The Visual Professionals.
2007 product catalog
&
LCD Monitors
Teleprompter kit
New
version 2.0
HD
www.ikancorp.com

New for 2007
&
LCD Monitors
Teleprompter kit
1
ikan provides professional quality
affordable monitors to video professionals
around the globe. With constantly evolving
video technology and ever shrinking
budgets, our goal is to provide a high
quality, cost effective SD or HD solution for
industry professionals.
You CAN with ikan.
HD
PrompterPro v2.0 V8000HD V8000W
V9200 V8400D RM8000

The PT1000 Teleprompter System is portable and easy to use.
With a setup time of five minutes, the lightweight PT1000’s
best feature is the $699 selling price … and that’s complete
with software!
Kit Includes
▪ 8” High Resolution LCD Monitor
> VGA, S-Video, and Composite
> Horizontal and Vertical Flip
▪ PrompterPro V2.0 Software
▪ All necessary Hardware
PT1000 Teleprompter Kit
$699
2

PrompterPro Version 2.0
$99
PrompterPro 2.0 is the new and improved version of PrompterPro. It includes
many new features that make the software even better than it was before.
Features like mouse control and an adjustable cue marker will make your
production life a lot easier. Being able to edit your text on the fly and saving the
changes are also a brand new feature that you are sure to love.
!
◄ PrompterPro 2.0 allows
you to edit your text on
the fly. You can import
standard text files or
Rich Text files.
◄ New to version 2.0 is the
ability to use the scroll
wheel on your mouse to
adjust speed and direction.
This feature gives you new
freedom like never before.
You can use your wireless
mouse to control the action!
◄ You can edit color, size,
and font. Once you make
your changes, you can also
save them for next time.

LCD Monitors
Accessories
Our multi-functional LCD monitors range in size from 2.5 inches
to 9.2 inches. All monitors feature antiglare TFT displays with
wide viewing angles for use in the field or the studio.
AC103 Battery Box Battery Plate
▪ Uses 10 AA batteries
▪ Power any of our monitors
▪ Inexpensive battery option
▪ Comes in handy
▪ Does not include batteries
$24.95 $59.95
▪ Works with“L” seriesbattery
▪ Small and Lightweight
▪ Cost effective
▪ Power any of our monitors
▪ Attaches to back of V2500
AC104 Batt. Box/w Charger
$89.95
SH7, SH8, SH9 Sun hood
$24.95
▪ Includes the AC103
▪ 10 AA batteries included
▪ Comes with10 cell charger
▪ Simple to use
▪ Rechargable
▪ Keeps out unwanted light
▪ Durable Construction
▪ Velcro Strips included
▪ Available for our 7”, 8”& 9”
AC106
Mount on a tripod or craneMount on a camera Use as a preview monitor
4

►Anti-glare screen
►Rear T-channel Mount
►Built-in speaker/volume control
►Resolution: 480 x 234
►Power Consumption: <7W
►Dimension: 2.7" x 2.8" x 1.1"
►Weight: 3.5 ounces
►Multi-System NTSC/PAL
V2500
$99.95
Package Includes:
▪ AV Cable
▪ Power Supply
You Get The Picture!
The super low cost, multi purpose,
razor sharp 2.5” monitor from ikan is
perfect for your camera, deck, jib, or
rack mount solutions. Ask any of our
numerous users how convenient and
portable this versatile monitor is.
5

V70007”
$349
V90009”
$449
This monitor features a larger 9” TFT screen making viewing easy even at a
distance. It’s lightweight, minimal power-consumption and low cost make it a
necessity for all DV cameras, decks and studios.
The V7000 is a small versatile LCD monitor in a wide screen format to match
today's demands for the 16:9 aspect ratio. It's lightweight, low power
consumption and low cost make it ideal for all DV cameras.
►16:9 and 4:3 Aspect Ratios
►Full Range of Quality Controls
►1440 x 234 Resolution (480 x 240 lines)
►Horizontal and Vertical Flip
►Built-in Speakers
►Multi-System NTSC/PAL
►16:9 and 4:3 Aspect Ratios
►Full Range of Quality Controls
►1440 x 234 Resolution (480 x 240 lines)
►Horizontal and Vertical Flip
►Built-in Speakers
►Multi-System NTSC/PAL
V7000 Includes:
▪ Remote control
▪ Power Supply
▪ AV Cable
▪ Camera Shoe Mount
▪ Table Stand / Wall Mount
▪ DC Adapter
V9000 Includes:
▪ Remote control
▪ Power Supply
▪ AV Cable
▪ Camera Shoe Mount
▪ Table Stand / Wall Mount
▪ DC Adapter
6

