IEI Technology WSB-9452 User manual

WSB-9452 PICMG 1.0 CPU Card
Page I
IEI Technology Corp.
User Manual
MODEL:
WSB-9452
Full-Size PICMG 1.0 CPU Card with Intel
®
Core™2 Duo/Solo,
VGA/DVI, Dual PCIe GbE, SATA 3Gb/s and Audio
Rev. 4.00 – 22 December, 2010

WSB-9452 PICMG 1.0 CPU Card
Page II
Revision
Date Version Changes
2010-12-22 4.00 Updated for R40 version
- Added JSPI1 connector
-Deleted JLAN_PWR1 jumper
2010-10-12 2.01 Minor changes
2008-10-28 2.00 Changed northbridge chipset from Intel® 945GM to Intel® 945GME
Added JAUTO1 and JLAN_PWR1 jumpers information
2007-09-04 1.01 Changed the Maximum memory in Table 1-1 from 2GB to 4GB
Added Disclosure of Hazardous Materials Appendix (Appendix F)
Added Packing List Chapter (Chapter 3)
2006-12-18 1.0 Initial release

WSB-9452 PICMG 1.0 CPU Card
Page III
Manual Conventions
WARNING!
Warnings appear where overlooked details may cause damage to the equipment or result
in personal injury. Warnings should be taken seriously. Warnings are easy to recognize.
The word “warning” is written as “WARNING,” both capitalized and bold and is followed by
text. The text is the warning message. A warning message is shown below:
WARNING:
This is an example of a warning message. Failure to adhere to warning
messages may result in permanent damage to the WSB-9452 or
personal injury to the user. Please take warning messages seriously.
CAUTION!
Cautionary messages should also be heeded to help reduce the chance of losing data or
damaging the WSB-9452. Cautions are easy to recognize. The word “caution” is written as
“CAUTION,” both capitalized and bold and is followed. The italicized text is the cautionary
message. A caution message is shown below:

WSB-9452 PICMG 1.0 CPU Card
Page IV
CAUTION:
This is an example of a caution message. Failure to adhere to cautions
messages may result in permanent damage to the WSB-9452. Please
take caution messages seriously.
NOTE:
These messages inform the reader of essential but non-critical information. These
messages should be read carefully as any directions or instructions contained therein can
help avoid making mistakes. Notes are easy to recognize. The word “note” is written as
“NOTE,” both capitalized and bold and is followed by text. The text is the cautionary
message. A note message is shown below:
NOTE:
This is an example of a note message. Notes should always be read.
Notes contain critical information about the WSB-9452. Please take
note messages seriously.

WSB-9452 PICMG 1.0 CPU Card
Page V
Copyright
The information in this document is subject to change without prior notice in order to
improve reliability, design and function and does not represent a commitment on the part
of the manufacturer.
In no event will the manufacturer be liable for direct, indirect, special, incidental, or
consequential damages arising out of the use or inability to use the product or
documentation, even if advised of the possibility of such damages.
This document contains proprietary information protected by copyright. All rights are
reserved. No part of this manual may be reproduced by any mechanical, electronic, or
other means in any form without prior written permission of the manufacturer.
TRADEMARKS
All registered trademarks and product names mentioned herein are used for identification
purposes only and may be trademarks and/or registered trademarks of their respective
owners.

