IEI Technology IMBA-C2260-i2 User manual

IMBA-C2260-i2 ATX Motherboard
Page i
User Manual
MODEL:
IMBA-C2260-i2
ATX Motherboard Supports LGA1150 Intel
®
Xeon
®
E3,
Core™ i3, Pentium® or Celeron® CPU, Intel® C226 Chipset,
DDR3, VGA, iDP, Dual Intel® PCIe GbE, Six SATA 6Gb/s,
Four USB 3.0, HD Audio, iRIS-2400 and RoHS
Rev. 1.01 – 18 February, 2014

IMBA-C2260-i2 ATX Motherboard
Page ii
Revision
Date Version Changes
18 February, 2014 1.01 Changed the PCIEX4_1 slot to a PCIe x1 slot
14 January, 2014 1.00 Initial release

IMBA-C2260-i2 ATX Motherboard
Page iii
Copyright
COPYRIGHT NOTICE
The information in this document is subject to change without prior notice in order to
improve reliability, design and function and does not represent a commitment on the part
of the manufacturer.
In no event will the manufacturer be liable for direct, indirect, special, incidental, or
consequential damages arising out of the use or inability to use the product or
documentation, even if advised of the possibility of such damages.
This document contains proprietary information protected by copyright. All rights are
reserved. No part of this manual may be reproduced by any mechanical, electronic, or
other means in any form without prior written permission of the manufacturer.
TRADEMARKS
All registered trademarks and product names mentioned herein are used for identification
purposes only and may be trademarks and/or registered trademarks of their respective
owners.

IMBA-C2260-i2 ATX Motherboard
Page iv
Table of Contents
1 INTRODUCTION.......................................................................................................... 1
1.1 INTRODUCTION........................................................................................................... 2
1.2 FEATURES................................................................................................................... 3
1.3 CONNECTORS ............................................................................................................. 4
1.4 DIMENSIONS............................................................................................................... 5
1.5 DATA FLOW................................................................................................................ 6
1.6 TECHNICAL SPECIFICATIONS ...................................................................................... 7
2 PACKING LIST........................................................................................................... 10
2.1ANTI-STATIC PRECAUTIONS.......................................................................................11
2.2 UNPACKING PRECAUTIONS........................................................................................11
2.3 PACKING LIST........................................................................................................... 12
2.4 OPTIONAL ITEMS...................................................................................................... 13
3 CONNECTORS ........................................................................................................... 15
3.1 PERIPHERAL INTERFACE CONNECTORS..................................................................... 16
3.1.1 IMBA-C2260-i2 Layout ................................................................................... 16
3.1.2 Peripheral Interface Connectors ..................................................................... 17
3.1.3 External Interface Panel Connectors............................................................... 18
3.2 INTERNAL PERIPHERAL CONNECTORS...................................................................... 19
3.2.1 +12V ATX Power Connector ........................................................................... 19
3.2.2 Additional Power Connector ........................................................................... 20
3.2.3 ATX Power Connector ..................................................................................... 20
3.2.4 Battery Connector............................................................................................ 22
3.2.5 Chassis Intrusion Connector............................................................................ 23
3.2.6 DDR3 DIMM Slots........................................................................................... 23
3.2.7 Digital I/O Connector...................................................................................... 24
3.2.8 EC Debug Connector....................................................................................... 25
3.2.9 Fan Connector (CPU)...................................................................................... 26
3.2.10 Fan Connectors (System)............................................................................... 27
3.2.11 Front Panel Audio Connector........................................................................ 27

