IHP MI1000 Operating instructions
Infrared Heater Panels
Medium Intensity Heater
Installation / Owners Manual
WARNING Read all
instructions
before using this
heater.
Read and understand all installation and maintenance instruc-
tions thoroughly before installing or servicing this equipment.
Improper installation, operation, adjustment, alteration, ser-
vice or maintenance can result in the risk of re and electrical
shock, and may cause property damage, injury or death.
SAFETY ALERT:
These instructions are applicable to the model stated on
the front cover of this manual only, and must not be used
with any other make or model.
These instructions are intended to apply in the United
Kingdom only, and should be followed along with any
other statutory obligations.
Do not attempt to open, the heater contains no service-
able parts. Attempting to do so will permanently damage
the heater and void all warranties.
Do not operate this heater unless it is properly installed.
Do not get wet or install where it may fall into water e.g.
bath, basin
Do not cover.
This accessory must be tted by a Competent person, and
installation must comply with the guidance provided in
the current editions of BS7671 (IEE Wiring Regulations)
and Part `P' of the Building Regulations. Failure to com-
ply with the requirements of these publications could lead
to prosecution.
Always isolate the AC Mains supply and allow the heater
to cool before handling or moving.
Please leave these instructions with the end user where
they should be kept in a safe place for future reference.
Product Compliance
This product complies with the essential requirements of the following EC Directives:
Electro-Magnetic Compatibility directive 2004/108/EC
Low Voltage Directive 2006/95/EEC
EC Marking directive 93/68/EEC
Commission Regulation (EU) 2015/1188 Lot 20 and complies with Article 1
Section (g) by denition under Article 2 Section (16) applicable only to indoor
space heating to reach and maintain a certain thermal comfort for human
beings
General Description
In contrast to convection heating, the Infrared Heater Panels Infrared Radiant
Heater heats objects and people rather than the air. As such it is highly eec-
tive for the heating of open spaces and even outdoors providing fresh, clean heat
akin to sunshine. Problems associated with convection heating such as condensation,
temperature laying and dry, stuy air are all but eliminated.
The HIxxxx is a medium intensity heater suitable for ceiling and wall mounting
between 3 and 10 metres. Key features of the heater include:
A highly thermally conductive aluminium emitting plate with a high emissivity
coating to ensure maximum radiant eciency
High temperature metal core, ceramic sheath heating elements
Panel is supplied with an electrical fused plug (with the exception of the
HI3200)
Angle mounting brackets are supplied
The heaters are intended to be controlled by a remote wall mounted thermostat.
The thermostat should be located in the same room on a side wall. Ideally it should
also be above 1.5m above the oor, but not directly under a heater.
Calculation of Power Requirements
To determine the number of panels required for a given area, one must divide power
rating of the panels into the total power requirements of the area to be heated.
For large open space, fully heated, 100 watts per square metre is recommended. For
spot / zone heating 150 watts is recommended. For fully insulated, closed buildings
50 watts per square metre would be sucient.
Additional wattage maybe required when heating is used intermittently or when fast
warm ups times are required. Lastly remember that in a typical installation, the
panels are thermostatically controlled and so do not run continuously.
First Time Use
When using the panels for the rst time or after a long time period of non use, one
must allow additional time (sometimes up to several days) to heat up the fabric of
the building. Once the core of the building is warm and dry, future heating loads
will be greatly reduced.
Installation
The IHP range of infrared heater panels are a component part of a designed heating
system. To comply with Commission Regulation (EU) 2015/1188 Lot 20, this prod-
uct must be installed and controlled by an external timed thermostat control system.
The supplied product ex must be wired to this control system in accordance with
the manufacturer's instructions to achieve the minimium ecodesign requirement.
Considerations should be given to the addition of open window sensing, occupancy
sensing and out of building heating control systems such as a mobile phone applica-
tion or other device to further increase energy savings. There are many sophisticated
control systems available. Please contact us for assistance if required.
Step 1:
Unpack heater, checking contents against the packing list. Remove
packing material from both ends of heater as per Fig. 3.
Table 1: Packing List
Item Description Qty
1. Heater 1 pc
2. Adjusting Brackets 4 pc
3. Sliding Bracket 1 pc
4. Fastener 1 set
5. Owner's Manual 1 copy
Figure 1: Remove Packing from both ends of heater
Step 2:
Plan your installation, ensuring that the heater is at a height of at least
3m and is 200mm from walls. Minimium bracket spacing should be
determined from Figure 2.
Figure 2: Heater and Bracket Positioning
Step 3:
Fix the ceiling / wall bracket to the ceiling / wall according to the
bracket spacing determined.
Figure 3: Wall / Ceiling Bracket
Step 4:
Assemble heater brackets and slide onto heater as illustrated. Do not
tighten wing nuts on heater.
Figure 4: Heater Brackets
Step 5:
Fix heater to ceiling / wall brackets as illustrated. This will typically
require 2 people for the larger heaters. Lastly tighten the wing nuts.
Figure 5: Fix to wall or ceiling
Specications
Specication MI1000 MI1800 MI2400 MI3200
Power@230V 1000W 1800W 2400W 3200W
Dimensions (mm) 600x189x67 1000x189x67 1500x189x67 2000x189x67
Package Size (mm) 680x250x145 1080x250x145 1580x250x145 2080x250x145
Net Weight 3.7kg 6.2kg 8.8kg 11.6kg
Voltage 220-240VAC
Rated Current 4.3A 7.8A 10.4A 13.9A
Fuse Rating 5A 13A 13A N/A*
Operating Temp. 250 - 380
°
C
Emitting Plate High emissivity coated Aluminium
Heating Element Nichrome core embedded in ceramic substrate
IP Rating IP54
* To be installed by qualied personnel only. Does not come with plug.
Product Warranty
Infrared Heater Panels grants a 60 month manufacturer's guarantee beginning with
the date of the invoice or shipping note. Within this period, we will regulate all
faults caused by material or production by repair or replacement of the defect
parts. The guarantee will only be accepted when the heating panel was properly
treated. Additional claims are explicitly excluded! The guarantee will only include
the repair/replacement of the radiant heating panel. We will take no responsibility
on scratches on face or back after the start of operation. We will not assume
liability for damages caused by kicks, wrong handling, humidity or by external
treatment.
Customer Details Product Details
Customer Name: Product:
Address: Serial No:
Install Date:
Email:
IMPORTANT: Please register your purchase at:
http://www.infraredheaterpanels.co.uk/page/warranty-registration
Manufacturer's
Details: Quantum Partners Ltd
(trading under the name Infrared Heater Panels or IHP)
Address: 406 Licheld Road,
Burton-On-Trent
Staordshire
United Kingdom
DE13 8EH
Email: info@InfraredHeaterPanels.co.uk
Website: www.InfraredHeaterPanels.co.uk
Distributor's Details:
Address:
Email:
Website:
