IEI Technology IMBA-C2260-i2 User manual

1
ATX motherboard supports 22nm LGA1150 Intel® Xeon E3/Core™ i3/
Pentium® and Celeron® per Intel® C226, DDR3, VGA, Dual Intel® PCIe
GbE, Four USB 3.0, Six SATA 6Gb/s, HD Audio, iRIS-2400 and RoHS
IMBA-C2260-i2
Quick Installation Guide
Version 1.0
Dec18, 2013.
Package List
IMBA-C2260-i2 package includes the following items:
1 x IMBA-C2260-i2 single board computer
1 x I/O shielding (P/N: 45014-0034C0-00-RS)
2 x SATA cable (P/N: 32000-062800-RS)
1 x Utility CD
1 x QIG (Quick Installation Guide)
©2006 Copyright by IEI Integration corp.
All rights reserved.

2
Specifications
CPU:
LGA1150 Intel® Xeon® E3/Core™ i3/Pentium® or Celeron®
processor supported
System Chipset:
Intel® C226
Memory:
Four 240-pin 1600/1333MHz dual-channel DDR3 SDRAM
ECC and non-ECC unbuffered DIMMs supported (system max.
32GB)
BIOS: UEFI BIOS
Graphic Engine:
Intel® HD Graphics Gen 7.5 support for DX11.1 and OpenCL
1.2, OpenGL 3.2 Full MPEG2, VC1, AVC Decode
Display Output:
VGA (Up to 1920x1200 @ 60 Hz)
iDP interface for HDMI, LVDS, VGA, DVI, DP
(Up to 3840x2160 @60 Hz)
Ethernet:
LAN1: Intel® I210 PCIe controller
LAN2: Intel® I217LM with Intel® AMT 9.0 support
Super IO: Fintek F81866
EC:
IWDD
Digital I/O:
8-bit digital I/O (4-bit input / 4-bit output)
Audio:
Realtek ALC662 HD Audio codec (Line-in, Line-out, Mic)
I/O Interface:
5 x RS-232
1 x RS-422/485
6 x SATA 6Gb/s
1 x LPT
4 x USB 3.0 (rear IO)
8 x USB 2.0 (4 x rear IO, 4 by pin header)

3
1 x mSATA (colay SATA port)
1 x 6-pin wafer for PS/2 KB/MS
Watchdog Timer:
Software programmable support 1~255 sec. system reset
FAN:
1 x 4-pin CPU fan connector
2 x 3-pin system fan connectors
Front Audio:
1 x 10-pin (2x5) header
Front Panel:
1 x Front Panel
(Power LED, HDD LED, Speaker, Power Button, Reset Button)
LAN LED:
2 x 2-pin (1x2) header for LAN1 LED, LAN2 LED
TPM:
1 x 20-pin (2x10) header
SMBus:
1 x 4-pin (1x4) wafer
I2C:
1 x 4-pin (1x4) wafer
IPMI:
1 x DDR3 SO-DIMM slot supports iRIS-2400
Expansion:
2 x PCI slots
2 x PCIe x1 slot
2 x PCIe x4 slots (support PCIe x1)
1 x PCIe x16 slot (with x8 signal)
Power supply: ATX Power Supply
Power Consumption:
3.3V@0.57A, [email protected]0A, [email protected], [email protected]A,
5VSB@0.19A
(Intel® 3.10GHz CPU with four 1333MHz 2GB DDR3 memory)
Operation Temperature:
-20°C ~ 60°C
Operation Humidity: 5% ~ 95%, non-condensing
Dimensions: 244mm x 305mm
Weight GW/NW: 1200g / 700g

