Fall Function ETX Baseboard with VGA/LVDS/
TTL,Audio, CF type II & Digital I/O
IEM-DB-7S-RS
Quick Installation Guide
Version 3.0
May 25, 2007
Package Contents
IEM-DB-7S-RS-R30 package includes the following items:
 1 x IEM-DB-7S-RS-R30 single board computer
 1 x FDD cable
 1 x HDD cable
 1 x RS-232/422/485 cable
 1 x Mini jumper pack
 1 x User manual(QIG)
©2006 Copyright by IEI Technology corp.
All rights reserved.

2
Specifications

CPU Module Interface: ETX Form Factor

Displan Interface: 1 x 30-pin 24-bit DFP for LVDS
1 x 40-pin for 18-bit TTL

Expansions Solt: 4 x PCI,3 x ISA

SSD: CF Type II

Audio: AC’97/HD Codec on ETX CPU Module

Ethernet Connector: 1 x RJ-45

RS-232: 1

RS-232,422,485: 1

KB/MS: 2

LPT: 1

VGA: 1

USB2.0: 4

IDE Connector: 2

FDD: 1

Digital I/O: 8 bit digital I/O, 4-inpot / 4-output for Programmable

IR connector: 5 pin-header

Power Supply: ATX
Ordering Information
IEM-DB-7S-RS-R30
ATX Size 7 Slots ETX Baseboard

3
Jumpers setting and Connectors
JP15: Compact Flash
Mode selcet
JP15 Description
1-2 SLAVE
2-3 MASTER
CN5: TV OUT Connector
PIN Description PIN Description
1 TVSYNC 2 TVY
3 GND 4 TVC
5 GND 6 TVCVBS
CN7: IR Connector
PIN Description
1 VCC5
2 NC
3 IR-RX
4 GND
5 IR-TX
CN14: RS-232/RS-422/RS-485 Connector
PIN Description PIN Description
1 DCD# 2 DSR
3 RXD 4 RTS
5 TXD 6 CTS
7 DTR# 8 RI
9 GND 10 NC
11 TXD485+ 12 TXD485#
13 RXD485+ 14 RXD485#
JP16: AT/ATX Power
Mode Select
JP16 Description
short AT Mode
open ATX Mode
CN9: IDE Connector(Bule)(IDE40)
PIN Description PIN Description
1 RESET# 2 GND
3 D7 4 D8
5 D6 6 D9
7 D5 8 D10
9 D4 10 D11
11 D3 12 D12
13 D2 14 D13
15 D1 16 D14
17 D0 18 D15
19 GND
21 DRQ 22 GND
23 IOW# 24 GND
25 IOR# 26 GND
27 RDY 28 GND
29 ACK# 30 GND
31 INTR 32 NC
33 A1 34 CABLE_ID
35 A0 36 A2
37 HD_SELECT 0 38 HD_SELECT 1
39 ACTIVE# 40 GND
CN32: 6-pin Header
Keyboard/Mouse Connector
PIN Description
1 VCC5
2 Mouse_Date
3 Mouse_Clock
4 Keyboard_ Date
5 Keyboard_ Clock
6 GND
JP15: Compact Flash
Mode selcet
JP15 Description
1-2 MASTER
2-3 SLAVE
* For Intel.Chipset mode

4
JP5: COM2 Serial Port RI and
Voitage selection
JP5 Description
1-2 COM2 RI PIN USE RI
3-4 COM2 RI PIN USE +5V
4-5 COM2 RI PIN USE +12V
JP14: LCD Panel Voitage and
BL_ADJ Select
JP14 Description
1-2 Panel Voltage 3.3V
2-3 Panel Voltage 5V
5-6 BL_ADJ pull VCC5
6-7 BL_ADJ pull GND
JP17: Serial Port (COM2) MODE
RS-232/RS-422/RS-485 Select
JP17 Description
1-2 RS-232
3-4 RS-485
5-6 RS-422
CN12: Floppy Connector
PIN Description PIN Description
1 GND 2 RWC-
3 GND 4 NC
5 GND 6 NC
7 GND 8 INDEX#
9 GND 10 MOTEA#
11 GND 12 DRVB#
13 GND 14 DRVA#
15 GND 16 MOTEB#
17 GND 18 DIR#
19 GND 20 STEP#
21 GND 22 WDATA#
23 GND 24 WGDATA#
25 GND 26 TRK#
27 GND 28 WPT#
29 GND 30 RDATA#
31 GND 32 HEAD
33 LPY/FLPY# 34 DSKCHG#
CN17: USB Connector
PIN Description PIN Description
1 VCC5 2 GND
3 USB3- 4 USB4+
5 USB3+ 6 USB4-
7 GND 8 VCC5
CN21: External Switches and Indicators
PIN Description PIN Description
1 PWRLED+ 2 VCC5
3 PWRLED+ 4 GND
5 PWRLED- 6 BUZZER
7 KBINH 8 PC_BEEP
9 GND 10 NC
11 GND 12 IDE_LED-
13 PWRBTN# 14 IDE_LED+
15 NC 16 NC
17 NC 18 RESET+
19 GND 20 RESET-
*Pin6-8 Short Onboard Buzzer
CN41: FAN Connector
PIN Description
3 NC
2 VCC12
1 GND
CN42: FAN Connector
PIN Description
3 NC
2 VCC12
1 GND
JP11: CLEAR CMOS
JP11 Description
1-2 Normal
2-3 CLEAR CMOS

