX Power Select Jumper
Added Section 4.6: Intel®AMT Setup Procedure
Added Chapter 6: Software Drivers
30 June, 2011 1.01 Modified Section 4.2.2 Socket LGA1155 Cooling Kit
Installation warning
25 May, 2011 1.00 Initial release

IMBA-C2060 ATX Motherboard
Page iii
Copyright
COPYRIGHT NOTICE
The information in this document is subject to change without prior notice in order to
improve reliability, design and function and does not represent a commitment on the part
of the manufacturer.
In no event will the manufacturer be liable for direct, indirect, special, incidental, or
consequential damages arising out of the use or inability to use the product or
documentation, even if advised of the possibility of such damages.
This document contains proprietary information protected by copyright. All rights are
reserved. No part of this manual may be reproduced by any mechanical, electronic, or
other means in any form without prior written permission of the manufacturer.
TRADEMARKS
All registered trademarks and product names mentioned herein are used for identification
purposes only and may be trademarks and/or registered trademarks of their respective
owners.

IMBA-C2060 ATX Motherboard
Page iv
Table of Contents
1 INTRODUCTION.......................................................................................................... 1
1.1 INTRODUCTION........................................................................................................... 2
1.2 BENEFITS ................................................................................................................... 2
1.3 FEATURES................................................................................................................... 3
1.4 CONNECTORS ............................................................................................................. 4
1.5 DIMENSIONS............................................................................................................... 5
1.6 DATA FLOW................................................................................................................ 6
1.7 TECHNICAL SPECIFICATIONS ...................................................................................... 7
2 PACKING LIST............................................................................................................. 9
2.1ANTI-STATIC PRECAUTIONS...................................................................................... 10
2.2 UNPACKING PRECAUTIONS....................................................................................... 10
2.3 PACKING LIST............................................................................................................11
2.4 OPTIONAL ITEMS...................................................................................................... 12
3 CONNECTORS ........................................................................................................... 14
3.1 PERIPHERAL INTERFACE CONNECTORS..................................................................... 15
3.1.1 IMBA-C2060 Layout........................................................................................ 15
3.1.2 Peripheral Interface Connectors ..................................................................... 16
3.1.3 External Interface Panel Connectors............................................................... 17
3.2 INTERNAL PERIPHERAL CONNECTORS...................................................................... 18
3.2.1 ATX Power Connector ..................................................................................... 18
3.2.2 Battery Connectors .......................................................................................... 19
3.2.3 CPU Power Connector.................................................................................... 20
3.2.4 DDR3 DIMM Slots........................................................................................... 21
3.2.5 Digital I/O Connector...................................................................................... 22
3.2.6 Fan Connector (CPU)...................................................................................... 23
3.2.7 Fan Connector (System) .................................................................................. 24
3.2.8 Front Panel Audio Connector.......................................................................... 25
3.2.9 Front Panel Connector .................................................................................... 26
3.2.10 I2C Connector................................................................................................ 27