WSB-9452 PICMG 1.0 CPU Card
Page VI
Table of Contents
1INTRODUCTION..................................................................................................... 1
1.1 WSB-9452 CPU CARD OVERVIEW............................................................................ 2
1.1.1 WSB-9452 Model Variations.............................................................................. 2
1.1.2 WSB-9452 CPU Card Applications ................................................................... 2
1.1.3 WSB-9452 CPU Card Benefits........................................................................... 2
1.1.4 WSB-9452 CPU Card Features ......................................................................... 3
1.2 WSB-9452 CPU CARD OVERVIEW............................................................................ 4
1.2.1 WSB-9452 CPU Card Connectors..................................................................... 5
1.2.2 Technical Specifications..................................................................................... 6
2DETAILED SPECIFICATIONS ............................................................................. 9
2.1 COMPATIBLE IEI BACKPLANES................................................................................. 10
2.2 CPU SUPPORT .......................................................................................................... 10
2.2.1 Intel®Core™2 Duo.......................................................................................... 10
2.2.2 Intel®Core™ Duo.............................................................................................11
2.2.3 Intel
®
Core™ Solo ............................................................................................11
2.2.4 Intel
®
Celeron
®
M ............................................................................................ 12
2.3 ON-BOARD CHIPSETS ............................................................................................... 12
2.3.1 Northbridge and Southbridge Chipsets ........................................................... 12
2.3.2 Intel®945GME Northbridge Chipset............................................................... 12
2.3.3 Intel ICH7-M Southbridge Chipset.................................................................. 13
2.4 GRAPHICS SUPPORT.................................................................................................. 14
2.4.1 Intel®GMA 950................................................................................................ 14
2.4.2 Analog VGA ..................................................................................................... 15
2.4.3 Digital LVDS.................................................................................................... 15
2.4.4 Digital Visual Interface (DVI).......................................................................... 15
2.5 DATA FLOW.............................................................................................................. 16
2.6 MEMORY SUPPORT ................................................................................................... 17
2.7 PCI BUS INTERFACE SUPPORT.................................................................................. 17
2.8 GBEETHERNET CONNECTION.................................................................................. 18
2.9 DRIVE INTERFACES .................................................................................................. 18

WSB-9452 PICMG 1.0 CPU Card
Page VII
2.9.1 SATA Drives ..................................................................................................... 18
2.9.2 IDE HDD Interfaces........................................................................................ 19
2.9.3 Floppy Disk Drive (FDD)................................................................................ 19
2.10 SATA3GB/S AND RAID FUNCTIONALITY (SATA3AND SATA4 ONLY).................. 19
2.11 SERIAL PORTS......................................................................................................... 20
2.12 REAL TIME CLOCK................................................................................................. 20
2.13 SYSTEM MONITORING............................................................................................ 21
2.14 INFRARED DATA ASSOCIATION (IRDA) INTERFACE ................................................ 21
2.15 USB INTERFACES................................................................................................... 21
2.16 OPERATING TEMPERATURE AND TEMPERATURE CONTROL..................................... 22
2.17 OPTIONALAUDIO INTERFACE................................................................................. 22
2.18 POWER CONSUMPTION........................................................................................... 22
2.19 PACKAGED CONTENTS AND OPTIONALACCESSORY ITEMS..................................... 23
2.19.1 Package Contents........................................................................................... 23
2.19.2 Special Items.................................................................................................. 23
2.19.3 Optional Accessory Items............................................................................... 24
3UNPACKING.......................................................................................................... 25
3.1ANTI-STATIC PRECAUTIONS...................................................................................... 26
3.2 UNPACKING.............................................................................................................. 26
3.2.1 Unpacking Precautions.................................................................................... 26
3.3 UNPACKING CHECKLIST........................................................................................... 27
3.3.1 Package Contents............................................................................................. 27
3.4 OPTIONAL ITEMS...................................................................................................... 29
4CONNECTORS AND JUMPERS......................................................................... 30
4.1 PERIPHERAL INTERFACE CONNECTORS..................................................................... 31
4.1.1 WSB-9452 CPU card Layout ........................................................................... 31
4.1.2 Peripheral Interface Connectors ..................................................................... 32
4.1.3 External Peripheral Interface Connectors....................................................... 33
4.1.4 On-board Jumpers ........................................................................................... 34
4.2 INTERNAL PERIPHERAL CONNECTORS...................................................................... 34
4.2.1 ATX-12V Power Source Connector.................................................................. 34
4.2.2 Audio Module Connector................................................................................. 36
4.2.3 Backplane to Mainboard Power Connector .................................................... 37

WSB-9452 PICMG 1.0 CPU Card
Page VIII
4.2.4 Battery Connector............................................................................................ 39
4.2.5 CPU Fan Connector........................................................................................ 40
4.2.6 Digital Input/Output (DIO) Connector............................................................ 42
4.2.7 DVI (Digital Visual Interface) Connector........................................................ 43
4.2.8 FDD Connector ............................................................................................... 45
4.2.9 Front Panel Connector .................................................................................... 47
4.2.10 IDE Connectors ............................................................................................. 49
4.2.11 Inverter Connector......................................................................................... 50
4.2.12 IrDA Interface Connector.............................................................................. 52
4.2.13 Keyboard Connector...................................................................................... 53
4.2.14 LVDS Connector ............................................................................................ 55
4.2.15 Parallel Port Connector ................................................................................ 56
4.2.16 PCI Express Mini Card Connector................................................................ 58
4.2.17 RS-232 Serial Port Connectors...................................................................... 60
4.2.18 SATA Drive Connectors ................................................................................. 62
4.2.19 SPI Flash Connector...................................................................................... 63
4.2.20 Trusted Platform Module Connector ............................................................. 65
4.2.21 TV Out Connector.......................................................................................... 66
4.2.22 USB Connectors............................................................................................. 68
4.3 EXTERNAL PERIPHERAL INTERFACECONNECTORS ................................................... 69
4.3.1 LAN Connectors............................................................................................... 70
4.3.2 Mini-DIN 6 PS/2 Connector .......................................................................... 71
4.3.3 USB Connector ................................................................................................ 72
4.3.4 VGA connector................................................................................................. 73
5INSTALLATION AND CONFIGURATION ....................................................... 75
5.1ANTI-STATIC PRECAUTIONS...................................................................................... 76
5.2 INSTALLATION CONSIDERATIONS.............................................................................. 76
5.2.1 Installation Notices.......................................................................................... 76
5.3 UNPACKING.............................................................................................................. 77
5.3.1 Unpacking Precautions.................................................................................... 77
5.3.2 Checklist........................................................................................................... 78
5.4 WSB-9452 CPU CARD INSTALLATION..................................................................... 79
5.4.1 Socket 478 CPU Installation............................................................................ 80
5.4.2 Cooling Kit (CF-479B-RS ) Installation.......................................................... 82

WSB-9452 PICMG 1.0 CPU Card
Page IX
5.4.3 DIMM Module Installation.............................................................................. 85
5.4.3.1 Purchasing the Memory Module............................................................... 85
5.4.3.2 DIMM Module Installation....................................................................... 86
5.4.4 Peripheral Device Connection......................................................................... 88
5.4.4.1 IDE Disk Drive Connectors (IDE1, IDE2)............................................... 89
5.4.4.2 Floppy Drive Connector (FDD1).............................................................. 91
5.4.5 SATA Drive Connection ................................................................................... 91
5.4.6 Installing the RS-232 Cable............................................................................. 93
5.4.7 USB 2.0 Cable Connection.............................................................................. 94
5.5 ON-BOARD JUMPERS ................................................................................................ 96
5.5.1 AT Power Select Jumper Settings..................................................................... 96
5.5.2 Clear CMOS Jumper........................................................................................ 98
5.5.3 LVDS LCD Voltage Selection........................................................................... 99
5.6 CHASSIS INSTALLATION.......................................................................................... 101
5.7 REAR PANEL CONNECTORS .................................................................................... 102
5.7.1 Keyboard and Mouse Connection.................................................................. 102
5.7.2 VGA Port Installation .................................................................................... 102
5.7.3 Ethernet Connection ...................................................................................... 102
5.7.4 USB Connection............................................................................................. 102
6AMI BIOS SETUP................................................................................................ 103
6.1 INTRODUCTION....................................................................................................... 104
6.1.1 Starting Setup................................................................................................. 104
6.1.2 Using Setup.................................................................................................... 104
6.1.3 Getting Help................................................................................................... 105
6.1.4 Unable to Reboot after Configuration Changes............................................ 105
6.1.5 BIOS Menu Bar.............................................................................................. 105
6.2 MAIN...................................................................................................................... 106
6.3ADVANCED............................................................................................................. 107
6.3.1 CPU Configuration........................................................................................ 109
6.3.2 IDE Configuration..........................................................................................110
6.3.2.1 IDE Master, IDE Slave ............................................................................113
6.3.3 Floppy Configuration......................................................................................117
6.3.4 Super IO Configuration ..................................................................................118
6.3.5 Hardware Health Configuration.................................................................... 122

