Ika Multidrive basic User manual

IKA MultiDrive basic

3

ENGLISH

4 5

Installation�� 14

EU Declaration of conformity �� 6

Explication of warning symbols �� 6

!

Safety instructions�� 7

Unpacking �� 12

Operation �� 16

Error codes �� 21

Intended use�� 9

Technical Data �� 25

Interfaces and outputs �� 23

Warranty �� 26

Maintenance and cleaning �� 22

Accessories �� 24

Operator panel and display �� 13

Useful information �� 10

Fig. 1

!

6 7

Safety instructions

/// General information

›

Read the operating instructions completely before starting up and follow the safety

instructions.

› Keep the operating instructions in a place where it can be accessed by everyone�

› Ensure that only trained staff work with the device�

› Follow the safety instructions, guidelines, occupational health and safety and accident

prevention regulations�

›

The device must only be used in a technically perfect condition�

Caution!

›Wear your personal protective equipment in accordance with the hazard category of the

medium to be processed, there is a risk of:

- splashing of liquids

- body parts, hair, clothing and jewellery getting caught

- sharp blade edges�

!Notice!

› Pay attention to the marked sites in Fig� 1�

/// Device setup

Caution!

› The power switch of the device must be accessed immediately, directly and without risk at

any time� If access to the power switch cannot be ensured, an additional emergency stop

switch that can be easily accessed must be installed in the work area�

!Notice!

› Set up the device in a spacious area on an even, stable, clean, non-slip, dry and ﬁreproof surface�

› Make sure that the ventilation slits are not blocked at back of the device�

› Ensure that the vessel and the cover is ﬁrmly attached to the drive unit prior to operating the

device�

› The drive unit cannot be operated without a closed vessel�

EU Declaration of conformity

We declare under our sole responsibility that this product corresponds to the directives 2014/35/EU,

2006/42/EC,

2014/30/EU and 2011/65EU

and conforms with the following standards or normative

documents: EN 61010-1, EN 61010-2-051, EN ISO 12100, EN 61326-1 and EN 60529�

A copy of the complete EU Declaration of conformity can be requested at sales@ika�com�

Source language: German

Explication of warning symbols

/// Warning symbols

Indicates an (extremely) hazardous situation, which, if not avoided, will

result in death, serious injury�

Danger!

Indicates a hazardous situation, which, if not avoided,

can result in

death, serious injury�

Warning!

Indicates a potentially hazardous situation, which, if not avoided, can

result in injury�

Caution!

Indicates practices which, if not avoided, can result in equipment damage�

Notice!

/// General Symbols

Position number

A–––

Correct/Result

Shows the correct execution or the result of an action step�

Wrong

Shows the incorrect execution of an action step�

Note

Displays action steps that require particular attention to detail�

/// Working with the device

Danger!

› Do not use the device in explosive atmospheres, it is not EX-protected�

› With substances capable of forming an explosive mixture, appropriate safety measures must

be applied, e�g� working under a fume hood�

› To avoid body injury and property damage, observe the relevant safety and accident preven-

tion measures when processing hazardous materials�

Warning!

› Only process samples that will not react dangerously to the extra energy produced through

processing� This also applies to any extra energy produced in other ways, e�g� through light

irradiation�

!

8 9

Intended use

///

Use

The MultiDrive basic device is a batch mill / mixer that can be operated with different vessels�

With this device and different vessels, a variety of grinding (impact grinding, cutting grinding)

and mixing tasks can be performed in the laboratory�

›

Milling:

Impact milling: For use with hard, brittle material, dried material or material that is brittle

because of cold (for example grain, coffee, etc�)� The granularity of the ﬁnal product is de-

termined by the duration of the grinding, the level to which the container is ﬁlled and the

physical property of the material being processed�

Cutting milling: For use with soft, ﬁbrous grinding material (for example hay, paper, etc�)�

In this case as well, the granularity of the ﬁnal product is determined by the duration of the

grinding, the level to which the container is ﬁlled and the physical property of the material being

processed�

› Blending:

For mixing and emulsifying food (for example ice cream, milk, and sauces) and other

substances� It can be widely used in microbiology and food science field�

Intended use: Tabletop device

Caution!

