IEI Technology WSB-9454 User manual

1
PICMG 1.0 LGA775 Intel®Pentium®D CPU wih VGA / DVI,
Daul PCIE GbE, SATAII and Audio
WSB-9454
Quick Installation Guide
Version 1.0
Nov. 20, 2006
Package Contents
WSB-9454 package includes the following items:
 1 x WSB-9454 single board computer
 1 x mini jumper pack
 1 x ATA 66/100 flat cable
 1 x Dual RS232 cable
 1 x SATA Power cable
 2 x SATA cable
 1 x KB/MS Y cable
 1 x USB cable
 1 x Utility CD
 1 x QIG (quick installation guide)
©2006 Copyright by IEI Technology corp.
All rights reserved.

2
Specifications

CPU: LGA 775 Intel®Pentium®D/4/Celeron®D with 533/800/1066
MHz FSB
 System Chipset: Intel®945G + ICH7
 BIOS: AMI Flash BIOS
 System Memory
4x 240-pin Daul channel DDRII 400/533/667 MHz up to 4GB
 Ethernet: Daul Broadcom BCM5787 PCI express GbE
 I/O
I/O Interface
2 x RS232
7 x USB 2.0
1 x IDE
1 x LPT
2 x SATAII-300
1 x IrDA
1 x PS/2 for KB/MS
 Display:
VGA integrated in Intel®945G
DVI by silconimage SIL1362(WSB-9454DVI Only)

Digital I/O: 8 bit digital I/O, 4 input /4 output
 Audio: 5.1 Channel Audio Kit with Realtek ALC655

WTD: Software programable supports 1-255 sec. System reset

Power Supply: ATX Power
 Power Consumption:[email protected],+12V@7.24A
(Pentium®4 3.0GHz, DDR2 533MHz 1GB*4)-3D MARK

Temperature: 0 ~ 60°C( 32 ~ 140°F)
 Humidity: 5% ~ 95% non-condensing
 Dimension: (L)338mm x (W)122mm
 Weight: GW: 1.2Kg

3
Ordering Information
WSB-9454-R10
PICMG1,0 Intel®Pentium®D 1066MHz processor, VGA, Daul PCIE GbE,
and SATAII
WSB-9454DVI-R10
PICMG1,0 Intel®Pentium®D 1066MHz processor, VGA/DVI, Daul PCIE GbE,
and SATAII
AC-KIT08R-R10
5.1 Channel Audio Kit with Realtek ALC655
CF-520-RS: CPU Clooer
32200-000017-RS: FDD cable
19800-000049-RS: LPT cable
CF-775A-RS: CPU cooler
Jumpers setting and Connectors
J_CMOS1 : Clear CMOS Setup
J_CMOS1 DESCRIPTION
1-2
(default)*
Keep CMOS Setup
(Normal Operation)
Short 2-3 Clear CMOS Setup
USB01, USB23, USB45: Internal USB Connector
USB01, USB23, USB45
PIN DESCRIPTION PIN DESCRIPTION
1 VCC 2 GND
3 DATA- 4 DATA+
5 DATA+ 6 DATA-
7 GND 8 VCC
IR1: IrDA connector
PIN DESCRIPTION
1 VCC
2 NC
3 IR-RX
4 GND
5 IR-TX
CPU_FAN1 : CPU Fan
Connector
PIN DESCRIPTION
1 Ground
2 +12V
3 Rotation Signal
4 Control

