Laufen CLEANET NAVIA H8206014000001 User manual

LAUFEN CLEANET NAVIA
OPERATING MANUAL
+1
Register your shower toilet now!
www.laufen-cleanet.com
YEAR’S
GUARANTEE
Laufen_Cleanet_Navia_manual_EN.indd 1Laufen_Cleanet_Navia_manual_EN.indd 1 29.10.21 09:4529.10.21 09:45

2
1 SAFETY AND WARNING NOTICES 3
2 INTRODUCTION 4
2.1 Notices 4
2.2 Shower toilet: LED indicator light 4
3 OVERVIEW OF YOUR NAVIA SHOWER TOILET 5
3.1 Shower toilet 5
3.2 Controller with rotary button 6
3.3 Laufen App 6
4 OPERATING THE SHOWER TOILET 7
4.1 Rear shower 8
4.1.1 Jet intensity 8
4.1.2 Shower jet position 8
4.1.3 Oscillation 8
4.2 Lady shower 9
4.2.1 Jet intensity 9
4.2.2 Shower jet position 9
4.2.3 Oscillation 9
4.3 Selecting special functions using the app 10
4.3.1 Appliance flushing 10
4.3.2 Configuring the basic profile 10
4.3.3 Water hardness 10
4.3.4 Heater settings 10
5 MAINTENANCE AND CLEANING 11
5.1 Cleaning the seat and cover unit 11
5.2 Cleaning the ceramic surface 11
5.3 Cleaning plastic surfaces and metal components 11
5.4 Suitable cleaning agents and equipment, cleaning tips 12
5.5 Unsuitable cleaning agents and equipment 12
5.6 Ordering consumables 12
5.7 Descaling 13
5.8 Changing the nozzle 14
5.9 Changing the cover ring 15
6 TROUBLESHOOTING 16
6.1 Messages and faults 16
7 DISPOSAL AND ENVIRONMENT 17
8 TECHNICAL DATA CLEANET NAVIA 18
9 LEGAL NOTICE 19
CONTENTS
Laufen_Cleanet_Navia_manual_EN.indd 2Laufen_Cleanet_Navia_manual_EN.indd 2 29.10.21 09:4529.10.21 09:45

3
1 SAFETY AND WARNING NOTICES
Intended use
The Laufen shower toilet is designed to wash the rear area and also the female intimate area with the
lady shower. Any other kind of use is not permitted. Glowing cigarettes or other burning objects must
not be thrown into the WC bowl. Laufen shall not accept liability for damage that occurs as a result of
connecting the appliance incorrectly, misuse, or inappropriate use.
Improper operation includes initiating the shower procedure without anyone sitting on the shower toilet.
This may cause water damage in the surrounding area.
Persons with physical, sensory or mental disabilities as well
as persons who are completely unfamiliar with the appliance
(especially children) may only use the shower toilet under the
supervision or instruction of a responsible person.
precautions (your safety)
Never operate a defective appliance.
Always use tap water to operate your Laufen shower toilet. Do not use rainwater, grey water,
or demineralised water.
Check all functions regularly to ensure they work normally. Should you have any suspicion
that the appliance is faulty, disconnect it immediately from the power supply and contact
Laufen customer services.
Do not attempt to open or repair the appliance yourself. Do not install any additional components or
make any modifications. The appliance contains live components. Opening the appliance can be
extremely dangerous!
Unprofessional repairs can cause dangerous accidents, malfunctions, or damage to the appliance and
installation. Repairs must therefore always be performed by trained and authorised personnel using
original spare parts and accessories.
Do not allow children to clean and maintain the appliance without supervision. Installation may only be
carried out using new hose sets. Old hose sets must not be reused.
Only original electrical connection, water inlet and replacement part material may be used.
For care and cleaning and also for descaling, use only original Laufen or Laufen-recommended
products. We do not accept liability for the use of other products.
Visit www.laufen-cleanet.com to view the Declaration of Conformity
Laufen_Cleanet_Navia_manual_EN.indd 3Laufen_Cleanet_Navia_manual_EN.indd 3 29.10.21 09:4529.10.21 09:45

