Ikan IKC-H2S1 User manual

IKC-H2S1
HDMI to SDI Converter QUICKSTART GUIDE
www.ikancorp.com
1.713.272.8822
[email protected]
© 2014 ikan Corporation. All right reserved
Checked by
CONDITIONS OF WARRANTY SERVICE
• Free service for one year from the day of purchase if the problem is caused by manufacturing errors.
• The components and maintenance service fee will be charged if the warranty period has expired.
Free Service will not be Provided in the Following Situations: (* Even if the product is still within the warranty period.)
• Damage caused by abuse or misuse, dismantling, or changes to the product not made by the company.
• Damage caused by natural disaster, abnormal voltage, and environmental factors etc.

What’s Included:
1 x HDMI to SDI Converter
1 x AC Adapter
2 x Mounting Brackets
SPECIFICATIONS:
Video Input 1 x BNC (HD/SD-SDI,3G/1, 485G/270M)
Video Output 1 x SDI Loop-Through
1 x HDMI (with HDCP v 1.1), 19pin Female
Audio Output External Audio Output (Stereo 3.5 pi)
HD Format Support 1920x1080 - 60p/59.94p/50p
1920x1080 - 60i, 59.94i, 50i, 30p, 29.97p, 25p, 24p, 23.98p
1920x1080 (30psf, 29.97psf, 25psf, 24psf, 23.98psf )
1280x720 - 60p, 59.94p, 50p
SD Format Support NTSC, PAL
Power Requirement 4DC (7V-24V) or AC Adapter (100 ~ 230V, 50Hz/60Hz)
Power Consuption 6W
Operation Temperature (-10°C ~ 40°C) (14°F ~ 104°F)
Operation Humidity 20% ~ 80% RH
Product Dimensions 4.6 x 3.9 x 1.4" (116.8 x 99 x 35.5mm)
Product Weight .8 lb (.362 Kg)
IKC-H2S1
HDMI to SDI Converter QUICKSTART GUIDE
www.ikancorp.com 713-272-8822

DESCRIPTION
UP
DOWN
SW 1
LCD BACKLIGHT
OFF
ON
SW 2
LCD DISPLAY
RESOLUTION
LEVEL METER
SW 3
HDMI RANGE
0 ~ 255
16 ~ 235
SW 4
INPUT AUDIO SELECT
HDMI AUDIO
EXTERNAL
SW 5
AUDIO GROUP
CH1 ~ CH8
CH9 ~ CH16
SW 6
EXTERNAL AUDIO INPUT
PHONE JACK
OPTICAL
SW 7
EXTERNAL AUDIO INPUT
PHONE JACK
AES/EBU (BALANCE)
OPTICAL
SPDIF (2CH)
IKC-H2S1
HDMI to SDI Converter QUICKSTART GUIDE
www.ikancorp.com 713-272-8822
INPUTS
OUTPUTS
DIP SWITCH SETTNG