WSB-9452 PICMG 1.0 CPU Card
Page X
6.3.6 ACPI Configuration....................................................................................... 125
6.3.6.1 General ACPI Configuration................................................................... 126
6.3.7 APM Configuration........................................................................................ 128
6.3.8 MPS Configuration........................................................................................ 131
6.3.9 Remote Access Configuration........................................................................ 132
6.3.10 Trusted Computing....................................................................................... 137
6.3.11 USB Configuration....................................................................................... 138
6.4 PCI/PNP................................................................................................................. 141
6.5 BOOT...................................................................................................................... 149
6.5.1 Boot Settings Configuration........................................................................... 149
6.5.2 Boot Device Priority...................................................................................... 153
6.5.3 Hard Disk Drives........................................................................................... 154
6.5.4 Removable Drives.......................................................................................... 155
6.6 SECURITY............................................................................................................... 157
6.7 CHIPSET ................................................................................................................. 159
6.7.1 Northbridge Configuration............................................................................ 160
6.7.1.1 Video Function Configuration ................................................................ 163
6.7.2 Southbridge Configuration ............................................................................ 168
6.8 EXIT....................................................................................................................... 171
7SOFTWARE DRIVERS....................................................................................... 173
7.1AVAILABLE SOFTWARE DRIVERS ............................................................................ 174
7.2 CHIPSET DRIVER INSTALLATION............................................................................. 174
7.3 VGADRIVER ......................................................................................................... 179
7.4 REALTEK LAN DRIVER (FOR GBELAN) INSTALLATION ....................................... 184
7.5 REALTEK HDAUDIO DRIVER (ALC888) INSTALLATION........................................ 190
7.5.1 BIOS Setup..................................................................................................... 190
7.5.2 Driver Installation ......................................................................................... 190
7.6 REALTEK AC`97AUDIO DRIVER (ALC665) INSTALLATION................................... 195
7.6.1 BIOS Setup..................................................................................................... 195
7.6.2 Driver Installation ......................................................................................... 195
ABIOS CONFIGURATION OPTIONS ................................................................ 203
A.1 BIOS CONFIGURATION OPTIONS........................................................................... 204
BWATCHDOG TIMER .......................................................................................... 208

WSB-9452 PICMG 1.0 CPU Card
Page XI
CEXTERNALAC’97 AUDIO CODEC..................................................................211
C.1 INTRODUCTION...................................................................................................... 212
C.2 PHYSICAL CONNECTION ........................................................................................ 214
C.3 DRIVER INSTALLATION .......................................................................................... 214
C.4 SOUND EFFECT CONFIGURATION........................................................................... 216
C.5 SOUND EFFECT...................................................................................................... 217
C.6 ENVIRONMENT SIMULATION.................................................................................. 217
C.7 KARAOKE MODE ................................................................................................... 219
C.8 EQUALIZER SELECTION ......................................................................................... 220
C.9 SPEAKER CONFIGURATION..................................................................................... 221
C.10 SPEAKER TEST..................................................................................................... 222
C.11 S/PDIF-IN &S/PDIF-OUT .................................................................................. 223
C.12 CONNECTOR SENSING.......................................................................................... 224
C.13 HRTF DEMO ....................................................................................................... 227
C.14 MICROPHONE EFFECT.......................................................................................... 227
C.15 GENERAL............................................................................................................. 228
DJMICRON RAID SETUP .................................................................................... 229
D.1 INTRODUCTION...................................................................................................... 230
D.1.1 RAID Support................................................................................................ 230
D.1.2 What is RAID................................................................................................. 230
D.2 RAID SETUP ......................................................................................................... 231
D.2.1 Introduction................................................................................................... 231
D.2.2 Install SATA Drives....................................................................................... 231
D.2.3 Configure the SATA Controller in BIOS........................................................ 231
D.2.4 Configure the RAID BIOS............................................................................. 232
D.2.4.1 Create a RAID volume........................................................................... 233
D.2.4.2 Delete a RAID volume........................................................................... 237
D.2.4.3 Revert an HDD to Non-RAID ............................................................... 239
D.2.4.4 Solve Mirror Conflict............................................................................. 241
D.2.4.5 Rebuild Mirror Drive............................................................................. 242
D.2.4.6 Save and Exit Setup ............................................................................... 243
D.2.4.7 Exit without Saving................................................................................ 243
D.2.5 Install the OS................................................................................................. 244