4
Ordering Information
IMBA-C2260-i2-R10:
ATX motherboard supports 22nm LGA1150 Intel® Xeon E3/
Core™ i3/Pentium® and Celeron® per Intel® C226, DDR3, VGA,
Dual Intel® PCIe GbE, four USB 3.0, six SATA 6Gb/s, HD Audio,
iRIS-2400 and RoHS
19800-003100-200-RS: Dual ports USB cable with bracket
19800-010500-100-RS: USB 3.0 cable with bracket
32205-003800-100-RS: RS-422/485 cable, 200mm
19800-000051-RS: RS-232 cable, 230mm (P=2.54)
32102-000100-200-RS:
SATA power cable, MOLEX 5264-4P to SATA15P
19800-000075-RS: PS/2 KB/MS Y-cable with bracket, 220mmz
19800-000049-RS: LPT Cable
CF-1156A-RS-R11:
High performance LGA1155/LGA1156 cooler kit, 1U chassis
compatible, 73W
CF-1156E-R11:
High performance LGA1155/LGA1156 cooler kit, 95W
DP-LVDS-R10:
DisplayPort to 24 bit dual channel LVDS converter board
(For iEi IDP connector)
DP-HDMI-R10:
DisplayPort to HDMI converter board (For iEi IDP connector)
DP-DVI-R10:
DisplayPort to DVI-D converter board (For iEi IDP connector)
DP-VGA-R10:
DisplayPort to VGA converter board (For iEi IDP connector)
DP-DP-R10:
DisplayPort to DisplayPort converter board (For iEi IDP connector)
TPM-IN01-R11: 20-Pin Infineon TPM module, software management
tool, firmware V3.17

5
Jumpers setting and connectors
LABEL FUNCTION
J_ATX_AT1 AT/ATX mode select switch
J_CMOS1 Clear CMOS button
PCIE x16 Power PCIEX16 channel mode setting
USB SW1, USB SW2 USB power setting
J_FLASH1 Flash descriptor security override
BAT1 Battery connector
CHASSIS1 Chassis status connector
CPU_FAN1 CPU fan connector
CPU12V1 +12V power source connector
ATX1 24-pin ATX power source connector
CHA_DIMM1, CHA_DIMM2
CHB_DIMM1, CHB_DIMM2
DDR3 DIMM slots
DIO1 Digital I/O connector
DP1 Display port connector
F_PANEL1 Front panel connector
FRONT_PANEL1 Front panel audio connector
IPMI1 Collocation IPMI module(iRIS-2400)
CN5 I2C connector
KB_MS1 Keyboard and mouse connector
LED_LAN1 LAN1 link LED connector
LED_LAN2 LAN2 link LED connector
LPT1 Parallel port connector
CN2 M-SATA card connector
COM2, COM3, COM5, COM6
Internal RS-232 serial port connectors
COM4 Internal RS-422/485 serial port connector
SATA1, SATA2, SATA3
SATA4, SATA5, SATA6 Serial ATA 3.0 connectors
CN1 SMBUS connector
SPDIF1 SPDIF connector
SYS_FAN1, SYS_FAN2 System fan connector
TPM1 TPM connector
USB1, USB2 Internal USB 2.0 connectors

6
CN4 Internal USB 3.0 connector
AUDIO_CV1 HD audio connector
LAN1_USB1 RJ45 LAN and USB 3.0 connectors
LAN2_USB2 RJ45 LAN and USB 3.0 connectors
K/M_USB1 Keyboard & Mouse and USB 2.0 connectors
CNUSB1 USB 2.0 connectors
VGACOM1 VGA and RS-232 serial port connectors
PCIE x16 Power: PCIEX16 channel mode setting
PCIE x16 DESCRIPTION
1 x16 PCIE (default) 1 x16 PCIE
2 x8 PCIE 2 x8 PCIE
1 x8 , 2x4 PCIE 1 x8 , 2x4 PCIE
Aptio Setup Utility – Copyright (C) 2012 American Megatrends, Inc.
Chipset
Auto Power Button Status [Disabled(ATX)]
Restore AC Power Loss [Last State]
> PCI Express Configuration
> PCI Azalia Configuration
Power Saving Function(ERP) [Disabled]
PCIEX16 Power [1 x16 PCIE]
USB SW1 [+5V DUAL]
USB SW2 [+5V DUAL]
------------------
Version 2.15.1236. Copyright (C) 2012 American Megatrends, Inc.
J_CMOS1: Clear CMOS button
PIN NO. DESCRIPTION
NC (default)
Keep CMOS Setup
(Normal Operation)
Press button Clear CMOS Setup
J_ATX_AT1: AT/ATX mode select switch
PIN NO. DESCRIPTION
Short 1 - 2 ATX Mode (default)
Short 2 - 3 AT Mode

