Ikan VX7c User manual

www.ikancorp.com
CONDITIONS OF WARRANTY SERVICE
• Free service for one year from the day of purchase if the problem is caused by manufacturing errors.
• The components and maintenance service fee will be charged if the warranty period has expired.
Free Service will not be Provided in the Following Situations: (* Even if the product is still within the warranty period.)
• Damage caused by abuse or misuse, dismantling, or changes to the product not made by the company.
• Damage caused by natural disaster, abnormal voltage, and environmental factors etc.
1.713.272.8822
[email protected]
© 2014 ikan Corporation. All right reserved
What’s included
Checked by
VX7c
7” 3G -SDI Monitor w/ Signal Conversion QUICKSTART GUIDE
 1 x VX7c Monitor
 1 x AC Adapter
 1 x Camera Shoe Mount (SM-103)
 1 x DV Battery Plate (Check one)
BP5-S Sony "L" Series
BP5-SU Sony "BP-U" Series
BP5-C Canon "900" Series
BP5-E6 Canon “E6” Series
BP5-P Panasonic "D54" Series
BP5-PG6 Panasonic “G6” Series
BP5-N Nikon “EN-EL15” Series

www.ikancorp.com 713-272-8822
VX7c
7” 3G -SDI Monitor w/ Signal Conversion QUICKSTART GUIDE
12 3 4 5 6 7810 11 12 13 14
9
VX7c
F2
F3
F4
F1
Input
ASPECT/
EXIT
MENU
BRIGHT CONTRAST CHROMA SHARPNESS
RGBTINT
1
2
3
4
5
6
7
8
12
11
10
9
13
14
15
User programmable function buttons. For quick access, the user may
program the F1 through F4 buttons to enable frequently accessed
monitor features.
Power Switch
Power ON / OFF
Power Indicator Light
When the power is ON, the LED green lights up
F1 / Button
Function key actions are selected in the menu
F4 / Button
Function key actions are selected in the menu
F2 / Button
Function key actions are selected in the menu
F3/ Button
Function key actions are selected in the menu
Input & Aspect/Exit Buttons
Aspect: 16:9, 4:3, Full
In MENU, it is to exit the menu
Button
Toggle left in MENU setting mode
and Buttons
Toggle up and down in MENU setting mode
/ MENU Button
Toggle right in MENU setting mode
In MENU, push button to select menu setting
BRIGHT/R Knob
Adjust brightness 0 - 100 (50)
Adjust red channel
CONTRAST/G Knob
Adjust contrast 0 - 100 (50)
Adjust green channel
CHROMA/B Knob
Adjust chroma 0 - 100 (50)
Adjust blue channel
TINT/SHARPNESS Knob
Adjust tint 0 - 100 (50)
Adjust sharpness 0 - 100 (10)
TALLY Indicator Lights
Front view

www.ikancorp.com 713-272-8822
VX7c
7” 3G -SDI Monitor w/ Signal Conversion QUICKSTART GUIDE
Rear view
+
+
Switch
1
2
3
4
5
On
50p
30p
25p
24p
24psf
720p
1080p
CAUTION: TURN OFF POWER
BEFORE ADJUSTING
SWITCHES
ON
123 4 5
OFF
VIDEO
Y/C
Y
Pb
Pr
SDI
IN
DC 12V
DC 12V - 20V
OUT
HDMI
+ +
1
TALLY Indicator Lights
VIDEO terminal (BNC)
IN : Composite signal input terminal
OUT : Input signal through-out terminal
YPbPr terminal (BNC)
IN : Component signal input terminal
OUT: : Input signal through-out terminal
HDMI terminal
IN : HDMI input terminal
OUT: : Input signal through-out terminal
DC 12V-24V power terminal
XLR DC Connection
TALLY Input Connector
RJ45 Connection
DC 7-24V power terminal
Standard DC Connection
Pro Battery Plate Mount Holes
Threaded for M3x.07 screws. Use to attach pro battery
plate adapter.
USB terminal
For factory service use only
¼-20 Threaded insert (on three sides of monitor)
Mounting Monitor
DV Battery Plate Slot
Mounting ikan DV battery plate
3G-SDI
2
3
4
5
6
8
7
9
11
12
10
+
+ +
+
VIDEO
IN
TALLY
OUT
HDMI
OUT IN
Y
Pb
Pr
3G-SDI
1
2
3
4
12
6
1010
5
7
10
8911 8
1 2 3 4 5 6 7 8
1
PIN Number Signal
Yellow
Red
Green
GND
NC
2
3
8
4 5 6 7
HIGH DEFINITION
3G-SDI LCD MONITOR
1
2 3
4Pin number Signal
1
2,3
4
GND
+12V
_
ikancorp.com MADE IN CHINA
RoHS
COMPLIANT
Model: VX7c
Picture Size: 7 inch
Resolution: 1280 x 800
Aspect Ratio: 16:9 / 4:3
Color System: NTSC / PAL
Operating Volts: DC 7.4 ~ 24V
Signal Input:
480i/p 576i/p 720p 1080i/p
*
*
*NOTE*
3G-SDI: Inputs automatically output via the 3G-SDI
output as well as the HDMI output.
HDMI: Inputs automatically output via the HDMI
output as well as the 3GI-SDI output.

