Toto NEOREST 500H User manual

Instruction Manual
NEOREST 500H
■ Thank you for your recent purchase of the product.
Please read the enclosed information to ensure the safe use of your product.
■ Be sure to read this Instruction Manual before using your product and keep it in a
safe place for future reference.
500H SN952M
(MS952CUMG)
M08009_HK_AH(EN)_CS5.indd 1M08009_HK_AH(EN)_CS5.indd 1 7/8/2015 8:13:07 AM7/8/2015 8:13:07 AM

2
What functions are available on your product?
NEOREST
Ref.
Page
500H
SN952M
Basic
Functions
Cleansing
Rear cleansing
●
16, 17
Rear soft cleansing
Front cleansing
Wide front cleansing
Changing
the washing method
Wand position adjustment
●
Water pressure adjustment
Oscillating cleansing
Pulsating cleansing
Personal setting lock
Drying Warm air drying ●
Changing the temperature Temperature adjustment ●24, 25
Sanitary
Functions
Removing odors Deodorizer ●
20, 21
"ewater+" sanitizing Auto wand cleaning ●
Auto bowl cleaning
Convenience
Functions
Flushing
Remote control
bowl unit cleaning ●17
Auto bowl unit cleaning 22, 23
Opening and closing
Opening and closing
the toilet seat
with remote control ●17
Auto open / close (lid) 22, 23
Lighting up Soft light ●
Heating the toilet seat Heated seat ●
-
Saving energy Auto energy saver ●26, 27
Timer energy saver
Maintenance
Bowl unit cleaning
●
33
Cleaning lift lever 34
Removable toilet lid 35
Wand cleaning 32
Product name (Model)
Part No.Functions
Product
name,
Part No.
■Part number system
Bowl Unit
CT952CUMG
Top Unit
SN952M
Combination model number
MS952CUMG
M08009_HK_AH(EN)_CS5.indd 2M08009_HK_AH(EN)_CS5.indd 2 7/8/2015 8:13:08 AM7/8/2015 8:13:08 AM

3
Removing odors inside
the bowl unit
Sanitize the bowl unit
with "ewater+"
Sanitize the wand with
"ewater+"
Cleaning
Support
Sanitary Toilet
Safety Precautions......................4
Operational Precautions .......... 11
Parts Names..............................12
Preparation ................................14
Changing Settings .............. 40
What to Do?.............................. 52
If there is no water due to
a power outage or water failure
...52
If
you cannot operate with
the remote control .....................52
Long Periods of Disuse .............53
Troubleshooting........................ 55
Specifications ........................... 62
Warranty.................................... 63
Basic Operations................. 16
Automatic Functions
(Cleaning Features)................. 20
DEODORIZER / AUTO WAND
CLEANING / AUTO BOWL CLEANING /
BOWL LIGHT / CLEAN INDICATOR
Automatic Functions
(Convenience Features) ......... 22
AUTO FLUSH / AUTO OPEN/CLOSE /
SOFT LIGHT
Temperature Adjustment......... 24
Energy Saver Features ........... 26
Power Plug ............................. 30
Top Unit ..................................... 31
Wand ......................................... 32
Wand cleaning
Bowl Unit................................... 33
Bowl Unit cleaning
Gap between the Top Unit and
Bowl Unit
.................................... 34
Gap between the Top Unit and
the Toilet Lid
............................... 35
Water Filter Drain Valve .......... 36
Deodorizing Filter..................... 37
Water Filter ............................... 38
Auto bowl cleaning
Auto wand cleaning
As you
approach
As
you sit
As you
stand up
Auto bowl cleaning
Deodorizer
Table of Contents
The self-cleaning functions operate
automatically.
(See pages 20 and 21 for details.)
ReferenceMaintenanceOperation
Introduction
M08009_HK_AH(EN)_CS5.indd 3M08009_HK_AH(EN)_CS5.indd 3 7/8/2015 8:13:08 AM7/8/2015 8:13:08 AM

