Ikan IKC-S2H1 User manual

IKC-S2H1
SDI to HDMI Converter QUICKSTART GUIDE
www.ikancorp.com
1.713.272.8822
[email protected]
© 2014 ikan Corporation. All right reserved
Checked by
CONDITIONS OF WARRANTY SERVICE
• Free service for one year from the day of purchase if the problem is caused by manufacturing errors.
• The components and maintenance service fee will be charged if the warranty period has expired.
Free Service will not be Provided in the Following Situations: (* Even if the product is still within the warranty period.)
• Damage caused by abuse or misuse, dismantling, or changes to the product not made by the company.
• Damage caused by natural disaster, abnormal voltage, and environmental factors etc.

What’s Included:
1 x SDI to HDMI Converter
1 x Power Cord
2 x Mounting Brackets
SPECIFICATIONS:
Video Input 1 x SD/HD/3G-SDI (BNC)
Video Output 1 x HDMI (v1.3)
1 x SDI Loop-Through
Audio Output 1 x SDI De-Embedded 2ch Analog Audio
1 x SDI DE-Embedded 2ch AES/EBU Audio
Standards SMPTE-259M/292M/424M/425M (Level A)
SDI support of YUV 4:2:2 8-bit/10-bit
HDMI support of YUV 4:2:2
RGB
HD Format Support 2K - 24psf, 24p
1920x1080p - 50, 59.94, 60
1920x1080psf - 23.98, 24, 25, 29.97, 30
1920 x1080p - 23.98, 24, 25, 29.97, 30
1920x1080i - 50, 59.94, 60
1280x720p - 50, 59.94, 60
SD Format Support NTSC, PAL
Audio Format Support SDI embedded 16-Channel (8ch + 8ch) Audio
Power Requirement DC6V ~ DC24V (DC6V ~ DC12V recommended)
Product Dimensions 4.6 x 3.7 x 1" (118mm x 95 x 25mm)
Product Weight .72 lb (.32 Kg)
IKC-S2H1
SDI to HDMI Converter QUICKSTART GUIDE
www.ikancorp.com 713-272-8822

DESCRIPTION
UP
DOWN
SW 1
LCD BACKLIGHT
OFF
ON
SW 2
LCD DISPLAY
RESOLUTION
LEVEL METER
SW 3
OUTPUT FORMAT
TCbCr 4:2:2
RGB 4:4:4
SW 4
HEADPHONE AMP GAIN
LOW
HIGH
SW 5
AUDIO GROUP
CH1 ~ CH8
CH9 ~ CH16
SW 6
DE-EMBEDDED AUDIO OUT CH SELECT
SW 7
(AES-EBU & ANALOG AUDIO)
DE-EMBEDDED AUDIO CH
SW 6
SW 7
CH 1/2 (CH 9/10)
OFF
OFF
CH 3/4 (CH 11/12)
OFF
ON
CH 5/6 (CH 13/14)
ON
OFF
CH 7/8 (CH 15/16)
ON
ON
INPUTS
OUTPUTS
DIP SWITCH SETTING
IKC-S2H1
SDI to HDMI Converter QUICKSTART GUIDE
www.ikancorp.com 713-272-8822