IMBA-C2260-i2 ATX Motherboard
Page v
3.2.12 Front Panel Connector .................................................................................. 28
3.2.13 I2CConnector................................................................................................ 29
3.2.14 Internal DisplayPort Connector.................................................................... 30
3.2.15 iRIS Module Slot............................................................................................ 31
3.2.16 Keyboard and Mouse Connector ................................................................... 32
3.2.17 LAN LED Connectors.................................................................................... 33
3.2.18 mSATA Card Slot............................................................................................ 34
3.2.19 Parallel Port Connector ................................................................................ 36
3.2.20 PCI Slots ........................................................................................................ 37
3.2.21 PCIe x1 Slots.................................................................................................. 38
3.2.22 PCIe x4 Slots.................................................................................................. 38
3.2.23 PCI Express x16 Slot...................................................................................... 39
3.2.24 Power Button ................................................................................................. 40
3.2.25 SATA 6Gb/s Drive Connector ........................................................................ 41
3.2.26 Serial Port Connector, RS-232....................................................................... 42
3.2.27 Serial Port Connector, RS-422/485................................................................ 43
3.2.28 SMBus Connector .......................................................................................... 44
3.2.29 SPI Flash Connector...................................................................................... 45
3.2.30 SPI Flash Connector, EC............................................................................... 46
3.2.31 TPM Connector.............................................................................................. 47
3.2.32 USB 2.0 Connectors....................................................................................... 48
3.3 EXTERNAL PERIPHERAL INTERFACE CONNECTOR PANEL ......................................... 49
3.3.1 Audio Connector .............................................................................................. 49
3.3.2 Ethernet and USB 3.0 Connectors................................................................... 50
3.3.3 Keyboard/Mouse and USB 2.0 Connectors ..................................................... 51
3.3.4 Serial Port and VGA Connector ...................................................................... 52
3.3.5 USB 2.0 Connectors......................................................................................... 53
4 INSTALLATION ......................................................................................................... 54
4.1ANTI-STATIC PRECAUTIONS...................................................................................... 55
4.2 INSTALLATION CONSIDERATIONS.............................................................................. 55
4.2.1 Socket LGA1150 CPU Installation .................................................................. 57
4.2.2 Socket LGA1150 Cooling Kit Installation........................................................ 60
4.2.3 DIMM Installation........................................................................................... 62
4.3 IRIS MODULE INSTALLATION................................................................................... 63

IMBA-C2260-i2 ATX Motherboard
Page vi
4.4 MSATACARD INSTALLATION................................................................................... 64
4.5 SYSTEM CONFIGURATION......................................................................................... 66
4.5.1 AT/ATX Power Mode Setting ........................................................................... 66
4.5.2 Clear CMOS Button......................................................................................... 66
4.5.3 Flash Descriptor Security Override................................................................. 67
4.5.4 mSATA Slot Setup............................................................................................. 68
4.5.5 PCIe x16 Interface Setup................................................................................. 68
4.5.6 USB Power Selection....................................................................................... 69
4.6 INTERNAL PERIPHERAL DEVICE CONNECTIONS........................................................ 70
4.6.1 SATA Drive Connection ................................................................................... 70
4.7 EXTERNAL PERIPHERAL INTERFACE CONNECTION ................................................... 71
4.7.1 Audio Connector .............................................................................................. 71
4.7.2 LAN Connection............................................................................................... 72
4.7.3 PS/2 Keyboard and Mouse Connection ........................................................... 73
4.7.4 Serial Device Connection ................................................................................ 74
4.7.5 USB Device Connection................................................................................... 75
4.7.6 VGA Monitor Connection ................................................................................ 76
4.8 INTEL®AMTSETUP PROCEDURE............................................................................. 77
4.9 IPMI SETUP PROCEDURE ......................................................................................... 78
4.9.1 Managed System Hardware Setup ................................................................... 78
4.9.2 Using the IEI iMAN Web GUI.......................................................................... 78
5 BIOS.............................................................................................................................. 81
5.1 INTRODUCTION......................................................................................................... 82
5.1.1 Starting Setup................................................................................................... 82
5.1.2 Using Setup...................................................................................................... 82
5.1.3 Getting Help..................................................................................................... 83
5.1.4 Unable to Reboot after Configuration Changes.............................................. 83
5.1.5 BIOS Menu Bar................................................................................................ 83
5.2 MAIN........................................................................................................................ 85
5.3ADVANCED............................................................................................................... 86
5.3.1 ACPI Settings................................................................................................... 87
5.3.2 RTC Wake Settings........................................................................................... 88
5.3.3 Trusted Computing........................................................................................... 89
5.3.4 CPU Configuration .......................................................................................... 90