4
FDD1: FDC Connector
PIN DESCRIPTION PIN DESCRIPTION
1 GND 2 REDUCE WRITE
3 GND 4 N/C
5 N/C 6 N/C
7 GND 8 INDEX#
9 GND 10 MOTOR ENABLE A#
11 GND 12 DRIVE SELECT B#
13 GND 14 DRIVE SELECT A#
15 GND 16 MOTOR ENABLE B#
17 GND 18 DIRECTION#
19 GND 20 STEP#
21 GND 22 WRITE DATA#
23 GND 24 WRITE GATE#
25 GND 26 TRACK 0#
27 GND 28 WRITE PROTECT#
29 GND 30 READ DATA#
31 GND 32 SIDE 1 SELECT#
33 GND 34 DISK CHANGE#
COM1,COM2 : 10-pin external connector
Connector Ports Address Interrupt
COM1 COM1 3F8 IRQ4
COM2 COM2 2F8 IRQ3
COM1,COM2 : Internal Serial Port Connector
PIN DESCRIPTION
1 DATA CARRIER DETECT (DCD)
2 RECEIVEDATA (RXD)
3 TRANSMIT DATA (TXD)
4 DATA TERMINAL READY (DTR)
5 GND (GND)
6 DATA SET READY (DSR)
7 REQUEST TO SEND (RTS)
8 CLEAR TO SEND (CTS)
9 RING INDICATOR (RI)
10 GND (GND)

5
LPT1 : Parallel Port Connector
PIN DESCRIPTION PIN DESCRIPTION
1 STROBE# 14 AUTO FORM FEED #
2 DATA0 15 ERROR#
3 DATA1 16 INITIALIZE#
4 DATA2 17 PRINTER SELECT LN#
5 DATA3 18 GND
6 DATA4 19 GND
7 DATA5 20 GND
8 DATA6 21 GND
9 DATA7 22 GND
10 ACKNOWLEDGE# 23 GND
11 BUSY 24 GND
12 PAPER EMPTY 25 GND
13 PRINTER SELECT 26 N/C
CPU12V1 : CPU POWER Connector
ATX-12V1 (CPU)
PIN DESCRIPTION PIN DESCRIPTION
1 GND 2 GND
3 +12V 4 +12V
DIO1 : Digital Input / Output Connector
PIN DESCRIPTION PIN DESCRIPTION
1 Ground 2 VCC
3 Output 0 4 Output 1
5 Output 2 6 Output 3
7 Input 0 8 Input 1
9 Input 2 10 Input 3
F_PANEL1 : External Switches and Indicators panel
PIN DESCRIPTION PIN DESCRIPTION
1 VCC 2 VCC
3 N/C 4 N/C
Power LED
5 GROUND 6 N/C
7 5VSB 8 Speaker
Speaker
PWRBTN 9 PWRBTN+ 10 N/C
11 VCC 12 Reset-
HDDLED 13 HDLED- 14 GND
RESET

6
J_AUDIO1: AC’97 Connector
PIN DESCRIPTION PIN DESCRIPTION
1 SYNC 2 BITCLK
3 SDOUT 4 PCBEEP
5 SDIN 6 RST#
7 VCC 8 GND
9 +12V
KB1: 5-pin Mini-DIN
Keyboard Connector
PIN DESCRIPTION
1 Keyboard Clock
2 Keyboard Data
3 N/C
4 GND
5 VCC
DVI1 : DVI Connector
DVI Connector
PIN DESCRIPTION PIN DESCRIPTION
1 Data 2- 14 VCC
2 Data 2+ 15 GND
3 GND 16 Hot Plug Detect.
4 N/C 17 Data 0-
5 N/C 18 Data 0+
6 DDC Clock 19 GND
7 DDC Data 20 N/C
8 N/C 21 N/C
9 Data 1- 22 GND
10 Data 1+ 23 Clock +
11 GND 24 Clock -
12 N/C 25 GND
13 N/C

7
PIDE1: IDE Interface Connector
PIN DESCRIPTION PIN DESCRIPTION
1 RESET# 2 GND
3 DATA 7 4 DATA 8
5 DATA 6 6 DATA 9
7 DATA 5 8 DATA 10
9 DATA 4 10 DATA 11
11 DATA 3 12 DATA 12
13 DATA 2 14 DATA 13
15 DATA 1 16 DATA 14
17 DATA 0 18 DATA 15
19 GND 20 N/C
21 IDE DRQ 22 GND
23 IOW# 24 GND
25 IOR# 26 GND
27 IDE CHRDY 28 BALE – DEFAULT
29 IDE DACK 30 GND
31 INTERRUPT 32 N/C
33 SA1 34 PDIAG#
35 SA0 36 SA2
37 HDC CS0# 38 HDC CS1#
39 HDD ACTIVE# 40 GND

8
