IEI Technology PICOe-6612 Series User manual

0-1
PICOe-6612
1

0-2
PICOe
-
6612
REVISION HISTORY
Title PICOe-6612 Intel Pentium M/Celeron M Motherbard
Revision Number Description Date of Issue
1.0 Initial release October 2006
COPYRIGHT NOTICE
The information in this document is subject to change without prior notice in order to
improve reliability, design and function and does not represent a commitment on the part
of the manufacturer.
In no event is the manufacturer liable for direct, indirect, special, incidental, or
consequential damages arising out of the use or inability to use the product or
documentation, even if advised of the possibility of such damages.
This document contains proprietary information protected by copyright. All rights are
reserved. No part of this manual may be reproduced by any mechanical, electronic, or
other means in any form without prior written permission of the manufacturer.
TRADEMARKS
IBM PC is a registered trademark of International Business Machines Corporation. INTEL
is a registered trademark of INTEL Corporation. AMI is registered trademarks of American
Megatrends Inc. Other product names mentioned herein are used for identification
purposes only and may be trademarks and/or registered trademarks of their respective
owners.
2

0-3
PICOe-6612
Table of Contents
1INTRODUCTION................................................................................................... 15
1.1 PICOE-6612 OVERVIEW .......................................................................................... 16
1.1.1 PICOe-6612 Models ........................................................................................ 16
1.1.2 PICOe-6612 Benefits ....................................................................................... 16
1.1.3 PICOe-6612 Features ...................................................................................... 16
1.2 PICOE-6612 OVERVIEW .......................................................................................... 17
1.2.1 PICOe-6612 Connectors.................................................................................. 18
1.2.2 Technical Specifications................................................................................... 19
2DETAILED SPECIFICATIONS ........................................................................... 23
2.1 OVERVIEW ............................................................................................................... 24
2.2 COMPATIBLE IEI BACKPLANES ................................................................................ 24
2.3 BOARD DIMENSIONS ................................................................................................ 24
2.4 CPU SUPPORT.......................................................................................................... 24
2.4.1 Pentium M........................................................................................................ 25
2.4.2 Celeron M ........................................................................................................ 25
2.5 ONBOARD CHIPSETS ................................................................................................ 26
2.5.1 Northbridge and Southbridge Chipsets ........................................................... 26
2.5.2 SiS661CX Northbridge Chipset ....................................................................... 26
2.5.3 SiS966 Southbridge Chipset............................................................................. 27
2.6 DATA FLOW.............................................................................................................. 28
2.7 GRAPHICS SUPPORT ................................................................................................. 29
2.8 MEMORY SUPPORT ................................................................................................... 29
2.9 PCI BUS INTERFACE SUPPORT ................................................................................. 30
2.10 GBE ETHERNET ..................................................................................................... 30
2.11 DRIVE INTERFACES ................................................................................................ 30
2.11.1 IDE HDD Interfaces....................................................................................... 31
2.11.2 Floppy Disk Drive (FDD) .............................................................................. 31
2.11.3 CompactFlash Support................................................................................... 31
2.11.4 SATA Drive Support ....................................................................................... 31
2.12 SERIAL PORTS ........................................................................................................ 31
2.13 REAL TIME CLOCK................................................................................................. 32
3