IMBA-C2260-i2 ATX Motherboard
Page vii
5.3.5 SATA Configuration.......................................................................................... 91
5.3.6 Intel(R) Rapid Start Technology....................................................................... 92
5.3.7 AMT Configuration.......................................................................................... 93
5.3.8 USB Configuration........................................................................................... 94
5.3.9 F81866 Super IO Configuration...................................................................... 95
5.3.9.1 Serial Port n Configuration....................................................................... 96
5.3.9.2 Parallel Port Configuration..................................................................... 101
5.3.10 iWDD H/W Monitor..................................................................................... 102
5.3.10.1 Smart Fan Mode Configuration............................................................ 104
5.3.11 Serial Port Console Redirection................................................................... 105
5.3.12 iEi Feature ....................................................................................................110
5.4 CHIPSET ..................................................................................................................111
5.4.1 PCH-IO Configuration ...................................................................................112
5.4.1.1 PCI Express Configuration......................................................................114
5.4.2 System Agent (SA) Configuration ...................................................................116
5.4.2.1 Graphics Configuration............................................................................116
5.4.2.2 NB PCIe Configuration............................................................................119
5.4.2.3 Memory Configuration ........................................................................... 120
5.5 BOOT...................................................................................................................... 121
5.6 SECURITY............................................................................................................... 123
5.7 SAVE &EXIT.......................................................................................................... 123
6 SOFTWARE DRIVERS............................................................................................ 125
6.1AVAILABLE SOFTWARE DRIVERS ............................................................................ 126
6.2 SOFTWARE INSTALLATION ...................................................................................... 126
6.3 CHIPSET DRIVER INSTALLATION............................................................................. 128
6.4 GRAPHICS DRIVER INSTALLATION.......................................................................... 131
6.5 LAN DRIVER INSTALLATION.................................................................................. 134
6.6 USB 3.0 DRIVER INSTALLATION ............................................................................ 138
6.7AUDIO DRIVER INSTALLATION ............................................................................... 141
6.8 INTEL®AMTDRIVER INSTALLATION .................................................................... 143
A BIOS OPTIONS ........................................................................................................ 147
B ONE KEY RECOVERY........................................................................................... 151
B.1 ONE KEY RECOVERY INTRODUCTION .................................................................... 152

IMBA-C2260-i2 ATX Motherboard
Page viii
B.1.1 System Requirement....................................................................................... 153
B.1.2 Supported Operating System......................................................................... 154
B.2 SETUP PROCEDURE FOR WINDOWS........................................................................ 155
B.2.1 Hardware and BIOS Setup ............................................................................ 156
B.2.2 Create Partitions ........................................................................................... 156
B.2.3 Install Operating System, Drivers and Applications..................................... 160
B.2.4 Build-up Recovery Partition.......................................................................... 161
B.2.5 Create Factory Default Image....................................................................... 163
B.3AUTO RECOVERY SETUP PROCEDURE.................................................................... 168
B.4 SETUP PROCEDURE FOR LINUX.............................................................................. 173
B.5 RECOVERY TOOL FUNCTIONS ................................................................................ 176
B.5.1 Factory Restore ............................................................................................. 178
B.5.2 Backup System............................................................................................... 179
B.5.3 Restore Your Last Backup.............................................................................. 180
B.5.4 Manual........................................................................................................... 181
B.6 RESTORE SYSTEMS FROM A LINUX SERVER THROUGH LAN.................................. 182
B.6.1 Configure DHCP Server Settings.................................................................. 183
B.6.2 Configure TFTP Settings............................................................................... 184
B.6.3 Configure One Key Recovery Server Settings............................................... 185
B.6.4 Start the DHCP, TFTP and HTTP................................................................. 186
B.6.5 Create Shared Directory................................................................................ 186
B.6.6 Setup a Client System for Auto Recovery...................................................... 187
B.7 OTHER INFORMATION............................................................................................ 190
B.7.1 Using AHCI Mode or ALi M5283 / VIA VT6421A Controller....................... 190
B.7.2 System Memory Requirement ........................................................................ 192
C TERMINOLOGY ..................................................................................................... 193
D DIGITAL I/O INTERFACE..................................................................................... 197
D.1 INTRODUCTION...................................................................................................... 198
D.2 DIO CONNECTOR PINOUTS ................................................................................... 198
D.3ASSEMBLY LANGUAGE SAMPLES........................................................................... 198
D.3.1 Enable the DIO Input Function .................................................................... 198
D.3.2 Enable the DIO Output Function.................................................................. 199
E WATCHDOG TIMER............................................................................................... 200