4
2 INTRODUCTION
30. October 2017 | Laufen ∙ Icons app 1
©
Laufen
Gegenüberstellung Icons
Menu
alternativer Iconvorschlag,
da Symbol bei iOS bereits für den
Home Button verwendet wird
POWER
or
or
30. October 2017 | Laufen ∙ Icons app 2
©
Laufen
Gegenüberstellung Icons
Fö hn
Kein Icon mehrKein Icon mehr
Kein Icon mehrKein Icon mehr
Kein Icon mehr
Düse wechseln
Kein Icon mehr
Kein Icon für P2 App
alternativer Iconvorschlag,
da auf native s Gestaltungs-
element zurückgegriffen wird
30. October 2017 | Laufen ∙ Icons app 3
©
Laufen
Gegenüberstellung Icons
BedienungsanleitungTutorialInformationen über
das Dusch-WC
RegistrierungTroubleshooting Fernbedienung
Downloads Schritt für Schritt AnleitungGerätestatus auslesen
Verbrauchsmaterial Erklärung der IconsErsatzzeile
FilmeServiceanfrageDirektwahl Laufen
Präsentationsmodus
Dialog und Feedback
Deckel entfernen
30. October 2017 | Laufen ∙ Icons app 1
©
Laufen
Gegenüberstellung Icons
Menu
alternativer Iconvorschlag,
da Symbol bei iOS bereits für den
Home Button verwendet wird
POWER
or
or
30. October 2017 | Laufen ∙ Icons app 2
©
Laufen
Gegenüberstellung Icons
Fö hn
Kein Icon mehrKein Icon mehr
Kein Icon mehrKein Icon mehr
Kein Icon mehr
Düse wechseln
Kein Icon mehr
Kein Icon für P2 App
alternativer Iconvorschlag,
da auf native s Gestaltungs-
element zurückgegriffen wird
30. October 2017 | Laufen ∙ Icons app 3
©
Laufen
Gegenüberstellung Icons
BedienungsanleitungTutorialInformationen über
das Dusch-WC
RegistrierungTroubleshooting Fernbedienung
Downloads Schritt für Schritt AnleitungGerätestatus auslesen
Verbrauchsmaterial Erklärung der IconsErsatzzeile
FilmeServiceanfrageDirektwahl Laufen
Präsentationsmodus
Dialog und Feedback
Deckel entfernen
30. October 2017 | Laufen ∙ Icons app 1
©
Laufen
Gegenüberstellung Icons
Menu
alternativer Iconvorschlag,
da Symbol bei iOS bereits für den
Home Button verwendet wird
POWER
or
or
30. October 2017 | Laufen ∙ Icons app 2
©
Laufen
Gegenüberstellung Icons
Fö hn
Kein Icon mehrKein Icon mehr
Kein Icon mehrKein Icon mehr
Kein Icon mehr
Düse wechseln
Kein Icon mehr
Kein Icon für P2 App
alternativer Iconvorschlag,
da auf native s Gestaltungs-
element zurückgegriffen wird
30. October 2017 | Laufen ∙ Icons app 3
©
Laufen
Gegenüberstellung Icons
BedienungsanleitungTutorialInformationen über
das Dusch-WC
RegistrierungTroubleshooting Fernbedienung
Downloads Schritt für Schritt AnleitungGerätestatus auslesen
Verbrauchsmaterial Erklärung der IconsErsatzzeile
FilmeServiceanfrageDirektwahl Laufen
Präsentationsmodus
Dialog und Feedback
Deckel entfernen
Menu
30. October 2017 | Laufen ∙ Icons app 1
©
Laufen
Gegenüberstellung Icons
Menu
alternativer Iconvorschlag,
da Symbol bei iOS bereits für den
Home Button verwendet wird
POWER
or
or
30. October 2017 | Laufen ∙ Icons app 2
©
Laufen
Gegenüberstellung Icons
Fö hn
Kein Icon mehrKein Icon mehr
Kein Icon mehrKein Icon mehr
Kein Icon mehr
Düse wechseln
Kein Icon mehr
Kein Icon für P2 App
alternativer Iconvorschlag,
da auf native s Gestaltungs-
element zurückgegriffen wird
30. October 2017 | Laufen ∙ Icons app 3
©
Laufen
Gegenüberstellung Icons
BedienungsanleitungTutorialInformationen über
das Dusch-WC
RegistrierungTroubleshooting Fernbedienung
Downloads Schritt für Schritt AnleitungGerätestatus auslesen
Verbrauchsmaterial Erklärung der IconsErsatzzeile
FilmeServiceanfrageDirektwahl Laufen
Präsentationsmodus
Dialog und Feedback
Deckel entfernen
Shower settings Help
Info
NOTICIES2.1
LED indicator light Information Description
No indication Normal operation Everything functioning correctly.
Steady red Care notice Please descale your shower toilet.
For further information and descriptions on the notice, see

Red, flashing Care programme
active
Descaling is active when the red LED indicator light is flashing.
For further information and descriptions,

Red, flashing
fast
Fault indication Please contact us at www.laufen-cleanet.com
For further information and descriptions of the problem,

SHOWER TOILET: LED INDICATOR LIGHT
The LED indicator light is located on the underside of
the appliance. It provides information about required
maintenance or possible malfunctions on your
shower toilet.
2.2
LED indicator light
Laufen_Cleanet_Navia_manual_EN.indd 4Laufen_Cleanet_Navia_manual_EN.indd 4 29.10.21 09:4529.10.21 09:45

5
SHOWER TOILET3.1
3 OVERVIEW OF YOUR NAVIA SHOWER TOILET
Descaling
agent opening
LED indicator light
Controller with
rotary button
Main switch
Laufen_Cleanet_Navia_manual_EN.indd 5Laufen_Cleanet_Navia_manual_EN.indd 5 29.10.21 09:4529.10.21 09:45

6
CONTROLLER WITH ROTARY BUTTON
You can operate the Laufen shower toilet
easily by turning and pressing the controller
located on the right. The following functions can
be activated using the controller:
Rear shower
Lady shower
Jet intensity
Shower jet position
Oscillation
LAUFEN APP
Your shower toilet can be operated easily
with the Laufen app for iPhone and Android,
including useful special functions.
For further descriptions, see section 4.2.
An active internet connection is not required.
Main menu
Rear shower
Lady shower
Jet intensity
Shower jet position
Water temperature
3.2
3.3
3 OVERVIEW OF YOUR NAVIA SHOWER TOILET
Controller with
rotary button
Laufen App
Oscillation
Basic profile management
Appliance connection
Maintenance menu
Descaling programme
Appliance flushing
Temperature settings
and ECO mode
Water hardness settings
Language and country settings
Appliance information
Ordering consumables
Info menu
Appliance information
List of serial numbers
Downloading instructions
Service menu
Recording service messages
First aid, questions and answers
Explanation of the icons and symbols
Install the free app directly from the App Store or Google Play.
Laufen_Cleanet_Navia_manual_EN.indd 6Laufen_Cleanet_Navia_manual_EN.indd 6 29.10.21 09:4529.10.21 09:45