0-4
PICOe
-
6612
2.14 SYSTEM MONITORING............................................................................................ 32
2.15 USB INTERFACES................................................................................................... 32
2.16 BIOS ..................................................................................................................... 32
2.17 OPERATING TEMPERATURE AND TEMPERATURE CONTROL..................................... 32
2.18 AUDIO CODEC ........................................................................................................ 33
2.19 POWER CONSUMPTION........................................................................................... 34
2.20 PACKAGED CONTENTS AND OPTIONAL ACCESSORY ITEMS..................................... 34
2.20.1 Package Contents........................................................................................... 34
2.20.2 Optional Accessory Items............................................................................... 35
3CONNECTORS AND JUMPERS ......................................................................... 37
3.1 PERIPHERAL INTERFACE CONNECTORS .................................................................... 38
3.1.1 PICOe-6612 Layout ......................................................................................... 38
3.1.2 Peripheral Interface Connectors ..................................................................... 39
3.1.3 Rear Panel Connectors .................................................................................... 41
3.1.4 Onboard Jumpers............................................................................................. 41
3.2 INTERNAL PERIPHERAL CONNECTORS...................................................................... 41
3.2.1 Audio Connector (9-pin) .................................................................................. 42
3.2.2 Backplane to Mainboard Connector................................................................ 43
3.2.3 CompactFlash Connector ................................................................................ 44
3.2.4 Digital Input/Output (DIO) Connector............................................................ 45
3.2.5 Fan Connector ................................................................................................. 46
3.2.6 Floppy Disk Connector .................................................................................... 48
3.2.7 Front Panel Connector .................................................................................... 49
3.2.8 IDE Connector (Primary) ................................................................................ 50
3.2.9 IR Interface Connector (6-pin) ........................................................................ 52
3.2.10 Keyboard Connector...................................................................................... 54
3.2.11 LCD LVDS Connector.................................................................................... 55
3.2.12 Panel Backlight Connector ............................................................................ 57
3.2.13 Parallel Port Connector ................................................................................ 58
3.2.14 RS-232 Serial Port Connectors...................................................................... 59
3.2.15 SATA Drive Connectors ................................................................................. 61
3.2.16 Internal USB Connectors............................................................................... 62
3.3 EXTERNAL PERIPHERAL INTERFACE CONNECTOR PANEL ......................................... 63
3.3.1 Keyboard/Mouse Connector ............................................................................ 63
3.3.2 LAN Connectors............................................................................................... 64
4

0-5
PICOe-6612
3.3.3 USB Connector ................................................................................................ 65
3.3.4 VGA connector................................................................................................. 66
4INSTALLATION AND CONFIGURATION ....................................................... 68
4.1 ANTI-STATIC PRECAUTIONS...................................................................................... 69
4.2 INSTALLATION CONSIDERATIONS ............................................................................. 69
4.2.1 Installation Notices .......................................................................................... 69
4.3 UNPACKING.............................................................................................................. 70
4.3.1 Unpacking Precautions.................................................................................... 70
4.3.2 Checklist........................................................................................................... 71
4.4 PICOE-6612 MOTHERBOARD INSTALLATION .......................................................... 71
4.4.1 CPU Installation .............................................................................................. 73
4.4.2 Cooling Kit (CF-479B-RS ) Installation .......................................................... 75
4.4.3 DIMM Module Installation .............................................................................. 77
4.4.3.1 Purchasing the Memory Module............................................................... 77
4.4.3.2 DIMM Module Installation....................................................................... 77
4.5 JUMPER SETTINGS.................................................................................................... 78
4.5.1 Clear CMOS Jumper........................................................................................ 79
4.5.2 LVDS Voltage Selection.................................................................................... 81
4.5.3 LVDS Voltage Selection.................................................................................... 82
4.6 CHASSIS INSTALLATION ........................................................................................... 83
4.6.1 Chassis selection.............................................................................................. 84
4.6.2 Install the Backplane........................................................................................ 84
4.6.3 Install the CompactFlash card......................................................................... 85
4.6.4 Mount the PICOe-6612 onto the Backplane.................................................... 86
4.6.5 Install the RS-232 Cable .................................................................................. 86
4.6.6 USB 2.0 Cable Connection .............................................................................. 87
4.6.7 IDE Disk Drive Connector (IDE1) .................................................................. 88
4.6.8 SATA Drive Connection ................................................................................... 89
4.7 REAR PANEL CONNECTORS ...................................................................................... 90
4.7.1 LCD Panel Connection .................................................................................... 90
4.7.2 Ethernet Connection ........................................................................................ 90
4.7.3 USB Connection............................................................................................... 91
4.7.4 Keyboard and Mouse Connection.................................................................... 91
5AMI BIOS SETUP .................................................................................................. 93
5.1 INTRODUCTION ........................................................................................................ 94
5