IMBA-C2260-i2 ATX Motherboard
Page ix
F INTEL® MATRIX STORAGE MANAGER.......................................................... 203
F.1 INTRODUCTION....................................................................................................... 204
F.1.1 Precautions .................................................................................................... 204
F.2 FEATURES AND BENEFITS ....................................................................................... 205
F.3 ACCESSING THE INTEL®MATRIX STORAGE MANAGER.......................................... 205
F.4 INSTALLING THE OPERATING SYSTEM TO THE RAIDARRAY.................................. 206
G HAZARDOUS MATERIALS DISCLOSURE....................................................... 207
G.1 HAZARDOUS MATERIALS DISCLOSURE TABLE FOR IPB PRODUCTS CERTIFIED AS
ROHS COMPLIANT UNDER 2002/95/EC WITHOUT MERCURY..................................... 208

IMBA-C2260-i2 ATX Motherboard
Page x
List of Figures
Figure 1-1: IMBA-C2260-i2.............................................................................................................2
Figure 1-2: Connectors ..................................................................................................................4
Figure 1-3: IMBA-C2260-i2 Dimensions (mm)..............................................................................5
Figure 1-4: Data Flow Diagram......................................................................................................6
Figure 3-1: Peripheral Interface Connectors .............................................................................16
Figure 3-2: +12V ATX Power Connector Pinout Location ........................................................19
Figure 3-3: Additional Power Connector Location....................................................................20
Figure 3-4: ATX Power Connector Location..............................................................................21
Figure 3-5: Battery Connector Location.....................................................................................22
Figure 3-6: Chassis Intrusion Connector Location...................................................................23
Figure 3-7: DDR3 DIMM Slot Locations......................................................................................24
Figure 3-8: Digital I/O Connector Location ................................................................................24
Figure 3-9: EC Debug Connector Location................................................................................25
Figure 3-10: CPU Fan Connector Location................................................................................26
Figure 3-11: System Fan Connector Locations.........................................................................27
Figure 3-12: Front Panel Audio Connector Location................................................................28
Figure 3-13: Front Panel Connector Location ...........................................................................29
Figure 3-14: I2C Connector Location ..........................................................................................30
Figure 3-15: Internal DisplayPort Connector Location.............................................................31
Figure 3-16: iRIS Module Slot Location......................................................................................32
Figure 3-17: Keyboard and Mouse Connector Location...........................................................33
Figure 3-18: LAN LED Connector Locations .............................................................................34
Figure 3-19: mSATA Card Slot Location....................................................................................35
Figure 3-20: Parallel Port Connector Location..........................................................................36
Figure 3-21: PCI Slot Locations ..................................................................................................37
Figure 3-22: PCIe x1 Slot Locations ...........................................................................................38
Figure 3-23: PCIe x4 Slot Locations ...........................................................................................39
Figure 3-24: PCIe x16 Slot Location ...........................................................................................40
Figure 3-25: Power Button Location...........................................................................................40
Figure 3-26: SATA 6Gb/s Drive Connector Location................................................................41