› Please pay attention to avoiding hand injury when operate the device�

› The vessel may be very hot after operation� Allow it to cool down before remove it from the

drive� Use your personal protective equipment�

› Hearing protection must be worn when working with the device in high speed�

!Notice!

› The device must be operated on ﬂat surface and must not be moved during operation�

› Covers or parts that can be removed from the device without tools must later be reﬁtted to

ensure safe operation� This will prevent the inﬁltration of foreign objects, liquids and other

contaminants�

› The vessel must always be closed during operation� Switch off the device immediately if any

material leaks from the vessel� Clean the device after disconnected power plug�

› The feet of the device must be clean and undamaged�

›

The device is designed for short term operation� The maximum operating time is 5 minutes�

After that, it should be switched off for 10 minutes to cool down�

›

As long as the set speed is not reached, the speed value ﬂashes�

///

Range of use

Indoor environments similar to that a laboratory of industry area (

EMC class A

)�

The safety of the user cannot be guaranteed:

› if the device is operated with accessories that are not supplied or recommended by the

manufacturer�

›

if the device is operated improperly or contrary to the manufacture’s speciﬁcations�

› if the device or the printed circuit board are modiﬁed by third parties�

/// Disposal instructions

› The device, accessories and packaging must be disposed of in accordance with local and

national regulations�

/// Maintenance

› The device must only be opened by trained specialists, even during repair� The device must

be unplugged from the power supply before opening� Live parts inside the device may still

be live for some time after unplugging from the power supply�

/// Power supply / switching off the device

› The voltage stated on the type plate must correspond to the power voltage�

› The device can only be disconnected from the power supply by pulling out the power plug

or the connector plug�

› The device must only be operated with the original power cord set�

› The socket for the power cord must be easily accessible�

› Socket must be earthed (protective ground contact)�

› The device does not start up again automatically following a cut in the power supply�

/// Accessories

› Protect the device and accessories from bumping and impacting�

› Check the device and accessories beforehand for damage each time when you use them� Do

not use damaged components�

› Safe operation is only guaranteed with the accessories described in the ”Accessories” section�

› Disconnect the power plug before attaching or changing any accessories�

10 11

Useful information

The device can be used in a wide range of applications

in conjunction with different vessels

�

/// Milling

In conjunction with milling vessel, the device can be used as a batch mill�

The list of grinding materials given below is not complete� It is possible to expand the range of

applications further by means of grinding experiments with corresponding grinding procedures

and sample preparations, e�g� with cooling�

Impact milling:

The milling vessel with a beater reduces soft, medium hard and brittle materials�

Everything that breaks, is dry, and does not have a high fat content can be ground�

Following is a list of substances that can be ground dry:

Wheat, barley, corn, malt, pectin, roasted coffee, nutshells, bones, ergot, peat, pharmaceutical,

feed materials, spices, resin, potash, seeds, salts, cinders, tablets�

Tough grinding material must be cooled, for example by adding pulverized dry ice to the grinding pot�

Also note the operating instructions for the IKA MultiDrive MI 250 and IKA MultiDrive MI 400

milling vessel�

Cutting milling:

The milling vessel with the cutting blade reduces bulky, elastic ﬁbrous and soft materials with

high cellulose content�

Mixed goods such as trash must be free of iron and non-iron metals� The feed material must not

be too moist or fatty�

Otherwise the material may adhere to the sides of the grinding container�

Following is a list of some materials that can be reduced:

Leaves, ﬁbers, hops, cardboard, paper, hay, plastics, tobacco and roots�

Also note the operating instructions for the IKA MultiDrive MI 250 and IKA MultiDrive MI 400

milling vessel�

Note: Materials that are not listed in these operating instructions may only be handled with the

grinding vessel after conﬁrmed with IKA, especially if there is a risk of explosion (dust explosion

due to electrostatic charge)�

Working with cooling water:

Also note the operating instructions for the IKA MultiDrive MI 250 and IKA MultiDrive MI 400

milling vessel�

Working with coolants – Dry ice cooling (CO):

Also note the operating instructions for the IKA MultiDrive MI 250 and IKA MultiDrive MI 400

milling vessel�

/// Blending

In combination with the IKA MultiDrive BL 2000 blending vessel, the device can be used as

a blender�

The blender can be used for many applications� The following list is not complete and can be

extended by experiments�

List of substances to be blended:

Ice cream, milk, sauces, vegetables, meat, nut butter, spices�

!Notice!

The device is designed for short term operation� The maximum operating time is 5 minutes�

After that, it should be switched off for 10 minutes to cool down�

As long as the set speed is not reached, the speed value ﬂashes�

12 13

Unpacking

›

Please unpack the device carefully�

›

Any damage should be notiﬁed immediately to the shipping agent (post oce, railway net-

work or logistics company)�

1 IKA MultiDrive basic

2Power cord set

3USB cable

4Socket wrench

5Disassembly tool I

6Disassembly tool II

7User guide

8Warranty card

Operator panel and display

A“Interval“ indicator Indicate the interval function is activated�

B“Timer” indicator Indicate the timer function is activated�

C“Counter” indicator Indicate the counter function is activated�

DRotating/pressing knob

Adjust the speed�

Set the timer when the timer setting is enabled�

Start/stop running of the device�

E“Int” button Activate the interval function�

FTimer button Switch between the setting of speed and timer�

GTime display Show the timer/counter value�

HSpeed display Show the speed value�

D

F E

AB

C

GH

IKA PETTE

Garanty

1+2+3

1

2

7

8

45 6

3

14 15

1.

2.

Installation

1.

2.

Click

24

/// Connecting to power

/// Attaching the vessel to the drive unit

3

2000 ml (max)

1500 ml

500 ml (min)

1000 ml

/// Filling the vessel

/// Closing the vessel

!Notice!

The socket used must be earthed (ﬁtted with earth contact)�

Observe the ambient conditions (temperature, humidity etc�) listed under “Technical Data”�

220 - 240 V ~

50/60 Hz

1000 W

IP 31

1.

2.

1

16 17

Operation

/// Switching on

Interval

Timer

Counter

Speed x 1000 rpm min:sec

Interval

Timer

Counter

Speed x 1000 rpm min:sec

/// Setting the speed

4

Interval

Timer

Counter

Speed x 1000 rpm min:sec

Interval

Timer

Counter

Speed x 1000 rpm min:sec

Interval

Timer

Counter

Speed x 1000 rpm min:sec

green

Note: After the cover has been securely closed, the color of the LED signal lamp changes from

red to green� The unit is only ready for operation when the LED is green�

18 19

/// Setting the timer

1.

2.

Interval

Timer

Counter

Speed x 1000 rpm min:sec

Interval

Timer

Counter

Speed x 1000 rpm min:sec

Interval

Timer

Counter

Speed x 1000 rpm min:sec

Interval

Timer

Counter

Speed x 1000 rpm min:sec

Timer editing

LED

Interval

Timer

Counter

min:sec

Interval

Timer

Counter

min:sec

Counter:

Timer:

Interval

Timer

Counter

min:sec

...