7
4 OPERATING THE SHOWER TOILET
30. October 2017 | Laufen ∙ Icons app 1
©
Laufen
Gegenüberstellung Icons
Menu
alternativer Iconvorschlag,
da Symbol bei iOS bereits für den
Home Button verwendet wird
POWER
or
or
30. October 2017 | Laufen ∙ Icons app 2
©
Laufen
Gegenüberstellung Icons
Fö hn
Kein Icon mehrKein Icon mehr
Kein Icon mehrKein Icon mehr
Kein Icon mehr
Düse wechseln
Kein Icon mehr
Kein Icon für P2 App
alternativer Iconvorschlag,
da auf native s Gestaltungs-
element zurückgegriffen wird
30. October 2017 | Laufen ∙ Icons app 3
©
Laufen
Gegenüberstellung Icons
BedienungsanleitungTutorialInforma tionen über
das Dusch-WC
RegistrierungTroubleshooting Fernbedienung
Downloads Schritt für Schritt AnleitungGerätestatus auslesen
Verbrauchsmaterial Erklärung der IconsErsatzzeile
FilmeServiceanfrageDirektwahl Laufen
Präsentationsmodus
Dialog und Feedback
Deckel entfernen
25 sec
30. October 2017 | Laufen ∙ Icons app 1
©
Laufen
Gegenüberstellung Icons
Menu
alternativer Iconvorschlag,
da Symbol bei iOS bereits für den
Home Button ve rwendet wi rd
POWER
or
or
30. October 2017 | Laufen ∙ Icons app 2
©
Laufen
Gegenüberstellung Icons
Fö hn
Kein Icon mehrKein Icon mehr
Kein Icon mehrKein Icon mehr
Kein Icon mehr
Düse wechseln
Kein Icon mehr
Kein Icon für P2 App
alternativer Iconvorschlag,
da auf native s Gestaltungs-
element zurückgegriffen wird
30. October 2017 | Laufen ∙ Icons app 3
©
Laufen
Gegenüberstellung Icons
BedienungsanleitungTutorialInforma tionen über
das Dusch-WC
RegistrierungTroubleshooting Fernbedienung
Downloads Schritt für Schritt AnleitungGerätestatus auslesen
Verbrauchs ma terial Erklärung der IconsErsatzzeile
FilmeServiceanfrageDirektwahl Laufen
Präsentationsmodus
Dialog und Feedback
Deckel entfernen
STOP
Your Laufen shower toilet can be operated using
either the controller with rotary button or via the
Laufen app.
Controller with
rotary button
Laufen
App
Rear shower
Stop
Lady shower
30. October 2017 | Laufen ∙ Icons app 1
©
Laufen
Gegenüberstellung Icons
Menu
alternativer Iconvorschlag,
da Symbol bei iOS bereits für den
Home Button verwendet wird
POWER
or
or
30. October 2017 | Laufen ∙ Icons app 2
©
Laufen
Gegenüberstellung Icons
Fö hn
Kein Icon mehrKein Icon mehr
Kein Icon mehrKein Icon mehr
Kein Icon mehr
Düse wechseln
Kein Icon mehr
Kein Icon für P2 App
alternativer Iconvorschlag,
da auf native s Gestaltungs-
element zurückgegriffen wird
30. October 2017 | Laufen ∙ Icons app 3
©
Laufen
Gegenüberstellung Icons
BedienungsanleitungTutorialInforma tionen über
das Dusch-WC
RegistrierungTroubleshooting Fernbedienung
Downloads Schritt für Schritt AnleitungGerätestatus auslesen
Verbrauchsmaterial Erklärung der IconsErsatzzeile
FilmeServiceanfrageDirektwahl Laufen
Präsentationsmodus
Dialog und Feedback
Deckel entfernen
30. October 2017 | Laufen ∙ Icons app 1
©
Laufen
Gegenüberstellung Icons
Menu
alternativer Iconvorschlag,
da Symbol bei iOS bereits für den
Home Button verwendet wird
POWER
or
or
30. October 2017 | Laufen ∙ Icons app 2
©
Laufen
Gegenüberstellung Icons
Fö hn
Kein Icon mehrKein Icon mehr
Kein Icon mehrKein Icon mehr
Kein Icon mehr
Düse wechseln
Kein Icon mehr
Kein Icon für P2 App
alternativer Iconvorschlag,
da auf native s Gestaltungs-
element zurückgegriffen wird
30. October 2017 | Laufen ∙ Icons app 3
©
Laufen
Gegenüberstellung Icons
BedienungsanleitungTutorialInforma tionen über
das Dusch-WC
RegistrierungTroubleshooting Fernbedienung
Downloads Schritt für Schritt AnleitungGerätestatus auslesen
Verbrauchsmaterial Erklärung der IconsErsatzzeile
FilmeServiceanfrageDirektwahl Laufen
Präsentationsmodus
Dialog und Feedback
Deckel entfernen
30. October 2017 | Laufen ∙ Icons app 1
©
Laufen
Gegenüberstellung Icons
Menu
alternativer Iconvorschlag,
da Symbol bei iOS bereits für den
Home Button verwendet wird
POWER
or
or
30. October 2017 | Laufen ∙ Icons app 2
©
Laufen
Gegenüberstellung Icons
Fö hn
Kein Icon mehrKein Icon mehr
Kein Icon mehrKein Icon mehr
Kein Icon mehr
Düse wechseln
Kein Icon mehr
Kein Icon für P2 App
alternativer Iconvorschlag,
da auf native s Gestaltungs-
element zurückgegriffen wird
30. October 2017 | Laufen ∙ Icons app 3
©
Laufen
Gegenüberstellung Icons
BedienungsanleitungTutorialInforma tionen über
das Dusch-WC
RegistrierungTroubleshooting Fernbedienung
Downloads Schritt für Schritt AnleitungGerätestatus auslesen
Verbrauchsmaterial Erklärung der IconsErsatzzeile
FilmeServiceanfrageDirektwahl Laufen
Präsentationsmodus
Dialog und Feedback
Deckel entfernen
30. October 2017 | Laufen ∙ Icons app 1
©
Laufen
Gegenüberstellung Icons
Menu
alternativer Iconvorschlag,
da Symbol bei iOS bereits für den
Home Button verwendet wird
POWER
or
or
30. October 2017 | Laufen ∙ Icons app 2
©
Laufen
Gegenüberstellung Icons
Fö hn
Kein Icon mehrKein Icon mehr
Kein Icon mehrKein Icon mehr
Kein Icon mehr
Düse wechseln
Kein Icon mehr
Kein Icon für P2 App
alternativer Iconvorschlag,
da auf native s Gestaltungs-
element zurückgegriffen wird
30. October 2017 | Laufen ∙ Icons app 3
©
Laufen
Gegenüberstellung Icons
Bedienungs anleitungTutorialInforma tionen über
das Dusch-WC
RegistrierungTroubleshooting Fernbedienung
Downloads Schritt für Schritt AnleitungGerätestatus auslesen
Verbrauchs ma terial Erklärung der IconsErsatzzeile
FilmeServiceanfrageDirektwahl Laufen
Präsentationsmodus
Dialog und Feedback
Deckel entfernen
30. October 2017 | Laufen ∙ Icons app 1
©
Laufen
Gegenüberstellung Icons
Menu
alternativer Iconvorschlag,
da Symbol bei iOS bereits für den
Home Button verwendet wird
POWER
or
or
30. October 2017 | Laufen ∙ Icons app 2
©
Laufen
Gegenüberstellung Icons
Fö hn
Kein Icon mehrKein Icon mehr
Kein Icon mehrKein Icon mehr
Kein Icon mehr
Düse wechseln
Kein Icon mehr
Kein Icon für P2 App
alternativer Iconvorschlag,
da auf native s Gestaltungs-
element zurückgegriffen wird
30. October 2017 | Laufen ∙ Icons app 3
©
Laufen
Gegenüberstellung Icons
Bedienungs anleitungTutorialInforma tionen über
das Dusch-WC
RegistrierungTroubleshooting Fernbedienung
Downloads Schritt für Schritt AnleitungGerätestatus auslesen
Verbrauchs ma terial Erklärung der IconsErsatzzeile
FilmeServiceanfrageDirektwahl Laufen
Präsentationsmodus
Dialog und Feedback
Deckel entfernen
30. October 2017 | Laufen ∙ Icons app 1
©
Laufen
Gegenüberstellung Icons
Menu
alternativer Iconvorschlag,
da Symbol bei iOS bereits für den
Home Button verwendet wird
POWER
or
or
30. October 2017 | Laufen ∙ Icons app 2
©
Laufen
Gegenüberstellung Icons
Fö hn
Kein Icon mehrKein Icon mehr
Kein Icon mehrKein Icon mehr
Kein Icon mehr
Düse wechseln
Kein Icon mehr
Kein Icon für P2 App
alternativer Iconvorschlag,
da auf native s Gestaltungs-
element zurückgegriffen wird
30. October 2017 | Laufen ∙ Icons app 3
©
Laufen
Gegenüberstellung Icons
BedienungsanleitungTutorialInforma tionen über
das Dusch-WC
RegistrierungTroubleshooting Fernbedienung
Downloads Schritt für Schritt AnleitungGerätestatus auslesen
Verbrauchsmaterial Erklärung der IconsErsatzzeile
FilmeServiceanfrageDirektwahl Laufen
Präsentationsmodus
Dialog und Feedback
Deckel entfernen
2×
Jet intensity