www.ikancorp.com 713-272-8822
VX7c
7” 3G -SDI Monitor w/ Signal Conversion QUICKSTART GUIDE
The MANUAL function allows you to change the values of Red, Green, and Blue (RGB).
This function recalls user dened values settings .The user setting will remain in memory
indenitely and can be erased by using the reset option in the main menu.
A graphical representation of the pixels exposed in your image. The left side of the
graph represents the blacks or shadows, the right side represents the highlights or bright
areas and the middle section is mid-tones. How high the peaks reach represent the
number of pixels in that particular tone. This tool helps you get proper exposure.
A feature that allows you to see what parts of the image are over exposed. It does this
by adding black stripes to the parts that are over exposed.
The DSLR Scaling function will allow users to extend their DSLR camera’s HDMI video
output any option of four – Normal, 3:2, 16:9 or Full Screen – convenience made simple.
This function displays the blanking portion of the incoming signal.
The LCD panel in this display has a native display of 1280 x 800 pixels. A signal of any
other resolution is scaled to t this native resolution. There may be time when it is
desired to view the incoming signal without scaling. Enabling Pixel to Pixel mode turns
off the scaling and displays a 1280 x 800 pixel window of the original image. Each pixel
of the panel displays one pixel of the original image. The user may use the arrow buttons
(buttons 3-6) on the monitor face to move the window left, right, up and down to see the
desired portion of the image.
The VX7c is equipped with Monochrome Peaking features which highlight the desired
focus area in a bright, red outline. The operator adjusts the focus control until the red
indicator outlines on the desired area are razor sharp, indicating optimal focus. For the
best results, be sure the subject is properly exposed.
The False Color feature utilizes a full spectrum of assigned color indicators, ensuring
awless shot exposure. As the camera Iris is adjusted, the subject of the image will
change color based on specic brightness values indicating optimal exposure. See
included chart for color assignments.
As an additional tool associated with the VX7c’s False Color feature, ikan’s exclusive
Adjustable Under Exposure and Over Exposed Waning feature gives the operator full
control of the VX7c False Color brightness values. By setting the preferred IRE
exposure limits, the operator is warned when the image exposure is exceeding or
falling under the preset IRE limit, providing customizable, full image exposure control.
The VX7c offers adjustable upper Clip Guide levels to accurately display overexposed
images in any shooting condition. The operator simply assigns the upper IRE to their
preference and any exposure over the set IRE limit will ash in a vivid purple, indicating
only the over exposed area.
This function displays a side by side comparison of the incoming video signal. Pushing
the F1/4 button one time will enter the mode. Each time the F1/4 button is pushed it
will freeze the current frame on the right hand side of the display while the left continues
to display the live signal. Pressing the exit button will exit the window mode. Use
Window 1 for 16:9 signals and Window 2 for 4:3 signals.
Display a crosshair on the center of screen.
Brightness 0-100
Contrast 0-100
Chroma 0-100
Sharpness 0-100
Tint 0-100
Color Temp. 5600 K
6500 K
9300 K
MANUAL
OSD Language English
Chinese
OSD Duration 5-60 second
Luma Under Warn
Luma Over Warn
Fuction 1-4 Window 1
Window 2
HV Delay
Guides
Peaking
False Color
Clip Guide
Underscan
DSLR Scaling
Check Field
Pixel
Histogram
Zebra
Menu Setup User 1-5
System Reset
CONFIGURATION OF SETTING MENUS
Crosshair

www.ikancorp.com 713-272-8822
VX7c
7” 3G -SDI Monitor w/ Signal Conversion QUICKSTART GUIDE
FEATURES
•1280 x 800 Resolution IPS Panel
• HDMI to SDI / SDI to HDMI Conversion
• Composite, Component, and HDMI Inputs & Outputs
• False Color – Adjustable Luminance & Over Luminance Warning
• Clip Guide – Adjustable Threshold
• Peaking
• Histogram
• Zebra
• Underscan
• Color Temperature Presets (9300K, 6500K, 5600K)
• RGB Adjust
• Guides
• Crosshair
• Guide Masks (Full / 16:9 / 15:9 /4:3 / 1.5:1 / 1.85:1 / 2:1 / 2.35:1/ User)
• Check Field (Blue, Red, Green, Mono)
• Side-by-Side Freeze Frame
• H/V Delay
• Aspect Ratio (Full / 16:9 / 15:9 /4:3 / 1.5:1 / 1.85:1 / 2:1 / 2.35:1/ User)
• 5 User Dened Groups
• Tally System (Front & Rear)
• DSLR Scaling
• Moveable Pixel-to-Pixel
SPECIFICATIONS
Diagonal (inch): 7-Inch
Aspect Ratio: 16:10
Resolution: 1280 x 800
Viewing angle: 170° horizontal/170° vertical
Display Technology: IPS
Brightness: 400 cd/m2
Response Time: 30ms
Pixel Pitch: 0.11775×0.11775 (mm)
Inputs: 3G-SDI, HDMI, Component, Composite
Outputs: 3G-SDI, HDMI, Component, Composite
Power Consumption: 11W
Color System: PAL/NTSC/SECAM (Auto-Detected)
Input Voltage: DC 6V - 24V
Build Material: Plastic
Dimensions: 7.36 x 5.6 x 1.3”
Weight : 1 lb
Shipping Dimensions: 3.1 x 14.75 x 7.75"
Shipping Weight: 3 lbs
Dimensions (Metric): 187 x 142 x 33mm
Weight (Metric): 0.45 kg
Shipping Dimensions (Metric): 120 x 196 x 76mm
Shipping Weight (Metric): 1.3 kg