0-6
PICOe
-
6612
5.1.1 Starting Setup................................................................................................... 94
5.1.2 Using Setup ...................................................................................................... 94
5.1.3 Getting Help..................................................................................................... 95
5.1.4 Unable to Reboot After Configuration Changes.............................................. 95
5.1.5 BIOS Menu Bar................................................................................................ 95
5.2 MAIN ....................................................................................................................... 96
5.3 ADVANCED............................................................................................................... 97
5.3.1 CPU Configuration.......................................................................................... 98
5.3.2 IDE Configuration ......................................................................................... 100
5.3.2.1 IDE Master, IDE Slave ........................................................................... 104
5.3.3 Floppy Configuration..................................................................................... 108
5.3.4 Super IO Configuration...................................................................................110
5.3.5 Hardware Health Configuration.....................................................................113
5.3.6 ACPI Configuration ........................................................................................115
5.3.6.1 Advanced ACPI Configuration ................................................................116
5.3.7 MPS Configuration .........................................................................................117
5.3.8 USB Configuration..........................................................................................119
5.4 PCI/PNP ................................................................................................................ 121
5.5 BOOT ..................................................................................................................... 127
5.5.1 Boot Settings Configuration........................................................................... 128
5.5.2 Boot Device Priority ...................................................................................... 131
5.5.3 Hard Disk Drives ........................................................................................... 132
5.5.4 Removable Drives .......................................................................................... 133
5.5.5 CD/DVD Drives ............................................................................................. 134
5.6 SECURITY............................................................................................................... 135
5.7 CHIPSET ................................................................................................................. 136
5.7.1 Northbridge SIS661FX Configuration........................................................... 137
5.7.2 SouthBridge SiS966 Configuration................................................................ 141
5.8 POWER KEY ........................................................................................................... 143
5.9 EXIT....................................................................................................................... 146
6SOFTWARE DRIVERS ....................................................................................... 149
6.1 A
VAILABLE SOFTWARE DRIVERS ............................................................................ 150
6.2 SIS AGP DRIVER INSTALLATION............................................................................ 150
6.3 REALTEK AUDIO DRIVER (ALC655) INSTALLATION.............................................. 153
6.4 SIS IDE DRIVER INSTALLATION ............................................................................ 157
6

0-7
PICOe-6612
6.5 REALTEK LAN DRIVER (FOR GBE LAN) INSTALLATION....................................... 159
6.6 SIS RAID DRIVER INSTALLATION ......................................................................... 162
6.7 SIS VGA UTILITIES DRIVER .................................................................................. 170
ABIOS CONFIGURATION OPTIONS ................................................................ 177
A.1 BIOS CONFIGURATION OPTIONS........................................................................... 178
BWATCHDOG TIMER .......................................................................................... 181
CADDRESS MAPPING.......................................................................................... 185
C.1 IO ADDRESS MAP ................................................................................................. 186
C.2 1ST MB MEMORY ADDRESS MAP ......................................................................... 186
C.3 IRQ MAPPING TABLE ............................................................................................ 187
C.4 DMA CHANNEL ASSIGNMENTS............................................................................. 187
DEXTERNAL AC’97 AUDIO CODEC ................................................................. 189
D.1.1 Accessing the AC’97 Codec .......................................................................... 190
D.1.2 Driver Installation......................................................................................... 190
D.2 SOUND EFFECT CONFIGURATION........................................................................... 190
D.2.1 Accessing the Sound Effects Manager .......................................................... 190
D.2.2 Sound Effect Manager Configuration Options ............................................. 192
ERAID SETUP ........................................................................................................ 195
E.1 INTRODUCTION ...................................................................................................... 196
E.1.1 RAID Support ................................................................................................ 196
E.1.2 What is RAID ................................................................................................. 196
E.2 RAID SETUP ......................................................................................................... 196
E.2.1 Introduction ................................................................................................... 196
E.2.2 Copy the RAID Driver ................................................................................... 197
E.2.3 Install SATA Drives........................................................................................ 198
E.2.4 Configure the SATA Controller in BIOS ........................................................ 198
E.2.5 Configure the RAID BIOS ............................................................................. 198
E.2.6 Install the OS ................................................................................................. 203
INDEX............................................................................................................................ 205
7