IMBA-C2060 ATX Motherboard
Page v
3.2.11 Keyboard/Mouse Connector........................................................................... 28
3.2.12 Parallel Port Connector ................................................................................ 29
3.2.13 PCI Slots ........................................................................................................ 30
3.2.14 PCIe x4 Slots.................................................................................................. 31
3.2.15 PCIe x8 Slot ................................................................................................... 32
3.2.16 PCI Express x16/x8 Slot................................................................................. 32
3.2.17 SATA 3Gb/s Drive Connector ........................................................................ 33
3.2.18 SATA 6Gb/s Drive Connector ........................................................................ 34
3.2.19 Serial Port Connector, RS-422/485................................................................ 35
3.2.20 Serial Port Connectors, RS-232..................................................................... 37
3.2.21 SMBus Connector .......................................................................................... 37
3.2.22 SPDIF Connector........................................................................................... 38
3.2.23 SPI ROM Connector...................................................................................... 39
3.2.24 TPM Connector.............................................................................................. 40
3.2.25 USB Connectors............................................................................................. 41
3.3 EXTERNAL PERIPHERAL INTERFACE CONNECTOR PANEL ......................................... 43
3.3.1 Audio Connector .............................................................................................. 43
3.3.2 Ethernet and USB Connector........................................................................... 44
3.3.3 HDMI Port Connector..................................................................................... 45
3.3.4 Keyboard/Mouse Connector ............................................................................ 46
3.3.5 Serial Port Connectors (COM6)...................................................................... 46
3.3.6 VGA and DVI Connector ................................................................................. 47
4 INSTALLATION ......................................................................................................... 49
4.1ANTI-STATIC PRECAUTIONS...................................................................................... 50
4.2 INSTALLATION CONSIDERATIONS.............................................................................. 50
4.2.1 Socket LGA1155 CPU Installation .................................................................. 52
4.2.2 Socket LGA1155 Cooling Kit Installation........................................................ 55
4.2.3 DIMM Installation........................................................................................... 57
4.3 JUMPER SETTINGS .................................................................................................... 58
4.3.1 AT/ATX Power Select Jumper.......................................................................... 58
4.3.2 Clear CMOS Jumper........................................................................................ 59
4.3.3 Wake-on LAN Jumper ...................................................................................... 60
4.4 INTERNAL PERIPHERAL DEVICE CONNECTIONS........................................................ 61
4.4.1 SATA Drive Connection ................................................................................... 61

IMBA-C2060 ATX Motherboard
Page vi
4.5 EXTERNAL PERIPHERAL INTERFACE CONNECTION ................................................... 63
4.5.1 Audio Connector .............................................................................................. 63
4.5.2 DVI Display Device Connection...................................................................... 64
4.5.3 HDMI Connection............................................................................................ 65
4.5.4 LAN Connection............................................................................................... 66
4.5.5 PS/2 Keyboard and Mouse Connection ........................................................... 66
4.5.6 Serial Device Connection ................................................................................ 67
4.5.7 USB Connection (Dual Connector)................................................................. 68
4.5.8 VGA Monitor Connection ................................................................................ 69
4.6 INTEL®AMTSETUP PROCEDURE............................................................................. 70
5 BIOS.............................................................................................................................. 72
5.1 INTRODUCTION......................................................................................................... 73
5.1.1 Starting Setup................................................................................................... 73
5.1.2 Using Setup...................................................................................................... 73
5.1.3 Getting Help..................................................................................................... 74
5.1.4 Unable to Reboot after Configuration Changes.............................................. 74
5.1.5 BIOS Menu Bar................................................................................................ 74
5.2 MAIN........................................................................................................................ 75
5.3ADVANCED............................................................................................................... 76
5.3.1 ACPI Settings................................................................................................... 77
5.3.2 Trusted Computing........................................................................................... 78
5.3.3 CPU Configuration.......................................................................................... 79
5.3.3.1 CPU Information....................................................................................... 80
5.3.4 SATA Configuration ......................................................................................... 82
5.3.5 Intel TXT(LT) Configuration............................................................................ 83
5.3.6 USB Configuration........................................................................................... 84
5.3.7 Super IO Configuration ................................................................................... 86
5.3.7.1 Serial Port n Configuration....................................................................... 87
5.3.7.2 Parallel Port Configuration....................................................................... 93
5.3.8 H/W Monitor.................................................................................................... 94
5.3.8.1 FAN 1 Configuration ................................................................................ 95
5.3.8.2 FAN 2 Configuration ................................................................................ 97
5.3.9 Serial Port Console Redirection ...................................................................... 99
5.4 CHIPSET ................................................................................................................. 101