7
CHASSIS1: Chassis status connector
PIN NO. DESCRIPTION PIN NO. DESCRIPTION
1 +3.3VSB 2 CHASSIS OPEN
J_FLASH1: Flash descriptor security override
PIN NO. DESCRIPTION
Short 1 - 2 Disabled (default)
Short 2 - 3 Enabled
USB SW1, USB SW2: USB power setting
PCIE x16 DESCRIPTION
+5V DUAL (default) +5V DUAL
+5V +5V
Aptio Setup Utility – Copyright (C) 2012 American Megatrends, Inc.
Chipset
Auto Power Button Status [Disabled(ATX)]
Restore AC Power Loss [Last State]
> PCI Express Configuration
> PCI Azalia Configuration
Power Saving Function(ERP) [Disabled]
PCIEX16 Power [1 x16 PCIE]
USB SW1 [+5V DUAL]
USB SW2 [+5V DUAL]
------------------
Version 2.15.1236. Copyright (C) 2012 American Megatrends, Inc.
BAT1: Battery connector
PIN NO. DESCRIPTION
PIN NO. DESCRIPTION
1 VBATT 2 GND
CPU_FAN1: CPU fan connector
PIN NO. DESCRIPTION
PIN NO. DESCRIPTION
1
GND
2
+12V
3
FANIO
4
PWM

8
ATX1: 24-pin ATX power source connector
PIN NO.
DESCRIPTION PIN NO.
DESCRIPTION
1 +3.3V 13 +3.3V
2 +3.3V 14 -12V
3 GND 15 GND
4 +5V 16 PS_ON
5 GND 17 GND
6 +5V 18 GND
7 GND 19 GND
8 Power good 20 -5V
9 5VSB 21 +5V
10 +12V 22 +5V
11 +12V 23 +5V
12 +3.3V 24 GND
CPU12V1: +12V power source connector
PIN NO.
DESCRIPTION PIN NO.
DESCRIPTION
1
GND
2
GND
3
+12V
4
+12V
DIO1: Digital I/O connector
PIN NO. DESCRIPTION PIN NO. DESCRIPTION
1
GND
2
VCC
3
Output 3
4
Output 2
5
Output 1
6
Output 0
7
Input 3
8
Input 2
9
Input 1
10
Input 0

9
FRONT_PANEL1: Front audio connector
PIN NO. DESCRIPTION PIN NO. DESCRIPTION
1
MIC2-L
2
GND
3
MIC2
-
R
4
Presence#
5
LINE2
-
R
6
MIC2-JD
7
FRONT-IO 8 NC
9
LINE2-L
10
LINE2
-
JD
F_PANEL1: Front panel connector
PIN
DESCRIPTION PIN
DESCRIPTION
PWR
LED
1
+5V
2
BEEP_PWR SPKR
3
NC
4
IPMI ID_LED+
IPMI LED
5
GND
6
IPMI ID_LED-
PWR
BTN
7
PWRBTN_SW#
8
PC_BEEP SPKR
9
GND
10
NC
RESET
HDD
LED
11
+5V
12
EXTRST-
13
SATA_LED#
14
GND
DP1: Display port connector
PIN NO.
DESCRIPTION PIN NO.
DESCRIPTION
1
+5V
2
LANE1N
3
LANE1P
4
GND
5
LANE3N
6
LANE3P
7
GND
8
AUX_CTRL_DET_D
9
GND
10
HPD
11
AUXP
12
A
UXN
13
GND
14
LANE2P
15
LANE2N
16
GND
17
LANE0P
18
LANE0N
19
+3.3V
20
NC