4
These precautions are important for safe usage. Be sure to follow them and use the product
correctly.
Symbols and Meanings
WARNING May result in death or serious injury.
CAUTION May result in injury or property damage.
The following symbols are used to indicate important safety instructions for the use of the product.
Symbol Meaning
This symbol indicates a prohibited use of the product.
This symbol is used to indicate a required step in the use of this product.
 This product is classified as Class 1 Equipment and must be grounded.
 Install this equipment where the electrical outlet is accessible.
 This appliance is not intended for use by persons (including children) with reduced physical, sensory or
mental capabilities, or lack of experience and knowledge, unless they have been given supervision or
instruction concerning use of the appliance by a person responsible for their safety.
Children should be supervised to ensure that they do not play with the appliance.
 Use the new hose set included with this equipment. Do not reuse an old hose set.
WARNING
Do not plug or unplug the power plug with wet hands.
 Doing so may cause electrical shock.
Do not get any water or cleaning solution on the top unit or power plug.
 Doing so may cause fire, electrical shock, heat or short circuit.
 Doing so may cause the product to crack resulting in injury or water damage.
Never disassemble, repair or alter.
 Doing so may cause fire, electrical shock, heat or short circuit.
Do not install the product on moving vehicles such as wheeled vehicles or boats.
 Doing so may cause fire, electric shock, short circuit or malfunction.
 The toilet seat, toilet lid, top unit or other parts may come loose and fall off, resulting in injury.
Safety Precautions
M08009_HK_AH(EN)_CS5.indd 4M08009_HK_AH(EN)_CS5.indd 4 7/8/2015 8:13:08 AM7/8/2015 8:13:08 AM

5
WARNING
Do not use the NEOREST if a malfunction occurs.
Always unplug the plug from the outlet.
 Close the water shutoff valve to stop water supply.
Possible malfunctions:
 Water is leaking from a pipe or the top unit.
 The product is cracked or broken.
 The product makes a strange noise or emits a strange odor.
 The product emits smoke.
 The product is abnormally hot.
 The bowl unit is clogged.
 The toilet seat cushion is out of place.
 Continued use after malfunction could cause a fire, electric shock, heat, short circuit, injury or
water damage.
Only use tap water or potable well water (underground water).
Do not use seawater.
 Doing so may cause irritation to the skin and malfunction.
Do not touch the power plug during thunderstorms.
 Doing so may cause electrical shock.
Do not allow the water supply hose to touch the power plug or outlet.
 Doing so may cause condensation resulting in a fire, electrical shock, heat or a short.
Do not do anything that may damage the power cord, power plug.
Do not strike, yank, twist, excessively bend, damage, alter, or heat the electrical cords. Also, do not
place anything heavy on, bind or pinch the electrical cords.
 Using a damaged electrical cord may result in a fire, electrical shock, heat or short.
Do not use a loose or faulty electrical outlet.
 Doing so may cause fire or short circuit.
Do no use any outlet or wiring equipment beyond its specified rating.
 Plugging too many plugs into the same outlet, for example using outlet splitters, can cause fire
due to heat.
Do not use any power supply other than the one specified.
AC 120V, 60Hz
 Doing so may cause fire or excessive heat.
Do not stick a finger or anything else into the warm air outlet.
Do not place anything on the warm air outlet or drape clothes over it.
 Doing so may cause burns, electrical shock or malfunction.
Keep cigarettes and other open flames away from the product.
 Failure to do so may cause fire.
Introduction
M08009_HK_AH(EN)_CS5.indd 5M08009_HK_AH(EN)_CS5.indd 5 7/8/2015 8:13:08 AM7/8/2015 8:13:08 AM

6
WARNING
Beware of irritation or burn
 Improper use of the toilet seat may cause irritation or burn.
When sitting for a long time on the toilet seat, switch the toilet seat temperature adjustment to "OFF".
When any of the following persons use a heated seat or warm air drying, someone should switch
the toilet seat temperature adjustment to "OFF" and switch the drying air temperature to "Low".