IMBA-C2060 ATX Motherboard
Page vii
5.4.1 North Bridge Configuration........................................................................... 102
5.4.2 South Bridge Configuration........................................................................... 104
5.4.3 Integrated Graphics....................................................................................... 108
5.4.4 ME Subsystem.................................................................................................110
5.5 BOOT.......................................................................................................................111
5.6 SECURITY................................................................................................................113
5.7 EXIT........................................................................................................................114
6 SOFTWARE DRIVERS.............................................................................................116
6.1AVAILABLE SOFTWARE DRIVERS .............................................................................117
6.2 SOFTWARE INSTALLATION .......................................................................................117
6.3 CHIPSET DRIVER INSTALLATION..............................................................................119
6.4 GRAPHICS DRIVER INSTALLATION.......................................................................... 122
6.5 LAN DRIVER INSTALLATION.................................................................................. 125
6.6AUDIO DRIVER INSTALLATION ............................................................................... 129
6.7 USB 3.0 DRIVER INSTALLATION ............................................................................ 131
6.8 INTEL®AMTDRIVER AND APPLICATION............................................................... 133
6.8.1 Intel® Management Engine Components Installation................................... 133
6.8.2 Intel® IT Director Application Installation................................................... 137
A BIOS OPTIONS ........................................................................................................ 144
B ONE KEY RECOVERY........................................................................................... 148
B.1 ONE KEY RECOVERY INTRODUCTION .................................................................... 149
B.1.1 System Requirement....................................................................................... 150
B.1.2 Supported Operating System......................................................................... 151
B.2 SETUP PROCEDURE FOR WINDOWS........................................................................ 152
B.2.1 Hardware and BIOS Setup ............................................................................ 152
B.2.2 Create Partitions ........................................................................................... 153
B.2.3 Install Operating System, Drivers and Applications..................................... 156
B.2.4 Build-up Recovery Partition.......................................................................... 157
B.2.5 Create Factory Default Image....................................................................... 159
B.3 SETUP PROCEDURE FOR LINUX.............................................................................. 164
B.4 RECOVERY TOOL FUNCTIONS ................................................................................ 167
B.4.1 Factory Restore ............................................................................................. 169
B.4.2 Backup System............................................................................................... 170

IMBA-C2060 ATX Motherboard
Page viii
B.4.3 Restore Your Last Backup.............................................................................. 171
B.4.4 Manual........................................................................................................... 172
B.5 OTHER INFORMATION............................................................................................ 173
B.5.1 Using AHCI Mode or ALi M5283 / VIA VT6421A Controller....................... 173
B.5.2 System Memory Requirement ........................................................................ 175
C TERMINOLOGY ..................................................................................................... 176
D DIGITAL I/O INTERFACE..................................................................................... 180
D.1 INTRODUCTION...................................................................................................... 181
D.2 DIO CONNECTOR PINOUTS ................................................................................... 181
D.3ASSEMBLY LANGUAGE SAMPLES........................................................................... 181
D.3.1 Enable the DIO Input Function .................................................................... 181
D.3.2 Enable the DIO Output Function.................................................................. 182
E WATCHDOG TIMER............................................................................................... 183
F INTEL® MATRIX STORAGE MANAGER.......................................................... 186
F.1 INTRODUCTION....................................................................................................... 187
F.1.1 Precautions .................................................................................................... 187
F.2 FEATURES AND BENEFITS ....................................................................................... 188
F.3 ACCESSING THE INTEL®MATRIX STORAGE MANAGER.......................................... 188
F.4 INSTALLING THE OPERATING SYSTEM TO THE RAIDARRAY .................................. 189
G HAZARDOUS MATERIALS DISCLOSURE....................................................... 190
G.1 HAZARDOUS MATERIALS DISCLOSURE TABLE FOR IPB PRODUCTS CERTIFIED AS
ROHS COMPLIANT UNDER 2002/95/EC WITHOUT MERCURY..................................... 191