WSB-9452 PICMG 1.0 CPU Card
Page XII
EHAZARDOUS MATERIALS DISCLOSURE................................................... 245
E.1 HAZARDOUS MATERIAL DISCLOSURE TABLE FOR IPB PRODUCTS CERTIFIED AS
ROHS COMPLIANT UNDER 2002/95/EC WITHOUT MERCURY..................................... 246

WSB-9452 PICMG 1.0 CPU Card
Page XIII
List of Figures
Figure 1-1: Data Flow Block Diagram..........................................................................4
Figure 2-1: Data Flow Block Diagram........................................................................16
Figure 4-1: ATX–12V Connector Location................................................................35
Figure 4-2: Audio Connector Location......................................................................36
Figure 4-3: Backplane to Mainboard Power Connector Location..........................38
Figure 4-4: Battery Connector Location ...................................................................39
Figure 4-5: CPU Fan Connector Location.................................................................41
Figure 4-6: DIO Connector Location .........................................................................42
Figure 4-7: DVI Connector Location..........................................................................44
Figure 4-8: FDD Connector Location ........................................................................46
Figure 4-9: Front Panel Connector Location............................................................48
Figure 4-10: IDE Connectors Location......................................................................49
Figure 4-11: Inverter Connector Location.................................................................51
Figure 4-12: IrDA Interface Connector Location......................................................52
Figure 4-13: Keyboard Connector Location.............................................................54
Figure 4-14: LVDS Connector Location....................................................................55
Figure 4-15: Parallel Port Connector Location.........................................................57
Figure 4-16: PCI Express Mini Card Connector Location.......................................59
Figure 4-17: RS-232 Serial Port Connector Location ..............................................61
Figure 4-18: SATA Connectors Location..................................................................62
Figure 4-19: SPI Flash Connector Location..............................................................64
Figure 4-20: TPM Connector Location......................................................................65
Figure 4-21: TV Out Connector Location..................................................................67
Figure 4-22: USB Port Connector Location..............................................................68
Figure 4-23: External Peripheral Interface Connector Panel..................................69
Figure 4-24: RJ-45 Ethernet Connector ....................................................................71
Figure 4-25: Mini-DIN 6 PS/2 Connector ...................................................................72
Figure 4-26: VGA Connector......................................................................................73

WSB-9452 PICMG 1.0 CPU Card
Page XIV
Figure 5-1: Make sure the CPU socket retention screw is unlocked.....................81
Figure 5-2: Lock the CPU Socket Retention Screw .................................................82
Figure 5-3: IEI CF-479B-RS Cooling Kit ....................................................................82
Figure 5-4: Install Support Bracket ...........................................................................83
Figure 5-5: Align the Cooling Kit ...............................................................................84
Figure 5-6: Secure the Cooling Kit ............................................................................85
Figure 5-7: Installing the DIMM Module ....................................................................87
Figure 5-8: Connection of IDE Connector.................................................................90
Figure 5-9: SATA Drive Cable Connection ...............................................................92
Figure 5-10: SATA Drive Connection........................................................................93
Figure 5-11: Dual RS-232 Cable Installation.............................................................94
Figure 5-12: USB Cable Installation ..........................................................................95
Figure 5-13 Jumper .....................................................................................................96
Figure 5-14: AT Power Select Jumper Location.......................................................97
Figure 5-15: Clear CMOS Jumper..............................................................................99
Figure 5-16: LVDS Voltage Selection Jumper Pinout Locations......................... 101
Figure 7-1: InstallShield Wizard Preparation Screen............................................ 175
Figure 7-2: Welcome Screen................................................................................... 175
Figure 7-3: License Agreement............................................................................... 176
Figure 7-4: Readme Information............................................................................. 177
Figure 7-5: Restart the Computer........................................................................... 178
Figure 7-6: Starting Install Shield Wizard Screen................................................. 179
Figure 7-7: Preparing Setup Screen....................................................................... 180
Figure 7-8: VGA Driver Installation Welcome Screen........................................... 181
Figure 7-9: VGA Driver License Agreement .......................................................... 182
Figure 7-10: VGA Driver Installing Notice.............................................................. 182
Figure 7-11: VGA Driver Installation Complete..................................................... 183
Figure 7-12: Access Windows Control Panel........................................................ 184
Figure 7-13: Double Click the System Icon ........................................................... 185
Figure 7-14: Double Click the Device Manager Tab.............................................. 186
Figure 7-15: Device Manager List........................................................................... 186
Figure 7-16: Search for Suitable Driver.................................................................. 187