Note: If the counter function is activated, the counter automatically starts to run from 0 seconds

to 5 minutes� Then the grinding/blending function of the unit stops�

Interval

Timer

Counter

Speed x 1000 rpm min:sec

Interval

Timer

Counter

Speed x 1000 rpm min:sec

/// Activating the interval function

20 21

Interval

Timer

Counter

Speed x 1000 rpm min:sec

Interval

Timer

Counter

Speed x 1000 rpm min:sec

Interval

Timer

Counter

Speed x 1000 rpm min:sec

15s

Interval

Timer

Counter

Speed x 1000 rpm min:sec

2s

Error codes

Any malfunctions during operation will be identiﬁed by an error message on the display�

Proceed as follows in such cases:

› Turn off the device by using the power switch�

› Carry out corrective measures�

› Restart the device�

If the actions described fails to resolve the fault or another error code is displayed then take

one of the following steps:

›

contact the service department�

›

send the device for repair, including a short description of the fault�

Causes

›

Inside temperature is too hot

Effect

› motor off

Solutions

›

Switch off the device and allow it to cool down�

› Restart the instrument�

Causes

› Motor can’t running normal (can’t start or not reach the target speed)

Effect

›

motor off

Solutions

› Switch off the device�

› Restart the device with power switch�

Causes

› Overload

Effect

›

motor off

Solutions

› Switch off the device

› Decrease the speed setting or the load�

E 3

E 4

E 47 / E 48

Causes

› Error vessel used

Effect

›

motor off

Solutions

› Remove the wrong vessel and try again

E 51

/// Starting the running

Note: In interval mode, the unit runs for 15 seconds each and then stops for 2 second� This

means that in counter mode the unit runs for 5 minutes or in timer mode for the set time and

then the grinding/blending function is switched off�

22 23

Maintenance and cleaning

The device is maintenance-free� It is only subject to the natural wear and tear of components and

their statistical failure rate�

/// Cleaning:

For cleaning disconnect the mains plug!

Use only cleaning agents which have been approved by IKA to clean the devices:

These are: water (containing surfactant) and isopropyl alcohol�

›

Wear protective gloves during cleaning the devices�

›

Electrical devices may not be placed in the cleansing agent for the purpose of cleaning�

›

Do not allow moisture to get into the device when cleaning�

› Before using another than the recommended method for cleaning or decontamination, the

user must ascertain with that this method does not destroy the device�

/// Ordering spare parts:

When ordering spare parts, please indicate:

›

device type�

›

serial number, see type plate

› item and designation of the spare part, see: www.ika.com, spare parts diagram and spare

parts list�

›

software version (Brieﬂy visible in the display when the device is switched on)�

/// Repairs:

Please send in device for repair only after it has been cleaned and is free from any

materials which may constitute a health hazard.

For repair, please request the “Decontamination Certiﬁcate” from IKA, or download printout of

it from the IKA website www.ika.com�

If you require servicing, return the device in its original packaging� Storage packaging is not

sucient� Please also use suitable transport packaging�

Interfaces and outputs

The device can be connected to a PC and operated with the laboratory software labworldsoft

®

through USB interface�

Note! ( )

Please comply with the system requirements together with the operating instructions and help

section included with the software�

/// USB interface:

The Universal Serial Bus (USB) is a serial bus for connecting the device to the PC� Equipped with

USB devices can be connected to a PC during operation (hot plugging)�

Connected devices and their properties are automatically recognized�

Use the USB interface in conjunction with labworldsoft®for operation in “Remote” mode and

also to update the ﬁrmware�

/// USB device drivers:

First, download the latest driver for IKA devices with USB interface from:

www.ika.com/ika/lws/download/usb-driver.zip.

Install the driver by running the setup ﬁle� Connect the IKA device through the USB data cable to

the PC� The data communication runs through a virtual COM port�

/// Command syntax and format:

The following applies to the command set:

› Commands are generally sent from the computer (Master) to the lab device (Slave)�

› The lab device only sends at the computer’s request� Even fault indications cannot be sent spon-

taneously from the lab device to the computer (automation system)�

› Commands are transmitted in capital letters�

› Commands and parameters including successive parameters are separated by at least one

space (Code: hex 0x20)�

› Each individual command (incl� parameters and data) and each response are terminated with

Blank CR LF (Code: hex 0x0d hex 0x0A) and have a maximum length of 80 characters�

› The decimal separator in a number is a dot (Code: hex 0x2E)�

24 25

The above details correspond as far as possible to the recommendations of the NAMUR working

party (NAMUR recommendations for the design of electrical plug connections for analogue and

digital signal transmission on individual items of laboratory control equipment, rev� 1�1)�

The NAMUR commands and the additional speciﬁc IKA commands serve only as low level com-

mands for communication between the device and the PC� With a suitable terminal or commu-

nications program these commands can be transmitted directly to the device� The IKA software

labworldsoft®, provides a convenient tool for controlling the device and collecting data under

MS Windows, and includes graphical entry features, for motor speed ramps for example�

Commands Function

IN_NAME Read the device name

IN_PV_4 Read current speed value

IN_SP_4 Read rate speed value

OUT_SP_4 xxx Change the speed value to xxx

START_4 Start the motor

STOP_4 Stop the motor

RESET Switch to normal operation mode

Accessories

› IKA MultiDrive BL 2000 blending vessel

› IKA MultiDrive MI 250 milling vessel

› IKA MultiDrive MI 400 milling vessel

See more accessories on www.ika.com�

Technical data

General data

Voltage VAC 220 �� 240 ±10 %

100 �� 120 ± 10 %

Frequency Hz 50 / 60

Motor rating input W 1000

Motor rating output W 800

Interface USB

Permissible ambient temperature °C + 5 �� + 40

Permissible relative humidity % 80

Protection class according to DIN EN 60529

IP 31

Dimensions (W × D × H) mm 300 × 250 × 450

Weight kg 10

Operation at a terrestrial altitude m max� 2000

Grinding/blending function

Process type batch

Short time operation (KB) min� 5 / 10 (5 min� ON / 10 min� OFF)

Grinding methods Cutting/impact

Speed range rpm 3000 �� 20000

Speed display LED

Speed deviation ± 5 % of current speed

Speed setting knob

Speed setting resolution rpm 1 (x100)

Timer function

Timer range 0 / 1 seconds �� 5 minutes

Timer display LED

Timer setting Button / knob

Timer setting resolution sec� 1

Interval function Yes (not adjustable)

Subject to technical changes!

26

Warranty

In accordance with IKA warranty conditions, the warranty period is 24 months� For claims under

the warranty please contact your local dealer� You may also send the machine direct to our factory,

enclosing the delivery invoice and giving reasons for the claim� You will be liable for freight costs�

The warranty does not cover worn out parts, nor does it apply to faults resulting from improper use,

insufficient care or maintenance not carried out in accordance with the instructions in this operating

manual�

20000024899_EN_IKA MultiDrive_032019_web

Technical speciﬁcations may be changed without prior notice�

IKAworldwide IKAworldwide /// #lookattheblue @IKAworldwide

Discover and order the fascinating products of IKA online:

www.ika.com

JAPAN

IKA Japan K.K.

Phone: +81 6 6730 6781

eMail: info_japan@ika�ne�jp

INDIA

IKA India Private Limited

Phone: +91 80 26253 900

eMail: info@ika�in

England

IKA England LTD.

Phone: +44 1865 986 162

eMail: sales�england@ika�com

Malaysia

IKA Works (Asia) Sdn Bhd

Phone: +60 3 6099-5666

eMail: sales�lab@ika�my

CHINA

IKA Works Guangzhou

Phone: +86 20 8222 6771

eMail: info@ika�cn

POLAND

IKA Poland Sp. z o.o.

Phone: +48 22 201 99 79

eMail: sales�poland@ika�com

USA

IKA Works, Inc.

Phone: +1 910 452-7059

eMail: sales@ika�net

KOREA

IKA Korea Ltd.

Phone: +82 2 2136 6800

eMail: info@ika�kr

Brazil

IKA Brasil

Phone: +55 19 3772 9600

eMail: sales@ika�net�br

IKA-Werke GmbH & Co. KG

Janke & Kunkel-Straße 10, 79219 Staufen, Germany

Phone: +49 7633 831-0, Fax: +49 7633 831-98

eMail: sales@ika�de

IKA MultiDrive basic User manual

Popular Food Processor manuals by other brands