0-8
PICOe
-
6612
List of Figures
Figure 1-1: PICOe-6612 Overview..............................................................................17
Figure 1-2: PICOe-6612 Solder Side Overview.........................................................18
Figure 2-1: Data Flow Block Diagram........................................................................28
Figure 3-1: Connector and Jumper Locations .........................................................38
Figure 3-2: Connector and Jumper Locations (Solder Side)..................................39
Figure 3-3: Audio Connector Location......................................................................42
Figure 3-4: Backplane to Mainboard Connector Location......................................43
Figure 3-5: CompactFlash Connector Location.......................................................44
Figure 3-6: DIO Connector Connector Locations ....................................................46
Figure 3-7: Fan Connector Location .........................................................................47
Figure 3-8: FDD Connector Location ........................................................................48
Figure 3-9: Front Panel Connector Locations..........................................................50
Figure 3-10: Primary IDE Device Connector Locations...........................................51
Figure 3-11: IR Connector Pinout Locations............................................................53
Figure 3-12: Keyboard Connector Location .............................................................54
Figure 3-13: LVDS Connector Locations ..................................................................56
Figure 3-14: Panel Backlight Connector Pinout Locations.....................................57
Figure 3-15: Parallel Port Connector Location.........................................................58
Figure 3-16: RS-232 Serial Port Connector Locations ............................................60
Figure 3-17: SATA Drive Connector Locations........................................................61
Figure 3-18: USB Connector Pinout Locations........................................................62
Figure 3-19: PICOe-6612 Rear Panel .........................................................................63
Figure 3-20: PS/2 Pinouts...........................................................................................64
Figure 3-21: RJ-45 Ethernet Connector ....................................................................65
Figure 3-22: Serial Port (COM1) and VGA Connector..............................................66
Figure 4-1: Make sure the CPU socket retention screw is unlocked .....................73
Figure 4-2: Lock the CPU Socket Retention Screw .................................................74
Figure 4-3: IEI CF-479B-RS Cooling Kit ....................................................................75
Figure 4-4: Cooling Kit Support Bracket...................................................................76
8

0-9
PICOe-6612
Figure 4-5: Connect the cooling fan cable ...............................................................76
Figure 4-6: DIMM Module Installation........................................................................78
Figure 4-7: Clear CMOS Jumper ................................................................................80
Figure 4-8: LVDS Voltage Selection Jumper Pinout Locations..............................82
Figure 4-9: LVDS Voltage Selection Jumper Settings.............................................83
Figure 4-10: CompactFlash Card Installation...........................................................85
Figure 4-11: Dual RS-232 Cable Installation.............................................................87
Figure 4-12: IDE Cable Connection ................................ Error! Bookmark not defined.
Figure 4-13: IDE Cable Connection ...........................................................................88
Figure 4-14: SATA Drive Cable Connection .............................................................89
Figure 4-15: SATA Drive Connection ........................................................................90
Figure 6-1: Starting Install Shield Wizard Screen ................................................. 151
Figure 6-2: Preparing Setup Screen ....................................................................... 151
Figure 6-3: Install Shield Screen............................................................................. 152
Figure 6-4: Installing Screen ................................................................................... 152
Figure 6-5: Restart the Computer ........................................................................... 153
Figure 6-6: InstallShield Wizard Extracting Files.................................................. 154
Figure 6-7: Audio Driver Install Shield Wizard Starting ....................................... 154
Figure 6-8: Audio Driver Setup Preparation .......................................................... 155
Figure 6-9: Audio Driver Digital Signal .................................................................. 155
Figure 6-10: Audio Driver Installation Continues ................................................. 156
Figure 6-11: Audio Driver Installation Complete................................................... 156
Figure 6-12: Select a Language .............................................................................. 157
Figure 6-13: Welcome Screen ................................................................................. 157
Figure 6-14: Chipset Driver Readme File Information .......................................... 158
Figure 6-15: Chipset Driver Installation Complete................................................ 158
Figure 6-16: Realtek LAN Driver InstallShield Wizard .......................................... 159
Figure 6-17: Realtek LAN Driver Welcome ............................................................ 160
Figure 6-18: Realtek LAN Driver Ready to Install ................................................. 161
Figure 6-19: Realtek LAN Driver Setup Status ...................................................... 161
Figure 6-20: Realtek LAN Driver Installation Complete........................................ 162
Figure 6-21: Starting Install Shield Wizard ............................................................ 162
Figure 6-22: Preparing Setup .................................................................................. 163
9