Shower arm
forwards
Shower arm back
Oscillation
>2 sec.
30. October 2017 | Laufen ∙ Icons app 1
©
Laufen
Gegenüberstellung Icons
Menu
alternativer Iconvorschlag,
da Symbol bei iOS bereits für den
Home Button verwendet wird
POWER
or
or
30. October 2017 | Laufen ∙ Icons app 2
©
Laufen
Gegenüberstellung Icons
Fö hn
Kein Icon mehrKein Icon mehr
Kein Icon mehrKein Icon mehr
Kein Icon mehr
Düse wechseln
Kein Icon mehr
Kein Icon für P2 App
alternativer Iconvorschlag,
da auf native s Gestaltungs-
element zurückgegriffen wird
30. October 2017 | Laufen ∙ Icons app 3
©
Laufen
Gegenüberstellung Icons
Bedienungs anleitungTutorialInforma tionen über
das Dusch-WC
RegistrierungTroubleshooting Fernbedienung
Downloads Schritt für Schritt AnleitungGerätestatus auslesen
Verbrauchsmaterial Erklärung der IconsErsatzzeile
FilmeServiceanfrageDirektwahl Laufen
Präsentationsmodus
Dialog und Feedback
Deckel entfernen
Laufen_Cleanet_Navia_manual_EN.indd 7Laufen_Cleanet_Navia_manual_EN.indd 7 29.10.21 09:4529.10.21 09:45