WSB-9452 PICMG 1.0 CPU Card
Page XV
Figure 7-17: Locate Driver Files.............................................................................. 188
Figure 7-18: Location Browsing Window............................................................... 189
Figure 7-19: 4-AUDIO\AC-KIT888HD\Windows Folder.......................................... 191
Figure 7-20: HD Audio Driver Setup Extracting Files........................................... 192
Figure 7-21: HD Audio Driver Setup Welcome Screen......................................... 193
Figure 7-22: HD Audio Driver Installation Complete ............................................ 194
Figure 7-23: CD 4-AUDIO\AC-KIT08R\Windows Folder........................................ 196
Figure 7-24: AC`97 Audio Driver Install Shield Wizard Starting.......................... 196
Figure 7-25: AC`97 Audio Driver Setup Preparation............................................. 197
Figure 7-26: AC`97 Audio Driver Welcome Screen............................................... 198
Figure 7-27: AC`97 Audio Driver Software Configuration.................................... 199
Figure 7-28: AC`97 Audio Driver Digital Signal..................................................... 200
Figure 7-29: AC`97 Audio Driver Installation Begins............................................ 201
Figure 7-30: AC`97 Audio Driver Installation Complete ....................................... 202

WSB-9452 PICMG 1.0 CPU Card
Page XVI
List of Tables
Table 1-1: WSB-9452 Model Variations.......................................................................2
Table 1-2: Technical Specifications ............................................................................8
Table 2-1: Supported CPUs........................................................................................10
Table 2-2: Power Consumption..................................................................................22
Table 3-1: Package List Contents..............................................................................28
Table 3-2: Package List Contents..............................................................................29
Table 4-1: Connector and Jumper Locations...........................................................31
Table 4-2: Peripheral Interface Connectors..............................................................33
Table 4-3: External Peripheral Interface Connectors ..............................................33
Table 4-4: On-board Jumpers ....................................................................................34
Table 4-5: ATX–12V Connector Pinouts....................................................................35
Table 4-6: Audio Connector Pinouts.........................................................................37
Table 4-7: Backplane to Mainboard Power Pin Outs...............................................38
Table 4-8: Battery Connector Pinouts.......................................................................40
Table 4-9: CPU Fan Connector Pinouts....................................................................41
Table 4-10: DIOConnector Pinouts............................................................................43
Table 4-11: DVI Connector Pinouts ...........................................................................45
Table 4-12: FDD Connector Pinouts..........................................................................47
Table 4-13: Front Panel Connector Location............................................................48
Table 4-14: IDE Connector Pinouts ...........................................................................50
Table 4-15: Inverter Connector Pinouts....................................................................51
Table 4-16: IrDA Interface Connector Pinouts..........................................................53
Table 4-17: KB1 Connector Pinouts..........................................................................54
Table 4-18: LVDS Connector Pinouts........................................................................56
Table 4-19: Parallel Port Connector Pinouts............................................................58
Table 4-20: PCI Express Mini Card Connector Pinouts...........................................60
Table 4-21: RS-232 Serial Port Connector Pinouts..................................................61
Table 4-22: SATA Connectors Pinouts .....................................................................63