V92009.2”
$449
The V9200 is a versatile 16:9 / 4:3 LCD monitor with double the resolution than the
V7000 and V9000. Its high resolution and larger screen size make it useful in many
types of video production.
The V8000W is an 8-inch video monitor utilizing a high resolution widescreen LCD
panel. This high quality unit is capable of displaying images for serious production
scenarios. It is compact enough for camera mounting or attaching to a jib-arm
and it’s large enough to be seen on a desktop even from a distance.
►16:9 Aspect Ratio
►Full Range of Quality Controls
►800x480 up to 1024x768 Resolution
►VGA & Composite Input
►Multi-System NTSC/PAL
►16:9 and 4:3 Aspect Ratios
►Two Composite Inputs
►800x480 Resolution
►Wide Viewing Angles
►Multi-System NTSC/PAL
V8000W8”
$499
Package Includes:
▪ AV Cables
▪ VGA Cable
▪ AC Adapter
▪ DC Adapter
▪ Camera Shoe Mount
▪ Table Stand / Wall Mount
▪ Remote Control
Package Includes:
▪ AV Cables
▪ AC Adapter
▪ DC Adapter
▪ Table Stand / Wall Mount
▪ Remote Control
800 x 480 Resolution
Digital Signal Processing
800 x 480 Resolution
Digital Signal Processing
7

V8000HD 8”
$795
HD
ikan sees the demands and delivers yet another winning cost effective innovation
for the rapidly evolving HD video industry. Introducing the first HD-LCD Monitor with
an On-Board Charging Battery Solution. At 800 X 480 with pass through capable
component inputs, the V8000HD is your perfect HD solution.
▲ Integrated“L”seriescamcorder
batterymountandcharger.
►Supports HD and SD
►16:9 and 4:3 aspect ratio
►Component, s-video, composite inputs and outputs
►High quality professional BNC connectors
►Full range quality controls
►Built-in support for “L” series camcorder batteries
►Built-in charger for “L” series camcorder batteries
►Multi-system NTSC/PAL
Package Includes:
▪ AC Adapter
▪ Camera Shoe Mount
▪ Remote Control
480p,720p and1080i
IN OUT
VIDEO
S-VIDEO
Y
Pb
Pr
COMPONENT
V8000HD
POWER
8

The V8000T LCD monitor that has VGA capabilities. It also includes video
inputs allowing it to perform double duty as a video monitor. Using the
Touchscreen feature you could use this as an interactive display in a kiosk or
other display.
V8000T 8”
$449
Tons of Inputs!
►VGA Touchscreen
►Composite and Y/C Input
►1024 x 768 Resolution
►Mac and PC Compatible
►Multi-System NTSC/PAL
Package Includes:
▪ Remote Control
▪ AC Adapter
▪ AV Cables
▪ VGA Cable
▪ Mounting Bracket
▪ DC Adapter
Touchscreen!
V8000T monitor is jam-packed with features not
found on most other similar sized units. The
V8000T has a VGA input and has a native
resolution of 640x480. It also supports resolutions
up to 1024x768. In addition it has two composite
video inputs, one RCA audio input, and an
s-video input. So whatever you have, odds are
the V8000T can take it.
9

V8400D 8.4”
$449
The ikan 8.4 inch High Resolution monitor is perfect for your 2nd editing monitor for those tight
Electronic Field Production setups. This unique model is dual mountable and perfect for kiosks or
desktop setups.
► 1024x768 Resolution
►4:3 Aspect Ratio
► VGA & Composite Inputs
► Speaker Built-in
► Desktop & Wallmount Capable
► MAC & PC Compatible
► Multi-System NTSC/PAL
Package Includes:
▪ AV Cables
▪ VGA Cable
▪ AC Adapter
▪ DC Adapter
▪ Remote Control
On Your Desk or On the Wall
The V8400D is equipped with an innovative base that also doubles as
a wallmount. There is no need to buy a separate accessory to mount
it on the wall.
10