10
LED_LAN2: LAN2 link LED connector
PIN NO. DESCRIPTION PIN NO.
DESCRIPTION
1 +3.3V 2 LAN2_LED_LNK#_ACT
LED_LAN1: LAN1 link LED connector
PIN NO. DESCRIPTION PIN NO. DESCRIPTION
1 +3.3V 2 LAN1_LED_LNK#_ACT
LPT1: Parallel port connector
PIN NO.
DESCRIPTION PIN NO.
DESCRIPTION
1
STROBE#
2
DATA0
3
DATA1
4
DATA2
5
DATA3
6
DATA4
7
DATA5
8
DATA6
9
DATA7
10
ACKNOWLEDGE
#
11
BUSY
12
PAPER EMPTY
13
PRINTER SELECT
14
AUTO FORM FEED #
15
ERROR#
16
INITIALIZE
#
17
PRINTER SELECT LN#
18
GND
19
GND
20
GND
21
GND
22
GND
23
GND
24
GND
25
GND
26
NC
CN5: I2C connector
PIN NO. DESCRIPTION PIN NO. DESCRIPTION
1
GND 2 PCH_GP38
3
PCH_GP39 4 +5V
KB_MS1: Keyboard and mouse connector
PIN NO. DESCRIPTION
PIN NO. DESCRIPTION
1 VCC 2 MSDATA
3 MSCLK 4 KBDATA
5 KBCLK 6 GND

11
CN2: M-SATA card connector
PIN NO. DESCRIPTION
PIN NO. DESCRIPTION
1
PCIE_WAKE#
2
+3.
3
V
3
N/C
4
GND
5
N/C
6
1.5V
7
N/C
8
N/C
9
GND
10
N/C
11
MSATA_CLK#
12
N/C
13
MSATA _CLK
14
N/C
15
GND
16
N/C
17
PLTRST_N
18
GND
19
N/C
20
+3.
3
V
21
GND
22
PLTRST_N
23
SATA_RX+
24
+3.
3
V
25
SATA_RX
-
26
GND
27
GND
28
1.5V
29
GN
D
30
SMB
_
CLK
31
SATA_TX
-
32
SMB
_
DATA
33
SATA_TX+
34
GND
35
GND
36
USB
_
D
ATA
-
37
GND
38
USB
_
D
ATA
+
39
+3.
3
V
40
GND
41
+3.
3
V
42
N/C
43
+3.
3
V
44
N/C
45
C
LINK
_CLK
46
N/C
47
CL
INK
_DATA
48
1.5V
49
CL
INK
_RST#
50
GND
51
MSATA_DET
52
+3.
3
V

12
COM4: RS-422/485 serial port connector
PIN NO. DESCRIPTION PIN NO. DESCRIPTION
1RXD485# 2 RXD485+
3TXD485+ 4 TXD485#
COM2, COM3, COM5, COM6: Internal RS-232 serial port connectors
Function PIN
DESCRIPTION
PIN
DESCRIPTION
COM2
1 DCD 2 DSR
3 RXD 4 RST
5 TXD 6 CTS
7 DTR 8 RI
9 GND 10 GND
COM3
11 DCD 12 DSR
13 RXD 14 RST
15 TXD 16 CTS
17 DTR 18 RI
19 GND 20 GND
COM5
21 DCD 22 DSR
23 RXD 24 RST
25 TXD 26 CTS
27 DTR 28 RI
29 GND 30 GND
COM6
31 DCD 32 DSR
33 RXD 34 RST
35 TXD 36 CTS
37 DTR 38 RI
39 GND 40 GND

13
SYS_FAN1, SYS_FAN2: System fan connector
PIN NO. DESCRIPTION PIN NO. DESCRIPTION
1
FANIO
2
+12V (PWM)
3
GND
SPDIF1: SPDIF connector
PIN NO. DESCRIPTION PIN NO. DESCRIPTION
1
+5V
2
NC
3
SPDIF
OUT
4
GND
5
SPDIF
IN
CN1: SMBUS connector
PIN NO. DESCRIPTION PIN NO. DESCRIPTION
1
GND
2
SMB_DATA
3
SMB_CLK
4
+5V
SATA1
,
SATA
2,
SATA
3,
SATA
4
,
SATA
5
,
SATA
6
:
Serial ATA 3.0
connectors
PIN NO. DESCRIPTION PIN NO. DESCRIPTION
1GND 2 SATA_TX+
3SATA_TX- 4 GND
5 SATA_RX- 6 SATA RX+
7 GND
TPM1: TPM connector
PIN NO. DESCRIPTION PIN NO.
DESCRIPTION
1
LC
LK
2
GND
3
LFRAME#
4
NC
5
LRERST#
6
+5V
7
LAD3
8
LAD2
9
+3.3V
10
LAD1
11
LAD0
12
GND
13
SCL
14
SDA
15
SB3V
16
SERIRQ
17
GND
18
GLKRUN#
19
LPCPD#
20
LDRQ#

14
CN4: Internal USB 3.0 connector
PIN NO.
DESCRIPTION PIN NO.
DESCRIPTION
1 VCC 2 USB3_RX-
3 USB3_RX+ 4 GND
5 USB3_TX- 6 USB3_TX+
7 GND 8 USB_DATA-
9 USB_DATA+ 10 NC
11 USB_DATA+ 12 USB_DATA-
13 GND 14 USB3_TX+
15 USB3_TX- 16 GND
17 USB3_RX+ 18 USB3_RX-
19 VCC 20 NC
USB1, USB2: Internal USB 2.0 connectors
PIN NO.
DESCRIPTION PIN NO.
DESCRIPTION
1 VCC 2 GND
3 USB_DATA- 4 USB_DATA+
5 USB_DATA+ 6 USB_DATA-
7 GND 8 VCC

15
K/M_USB1: Keyboard & Mouse and USB 2.0 connectors
USB1: External USB 2.0 connectors
PIN NO. DESCRIPTION PIN NO.
DESCRIPTION
1 VCC 5 VCC
2 USB_DATA- 6 USB_DATA-
3 USB_DATA+ 7 USB_DATA+
4 GND 8 GND
KB_MS1: Keyboard / Mouse connector
PIN NO. DESCRIPTION PIN NO.
DESCRIPTION
9 GND 10 KEYBOARD DATA
11 MOUSE DATA 12 VCC
13 KEYBOARD CLOCK
14 MOUSE CLOCK
LAN1_USB1, LAN2_USB2: Ethernet and USB 3.0 connectors
USB1: External USB 3.0 connectors
PIN NO. DESCRIPTION PIN NO.
DESCRIPTION
1 VCC 10 VCC
2 USB_DATA- 11 USB_DATA-
3 USB_DATA+ 12 USB_ DATA+
4 GND 13 GND
5 USB3_RX- 14 USB3_RX-
6 USB3_RX+ 15 USB3_ RX+
7 GND 16 GND
8 USB3_TX- 17 USB3_TX-
9 USB3_TX+ 18 USB3_TX+
LAN1: RJ45 LAN connector
PIN NO. DESCRIPTION PIN NO.
DESCRIPTION
20 LAN1_MDI0P 24 LAN1_MDI2P
21 LAN1_MDI0N 25 LAN1_MDI2N
22 LAN1_MDI1P 26 LAN1_MDI3P
23 LAN1_MDI1N 27 LAN1_MDI3N

16
CNUSB1: USB 2.0 connectors
PIN NO. DESCRIPTION PIN NO.
DESCRIPTION
1 VCC 5 VCC
2 USB_DATA- 6 USB_DATA-
3 USB_DATA+ 7 USB_DATA+
4 GND 8 GND
VGACOM1: VGA and RS-232 serial port connectors
VGA: VGA connector
PIN NO. DESCRIPTION PIN NO.
DESCRIPTION
1 RED 2 GREEN
3 BLUE 4 NC
5 GND 6 GND
7 GND 8 GND
9 VCC 10 GND
11 NC 12 DDCDA
13 HSYNC 14 VSYNC
15 DDCCLK
COM1: External RS-232 serial port connector
1
DCD
1
2
RXD
1
3
TXD
1
4
DTR
1
5
GND
1
6
DSR
1
7
RTS
1
8
CTS
1
9
RI
1

17
Board Layout: Jumper and Connector Locations
(Unit: mm)
