iflo Rhea User manual

Installation Instructions
Rhea
Toilet Seat
187933
Please note: Images shown are for illustration
purposes only.
2

Fitting Instructions
Rhea Toilet Seat
Use this checklist to ensure all the
parts are accounted for and not
damaged. Under no circumstances
should this product be installed if
any of the parts are damaged or
missing. In the unlikely event that
there are installation issues, please
contact your local branch.
Please read these instructions prior to installation. These instructions must be carried out in order.
Item
1
2
3
4
5
6
7
Description
Toilet Seat with Cover
Stainless Steel Cover
Stainless Steel Screw
Stainless Steel Support with Stainless Steel Connector
Rubber Disc
Rubber Pipe Insert
Pan
Qty
1
2
2
2
2
2
1
Place the rubber inserts (6) into the small holes in the pan (7). Place the stainless steel supports (4)
onto the rubber discs (5) with connectors uppermost, then place over the rubber inserts aligning the
slot with the hole in the rubber inserts (6). Thread stainless steel screws (3) through the slots in the
supports (4), rubber discs (5) and into the rubber inserts (6). Tighten the screws (3) do not fully
tighten. Fit the seat cover (1) by engaging the connectors (4) with the holes in the seat hinges and
push down firmly until seat “clicks” into place. Adjust the seat cover (1) to align with the pan (7), lift
the seat cover (1) and tighten the screws (3), cover the supports (4) with the stainless steel covers (2).
Engage connectors with holes in seat
hinge and push down firmly until
seat ‘clicks’ into place.
Remarks
• Clean using warm soapy water & dry with a soft cloth.
To remove the seat simply press the
button at the rear of the seat and lift
off.
Customer Support:
We have taken great care to ensure that this product reaches you in perfect condition. However, should any parts be damaged
or missing please contact your local branch. This does not affect your statutory rights. In addition if you require replacement
parts, your local branch will be only to happy to assist.
www.iflo.co.uk
JB70162 01/13