Young children, the aged and other users unable to set the temperature appropriately themselves
 The ill, physically disabled and others who do not have freedom of movement.
 Those using any medicines that cause drowsiness (sleeping or cold medicine), those who have
been drinking heavily, anyone severely fatigued and anyone else liable to fall asleep.
This is an electrical product. Do not install it anywhere water is likely to get on
the product or anywhere with humidity high enough that water is likely to form
on the surface of this product. When using the product in a bathroom, install
a fan or ventilation port and ensure good air flow through the bathroom.
 Failure to do so may cause fire or electrical shock.
Always connect the NEOREST to the cold water supply.
 Connecting to hot water supply may result in burns and equipment damage.
Make sure that a properly grounded (3 prong) outlet has been installed.
 Failure to install a grounded outlet could cause electrical shock in the event of a malfunction or
short circuit.
Insert the power plug securely into the outlet.
 Failure to do so may cause fire, heat or short circuit.
To unplug, hold the power plug, not the power cord.
Do not unplug by pulling the power cord.
 Pulling on the power cord may cause damage and result in fire or heat.
If the electric cord is damaged, avoid danger by having the manufacturer’s
repair department or equivalent specialist replace it.
Always disconnect the power plug from the outlet before cleaning or
maintenance or inspection.
 Failure to do so may cause electrical shock or malfunction.
Periodically remove dust and dirt from the electrical plug and make sure it is
securely plugged into the wall outlet.
 Failure to do so may cause fire, heat or short circuit.
Pull the plug out from the outlet and wipe clean with a dry cloth.
Safety Precautions (Continued)
M08009_HK_AH(EN)_CS5.indd 6M08009_HK_AH(EN)_CS5.indd 6 7/8/2015 8:13:08 AM7/8/2015 8:13:08 AM

7
WARNING
Preliminary studies in females suggest that overuse of continuous spraying
can increase the possibility of vaginal mucosa drying and potential
reduction in desirable microbial organisms.
Although these studies have not been validated, please consult your
healthcare provider for concerns regarding whether these circumstances
may apply to you.
More importantly, if you are an individual suffering from any immune
deficiency as a result of disease, chemotherapy, or other medical condition
compromising the immune system you should consult your healthcare
provider before use of this product.
CAUTION
Do not use the product if the top unit is unstable.
 Doing so may cause the top unit to come loose and fall, resulting in injury.
If the product is damaged, do not touch the damaged section.
 Doing so may cause electrical shock or injury. Replace it immediately.
Do not apply strong force, mechanical shock, step on or stand on the toilet
seat, toilet lid or top unit. Also do not place any heavy object on the toilet
seat, toilet lid or top unit.
 Doing so may cause cracking or cause the top unit to come loose and fall, resulting in injury.
 Doing so may damage the product and cause injury or water damage.
Do not lift up this product by the toilet seat or lid.
Do not raise the toilet seat or lid while objects are resting on top of the toilet.
 Doing so may cause the top unit to come loose and fall resulting in injury.
When cleaning or maintaining the plastic parts (top unit etc.) or the water
supply hose, use a kitchen cleaner diluted with water. Do not use any of the
following.
Toilet cleaner, household cleaner, benzene, paint thinner, powdered cleanser or nylon scrubbing pads.
 These items may damage or crack the plastic and cause injury or malfunction.
 These items could damage the water supply hose and cause a water leak.
To prevent a sudden water leak, do not remove the water filter drain valve
when the shutoff valve is open.
 Doing so will cause water to spurt out.
(Refer to Page 36 for instructions on cleaning the water filter drain valve.)
Do not fold or crush the water supply hose; do not damage by cutting with a sharp object.
 Doing so may cause water leaks.
Introduction
M08009_HK_AH(EN)_CS5.indd 7M08009_HK_AH(EN)_CS5.indd 7 7/8/2015 8:13:08 AM7/8/2015 8:13:08 AM

8
Safety Precautions (Continued)
CAUTION
Do not pour hot water into the toilet.
 Doing so may result in damage to the toilet, injury or water damage.
Do not flush anything other than bodily waste and toilet paper. Also, do not
flush too much toilet paper.
 Doing so may clog the toilet, causing waste water overflow and water damage.
When operating the lift lever for cleaning, do not insert your fingers into the
gap between the top unit and the bowl unit.
Do not use the product while the top unit is lifted up.
If a water leak should occur, always close the shutoff valve.
When the ambient temperature is likely to drop to 0°C or lower, prevent
damage to the pipes and hoses due to freezing.
 Frozen water pipes could cause the top unit and the pipes to break, resulting in a water leak.

