E2D400 Series Panel PC
Page I
MODEL:
User Manual
Touch Panel PC
E2D400
E2D400 / 00 01 / 2013

Page II
E2D400 Series Panel PC
Copyright
COPYRIGHT NOTICE
The information in this document is subject to change without prior notice in order to
improve reliability, design and function and does not represent a commitment on the part
of the manufacturer.
In no event will the manufacturer be liable for direct, indirect, special, incidental, or
consequential damages arising out of the use or inability to use the product or
documentation, even if advised of the possibility of such damages.
This document contains proprietary information protected by copyright. All rights are
reserved. No part of this manual may be reproduced by any mechanical, electronic, or
other means in any form without prior written permission of the manufacturer.
TRADEMARKS
All registered trademarks and product names mentioned herein are used for identification
purposes only and may be trademarks and/or registered trademarks of their respective
owners.

E2D400 Series Panel PC
Page III
Standards Compliance
VCCI – CLASS B FOR E2D400
Translation:
This a Class B product based on the standard of the VCCI Council. If this is used near a radio or
television receiver in a domestic environment, it may cause radio interference. Install and use the
equipment according to the instruction manual.

Page IV
E2D400 Series Panel PC
WARNING:
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference
to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following measures:
--Reorient or relocate the receiving antenna.
--Increase the separation between the equipment and receiver.
--Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
--Consult the dealer or an experienced radio/TV technician for help.
You are cautioned that any change or modifications to the equipment not expressly
approve by the party responsible for compliance could void your authority to operate
such equipment.

E2D400 Series Panel PC
Page V
Packing List
NOTE:
If any of the components listed in the checklist below are missing,
please do not proceed with the installation. Contact the ifm electronic
GmbH reseller or vendor you purchased the E2D400 series from or
contact an ifm electronic GmbH sales representative directly.
The items listed below should all be included in the E2D400 series package.
1 x ifm electronic E2D400 series flat panel PC
1 x Power adapter
1 x Power cord
1 x Screw kit
1 x SATA and power cable
1 x User manual and driver CD
1 x Touch pen
Images of the above items are shown in Chapter 3 on page 22.

Page VI
E2D400 Series Panel PC
Table of Contents
1 Introduction ......................................................................................................1
E2D400 Series Flat Panel PC Overview ...........................................................2
1.1.1 Features................................................................................................2
1.1.2 Applications...........................................................................................3
1.2 External Overview .......................................................................................3
1.2.1 General Description ..............................................................................3
1.2.2 Front Panel ...........................................................................................4
1.2.3 Rear Panel............................................................................................4
1.2.4 I/O Interface Panel ................................................................................5
1.2.5 Top Panel and Side Panels...................................................................6
1.3 Internal Overview ........................................................................................6
1.4 System Specifications .................................................................................7
2 Detailed Specifications....................................................................................9
2.1 Dimensions................................................................................................10
2.2 Intel® Atom™ Processor ........................................................................... 11
2.3 Motherboard Components......................................................................... 11
2.3.1 Memory Support ................................................................................. 11
2.3.2 Storage Capacity.................................................................................12
2.4 External Peripheral Interface Connectors..................................................12
2.4.1 Serial Port Connectors........................................................................13
2.4.2 LAN Connectivity ................................................................................13
2.4.3 External USB Connectors ...................................................................14
2.5 E2D400 Front Side....................................................................................14
2.5.1 Monitor................................................................................................14
2.5.2 Touch-Screen Module .........................................................................15
2.6 Audio .........................................................................................................15
2.6.1 AC’97 Audio Codec Controller ............................................................15
2.6.2 Stereo Speakers .................................................................................16
2.7 System Power ...........................................................................................16
2.7.1 Power Mode........................................................................................16

E2D400 Series Panel PC
Page VII
2.7.2 Power Adapter ....................................................................................17
2.7.3 Power Connector ................................................................................17
2.8 Wireless Connections................................................................................18
2.8.1 USB Bluetooth Module........................................................................18
2.8.2 Wireless Ethernet ...............................................................................18
3 Unpacking.......................................................................................................20
3.1 Unpacking .................................................................................................21
3.1.1 Packing List ........................................................................................22
4 Installation ......................................................................................................24
4.1 Anti-static Precautions ............................................................................... 25
4.2 Installation Precautions .............................................................................25
4.3 Preinstalled Components ..........................................................................26
4.4 Installation and Configuration Steps ..........................................................26
4.5 Removing the Back Cover.........................................................................27
4.6 CF Card Installation...................................................................................28
4.7 HDD Installation ........................................................................................29
4.8 AT/ATX Mode Selection.............................................................................30
4.8.1 AT Power Mode...................................................................................30
4.8.2 ATX Power Mode ................................................................................31
4.9 Jumper Settings ........................................................................................31
4.9.1 Access the Jumpers............................................................................32
4.9.2 Preconfigured Jumpers.......................................................................32
4.9.3 Clear CMOS Jumper...........................................................................33
4.9.4 COM Port Pin 9 Select........................................................................34
4.9.5 COM3 RX Function Select Jumper .....................................................36
4.9.6 COM3 TX Function Select Jumper .....................................................37
4.9.7 COM3 RS-232/422/485 Serial Port Select Jumper.............................38
4.10 Mounting the System...............................................................................39
4.10.1 Wall Mounting ...................................................................................40
4.10.2 Panel Mounting.................................................................................43
4.10.3 Arm Mounting....................................................................................44
4.10.4 Cabinet and Rack Installation ...........................................................45