0-10
PICOe
-
6612
Figure 6-23: Install Shield........................................................................................ 164
Figure 6-24: License Agreement............................................................................. 165
Figure 6-25: Install Application Directory.............................................................. 166
Figure 6-26: Select Needed Components .............................................................. 167
Figure 6-27: Ready to Install ................................................................................... 168
Figure 6-28: Setup Status........................................................................................ 169
Figure 6-29: Restart the Computer ......................................................................... 170
Figure 6-30: Starting Install Shield Wizard ............................................................ 171
Figure 6-31: Preparing Setup .................................................................................. 171
Figure 6-32: VGA Utilities Welcome Screen .......................................................... 172
Figure 6-33: Select Setup Installation Type........................................................... 172
Figure 6-34: Select Folders to Copy Files ............................................................. 173
Figure 6-35: Review Settings .................................................................................. 173
Figure 6-36: Read ReadMe File ............................................................................... 174
Figure 6-37: Restart the Computer ......................................................................... 174
10

0-11
PICOe-6612
List of Tables
Table 1-1: PICOe-6612 Model Specifications ...........................................................16
Table 1-2: Technical Specifications ..........................................................................21
Table 2-1: Supported CPUs........................................................................................25
Table 2-2: Supported Pentium® M CPUs..................................................................25
Table 2-3: Supported Celeron® M CPUs...................................................................26
Table 2-4: Power Consumption .................................................................................34
Table 3-1: Peripheral Interface Connectors..............................................................40
Table 3-2: Rear Panel Connectors.............................................................................41
Table 3-3: Onboard Jumpers .....................................................................................41
Table 3-4: Audio Connector Pinouts.........................................................................42
Table 3-5: Backplane to Mainboard Connector Pinouts .........................................43
Table 3-6: CompactFlash Connector Pinouts ..........................................................45
Table 3-7: DIO Connector Connector Pinouts..........................................................46
Table 3-8: Fan Connector Pinouts.............................................................................47
Table 3-9: FDD Connector Pinouts............................................................................49
Table 3-10: Front Panel Connector Pinouts .............................................................50
Table 3-11: Primary IDE Connector Pinouts.............................................................52
Table 3-12: IR Connector Pinouts..............................................................................53
Table 3-13: Keyboard Connector Pinouts ................................................................54
Table 3-14: LCD LVDS Connector Pinouts ...............................................................56
Table 3-15: Panel Backlight Connector Pinouts ......................................................58
Table 3-16: Parallel Port Connector Pinouts ............................................................59
Table 3-17: RS-232 Serial Port Connector Pinouts..................................................60
Table 3-18: SATA Drive Connector Pinouts .............................................................62
Table 3-19: USB Port Connector Pinouts .................................................................63
Table 3-20: Mini-DIN 6 PS/2 Connector Pinouts.......................................................64
Table 3-21: LAN Pinouts.............................................................................................65
Table 3-22: RJ-45 Ethernet Connector LEDs............................................................65
Table 3-23: USB Port Pinouts ....................................................................................66
11

0-12
PICOe
-
6612
Table 3-24: VGA Connector Pinouts .........................................................................67
Table 4-1: Jumpers ....................................................................................................79
Table 4-2: Clear CMOS Jumper Settings ..................................................................80
Table 4-3: LVDS Voltage Selection Jumper Settings ..............................................81
Table 4-4: LVDS Voltage Selection Jumper Settings ..............................................83
Table 4-5: IEI Provided Cables...................................................................................84
Table 5-1: BIOS Navigation Keys...............................................................................95
12