IMBA-C2260-i2 ATX Motherboard
Page xi
Figure 3-27: RS-232 Serial Port Connector Location................................................................42
Figure 3-28: RS-422/485 Connector Location............................................................................44
Figure 3-29: SMBus Connector Location...................................................................................45
Figure 3-30: SPI Flash Connector Location...............................................................................45
Figure 3-31: SPI EC Flash Connector Location.........................................................................46
Figure 3-32: TPM Connector Location........................................................................................47
Figure 3-33: USB 2.0 Connector Pinout Locations...................................................................48
Figure 3-34: External Peripheral Interface Connector..............................................................49
Figure 3-35: Audio Connector.....................................................................................................50
Figure 3-36: Serial Port Connector Pinouts...............................................................................52
Figure 3-37: VGA Connector .......................................................................................................53
Figure 4-1: Disengage the CPU Socket Load Lever..................................................................57
Figure 4-2: Remove Protective Cover.........................................................................................58
Figure 4-3: Insert the Socket LGA1150 CPU..............................................................................59
Figure 4-4: Close the Socket LGA1150 ......................................................................................59
Figure 4-5: Cooling Kit Support Bracket....................................................................................61
Figure 4-6: DIMM Installation.......................................................................................................62
Figure 4-7: iRIS Module Installation............................................................................................63
Figure 4-8: Remove the Retention Screws for the mSATA Card.............................................64
Figure 4-9: Insert the mSATA Card into the Socket at an Angle.............................................65
Figure 4-10: Secure the mSATA Card.........................................................................................65
Figure 4-11: AT/ATX Power Mode Switch Location..................................................................66
Figure 4-12: Clear CMOS Button Location.................................................................................67
Figure 4-13: Flash Descriptor Security Override Jumper Location ........................................67
Figure 4-14: mSATA Slot Setup Jumper Location....................................................................68
Figure 4-15: SATA Drive Cable Connection...............................................................................70
Figure 4-16: SATA Power Drive Connection..............................................................................71
Figure 4-17: Audio Connector.....................................................................................................72
Figure 4-18: LAN Connection......................................................................................................73
Figure 4-19: PS/2 Keyboard/Mouse Connector.........................................................................74
Figure 4-20: Serial Device Connector.........................................................................................75
Figure 4-21: USB Device Connection.........................................................................................76
Figure 4-22: VGA Connector .......................................................................................................77
Figure 4-23: IEI iMAN Web Address............................................................................................79
Figure 4-24: IEI iMAN Web GUI....................................................................................................80

IMBA-C2260-i2 ATX Motherboard
Page xii
Figure 6-1: Introduction Screen............................................................................................... 127
Figure 6-2: Available Drivers.................................................................................................... 127
Figure 6-3: Chipset Driver Welcome Screen........................................................................... 128
Figure 6-4: Chipset Driver License Agreement...................................................................... 129
Figure 6-5: Chipset Driver Read Me File ................................................................................. 129
Figure 6-6: Chipset Driver Setup Operations ......................................................................... 130
Figure 6-7: Chipset Driver Installation Finish Screen............................................................ 130
Figure 6-8: Graphics Driver Welcome Screen ........................................................................ 131
Figure 6-9: Graphics Driver License Agreement.................................................................... 132
Figure 6-10: Graphics Driver Read Me File............................................................................. 132
Figure 6-11: Graphics Driver Setup Operations..................................................................... 133
Figure 6-12: Graphics Driver Installation Finish Screen ....................................................... 133
Figure 6-13: Intel® Network Connection Menu....................................................................... 134
Figure 6-14: LAN Driver Welcome Screen .............................................................................. 135
Figure 6-15: LAN Driver License Agreement.......................................................................... 135
Figure 6-16: LAN Driver Setup Options................................................................................... 136
Figure 6-17: LAN Driver Installation ........................................................................................ 137
Figure 6-18: LAN Driver Installation Complete....................................................................... 137
Figure 6-19: USB 3.0 Driver Welcome Screen........................................................................ 138
Figure 6-20: USB 3.0 Driver License Agreement.................................................................... 139
Figure 6-21: USB 3.0 Driver Read Me File............................................................................... 139
Figure 6-22: USB 3.0 Driver Setup Operations....................................................................... 140
Figure 6-23: USB 3.0 Driver Installation Finish Screen ......................................................... 141
Figure 6-24: InstallShield Wizard Welcome Screen ............................................................... 142
Figure 6-25: Audio Driver Software Configuration................................................................. 142
Figure 6-26: Restart the Computer .......................................................................................... 143
Figure 6-27: Intel® ME Driver Welcome Screen ..................................................................... 144
Figure 6-28: Intel® ME Driver License Agreement................................................................. 145
Figure 6-29: Intel® ME Driver Setup Operations.................................................................... 145
Figure 6-30: Intel® ME Driver Installation Finish Screen ...................................................... 146
Figure B-1: IEI One Key Recovery Tool Menu ........................................................................ 152
Figure B-2: Launching the Recovery Tool.............................................................................. 157
Figure B-3: Recovery Tool Setup Menu .................................................................................. 157
Figure B-4: Command Mode..................................................................................................... 158
Figure B-5: Partition Creation Commands.............................................................................. 159