8
REAR SHOWER
While you are sitting on the shower toilet, briefly press the controller on the right side to start the rear
shower. If you need to stop the shower prematurely, press the controller again.
If you wish to shower again, press the controller while the shower arm is retracting at the end of the first
showering procedure.
The factory setting for the heating is always “switched on” (see section 4.2.3).
If you shower repeatedly, the water will gradually become cooler.
The shower duration is factory preset to 25 seconds.
Improper operation includes initiating the shower procedure without anyone sitting on the shower toilet.
This may cause water damage in the surrounding area.
JET INTENSITY
The jet intensity can be adjusted to one of 7 settings. You can adjust the jet intensity while showering by
turning the controller.
Turn the controller forwards to increase
the jet intensity.
4.1
4.1.1
4.1.2
4 OPERATING THE SHOWER TOILET
Turn the controller backwards to reduce
the jet intensity.
The jet intensity is factory preset to 4 out of a possible 7.
SHOWER JET POSITION
The position of the shower jet can be adjusted to one of 7 settings. While showering,
you can simultaneously press and turn the controller back or forwards.
The shower jet follows the direction of rotation.
Press the controller and simultaneously
turn it forwards to move the shower jet
forwards.
Press the controller and simultaneously
turn it back to move the shower jet back.
The jet position is factory preset to 4 out of a possible 7.
OSCILLATION
Press the controller and turn it quickly forwards and backwards twice to generate an automatic forwards
and backwards movement of the shower jet.
4.1.3
Laufen_Cleanet_Navia_manual_EN.indd 8Laufen_Cleanet_Navia_manual_EN.indd 8 29.10.21 09:4529.10.21 09:45

9
LADY SHOWER
When seated on the shower toilet, press the rotary button on the right-hand side and hold it down for
approx. 2 seconds to start the lady shower. To stop the Lady shower prematurely, simply press the
button again.
If you want to shower a second time, press the rotary button again and hold it (approx. 2 seconds),
while the shower arm retracts after the first shower process.
JET INTENSITY
While the lady shower is active, you can select one of 7 jet intensity settings. On the whole, the jet
intensity settings are more gentle that the rear shower settings.
OPERATION WHILE USING THE SHOWER TOILET
You can adjust the jet intensity during showering by turning
the rotary button.
"Turn the rotary button forwards
to increase the jet intensity."
4.2
4.2.1
4.2.2
4 OPERATING THE SHOWER TOILET
SHOWER JET POSITION
While the lady shower is active, you can adjust the shower jet to one of 7 positions.
OPERATION WHILE USING THE SHOWER TOILET
While showering, you can simultaneously press and turn the rotary button back or forwards.
The shower jet follows the direction of rotatio.
"Press and turn the rotary button forwards
simultaneously to move the shower jet
forwards."
"Press and turn the rotary button back
simultaneously to move the shower jet
back."
"Turn the rotary button back
to reduce the jet intensity."
>2 sec.
OSCILLATION
Press the controller and turn it quickly forwards and backwards twice to generate an automatic forwards
and backwards movement of the shower jet.
4.2.3
Laufen_Cleanet_Navia_manual_EN.indd 9Laufen_Cleanet_Navia_manual_EN.indd 9 29.10.21 09:4529.10.21 09:45

10
SELECTING SPECIAL FUNCTIONS USING THE APP
The Laufen app gives you access to practical special functions which you can only select
via your smartphone.
APPLIANCE FLUSHING
The appliance flushing feature allows you to flush out your shower toilet completely to clean it and
to supply it with fresh water. It is recommended that appliance flushing be carried out particularly after
longer periods of inactivity (e.g., after holidays).
CONFIGURING THE BASIC PROFILE
The Laufen app allows you to save a personal user profile.
You can use this to individually set the desired jet intensity and position.
WATER HARDNESS
The Laufen app allows you to store the hardness of your mains water in order to ensure
an optimum interval for the automatic descaling programme.
There are various ways of measuring the water hardness:
Ask your water supply company. You will usually find this
information on your water bill.
Factory setting: 25–35 °fH
HEATER SETTINGS
You can adjust the heater settings using the app. The factory setting for the
heater is always ON.
4.3
4.3.1
4.3.2
4.3.3
4.3.4
4 OPERATING THE SHOWER TOILET
30. October 2017 | Laufen ∙ Icons app 1
©
Laufen
Gegenüberstellung Icons
Menu
alternativer Iconvorschlag,
da Symbol bei iOS bereits für den
Home Button verwendet wird
POWER
or
or
30. October 2017 | Laufen ∙ Icons app 2
©
Laufen
Gegenüberstellung Icons
Fö hn
Kein Icon mehrKein Icon mehr
Kein Icon mehrKein Icon mehr
Kein Icon mehr
Düse wechseln
Kein Icon mehr
Kein Icon für P2 App
alternativer Iconvorschlag,
da auf native s Gestaltungs-
element zurückgegriffen wird
30. October 2017 | Laufen ∙ Icons app 3
©
Laufen
Gegenüberstellung Icons
BedienungsanleitungTutorialInformationen über
das Dusch-WC
RegistrierungTroubleshooting Fernbedienung
Downloads Schritt für Schritt AnleitungGerätestatus auslesen
Verbrauchsmaterial Erklärung der IconsErsatzzeile
FilmeServiceanfrageDirektwahl Laufen
Präsentationsmodus
Dialog und Feedback
Deckel entfernen
30. October 2017 | Laufen ∙ Icons app 1
©
Laufen
Gegenüberstellung Icons
Menu
alternativer Iconvorschlag,
da Symbol bei iOS bereits für den
Home Button verwendet wird
POWER
or
or
30. October 2017 | Laufen ∙ Icons app 2
©
Laufen
Gegenüberstellung Icons
Fö hn
Kein Icon mehrKein Icon mehr
Kein Icon mehrKein Icon mehr
Kein Icon mehr
Düse wechseln
Kein Icon mehr
Kein Icon für P2 App
alternativer Iconvorschlag,
da auf native s Gestaltungs-
element zurückgegriffen wird
30. October 2017 | Laufen ∙ Icons app 3
©
Laufen
Gegenüberstellung Icons
BedienungsanleitungTutorialInformationen über
das Dusch-WC
RegistrierungTroubleshooting Fernbedienung
Downloads Schritt für Schritt AnleitungGerätestatus auslesen
Verbrauchsmaterial Erklärung der IconsErsatzzeile
FilmeServiceanfrageDirektwahl Laufen
Präsentationsmodus
Dialog und Feedback
Deckel entfernen
30. October 2017 | Laufen ∙ Icons app 1
©
Laufen
Gegenüberstellung Icons
Menu
alternativer Iconvorschlag,
da Symbol bei iOS bereits für den
Home Button verwendet wird
POWER
or
or
30. October 2017 | Laufen ∙ Icons app 2
©
Laufen
Gegenüberstellung Icons
Fö hn
Kein Icon mehrKein Icon mehr
Kein Icon mehrKein Icon mehr
Kein Icon mehr
Düse wechseln
Kein Icon mehr
Kein Icon für P2 App
alternativer Iconvorschlag,
da auf native s Gestaltungs-
element zurückgegriffen wird
30. October 2017 | Laufen ∙ Icons app 3
©
Laufen
Gegenüberstellung Icons
BedienungsanleitungTutorialInformationen über
das Dusch-WC
RegistrierungTroubleshooting Fernbedienung
Downloads Schritt für Schritt AnleitungGerätestatus auslesen
Verbrauchsmaterial Erklärung der IconsErsatzzeile
FilmeServiceanfrageDirektwahl Laufen
Präsentationsmodus
Dialog und Feedback
Deckel entfernen
Description
ON The boiler heater is permanently switched on and produces
and maintains the desired water temperature.
ECO The boiler heater switches on as soon as you indicate your presence
to the appliance by briefly turning the controller. Warm water is available after

