Ikan Multi-K User manual

INTRODUCTION
Thank you for purchasing the ikan Multi-K. The Multi-K is extremely easy to use and will quickly become an
integral part of your production kit. For more information on this and many other innovative ikan products, please visit our
website: www.ikancorp.com.
PACKAGE CHECK LIST
Multi-K Light
Camera shoe mount
AC Adapter
GETTING STARTED
1. Power on the light using the Main Power switch
2. Control the amount of light with the Dimmer Knob clock-wise until you hear a “click”.
3. Turn the light off by twisting the Dimmer Knob counter clock-wise unit you hear a “click”.
4. The Multi-K can also be powered by the included AC adapter.
5. Adjust to desired color temperature
ADJUSTING THE BRIGHTNESS
The Dimmer Knob on the top of the light allows you to adjust the intensity of the light. Adjust the intensity of the light by
turning the Dimmer Knob clock-wise to increase the intensity and counter clock-wise to reduce it.
12v -18v Power
CONDITIONS OF WARRANTY SERVICE
• Free service for one year from the day of purchase if the problem is caused by manufacturing errors.
• The components and maintenance service fee will be charged if the warranty period has expired.
Free Service will not be Provided in the Following Situations: (* Even if the product is still within the warranty period.)
• Damage caused by abuse or misuse, dismantling, or changes to the product not made by the company.
• Damage caused by natural disaster, abnormal voltage, and environmental factors etc.
Power on / Dimmer knob
Power on / Dimmer knob
144 LED bulbs
¼-20 threaded hole
color temperatures
QUICK START GUIDE / Multi-K
3903 Stoney Brook Dr. Houston TX 77063. 1-713-272-8822, [email protected] © 2009 ikan Corporation. All right reserved. www.ikancorp.com
Power
2800’ x
3200’ x
4000’ x
4800’ x
5600’ x
8500’ x
++
++
Checked by
Specifications:
• 2800°k - 6500°k Color Range
• DC12 - 18v
• Input: 6 x AA Batteries
• Weight: .8 lbs
• Dimensions: L 4.9” x W 4.3” x H 1.6”
Color temperature switch
6 AA Battery option
Back view
Front view
Side view

QUICK START GUIDE / Multi-K
The right amount of light
The ID 500 lux drop off
2800 K 3200 K 4000 K
4800 K 5600 K 6500 K
1 meter
3 meters
5 meters 1 fc / 10 lux
4 fc / 40 lux
168 fc / 1680 lux
1 meter
3 meters 4 fc / 40 lux
5 meters 2 fc / 20 lux
44 fc / 440 lux
1 meter
3 meters 5 fc / 50 lux
5 meters 2 fc / 20 lux
40 fc / 400 lux
1 meter
3 meters 3 fc / 30 lux
5 meters 1 fc / 10 lux
35 fc / 350 lux 1 meter
3 meters 3 fc / 30 lux
5 meters 1 fc / 10 lux
30 fc / 300 lux 1 meter
3 meters 2 fc / 20 lux
5 meters 1 fc / 10 lux
27 fc / 270 lux