IMBA-C2260-i2 ATX Motherboard
Page xiii
Figure B-6: Launching the Recovery Tool.............................................................................. 161
Figure B-7: Manual Recovery Environment for Windows..................................................... 161
Figure B-8: Building the Recovery Partition........................................................................... 162
Figure B-9: Press Any Key to Continue .................................................................................. 162
Figure B-10: Press F3 to Boot into Recovery Mode............................................................... 163
Figure B-11: Recovery Tool Menu ........................................................................................... 163
Figure B-12: About Symantec Ghost Window........................................................................ 164
Figure B-13: Symantec Ghost Path ......................................................................................... 164
Figure B-14: Select a Local Source Drive ............................................................................... 165
Figure B-15: Select a Source Partition from Basic Drive ...................................................... 165
Figure B-16: File Name to Copy Image to ............................................................................... 166
Figure B-17: Compress Image.................................................................................................. 166
Figure B-18: Image Creation Confirmation............................................................................. 167
Figure B-19: Image Creation Complete................................................................................... 167
Figure B-20: Image Creation Complete................................................................................... 167
Figure B-21: Press Any Key to Continue ................................................................................ 168
Figure B-22: Auto Recovery Utility.......................................................................................... 169
Figure B-23: Disable Automatically Restart............................................................................ 169
Figure B-24: Launching the Recovery Tool............................................................................ 170
Figure B-25: Auto Recovery Environment for Windows ....................................................... 170
Figure B-26: Building the Auto Recovery Partition................................................................ 171
Figure B-27: Factory Default Image Confirmation ................................................................. 171
Figure B-28: Image Creation Complete................................................................................... 172
Figure B-29: Press any key to continue.................................................................................. 172
Figure B-30: Partitions for Linux.............................................................................................. 174
Figure B-31: System Configuration for Linux......................................................................... 175
Figure B-32: Access menu.lst in Linux (Text Mode).............................................................. 175
Figure B-33: Recovery Tool Menu ........................................................................................... 176
Figure B-34: Recovery Tool Main Menu.................................................................................. 177
Figure B-35: Restore Factory Default...................................................................................... 178
Figure B-36: Recovery Complete Window.............................................................................. 178
Figure B-37: Backup System.................................................................................................... 179
Figure B-38: System Backup Complete Window ................................................................... 179
Figure B-39: Restore Backup ................................................................................................... 180
Figure B-40: Restore System Backup Complete Window..................................................... 180

IMBA-C2260-i2 ATX Motherboard
Page xiv
Figure B-41: Symantec Ghost Window ................................................................................... 181
Figure B-42: Disable Automatically Restart............................................................................ 188