OFF The boiler heater is switched off permanently. Only cold water
is available. Which means energy consumption is minimised.
30. October 2017 | Laufen ∙ Icons app 1
©
Laufen
Gegenüberstellung Icons
Menu
alternativer Iconvorschlag,
da Symbol bei iOS bereits für den
Home Button verwendet wird
POWER
or
or
30. October 2017 | Laufen ∙ Icons app 2
©
Laufen
Gegenüberstellung Icons
Fö hn
Kein Icon mehrKein Icon mehr
Kein Icon mehrKein Icon mehr
Kein Icon mehr
Düse wechseln
Kein Icon mehr
Kein Icon für P2 App
alternativer Iconvorschlag,
da auf native s Gestaltungs-
element zurückgegriffen wird
30. October 2017 | Laufen ∙ Icons app 3
©
Laufen
Gegenüberstellung Icons
Bedienungs anleitungTutorialInforma tionen über
das Dusch-WC
RegistrierungTroubleshooting Fernbedienung
Downloads Schritt für Schritt AnleitungGerätestatus auslesen
Verbrauchsmaterial Erklärung der IconsErsatzzeile
FilmeServiceanfrageDirektwahl Laufen
Präsentationsmodus
Dialog und Feedback
Deckel entfernen
Laufen_Cleanet_Navia_manual_EN.indd 10Laufen_Cleanet_Navia_manual_EN.indd 10 29.10.21 09:4529.10.21 09:45

11
CLEANING THE SEAT AND COVER UNIT
The seat and cover are integrated in a single unit because of the
lowering system.
The seat and cover unit can be removed to make the shower toilet
easier to clean. Simply lift the seat and cover to a vertical position, use a
coin to release the locking screws and pull the seat and cover from the
hinge at both sides. Clean the seat and cover in a bathtub for exmaple.
You can also use a mild diluted liquid detergent. After cleaning,
reassemble the seat and cover and insert in the hinge in a vertical
position and tighten. You will find further cleaning and
care hints in the separate care instructions.
CLEANING THE CERAMIC SURFACE
Aggressive cleaning products are no longer required due to the
specially glazed ceramic surface. Clean the ceramic surface
using a standard all-purpose detergent diluted with water.
Use a sponge with a soft, non-scratch surface or alternatively
a microfibre cloth.
Do not use aggressive or abrasive agents, tools or
instruments to clean the appliance.
CLEANING PLASTIC SURFACES
AND METAL COMPONENTS
Plastic surfaces
Seat and cover unit
Cover ring and nozzle
Descaling
Wipe over these components with a soft, damp cloth and an extremely
mild, diluted cleaning detergent, if required.
Then dry the components using a soft cloth.
Do not use aggressive or abrasive agents, tools or
instruments to clean the appliance.
5.1
5.2
5.3
5 MAINTENANCE AND CLEANING
Metal components
Controller and metal cover
Hinge
Shower arm
Laufen_Cleanet_Navia_manual_EN.indd 11Laufen_Cleanet_Navia_manual_EN.indd 11 29.10.21 09:4529.10.21 09:45