5
r
CN34: GPIO Connector
PIN Description PIN Description
1 VCC5 2 GND
3 GPIO0 4 GPIO1
5 GPIO2 6 GPIO3
7 GPIO4 8 GPIO5
9 GPIO6 10 GPIO7
CN37: Inverter Connector
PIN Description
1 BL_ADJ
2 GND
3 +12V
4 GND
5 BL_EN
CN10: Print Connector
PIN Description PIN Description
1 STB# 14 AFD#
2 PD0 15 ERROR#
3 PD1 16 INIT#
4 PD2 17 SLCTIN#
5 PD3 18 GND
6 PD4 19 GND
7 PD5 20 GND
8 PD6 21 GND
9 PD7 22 GND
10 ACK# 23 GND
11 BUSY 24 GND
12 PE 25 GND
13 SELECT
CN11: IDE Connector(IDE44)
PIN Description PIN Description
1 RESET# 2 GND
3 D7 4 D8
5 D6 6 D9
7 D5 8 D10
9 D4 10 D11
11 D3 12 D12
13 D2 14 D13
15 D1 16 D14
17 D0 18 D15
19 GND
21 DRQ 22 GND
23 IOW# 24 GND
25 IOR# 26 GND
27 RDY 28 GND
29 ACK# 30 GND
31 INTR 32 NC
33 A1 34 CABLE_ID
35 A0 36 A2
37 HD_SELECT 0 38 HD_SELECT 1
39 ACTIVE# 40 GND
41 VCC5 42 VCC5
43 GND 44 NC
CN39: ATX POWER Conector
PIN Description PIN Description
11 +3.3V 1 +3.3V
12 -12V 2 +3.3V
13 GND 3 GND
14 PS_ON 4 VCC5
15 GND 5 GND
16 GND 6 VCC5
17 GND 7 GND
18 -5V 8 NC
19 VCC5 9 5VSB
20 VCC5 10 +12V

6
CN35: Flat panel Dual (two) Channe;LVDS
Conector (Hirose DF13-30DP-1.25V)
PIN Description PIN Description
2 GND 1 DENSEL#
4 LVDSA_0- 3 LVDSA_0+
6 LVDSA_1- 5 LVDSA_1+
8 LVDSA_2- 7 LVDSA_2+
10 LVDSA_CLK- 9 LVDSA_CLK+
12 LVDSA_3- 11 LVDSA_3+
14 GND 13 GND
16 LVDSB_0- 15 LVDSB_0+
18 LVDSB_1- 17 LVDSB_1+
20 LVDSB_2- 19 LVDSB_2+
22 LVDSB_CLK- 21 LVDSB_CLK+
24 LVDSB_3- 23 LVDSB_3+
26 GND 25 GND
28 VCC_LVDS 27 VCC_LVDS
30 VCC_LVDS 29 VCC_LVDS
CN36: Flat Panel TTL Conector (Hirose
DF13-40DP-1.25V)
PIN Description PIN Description
2 VCC_FP 1 VCC_FP
4 GND 3 GND
6 VCC_FP 5 VCC_FP
8 GND 7 SMB_SDA / I_SDA
10 B1 9 B0
12 B3 11 B2
14 B5 13 B4
16 NC 15 NC
18 G1 17 G0
20 G3 19 G2
22 G5 21 G4
24 NC 23 NC
26 R1 25 R0
28 R3 27 R2
30 R5 29 R4
32 NC 31 NC
34 GND 33 GND
36 FP_VS 35 FP_CLK
38 FP_HS 37 FP_DE
40 FP_ENVEE 39 SMB_SCL / I_SCL