IMBA-C2060 ATX Motherboard
Page ix
List of Figures
Figure 1-1: IMBA-C2060 .................................................................................................................2
Figure 1-2: Connectors ..................................................................................................................4
Figure 1-3: IMBA-C2060 Dimensions (mm)..................................................................................5
Figure 1-4: Data Flow Diagram......................................................................................................6
Figure 3-1: Connectors and Jumpers.........................................................................................15
Figure 3-2: ATX Power Connector Pinout Location..................................................................18
Figure 3-3: Battery Connector Locations...................................................................................20
Figure 3-4: CPU Power Connector Location..............................................................................21
Figure 3-5: DDR3 DIMM Slot Locations......................................................................................22
Figure 3-6: Digital I/O Connector Location ................................................................................23
Figure 3-7: CPU Fan Connector Location..................................................................................24
Figure 3-8: System Fan Connector Location.............................................................................25
Figure 3-9: Front Panel Audio Connector Location..................................................................26
Figure 3-10: Front Panel Connector Location ...........................................................................27
Figure 3-11: I2C Connector Location..........................................................................................28
Figure 3-12: Keyboard/Mouse Connector Location..................................................................29
Figure 3-13: Parallel Port Connector Location..........................................................................30
Figure 3-14: PCI Slot Locations ..................................................................................................31
Figure 3-15: PCIe x4 Slot Locations ...........................................................................................31
Figure 3-16: PCIe x8 Slot Location .............................................................................................32
Figure 3-17: PCIe x16 Slot Location ...........................................................................................33
Figure 3-18: SATA 3Gb/s Drive Connector Location................................................................34
Figure 3-19: SATA 6Gb/s Drive Connector Location................................................................35
Figure 3-20: RS-422/485 Connector Location............................................................................36
Figure 3-21: Serial Port Connector Location.............................................................................37
Figure 3-22: SMBus Connector Location...................................................................................38
Figure 3-23: SPDIF Connector Location ....................................................................................39
Figure 3-24: SPI Connector Location .........................................................................................40
Figure 3-25: TPM Connector Location........................................................................................41
Figure 3-26: USB Connector Pinout Locations.........................................................................42

IMBA-C2060 ATX Motherboard
Page x
Figure 3-27: External Peripheral Interface Connector..............................................................43
Figure 3-28: Audio Connector.....................................................................................................44
Figure 3-29: Ethernet Connector.................................................................................................44
Figure 3-30: Serial Port Connector Pinouts...............................................................................47
Figure 3-31: VGA Connector .......................................................................................................48
Figure 4-1: Disengage the CPU Socket Load Lever..................................................................52
Figure 4-2: Remove Protective Cover.........................................................................................53
Figure 4-3: Insert the Socket LGA1155 CPU..............................................................................54
Figure 4-4: Close the Socket LGA1155 ......................................................................................54
Figure 4-5: Cooling Kits (CF-1156A-RS and CF-1156E-RS) .....................................................55
Figure 4-6: Cooling Kit Support Bracket....................................................................................56
Figure 4-7: DIMM Installation.......................................................................................................57
Figure 4-8: AT/ATX Power Mode Jumper Location...................................................................59
Figure 4-9: Clear BIOS Jumper Location ...................................................................................60
Figure 4-10: Wake-on LAN Connector Pinout Locations .........................................................61
Figure 4-11: SATA Drive Cable Connection...............................................................................62
Figure 4-12: SATA Power Drive Connection..............................................................................62
Figure 4-13: Audio Connector.....................................................................................................63
Figure 4-14: DVI Connector .........................................................................................................64
Figure 4-15: HDMI Connection....................................................................................................65
Figure 4-16: LAN Connection......................................................................................................66
Figure 4-17: PS/2 Keyboard/Mouse Connector.........................................................................67
Figure 4-18: Serial Device Connector.........................................................................................68
Figure 4-19: USB Connector........................................................................................................69
Figure 4-20: VGA Connector .......................................................................................................70
Figure 6-1: Introduction Screen............................................................................................... 118
Figure 6-2: Available Drivers.................................................................................................... 118
Figure 6-3: Chipset Driver Screen............................................................................................ 119
Figure 6-4: Chipset Driver Welcome Screen........................................................................... 120
Figure 6-5: Chipset Driver License Agreement...................................................................... 120
Figure 6-6: Chipset Driver Read Me File ................................................................................. 121
Figure 6-7: Chipset Driver Setup Operations ......................................................................... 121
Figure 6-8: Chipset Driver Installation Finish Screen............................................................ 122
Figure 6-9: Graphics Driver Welcome Screen........................................................................ 123
Figure 6-10: Graphics Driver License Agreement.................................................................. 123