12
SUITABLE CLEANING AGENTS AND EQUIPMENT, CLEANING TIPS
Slightly acidic cleaning agents such as vinegar, all-purpose, glass, bathroom or limescale cleaner
Foam cleaning agents
Dilute cleaning agent with water
Always use liquid cleaning agents
Ensure the cleaning agent is dermatologically compatible
Normal toilet brushes
Soft, non-abrasive sponges
Microfibre cloths
UNSUITABLE CLEANING AGENTS AND EQUIPMENT
Abrasive and powdery cleaning or scouring agents
such as scouring powder, sand and scouring cream
Strong, corrosive products such as steel or fitting cleaners,
aggressive pipe or drain cleaners, alkaline solutions, bleach and
mould remover
Chlorinated cleaning agents
Cleaning agents that irritate the eyes and skin
Hard and abrasive sponges
Steel wool, pan scourers, etc.
Pointed objects such as scrapers designed for mechanical cleaning
ORDERING CONSUMABLES
You can order the following consumables
on www.laufen-cleanet.com or from
specialist dealers.
5.4
5.5
5.6
5 MAINTENANCE AND CLEANING
Article no.
6 descaling tablets for 2 applications 8.9260.4.000.000.1
Nozzle and cover ring 8.9260.6.000.000.1
Rotary button 8.9260.8.000.000.1
Cover for descaling opening 8.9260.7.000.000.1
Subject to modifications
Laufen_Cleanet_Navia_manual_EN.indd 12Laufen_Cleanet_Navia_manual_EN.indd 12 29.10.21 09:4529.10.21 09:45

13
DESCALING
The Laufen shower toilet incorporates an integral descaling program for descaling water-carrying
components. Your appliance detects the need for descaling and informs you (red LED indicator light)
accordingly. When the descaling message appears, you can continue using the shower toilet
in the usual way until descaling is actually performed. Carry out descaling within a few days of receiving
the message. The descaling programme takes around 75 minutes (LED indicator light flashes red).
The shower toilet builds up deposits of limescale over time. The amount of limescale depends
on the hardness of the water, the temperature setting, and the frequency of use of the
shower toilet.
It is not possible to interrupt the descaling program once it has started. The shower toilet
functions are disabled during the cycle. However, the appliance can be used as a normal
WC without shower function.
Please note that the use of unsuitable descaling agents can damage the appliance and leave
residues in the water.
Guarantee and liability claims arising from damage of this nature are expressly rejected.
Descaling signal
The LED indicator light on the shower toilet shows red.
Open the cover on the right hand side of the bowl
by pressing on it.
Put 3 genuine Laufen descaling agent tabs into the opening
and click the cover back in. The descaling programme
will be started automatically by the shower toilet.
You can obtain the necessary descaling agent from Laufen. It is matched
to the descaling programme of your appliance. Please always
use genuine Laufen descaling agent.
At the end of the descaling cycle, the shower toilet and all its functions
are ready to use again.
Please note that failing to initiate the recommended descaling cycle can result in damage to the
appliance. Guarantee and liability claims arising from damage of this nature are expressly rejected.
5.7
5 MAINTENANCE AND CLEANING
Article no.
Descaling agent 8.9260.4.000.000.1
Subject to modifications
Laufen_Cleanet_Navia_manual_EN.indd 13Laufen_Cleanet_Navia_manual_EN.indd 13 29.10.21 09:4529.10.21 09:45

14
5 MAINTENANCE AND CLEANING
CHANGING THE NOZZLE
The shower arm can be extended to clean or
replace the nozzle.
Press the controller while simultaneously turning it
forwards, to move the shower arm forwards.
Carefully pull off the nozzle.
Clean the nozzle and descale it using
commercially available descaling agent such as cleaning
vinegar.
All seals on the nozzle must always be greased after cleaning.
If you would prefer to replace the nozzle, replacement nozzles
can be purchased from Laufen or specialist dealers.
Carefully attach the cleaned or new nozzle.
Press the controller while simultaneously turning it
backwards, to move the shower arm backwards.
5.8
Article no.
Nozzle and cover ring 8.9260.6.000.000.1
Subject to modifications
Laufen_Cleanet_Navia_manual_EN.indd 14Laufen_Cleanet_Navia_manual_EN.indd 14 29.10.21 09:4529.10.21 09:45

15
5 MAINTENANCE AND CLEANING
CHANGING THE COVER RING
If the cover ring becomes covered in limescale or scratched,
it can be replaced with a new one. Replacement cover rings can
be purchased from Laufen or specialist dealers.
You will require a special tool to replace
the cover ring. The tool is supplied with the new cover ring.
Attach the special tool to the bottom edge of the cover ring.
There is an opening for the tool located there.
Gently push down the tool until the cover ring lifts
out of the snap retainer.
Use your other hand to prevent the cover ring from falling.
Lift out the cover ring completely and remove it.
Insert the top edge of the new cover ring and push
until it clicks into place. Make sure that the tool
opening is pointing downwards.
5.9
Article no.
Nozzle and cover ring 8.9260.6.000.000.1
Subject to modifications
Laufen_Cleanet_Navia_manual_EN.indd 15Laufen_Cleanet_Navia_manual_EN.indd 15 29.10.21 09:4529.10.21 09:45