Page VIII
E2D400 Series Panel PC
4.11 Bottom Panel Connectors........................................................................48
4.11.1 LAN Connection ................................................................................48
4.11.2 Serial Device Connection..................................................................49
4.11.3 USB Device Connection....................................................................50
5 System Maintenance .....................................................................................51
5.1 System Maintenance Introduction .............................................................52
5.2 Anti-static Precautions ............................................................................... 52
5.3 Turn off the Power .....................................................................................53
5.4 Opening the System..................................................................................53
5.4.1 Removing the Back Cover ..................................................................53
5.4.2 E2D400 Series Internal Aluminum Cover Removal ............................54
5.5 Replacing Components .............................................................................55
5.5.1 Memory Module Replacement ............................................................55
5.5.2 CF Card Replacement ........................................................................56
5.6 Reinstalling the Covers..............................................................................57
6 AMI BIOS Setup..............................................................................................58
6.1 Introduction................................................................................................59
6.1.1 Starting Setup .....................................................................................59
6.1.2 Using Setup ........................................................................................59
6.1.3 Getting Help........................................................................................60
6.1.4 Unable to Reboot After Configuration Changes ..................................60
6.1.5 BIOS Menu Bar...................................................................................60
6.2 Main ..........................................................................................................61
6.3 Advanced...................................................................................................62
6.3.1 CPU Configuration ..............................................................................63
6.3.2 IDE Configuration................................................................................64
6.3.3 Super IO Configuration .......................................................................72
6.3.4 Hardware Health Configuration...........................................................74
6.3.5 Power Configuration ...........................................................................78
6.3.6 APM Configuration .............................................................................. 79
6.3.7 Remote Configuration .........................................................................82
6.3.8 USB Configuration ..............................................................................85

E2D400 Series Panel PC
Page IX
6.4 PCI/PnP.....................................................................................................87
6.5 Boot...........................................................................................................89
6.5.1 Boot Settings Configuration ................................................................90
6.6 Security .....................................................................................................92
6.7 Chipset ......................................................................................................93
6.7.1 North Bridge Chipset Configuration ....................................................94
6.7.2 SouthBridge Configuration..................................................................97
6.8 Exit ............................................................................................................98
7 Software Drivers ..........................................................................................101
7.1 Available Software Drivers.......................................................................102
7.2 Starting the Driver Program .....................................................................102
7.3 Chipset Driver Installation........................................................................103
7.4 VGA Driver Installation ............................................................................108
7.5 Audio Driver Installation........................................................................... 113
7.6 LAN Driver Installation............................................................................. 116
7.7 Touch Screen Driver ................................................................................ 119
7.8 Bluetooth Driver.......................................................................................122
7.9 Wireless Driver ........................................................................................127

E2D400 Series Panel PC
Page 1
1 Introduction
Chapter
1

Page 2
E2D400 Series Panel PC
E2D400 Series Flat Panel PC Overview
Figure 1-1: E2D400 Flat Panel PC
The E2D400 series is Intel® Atom™ powered flat panel PCs with a rich variety of
functions and peripherals. The E2D400 model is designed for easy and simplified
integration in to kiosk and point-of-sales (POS) applications.
An Intel® 945GSE graphics memory controller hub (GMCH) coupled with an Intel®
ICH7-M input/output controller hub ensures optimal memory, graphics, and peripheral I/O
support. The system comes with 1.0 GB of preinstalled DDR2 SDRAM and supports a
maximum of 2.0 GB of DDR2 SDRAM ensuring smooth data throughputs with reduced
bottlenecks and fast system access.
Two serial ports and two external USB 2.0 ports ensure simplified connectivity to a variety
of external peripheral devices. Wi-Fi capabilities and an RJ-45 Ethernet connector ensure
smooth connection of the system to an external LAN.
1.1.1 Features
Intel® Atom™ processor
Intel® 945GSE chipset

E2D400 Series Panel PC
Page 3
1GB 533 MHz DDR2 SDRAM preinstalled
802.11 b/g wireless module
Four USB 2.0 ports
Watchdog timer that triggers a system reset if the system hangs for some
reason
IP 64 compliant front panel
AT or ATX power mode
Touch screen
Bluetooth
RoHS compliance
Panel properties:
Model Size Brightness Resolution
E2D400 12.1” 500 cd/m21024 x 768
Table 1-1: Panel properties
1.1.2 Applications
The E2D400 panel PCs are elegant yet sophisticated systems that are easily implemented
in commercial environments, industrial environments and corporate environments.
1.2 External Overview
1.2.1 General Description
The stylish E2D400 panel PC comprises of a screen, rear panel, top panel, bottom panel
and two side panels (left and right). An ABS/PC plastic front frame surrounds the front
screen. The rear panel provides screw holes for a wall-mounting bracket compliant with
VESA FDMI standard. An I/O interface panel on the bottom panel of the E2D400 provides
access to external interface connectors that include LAN, USB 2.0, serial port, reset
button, power connector and power switch.