IMBA-C2060 ATX Motherboard
Page xi
Figure 6-11: Graphics Driver Setup Operations..................................................................... 124
Figure 6-12: Graphics Driver Installation Finish Screen ....................................................... 124
Figure 6-13: Intel® Network Connection Menu....................................................................... 125
Figure 6-14: LAN Driver Welcome Screen .............................................................................. 126
Figure 6-15: LAN Driver License Agreement.......................................................................... 126
Figure 6-16: LAN Driver Setup Options................................................................................... 127
Figure 6-17: LAN Driver Installation ........................................................................................ 128
Figure 6-18: LAN Driver Installation Complete....................................................................... 128
Figure 6-19: Audio Driver – Extracting Files........................................................................... 129
Figure 6-20: Audio Driver Welcome Screen............................................................................ 130
Figure 6-21: Audio Driver Installation...................................................................................... 130
Figure 6-22: Audio Driver Installation Complete.................................................................... 130
Figure 6-23: USB 3.0 Driver Welcome Screen........................................................................ 131
Figure 6-24: USB 3.0 Driver License Agreement.................................................................... 132
Figure 6-25: USB 3.0 Driver Installation Screen..................................................................... 132
Figure 6-26: USB 3.0 Driver Update Complete ....................................................................... 133
Figure 6-27: Intel® ME Driver Welcome Screen ..................................................................... 134
Figure 6-28: Intel® ME Driver License Agreement................................................................. 135
Figure 6-29: Intel® ME Driver Read Me File ............................................................................ 135
Figure 6-30: Intel® ME Driver Setup Operations.................................................................... 136
Figure 6-31: Intel® ME Driver Installation Finish Screen ...................................................... 137
Figure 6-32: IT Director Welcome Screen ............................................................................... 138
Figure 6-33: IT Director License Agreement........................................................................... 139
Figure 6-34: IT Director Installation......................................................................................... 139
Figure 6-35: IT Director Installation Complete........................................................................ 140
Figure 6-36: IT Director Configuration Tool Welcome Screen.............................................. 141
Figure 6-37: IT Director – Creating Password ........................................................................ 142
Figure 6-38: IT Director Configuration Complete................................................................... 142
Figure B-1: IEI One Key Recovery Tool Menu ........................................................................ 149
Figure B-2: Launching the Recovery Tool.............................................................................. 153
Figure B-3: Recovery Tool Setup Menu .................................................................................. 154
Figure B-4: Command Mode..................................................................................................... 154
Figure B-5: Partition Creation Commands.............................................................................. 155
Figure B-6: Launching the Recovery Tool.............................................................................. 157
Figure B-7: System Configuration for Windows .................................................................... 157