0-13
PICOe-6612
List of BIOS Menus
BIOS Menu 1: Main ....................................................................................................96
BIOS Menu 2: Advanced.............................................................................................98
BIOS Menu 3: CPU Configuration..............................................................................99
BIOS Menu 4: IDE Configuration ............................................................................ 101
BIOS Menu 5: IDE Master and IDE Slave Configuration....................................... 105
BIOS Menu 6: Floppy Configuration ...................................................................... 109
BIOS Menu 7: Super IO Configuration ................................................................... 110
BIOS Menu 8: Hardware Health Configuration...................................................... 114
BIOS Menu 9: ACPI Configuration.......................................................................... 115
BIOS Menu 10: General ACPI Configuration ......................................................... 116
BIOS Menu 11: MPS Configuration ........................................................................ 118
BIOS Menu 12: USB Configuration......................................................................... 119
BIOS Menu 13: PCI/PnP Configuration .................................................................. 122
BIOS Menu 14: Boot................................................................................................. 127
BIOS Menu 15: Boot Settings Configuration......................................................... 128
BIOS Menu 16: Boot Device Priority Settings ....................................................... 132
BIOS Menu 17: Removable Drives.......................................................................... 134
BIOS Menu 18: Security........................................................................................... 135
BIOS Menu 19: Chipset............................................................................................ 137
BIOS Menu 20:NorthBridge Chipset Configuration.............................................. 138
BIOS Menu 21:SouthBridge Chipset Configuration ............................................. 142
BIOS Menu 22:Power ............................................................................................... 144
BIOS Menu 23:Exit ................................................................................................. 146
13

PICOe
-
6612
Glossary
AC ’97 Audio Codec 97
ACPI Advanced Configuration and
Power Interface
APM Advanced Power Management
ARMD ATAPI Removable Media Device
ASKIR Shift Keyed Infrared
ATA Advanced Technology
Attachments
BIOS Basic Input/Output System
CFII CompactFlash Type 2
CMOS Complementary Metal Oxide
Semiconductor
CPU Central Processing Unit
Codec Compressor/Decompressor
COM Serial Port
DAC Digital to Analog Converter
DDR Double Data Rate
DIMM Dual Inline Memory Module
DIO Digital Input/Output
DMA Direct Memory Access
EIDE Enhanced IDE
EIST Enhanced Intel SpeedStep
Technology
FDD Floppy Disk Drive
FDC Floppy Disk Connector
FFIO Flexible File Input/Output
FIFO First In/First Out
FSB Front Side Bus
IrDA Infrared Data Association
HDD Hard Disk Drive
IDE Integrated Data Electronics
I/O Input/Output
ICH4 I/O Controller Hub 4
L1 Cache Level 1 Cache
L2 Cache Level 2 Cache
LCD Liquid Crystal Display
LPT Parallel Port Connector
LVDS Low Voltage Differential Signaling
MAC Media Access Controller
OS Operating System
PCI Peripheral Connect Interface
PIO Programmed Input Output
PnP Plug and Play
POST Power On Self Test
RAM Random Access Memory
SATA Serial ATA
S.M.A.R.T Self Monitoring Analysis and
Reporting Technology
SPD Serial Presence Detect
S/PDI Sony/Philips Digital Interface
SDRAM Synchronous Dynamic Random
Access Memory
SIR Serial Infrared
UART Universal Asynchronous
Receiver-transmitter
USB Universal Serial Bus
VGA Video Graphics Adapter
0-14
14

Page 15
PICOe-6612
1
Chapter
1
Introduction

Page 16
IEI®Technology, Corp.
PICOe-6612
1.1 PICOe-6612 Overview
The half size PICOe-6612 socket 479 Pentium M or Celeron M CPU card is compatible
with all PICMG 1.0 half size backplanes and IEI PICOe backplanes for extra PCI Express
(PCIe) slots. The PICOe-6612 is designed for system manufacturers, integrators, and
VARs that want performance, reliability, and quality at a reasonable price.
1.1.1 PICOe-6612 Models
The PICOe-6612 series has four models:
 PICOe-6612-R10
 PICOe-6612LVDS-R10
The specifications for the two models are show in Table 1-1.
PICOe-6612 -R10 LVDS-R10
CRT/LCD YES YES
Dual GbE YES YES
Dual USB YES YES
SATA Drives YES YES
LVDS NO YES
Table 1-1: PICOe-6612 Model Specifications
1.1.2 PICOe-6612 Benefits
Some of the PICOe-6612 benefits are listed below:
 Same dimensions and backward compatible with half-size PCI SBC
 Higher Performance as PCI only solution
 Improved configuration with PCIe add on card
1.1.3 PICOe-6612 Features
Some of the PICOe-6612 features are listed below:
 Half size CPU card