IMBA-C2260-i2 ATX Motherboard
Page xv
List of Tables
Table 1-1: IMBA-C2260-i2 Specifications.....................................................................................9
Table 2-1: Packing List.................................................................................................................12
Table 2-2: Optional Items.............................................................................................................14
Table 3-1: Peripheral Interface Connectors...............................................................................18
Table 3-2: Rear Panel Connectors..............................................................................................19
Table 3-3: +12V ATX Power Connector Pinouts........................................................................19
Table 3-4: Additional Power Connector Pinouts.......................................................................20
Table 3-5: ATX Power Connector Pinouts .................................................................................21
Table 3-6: Chassis Intrusion Connector Pinouts......................................................................23
Table 3-7: Digital I/O Connector Pinouts....................................................................................25
Table 3-8: EC Debug Connector Pinouts ...................................................................................26
Table 3-9: CPU Fan Connector Pinouts......................................................................................26
Table 3-10: System Fan Connector Pinouts ..............................................................................27
Table 3-11: Front Panel Audio Connector Pinouts ...................................................................28
Table 3-12: Front Panel Connector Pinouts...............................................................................29
Table 3-13: I2C Connector Pinouts..............................................................................................30
Table 3-14: Internal DisplayPort Connector Pinouts ................................................................31
Table 3-15: Keyboard and Mouse Connector Pinouts..............................................................33
Table 3-16: LAN1 LED Connector (LED_LAN1) Pinouts...........................................................34
Table 3-17: LAN2 LED Connector (LED_LAN2) Pinouts...........................................................34
Table 3-18: mSATA Card Slot Pinouts........................................................................................36
Table 3-19: Parallel Port Connector Pinouts .............................................................................37
Table 3-20: SATA 6Gb/s Drive Connector Pinouts....................................................................41
Table 3-21: RS-232 Serial Port Connector Pinouts...................................................................43
Table 3-22: RS-422/485 Connector Pinouts ...............................................................................44
Table 3-23: DB-9 RS-422/485 Pinouts.........................................................................................44
Table 3-24: SMBus Connector Pinouts ......................................................................................45
Table 3-25: SPI Flash Connector Pinouts ..................................................................................46
Table 3-26: SPI EC Flash Connector Pinouts ............................................................................46
Table 3-27: TPM Connector Pinouts...........................................................................................47

IMBA-C2260-i2 ATX Motherboard
Page xvi
Table 3-28: USB 2.0 Connector Pinouts.....................................................................................48
Table 3-29: USB 3.0 Port Pinouts................................................................................................50
Table 3-30: LAN Pinouts ..............................................................................................................51
Table 3-31: USB 2.0 Port Pinouts................................................................................................51
Table 3-32: PS/2 Connector Pinouts...........................................................................................51
Table 3-33: Serial Port Connector Pinouts ................................................................................52
Table 3-34: VGA Connector Pinouts...........................................................................................53
Table 3-35: USB 2.0 Port Pinouts................................................................................................53
Table 4-1: AT/ATX Power Mode Switch Settings.......................................................................66
Table 4-2: Flash Descriptor Security Override Jumper Settings.............................................67
Table 4-3: mSATA Slot Setup Jumper Settings.........................................................................68
Table 4-4: PCIe x16 Interface Setup............................................................................................69
Table 4-5: BIOS Options and Configured USB Ports................................................................69
Table 4-6: USB Power Source Setup..........................................................................................69
Table 5-1: BIOS Navigation Keys................................................................................................83
Table 5-2: BIOS Options and Configured USB Ports............................................................. 114
Table 6-1: Digital I/O Connector Pinouts................................................................................. 198