IMBA-C2060 ATX Motherboard
Page xii
Figure B-8: Build-up Recovery Partition................................................................................. 158
Figure B-9: Press any key to continue.................................................................................... 158
Figure B-10: Press F3 to Boot into Recovery Mode............................................................... 159
Figure B-11: Recovery Tool Menu ........................................................................................... 159
Figure B-12: About Symantec Ghost Window........................................................................ 160
Figure B-13: Symantec Ghost Path ......................................................................................... 160
Figure B-14: Select a Local Source Drive ............................................................................... 161
Figure B-15: Select a Source Partition from Basic Drive ...................................................... 161
Figure B-16: File Name to Copy Image to ............................................................................... 162
Figure B-17: Compress Image.................................................................................................. 162
Figure B-18: Image Creation Confirmation............................................................................. 163
Figure B-19: Image Creation Process...................................................................................... 163
Figure B-20: Image Creation Complete................................................................................... 163
Figure B-21: Press Any Key to Continue ................................................................................ 164
Figure B-22: Partitions for Linux.............................................................................................. 165
Figure B-23: System Configuration for Linux......................................................................... 166
Figure B-24: Access menu.lst in Linux (Text Mode).............................................................. 166
Figure B-25: Recovery Tool Menu ........................................................................................... 167
Figure B-26: Recovery Tool Main Menu.................................................................................. 168
Figure B-27: Restore Factory Default...................................................................................... 169
Figure B-28: Recovery Complete Window.............................................................................. 169
Figure B-29: Backup System.................................................................................................... 170
Figure B-30: System Backup Complete Window ................................................................... 170
Figure B-31: Restore Backup ................................................................................................... 171
Figure B-32: Restore System Backup Complete Window..................................................... 171
Figure B-33: Symantec Ghost Window ................................................................................... 172

IMBA-C2060 ATX Motherboard
Page xiii
List of Tables
Table 1-1: IMBA-C2060 Specifications .........................................................................................8
Table 2-1: Packing List.................................................................................................................12
Table 2-2: Optional Items.............................................................................................................13
Table 3-1: Peripheral Interface Connectors...............................................................................17
Table 3-2: Rear Panel Connectors..............................................................................................17
Table 3-3: ATX Power Connector Pinouts .................................................................................19
Table 3-4: Battery Connector (BT2) Pinouts..............................................................................20
Table 3-5: CPU Power Connector Pinouts.................................................................................21
Table 3-6: Digital I/O Connector Pinouts....................................................................................23
Table 3-7: CPU Fan Connector Pinouts......................................................................................24
Table 3-8: System Fan Connector Pinouts ................................................................................25
Table 3-9: Front Panel Audio Connector Pinouts .....................................................................26
Table 3-10: Front Panel Connector Pinouts...............................................................................27
Table 3-11: I2C Connector Pinouts.............................................................................................28
Table 3-12: Keyboard/Mouse Connector Pinouts .....................................................................29
Table 3-13: Parallel Port Connector Pinouts .............................................................................30
Table 3-14: SATA 3Gb/s Drive Connector Pinouts....................................................................34
Table 3-15: SATA 6Gb/s Drive Connector Pinouts....................................................................35
Table 3-16: RS-422/485Connector Pinouts ................................................................................36
Table 3-17: D-sub 9 RS-422/485 Pinouts....................................................................................36
Table 3-18: Serial Port Connector Pinouts ................................................................................37
Table 3-19: SMBus Connector Pinouts ......................................................................................38
Table 3-20: SPDIF Connector Pinouts........................................................................................39
Table 3-21: SPI Connector Pinouts.............................................................................................40
Table 3-22: TPM Connector Pinouts...........................................................................................41
Table 3-23: USB Port Connector Pinouts...................................................................................42
Table 3-24: LAN Pinouts ..............................................................................................................44
Table 3-25: Connector LEDs........................................................................................................45
Table 3-26: USB Port Pinouts......................................................................................................45
Table 3-27: HDMI Connector Pinouts .........................................................................................46

IMBA-C2060 ATX Motherboard
Page xiv
Table 3-28: PS/2 Connector Pinouts...........................................................................................46
Table 3-29: Serial Port Connector Pinouts ................................................................................47
Table 3-30: VGA Connector Pinouts...........................................................................................47
Table 3-31: DVI Connector Pinouts.............................................................................................48
Table 4-1: Jumpers.......................................................................................................................58
Table 4-2: AT/ATX Power Mode Jumper Settings.....................................................................59
Table 4-3: Clear BIOS Jumper Settings......................................................................................59
Table 4-4: Wake-on LAN Connector Pinouts.............................................................................60
Table 5-1: BIOS Navigation Keys................................................................................................74
Table 6-1: Digital I/O Connector Pinouts................................................................................. 181