7
PCI Slot Connector
SIGNAL PIN NO. PCI SLOT1 PCI SLOT2 PCI SLOT3 PCI SLOT4
REQ# B18 REQ0# REQ1# REQ2# REQ3#
GNT# A17 GNT0# GNT1# GNT2# GNT3#
CLOCK B16 PCI CLK1 PCI CLK2 PCI CLK3 PCI CLK4
IDSEL A26 AD19 AD20 AD21 AD22
INTA# A6 A B C D
INTB# B7 B C D A
INTC# A7 C D A B
INTD# B8 D A B C
X1 :USB, AUDIO, PCI
PIN Description PIN Description PIN Description PIN Description
2 GND 1 GND 52 VCC5 51 VCC5
4 PCICLK4 3 PCICLK3 54 SERR# 53 PAR
6 GND 5 GND 56 NC 55 PERR#
8 PCICLK2 7 PCICLK1 58 USB2- 57 PME#
10 GNT3# 9 REQ3# 60 DEVSEL# 59 LOCK#
12 VCC3 11 GNT2# 62 USB3- 61 TRDY#
14 GNT1# 13 REQ2# 64 STOP# 63 IRDY3
16 VCC3 15 REQ1# 66 USB2+ 65 FRAME#
18 NC 17 GNT0# 68 GND 67 GND
20 VCC5 19 VCC5 70 CBE2# 69 AD16
22 REQ0# 21 NC 72 USB3+ 71 AD17
24 VCC3 23 AD0 74 AD18 73 AD19
26 AD2 25 AD1 76 USB0- 75 AD20
28 AD3 27 AD4 78 AD21 77 AD22
30 AD5 29 AD6 80 USB1- 79 AD23
32 AD7 31 CBE0# 82 CBE3# 81 AD24
34 AD9 33 AD8 84 VCC5 83 VCC5
36 GND 35 GND 86 AD26 85 AD25
38 LINEINL 37 AD10 88 USB0+ 87 AD28
40 MIC 39 AD11 90 AD29 89 AD27
42 LINEINR 41 AD12 92 USB1+ 91 AD30
44 VCCAUD 43 AD13 94 AD31 93 PCIRST#
46 LINEOUTL 45 AD14 96 INTD# 95 INTC#
48 GNDAUD 47 AD15 98 INTB# 97 INTA#
50 LINEOUTR 49 CBE1# 100 GND 99 GND

8
X2 : ISA, GPIO
PIN Description PIN Description PIN Description PIN Description
2 GND 1 GND 52 VCC5 51 VCC5
4 SD15 3 SD14 54 IRQ5 53 SA6
6 MASTER# 5 SD13 56 IRQ6 55 SA7
8 DREQ7 7 SD12 58 IRQ7- 57 SA8
10 DACK7# 9 SD11 60 SYSCLK 59 SA9
12 DREQ6 11 SD10 62 REFSH# 61 SA10
14 DACK6# 13 SD9 64 DRQE1 63 SA11
16 DREQ5 15 SD8 66 DACK1# 65 SA12
18 DACK5# 17 MEMW# 68 GND 67 GND
20 DREQ0 19 MEMR# 70 DREQ3 69 SA13
22 DACK0# 21 LA17 72 DACK3# 71 SA14
24 IRQ14 23 LA18 74 IOR# 73 SA15
26 IRQ15 25 LA19 76 IOW#- 75 SA16
28 IRQ12 27 LA20 78 SA17 77 SA18
30 IRQ11 29 LA21 80 SMEMR# 79 SA19
32 IRQ10 31 LA22 82 AEN 81 IOCHRDY
34 IOCS16# 33 LA23 84 VCC5 83 VCC5
36 GND 35 GND 86 SMEMW# 85 SD0
38 MCS16# 37 SBHE# 88 SD1 87 SD2
40 OSC 39 SA0 90 OWS# 89 SD3
42 BALE 41 SA1 92 SD4 91 DREQ2
44 TC 43 SA2 94 IRQ9 93 SD5
46 DACK2# 45 SA3 96 SD7 95 SD6
48 IRQ3 47 SA4 98 RSTDRV 97 IOCHK#
50 IRQ4 49 SA5 100 GND 99 GND