IMBA-C2260-i2 ATX Motherboard
Page xvii
BIOS Menus
BIOS Menu 1: Main.......................................................................................................................85
BIOS Menu 2: Advanced..............................................................................................................86
BIOS Menu 3: ACPI Configuration..............................................................................................87
BIOS Menu 4: RTC Wake Settings..............................................................................................88
BIOS Menu 5: Trusted Computing..............................................................................................89
BIOS Menu 6: CPU Configuration...............................................................................................90
BIOS Menu 7: SATA Configuration.............................................................................................91
BIOS Menu 8: Intel(R) Rapid Start Technology .........................................................................92
BIOS Menu 9: AMT Configuration...............................................................................................93
BIOS Menu 10: USB Configuration.............................................................................................94
BIOS Menu 11: F81866 Super IO Configuration........................................................................95
BIOS Menu 12: Serial Port n Configuration Menu.....................................................................96
BIOS Menu 13: Parallel Port Configuration Menu.................................................................. 101
BIOS Menu 14: iWDD H/W Monitor .......................................................................................... 103
BIOS Menu 15: Smart Fan Mode Configuration ..................................................................... 104
BIOS Menu 16: Serial Port Console Redirection.................................................................... 106
BIOS Menu 17: iEi Feature........................................................................................................ 110
BIOS Menu 18: Chipset............................................................................................................. 111
BIOS Menu 19: PCH-IO Configuration..................................................................................... 112
BIOS Menu 20: PCI Express Configuration ............................................................................ 114
BIOS Menu 21: PCIEX1_1 and PCIEX4_1 Configuration Menu............................................. 115
BIOS Menu 22: System Agent (SA) Configuration................................................................. 116
BIOS Menu 23: Graphics Configuration.................................................................................. 117
BIOS Menu 24: LCD Control..................................................................................................... 118
BIOS Menu 25: NB PCIe Configuration ................................................................................... 119
BIOS Menu 26: Memory Configuration.................................................................................... 120
BIOS Menu 27: Boot.................................................................................................................. 121
BIOS Menu 28: Security............................................................................................................ 123
BIOS Menu 29: Save & Exit.......................................................................................................124
BIOS Menu 30: IEI Feature........................................................................................................ 173

IMBA-C2260-i2 ATX Motherboard
Page 1
Chapter
1
1 Introduction

IMBA-C2260-i2 ATX Motherboard
Page 2
1.1 Introduction
Figure 1-1: IMBA-C2260-i2
The IMBA-C2260-i2 is an ATX motherboard. It accepts a Socket LGA1150 Intel® Xeon®
E3, Core™ i3, Pentium® or Celeron® processor and supports four 240-pin
1600/1333 MHz dual-channel DDR3 DIMM modules up to 32 GB.
The IMBA-C2260-i2 provides two GbE interfaces through the Intel® I217 (with Intel® AMT
9.0 support) and the Intel® I210 PCIe controllers. The integrated Intel® C226 chipset
supports six SATA 6Gb/s drives. In addition, the IMBA-C2260-i2 includes VGA and iDP
interfaces for dual independent display.
Expansion and I/O include two PCI slots, one PCIe x16 slot with x8 signal, two PCIe x4
slots, two PCIe x1 slots, four USB 3.0 and four USB 2.0 on the rear panel, four USB 2.0 by
pin headers, six COM ports and one mSATA card slot. High Definition Audio (HDA)
support ensures HDA devices can be easily implemented on the IMBA-C2260-i2.

IMBA-C2260-i2 ATX Motherboard
Page 3
1.2 Features
Some of the IMBA-C2260-i2 motherboard features are listed below:
ATX form factor
LGA1150 Intel® Xeon® E3, Core™ i3, Pentium® or Celeron® processor
supported
Intel® C226 chipset
Four 240-pin 1600/1333 MHz dual-channel DDR3 DIMMs support up to 32 GB
Two Intel® PCIe GbE connectors (LAN1 with Intel® AMT 9.0 support)
Supports PCI Express Generation 3.0 at 8 GT/s I/O bandwidth
Dual independent display by VGAand iDP interfaces
Supports IPMI 2.0 via iRIS-2400 module
Six SATA 6Gb/s connectors support RAID 0, 1, 5, 10
Four USB 3.0 ports on the rear panel
One mSATA card slot
One PCIe x16 slot with x8 signal
Two PCIe x4 slots
Two PCIe x1 slots
Two PCI slots
Six COM ports
TPM V1.2 hardware security function supported by TPM module
High Definition Audio
RoHS compliant