WSB-9452 PICMG 1.0 CPU Card
Page XVII
Table 4-23: SPI Flash Connector Pinouts.................................................................64
Table 4-24: TPM Connector Pinouts..........................................................................66
Table 4-25: TV Out Connector Pinouts .....................................................................67
Table 4-26: USB Port Connector Pinouts .................................................................69
Table 4-27: LAN Pinouts.............................................................................................70
Table 4-28: Ethernet Connector Pinouts...................................................................70
Table 4-29: Mini-DIN 6 PS/2 Connector.....................................................................72
Table 4-30: USB Port Pinouts.....................................................................................73
Table 4-31: VGA Connector Pinouts .........................................................................74
Table 5-1: IEI Provided Cables...................................................................................88
Table 5-2: On-board Jumpers ....................................................................................96
Table 5-3: AT Power Select Jumper Settings...........................................................97
Table 5-4: Clear CMOS Jumper Settings ..................................................................98
Table 5-5: LVDS LCD Voltage Selection Jumper Settings................................... 100
Table 6-1: BIOS Navigation Keys............................................................................ 105

WSB-9452 PICMG 1.0 CPU Card
Page XVIII
List of BIOS Menus
BIOS Menu 1: Main................................................................................................... 106
BIOS Menu 2: Advanced.......................................................................................... 108
BIOS Menu 3: CPU Configuration........................................................................... 109
BIOS Menu 4: IDE Configuration ............................................................................ 111
BIOS Menu 5: IDE Master and IDE Slave Configuration....................................... 113
BIOS Menu 6: Floppy Configuration ...................................................................... 117
BIOS Menu 7: Super IO Configuration ................................................................... 118
BIOS Menu 8: Hardware Health Configuration...................................................... 122
BIOS Menu 9: ACPI Configuration.......................................................................... 125
BIOS Menu 10: General ACPI Configuration......................................................... 126
BIOS Menu 11: APM Configuration ........................................................................ 128
BIOS Menu 12: MPS Configuration ........................................................................ 131
BIOS Menu 13: Remote Access Configuration ..................................................... 132
BIOS Menu 14: Trusted Computing Configuration............................................... 137
BIOS Menu 15: USB Configuration......................................................................... 138
BIOS Menu 16: PCI/PnP Configuration.................................................................. 143
BIOS Menu 17: Boot................................................................................................. 149
BIOS Menu 18: Boot Settings Configuration......................................................... 150
BIOS Menu 19: Boot Device Priority Settings....................................................... 153
BIOS Menu 20: Hard Disk Drives............................................................................ 154
BIOS Menu 21: Removable Drives.......................................................................... 156
BIOS Menu 22: Security........................................................................................... 157
BIOS Menu 23: Chipset............................................................................................ 159
BIOS Menu 24: Northbridge Chipset Configuration ............................................. 160
BIOS Menu 25: Video Function Configuration...................................................... 163
BIOS Menu 26:Southbridge Chipset Configuration.............................................. 168
BIOS Menu 27:Exit ................................................................................................... 171

WSB-9452 PICMG 1.0 CPU Card
Page 1
1 Introduction
Chapter
1

WSB-9452 PICMG 1.0 CPU Card
Page 2
1.1 WSB-9452 CPU Card Overview
The PICMG 1.0 form factor WSB-9452 CPU card with Intel®Core™2 Duo/ Intel®Core™
Duo/ Intel®Core™ Solo / Intel®Celeron®M processor platform is fully equipped with the
latest technology and advanced multi-mode I/Os. The WSB-9452 is designed for system
manufacturers, integrators, and VARs that want performance, reliability, and quality at a
reasonable price.
1.1.1 WSB-9452 Model Variations
The WSB-9452 has four model variations shown in Table 1-1.
Model Name SATA
1.5Gb/s
SATA
3Gb/s
IDE Digital Video Interface (DVI)
WSB-9452-R40 Two -- One None
WSB-9452S-R40 Two Two Two None
WSB-9452DVI-R40 Two -- One One
WSB-9452SDVI-R40 Two Two Two One
Table 1-1: WSB-9452 Model Variations
1.1.2 WSB-9452 CPU Card Applications
The WSB-9452 CPU card has been designed for use in industrial applications where
board expansion is critical and operational reliability is essential.
1.1.3 WSB-9452 CPU Card Benefits
Some of the WSB-9452 CPU card benefits include:
Dual-core Intel®processor support
oTwo physical cores in a package share the system load
oEach core has its own L1 cache and shares the L2 cache to enhance the
processing speed