IMBA-C2060 ATX Motherboard
Page xv
BIOS Menus
BIOS Menu 1: Main.......................................................................................................................75
BIOS Menu 2: Advanced..............................................................................................................77
BIOS Menu 3: ACPI Configuration..............................................................................................77
BIOS Menu 4: TPM Configuration...............................................................................................78
BIOS Menu 5: CPU Configuration...............................................................................................79
BIOS Menu 6: CPU Configuration...............................................................................................80
BIOS Menu 7: SATA Configuration.............................................................................................82
BIOS Menu 8: Intel TXT(LT) Configuration ................................................................................84
BIOS Menu 9: USB Configuration...............................................................................................84
BIOS Menu 10: Super IO Configuration......................................................................................86
BIOS Menu 11: Serial Port n Configuration Menu.....................................................................87
BIOS Menu 12: Parallel Port Configuration Menu.....................................................................93
BIOS Menu 13: H/W Monitor........................................................................................................94
BIOS Menu 14: FAN 1 Configuration..........................................................................................96
BIOS Menu 15: FAN 2 Configuration..........................................................................................98
BIOS Menu 16: Serial Port Console Redirection.................................................................... 100
BIOS Menu 17: Chipset............................................................................................................. 102
BIOS Menu 18:Northbridge Chipset Configuration................................................................ 102
BIOS Menu 19: Southbridge Chipset Configuration.............................................................. 105
BIOS Menu 20: Integrated Graphics........................................................................................ 109
BIOS Menu 21: ME Subsystem................................................................................................. 110
BIOS Menu 22: Boot.................................................................................................................. 111
BIOS Menu 23: Security............................................................................................................ 113
BIOS Menu 24:Exit..................................................................................................................... 114

IMBA-C2060 ATX Motherboard
Page 1
Chapter
1
1 Introduction

IMBA-C2060 ATX Motherboard
Page 2
1.1 Introduction
Figure 1-1: IMBA-C2060
The IMBA-C2060 is an ATX motherboard. It accepts a Socket LGA1155 Intel® Xeon® or
Core™ i3 processor with quad or dual core and supports four 240-pin 1333/1066 MHz
dual-channel DDR3 DIMM modules up to 32.0 GB maximum. The IMBA-C2060 includes a
VGA, HDMI, and DVI-D port. Expansion and I/O include three PCI card slots, one PCIe
x16 (x16 or x8 mode) slot, one PCIe x16 (x8 mode) slot, two PCIe x4 card slots, two USB
3.0 ports on the rear panel by ASMedia ASM1042, four USB 2.0 by rear panel, eight USB
2.0 by pin header, four SATA 3Gb/s connectors, two SATA 6Gb/s connectors, six COM
ports, and two keyboard/mouse connectors.
1.2 Benefits
Some of the IMBA-C2060 motherboard benefits include:
Powerful graphics with multiple monitors
Staying connected with both wired LAN connections
Speedy running of multiple programs and applications

IMBA-C2060 ATX Motherboard
Page 3
1.3 Features
Some of the IMBA-C2060 motherboard features are listed below:
ATX form factor
RoHS compliant
LGA1155 CPU socket
Three PCI card expansion slots
Multiple PCIe expansion card configurations:
Slot PCIe x16 PCIe x8 PCIe x4 PCI
Configuration 1 1 N/A 2 3
Configuration 2 N/A 2 2 3
Configuration 3 N/A 1 2 3
Supports four dual-channel DDR3 DIMMs
One external RS-232 serial port
Four internal RS-232 serial ports connectors
One internal RS-422/485 serial port connector
Two Intel® PCIe Gigabit Ethernet connectors (LAN2 with Intel® AMT 7.0
support)
Four SATA3Gb/s connectors
Two SATA6Gb/s connectors
High Definition Audio
Intel® C206 chipset

IMBA-C2060 ATX Motherboard
Page 4
1.4 Connectors
The connectors on the IMBA-C2060 are shown in the figure below.
Figure 1-2: Connectors