9
X3 : Serial Port, Print, LCD, TV OUT,
PIN Description PIN Description PIN Description PIN Description
2 GND 1 GND 52 NC 51 LPT/FLPY#
4 CRT_B 3 CRT_R 54 GND 53 VCC5
6 CRT_G 5 CRTHSYNC 56 AFD# 55 STB#
8 DDCSCL 7 CRTVSYNC 58 PD7 57 NC
10 DDCSDA 9 LCD_PLUG# 60 ERR# 59 IRRX
12 LSY3#/FPCLK 11 LSCLK#/B4 62 PD6 61 IRTX
14 LSY3+/LCDEN 13 LSCLK+/B5 64 INIT# 63 U_RXD2
16 GND 15 GND 66 GND 65 GND
18 LSY2+/B3 17 LSY1+/B1 68 PD5 67 U_RTS2#
20 LSY2#/B2 19 LSY1#/B0 70 SLIN# 69 U_DTR2#
22 GND 21 GND 72 PD4 71 U_DCD2#
24 LSY0+/G5 23 LFY3#/G2 74 PD3 73 U_DSR2#
26 LSY0#/G4 25 LFY3+/G3 76 PD2 75 U_CTS2#
28 GND 27 GND 78 PD1 77 U_TXD2
30 L_FCLK+/G1 29 LFY2#/R4 80 PD0 79 U_RI2#
32 L_FCLK#/G0 31 LFY2+/R5 82 VCC5 81 VCC5
34 GND 33 GND 84 ACK# 83 U_RXD1
36 L_FY1+/R3 35 LFY0+/R1 86 BUSY 85 U_RTS1#
38 L_FY1#/R2 37 LFY0#/R0 88 PE 87 U_DTR1#
40 VCC5 39 VCC5 90 SLCT 89 U_DCD1#
42 LCD_VSYNC 41 JILI_DAT 92 MSCLK 91 U_DSR1#
44 FPENABKL 43 JILI_CLK 94 MSDATA 93 U_CTS1#
46 FPENAVDD 45 LCD_HSYNC 96 KBCLK 95 U_TXD1
48 TV_Y 47 TV_CVBS 98 KBDATA 97 U_RI1#
50 TV_C 49 TV_SYNC 100 GND 99 GND

10
X4 : IDE, Compact Flash, LAN, Power
PIN Description PIN Description PIN Description PIN Description
2 GND 1 GND 52 IDEPIORX 51 IDESIOWX
4 PWGIN 3 5VSB 54 IDEIOWX 53 IDESDREQR
6 PCBEEP 5 PS_ON 56 IDEPDREQR 55 IDESDR15
8 VBAT 7 PWRBTN# 58 IDEPDR15 57 IDESDR0
10 L1_LINK# 9 KBINH 60 IDEPDR0 59 IDESDR14
12 L1_ACT# 11 NC 62 IDEPDR14 61 IDESDR1
14 NC 13 NC 64 IDEPDR1 63 IDESDR13
16 SMB_SCL/NC 15 NC 66 GND 65 GND
18 VCC5 17 VCC5 68 IDEPDR13 67 IDESDR2
20 NC 19 USB_OC# 70 IDEPDR2 69 IDESDR12
22 SMB_SDA/NC 21 NC 72 IDEPDR12 71 IDESDR3
24 NC 23 NC 74 IDEPDR3 73 IDESDR11
26 NC 25 IDESCS1X 76 IDEPDR11 75 IDESDR4
28 DASP_S 27 IDESCS0X 78 IDEPDR4 77 IDESDR10
30 IDEPCS1X 29 IDESA2 80 IDEPDR10 79 IDESDR5
32 IDEPCS0X 31 IDESA0 82 VCC5 81 VCC5
34 GND 33 GND 84 IDEPDR5 83 IDEPDR9
36 IDEPA2 35 PDIAG_S 86 IDEPDR9 85 IDEPDR6
38 IDEPA0 37 IDESA1 88 IDEPDR6 87 IDEPDR8
40 IDEPA1 39 IDESINTR 90 PCABLE66# 89 RINGWAKE#
42 NC 41 NC 92 IDEPDR8 91 L1_RXIN-
44 IDEPINTR 43 IDESDACKX 94 IDEPDR7 93 L1_RXIN+
46 IDEPDACKX 45 IDESIORDYR 96 IDESDR7 95 L1_TXD-
48 IDEPIORDYR 47 IDESIORX 98 IDEPRSTX 97 L1_TXD+
50 VCC5 49 VCC5 100 GND 99 GND

11
Board Layout: Jumper and Connector Locations