Page 4
E2D400 Series Panel PC
1.2.2 Front Panel
The front side of the E2D400 series is a flat panel TFT LCD screen with LED backlight
surrounded by an ABS/PC plastic frame. The top of the front panel has a power LED.
Figure 1-2: E2D400 Front View
1.2.3 Rear Panel
The rear panel provides access to retention screw holes that support the wall mounting.
Refer to Figure 1-3.

E2D400 Series Panel PC
Page 5
Figure 1-3: E2D400 Rear View
1.2.4 I/O Interface Panel
The I/O interface panel located on the bottom of the E2D400 has the following I/O
interface connectors:
1 x Audio connector
1 x 12 V DC In connector
1 x External SATA connector
1 x RS-232 connector
1 x RS-232/422/485 connector
2 x LAN connectors
4 x USB 2.0 connectors
1 x Power switch
1 x Reset button
The external I/O interface connector panel is shown in Figure 1-4.
Figure 1-4: E2D400 I/O Interface Connector Panel

Page 6
E2D400 Series Panel PC
1.2.5 Top Panel and Side Panels
The top panel and side panels of the E2D400 series provides access to slots that support
panel mount and rack mount (Figure 1-5).
Figure 1-5: E2D400 Top View
Figure 1-6: Side View
1.3 Internal Overview
The E2D400 has the following components installed internally:
1 x Motherboard
1 x 1.0 GB 533 MHz DDR2 SDRAM SO-DIMM
1 x Wireless module
1 x Bluetooth module

E2D400 Series Panel PC
Page 7
1.4 System Specifications
The technical specifications for the E2D400 series systems are listed in
Table 1-2.
Specification E2D400
LCD Size 12.1”
Max. Resolution 1024 x 768
Contrast Ratio 700:1
Brightness (cd/m2) 500
LCD Color 262K
Pixel Pitch (H x V) (mm) 0.3057 x 0.3057
Viewing Angle (H-V) 160 / 160
Backlight LED backlight
SBC Model AFLMB-945GSE
CPU 1.6 GHz Intel® Atom™ N270 processor
GMCH Intel® 945GSE
Memory One 1.0 GB 533 MHz DDR2 SDRAM SO-DIMM pre-installed
(Supports up to 2 GB 533/400 MHz DDR2 SDRAM)
SSD slot 4 GByte CompactFlash Type II preinstalled
Watchdog Timer Software Programmable supports 1 sec. ~ 255 sec. system reset
Audio AMP 1.5 W + AMP 1.5 W (built-in stereo speakers)
1 x PCIe mini card (wireless LAN 802.11 b/g module)Expansion
1 x Bluetooth module (USB interface, Bluetooth v 2.0)
HDD Drive Bay 1 x 2.5” SATA HDD bay or HSDPA module
Construction Material ABS + PC plastic front frame
Mounting Panel
Wall
Arm (VESA 75 mm x 75 mm or 100 mm x 100 mm)
Front Panel Color Gray 7539U
Dimensions (W x H x D) (mm) 304 x 246 x 49.5
Operation Temperature -10ºC ~ 50ºC with CF card

Page 8
E2D400 Series Panel PC
Specification E2D400
0ºC ~ 40ºC with HDD
Storage Temperature -20ºC ~ 60ºC
Net weight 1.8 kg
IP level (front panel) IP 64
EMC CE, FCC and CCC
Safety CB
Touch Screen Resistive Type 5-wire
(touch controller is on board)
50 W
Input: 90 VAC ~ 264 VAC @ 50 Hz / 60 Hz
Power Adapter
Output: 12 V DC
Power Consumption 32 W
1 x 12 V DC input jack
1 x Audio connector
1 x RS-232 COM port connectors
1 x RS-232/422/485 COM port connector
2 x RJ-45 for LAN
2 x USB 2.0 ports
1 x Power switch
I/O Ports and Switches
1 x Reset button
Table 1-2: E2D400 Series System Specifications

E2D400 Series Panel PC
Page 9
2 Detailed Specifications
Chapter
2

Page 10
E2D400 Series Panel PC
2.1 Dimensions
The following section provides detailed schematics and information on the dimensions of
the E2D400 series.
Figure 2-1: E2D400 Top and Bottom Panel Dimensions (mm)