Regulate the room temperature to prevent the pipes and hoses from freezing during cold months.
When not using the NEOREST for a long time, close the shutoff valve, drain
the water from the top unit and water supply hose, and pull the electrical
plug from the outlet.
 When using the product again, allow the product to refill with water first.
Otherwise, the water in the tank might become contaminated and cause skin inflammation or
other problems. (Refer to Page 54 for instructions on replenishing the water.)
 Leaving the power on may cause fire or heat.
When installing the water filter drain valve, make sure that it is securely
tightened in its proper position.
 Failure to securely tighten it may cause a water leaks.
If the bowl unit is clogged, disconnect the power plug and remove the clog.
 If the auto flush were allowed to function, it would make the wastewater in the bowl unit overflow
and may result in water damage.

Use commercially available tools that are made for unclogging the bowl unit to remove the clogging.
Always flush, even after just urinating.
 Failure to do so may cause inadequate flushing or clogging of the bowl unit, resulting in waste
water overflow and water damage.
Wipe condensation on the bowl unit, tank, water supply pipe and shutoff
valve with a dry cloth.
 Condensation may cause staining and corrosion of the floor.
 Ventilate the restroom to prevent condensation.
Wipe any urine, condensation, cleaner, water, etc. that has gotten on the
floor with a well-wrung mop or cloth.
 Failure to do so may cause staining and corrosion of the floor.
M08009_HK_AH(EN)_CS5.indd 8M08009_HK_AH(EN)_CS5.indd 8 7/8/2015 8:13:09 AM7/8/2015 8:13:09 AM

9
DANGER To reduce the risk of electrocution:
1. Do not use while bathing.
2. Do not place or store the product where it can fall or be pulled into a tub or sink.
3. Do not place in or drop into water or other liquid.
4. Do not reach for the product when it has fallen into water. Unplug it immediately
WARNING
To reduce the risk of burns, electrocution, fire or injury to persons:
1. Close supervision is necessary when this product is used by, on, or near children or
invalids.
2. Use this product only for its intended use as described in this manual. Do not use
attachments not recommended by the manufacturer.
3. Never operate this product if it has a damaged cord or plug, is not working properly, has
been dropped or damaged, or has been dropped in water. Return the product to a service
center for examination and repair.
4. Keep the cord away from heated surfaces.
5. Never block the air openings on the product or place it on a soft surface, such as a bed
or couch, where the air openings may be blocked. Keep the air openings free of lint, hair,
and other similar items.
6. Never use while sleepy or drowsy.
7. Never drop or insert any object into any opening or hose.
8. Do not use outdoors. Do not operate where aerosol (spray) products are being used or
where oxygen is being administered.
9. Connect this product to a properly grounded outlet only.
See "Grounding Instructions" in Page 10.
10. The tank should be filled with water only.
Introduction
M08009_HK_AH(EN)_CS5.indd 9M08009_HK_AH(EN)_CS5.indd 9 7/8/2015 8:13:09 AM7/8/2015 8:13:09 AM

10
Safety Precautions (Continued)
Grounding Instructions
This product should be grounded. In the event of an electrical short circuit, grounding reduces
the risk of electric shock by providing an escape wire for the electrical current.
The plug must be plugged into an outlet that is properly installed and grounded.
DANGER - Improper use of the grounding plug can result in a risk of electric shock.
If repair or replacement of the cord or plug is necessary, do not connect the grounding wire to
either flat-head terminal.
Check with a qualified electrician or serviceman if the grounding wire instructions are not
completely understood, or if in doubt as to whether the product is properly grounded.
This product is factory equipped with a specific electric cord and plug to permit connection to
a proper electric circuit. Make sure that the product is connected to an outlet having the same
configuration as the plug.
No adapter should be used with this product. Do not modify the plug provided - if it will not fit in
the outlet, have the proper outlet installed by a qualified electrician.
If the product must be reconnected for use on a different type of electric circuit, the reconnection
should be made by qualified service personnel.
If it is necessary to use an extension cord, use only a three wire extension cord that has a three
blade grounding plug, and a three-slot receptacle outlet that will accept the plug on the product.
Replace or repair a damaged cord.
Grounding pin
Save these instructions.
M08009_HK_AH(EN)_CS5.indd 10M08009_HK_AH(EN)_CS5.indd 10 7/8/2015 8:13:09 AM7/8/2015 8:13:09 AM