Page 17
PICOe-6612
 RoHS compliant
 Socket 479 Intel® Pentium M/Celeron M processors supported
 Dual-independent display functionality
 Four PCI Master expansion boards supported
 Two PCI Express x1 (PCIe x 1) expansion boards supported
 Front side bus (FSB) up to 533MHz supported
 Up to 1GB of 400MHz DDR memory supported
 Dual channel 24-bit LVDS supported
 Two high performance gigabit Ethernet (GbE) controllers onboard
 Five USB 2.0 devices supported
 Two RS-232 serial communication channels
 Four 150Mb/s SATA drives supported
 Integrated audio
1.2 PICOe-6612 Overview
Figure 1-1: PICOe-6612 Overview

Page 18
IEI®Technology, Corp.
PICOe-6612
Figure 1-2: PICOe-6612 Solder Side Overview
1.2.1 PICOe-6612 Connectors
The PICOe-6612 has the following connectors onboard:
 1 x Audio connector
 1 x Backplane to mainboard connector
 1 x CompactFlash connector
 1 x Digital input/output (DIO) connector
 1 x Fan connector
 1 x Floppy disk drive connector
 1 x Front panel connector
 1 x IDE connector
 1 x Infrared connector
 1 x Keyboard connector
 1 x Low voltage differential signal (LVDS) connector
 1 x Panel backlight 12V power source
 1 x Parallel port connector
 4 x SATA connectors (150Mb/s)
 2 x Serial port connectors
 2 x USB connectors

Page 19
PICOe-6612
The PICOe-6612 has the following connectors on the board rear panel:
 2 x Ethernet connectors
 1 x PS/2 Keyboard/mouse connector
 1 x USB connector
 1 x VGA connector
The PICOe-6612 has the following onboard jumpers:
 Clear CMOS
 LVDS voltage selection
 FSB voltage selection
1.2.2 Technical Specifications
PICOe-6612 technical specifications are listed in Table 1-2. Detailed descriptions of each
specification can be found in Chapter 2 Detailed Specifications.
Specification PICOe-6612
Form Factor Half size CPU Card
CPU
Intel socket 479 Pentium M
Intel socket 479 Celeron M
Front Side Bus (FSB) 400MHz or 533MHz
Northbridge Chipset SiS 661CX
Southbridge Chipset SiS 966
Display
CRT Integrate in the SiS 661CX northbridge
24-bit dual channel LVDS
Memory Supports one 184-pin, 400MHz or 333MHz, 1GB DDR
DIMM module
BIOS AMI BIOS Label

Page 20
IEI®Technology, Corp.
PICOe-6612
SSD CompactFlash (CF)
Super I/O W83697HG
Audio Realtek ALC655 AC'97 Codec
LAN Dual RTL8110SC
COM Two RS-232 serial connectors
USB2.0 Five USB 2.0 devices supported by two onboard USB 2.0
connectors and one external USB 2.0 port
IDE One 40-pin IDE connects to two Ultra ATA33/66/100
devices
Parallel Port One LPT port connector
SATA Four 150Mb/s SATA connectors
KB/MS One PS/2 connector and one onboard connector
WDT Software programmable 1-255 sec. by super I/O
IrDA SIR / ASKIR
Digital I/O 8-bit digital I/O with 4 input and 4 output
Fan connector One 3-pin for CPU Fan
Expansion Four PCI expansion cards on backplane OR
Two PCIe x1 expansion cards on backplane
Power +5V/+12V&-12V, AT/ATX support
Temperature 0ºC - 60ºC
Humidity 5%~95% non-condensing