16
6 TROUBLESHOOTING
Electric shock!
Risk of death!
MESSAGES AND FAULTS
Laufen customer services
If faults occur and cannot be rectified using the information in the operating manual,
please contact Laufen customer services.
www.laufen-cleanet.com
6.1
Never open the appliance to perform repairs yourself.
Contact Laufen customer services.
Messages and faults during operation Possible causes Remedy Section
Does not function Main switch is off. Switch on the main switch located under the appliance on the left. 3.1
General problem with the appliance Switch off the main switch under the appliance, wait
approximately 1 minute then switch it on again.
Power supply is interrupted. Have the power supply checked by a qualified
electrician.
Controller does not work. Controller is faulty. Please contact Laufen customer services.
Water temperature is low. Heater is deactivated. 
and set economy mode to ECO or ON.
General problem with the appliance Switch off the main switch under the appliance,
wait approximately 1 minute then switch it on again.
Jet is weak or no
water emerges.
Intensity setting of shower jet
too low.
Increase the intensity of the shower jet using the Laufen
app or turn the controller forwards during the showering
procedure. Save the setting in the basic profile using the app.
4.1.1
Nozzle is covered in limescale or
blocked.
Initiate a descaling cycle on the shower toilet.
Descale the nozzle or replace it.
5.7
5.8
Rear shower used too frequently in
succession with a high jet intensity.
Please wait at least ten minutes until the rear shower
can be used normally again.
Shower arm does not move back. Shower toilet is faulty. Switch off the main switch under the appliance, wait
approximately 1 minute then switch it on again.
Please contact Laufen customer services
if there is no response.
Lowering system for the seat and cover
unit does not function.
Damper is faulty. Please contact Laufen customer services.
Red LED indicator light is permanently
illuminated.
Carry out descaling. Insert three Laufen descaling agent tabs into the
opening on the right hand side of the bowl.
Red LED indicator light flashes quickly. A fault has occurred on the
shower toilet.
Switch off the main switch under the appliance, wait
approximately 1 minute then switch it on again.
Please contact Laufen customer services if there
is no response.
30. October 2017 | Laufen ∙ Icons app 1
©
Laufen
Gegenüberstellung Icons
Menu
alternativer Iconvorschlag,
da Symbol bei iOS bereits für den
Home Button verwendet wird
POWER
or
or
30. October 2017 | Laufen ∙ Icons app 2
©
Laufen
Gegenüberstellung Icons
Fö hn
Kein Icon mehrKein Icon mehr
Kein Icon mehrKein Icon mehr
Kein Icon mehr
Düse wechseln
Kein Icon mehr
Kein Icon für P2 App
alternativer Iconvorschlag,
da auf native s Gestaltungs-
element zurückgegriffen wird
30. October 2017 | Laufen ∙ Icons app 3
©
Laufen
Gegenüberstellung Icons
BedienungsanleitungTutorialInforma tionen über
das Dusch-WC
RegistrierungTroubleshooting Fernbedienung
Downloads Schritt für Schritt AnleitungGerätestatus auslesen
Verbrauchsmaterial Erklärung der IconsErsatzzeile
FilmeServiceanfrageDirektwahl Laufen
Präsentationsmodus
Dialog und Feedback
Deckel entfernen
Laufen_Cleanet_Navia_manual_EN.indd 16Laufen_Cleanet_Navia_manual_EN.indd 16 29.10.21 09:4529.10.21 09:45

17
7 DISPOSAL AND ENVIRONMENT
The Laufen shower toilet complies with the requirements of EU Directive “Restriction of Hazardous

and chromium VI.
Correct disposal of old appliances
Waste electrical equipment often contains materials that are still usable. At the same time, however,
they also contain many hazardous substances that guarantee the operational reliability and safety of
the equipment. Incorrect handling and disposal of these substances poses a hazard to humans and
the environment.
The symbol on the type plate of your shower toilet indicates that disposal of the appliance with the
household waste is not permitted. Please dispose of used batteries correctly. Do not dispose of
batteries with the household waste.
Please contact the relevant collection point for returning and recycling electrical equipment
in your area.
Store your old appliance in a childproof location until it is transported for disposal.
The plastic parts are marked with internationally standardised symbols to ensure that plastic waste is
separated according to type. As a result, your old appliance can be recycled in an environmentally
compatible manner.
Laufen_Cleanet_Navia_manual_EN.indd 17Laufen_Cleanet_Navia_manual_EN.indd 17 29.10.21 09:4529.10.21 09:45

18
8 TECHNICAL DATA CLEANET NAVIA
Rated voltage 
Mains frequency 
Power consumption during operation (max.) 
Protection level IPX4
Protection class I
Water flow pressure range 
Seat and cover load (max.) 
Storage temperature range 
Operating temperature range 
Number of shower pressure settings 7
Number of shower temperature levels 7
Units

Subject to modifications
The Cleanet Navia shower toilet complies with the requirements of:





Laufen_Cleanet_Navia_manual_EN.indd 18Laufen_Cleanet_Navia_manual_EN.indd 18 29.10.21 09:4529.10.21 09:45

19
9 LEGAL NOTICE
This manual contains important information on the intended use, correct operation and proper
maintenance of the appliance.
Users must understand and comply with the instructions in this operating manual in order to ensure
both hazard-free use of the appliance as well as maximum safety during operation and maintenance.
It is not possible to include every conceivable application and type of misuse in this operating manual.
We would also like to draw attention to the following: The content of this manual neither forms part of
an earlier or existing agreement, commitment or legal relationship, nor does it amend an existing
agreement, commitment or legal relationship. Any obligation on the part of Laufen originates from the
respective warranty conditions, which also include the complete and decisive warranty obligation of
Laufen. The information provided in these operating instructions represents neither an extension nor a
restriction of the claims from the warranty conditions.

permitted after obtaining prior written permission from Laufen.
Laufen_Cleanet_Navia_manual_EN.indd 19Laufen_Cleanet_Navia_manual_EN.indd 19 29.10.21 09:4529.10.21 09:45


10.2021
Laufen_Cleanet_Navia_manual_EN.indd 20Laufen_Cleanet_Navia_manual_EN.indd 20 29.10.21 09:4529.10.21 09:45