►Four V2500 LCD TFT monitors
►Rackmount Unit pre-assembled with monitors
►Power supply for four monitors
►Two V8000 LCD TFT monitors
►Rackmount Unit pre-assembled with monitors
►Power supply for two monitors
5U
Metal Rack Unit
RM8000
$999
Metal Rack Unit
RM2500
$595.00
Convenient, affordable, and versatile, the ikan rackmount
systems are the perfect solution for all your video switching
applications.
11
Tiltable
Other models available:
►RM8000HD
with 2 V8000HD $1,699
►RM8000W
with 2 V8000W $1,099
►RM7000
with 2 V7000 $799

The Visual Professionals.
2007 product catalog
www.ikancorp.com
&
Location
Studio Lights

&
Location
Studio Lights
New for 2007
SL100
ikan designs, manufactures and distributes
professional quality affordable lighting for
video and film studios around the globe.
With the industry making the move toward
cooler more efficient lighting systems, ikan’s
fluorescent fixtures are quickly becoming
industry favorites.
You CAN with ikan.

Features
►DMX 512
►Height adjustable yoke
►Integrated dimmer
►Built-in barn doors
►Built-in ballast
►Light-weight aluminum construction
►Integrated eggcrate and filter channel
►3000K lamps included (Daylight lamps available)
►Save power
►Minimal heat
Light Accessories
Fluorescent Lights
“All in all we very much liked the performance
of the ikan S200D and would welcome it
as a permanent resident in the studio.”
Bruce Coykendall/VideoMaker
Battery Box Gel Frame
Starting at
$30.00
ECS400 Egg Crate
Starting at
$40.00
CX403 DMX Control Box
Starting at
$299.00
FHS400
S200D You can slide this egg
crate into the filter
channel and make the
light more direct.
This frame allows you
to attach a gel to it
and then slide it into
the filter channel on
the light.
DMX control box
designed to control
our DMX enabled
lights. The CX403 is a
four channel dimmer.
2

Location Flourescent Lights
single column
S200D
S400D
Tired of blowing fuses out in the field? Switch
to Fluorescent! The ikan S200D and S400D are
energy efficient yet powerful light fixtures that
are compact enough to be taken out in the
field effortlessly.
ikan lighting is cool and energy efficient, try
putting halogen lights this close to your
talent...you CAN with ikan!
▲
The ikan S200D and S400D are compact,
portable and storable. Barndoors act as
protection for the bulbs when shut.
▲
3

The versatility of the ikan fluorescent lights
make for a perfect solution for your broadcast
facility or studio needs.
▲
Studio Flourescent Lights
dual column
ikan fills the need of large and small studios
around the world with inexpensive turnkey lighting
essentials. With DMX compatible built in dimming
controls, LED readouts and long lasting quality, our
cool, efficient, fluorescent lighting is quickly
becoming an industry standard.
L1600D
◄ The lighting status can
be seen via the LED
readout located at the
bottom of all fixtures.
4

All ikan Fluorescent Lights
$749
► TUBES: Two 55watt Bulbs
► SIZE: 8.1” x 22.8” x 4.3”
► WEIGHT: 9 lbs
S200D
► TUBES: Four 55watt Bulbs
► SIZE: 14.5” x 22.8” x 4.3”
► WEIGHT: 15 lbs
$999
S400D
$1,349
S600D
$1,649
► TUBES: Six 55watt Bulbs
► SIZE: 21.5” x 22.8” x 4.3”
► WEIGHT: 20 lbs
► TUBES: Eight 55watt Bulbs
► SIZE: 28.2” x 22.8” x 4.3”
► WEIGHT: 22 lbs
S800D
L200D
$2,895
L1600D
$1,049
L400D
$1,699
L800D
► TUBES: Two 55watt Bulbs
► SIZE: 6” x 43.3” x 4.3”
► WEIGHT: 15 lbs
► TUBES: Sixteen 55watt Bulbs
► SIZE: 28.4" x 43.3"x 4.3"
► WEIGHT: 60 lbs
► TUBES: Four 55watt Bulbs
► SIZE: 8.1” x 43.3” x 4.3”
► WEIGHT: 17 lbs
► TUBES: Eight 55watt Bulbs
► SIZE: 14.6” x 43.3” x 4.3”
► WEIGHT: 24 lbs
► TUBES: Twelve 55watt Bulbs
► SIZE: 21.5” x 43.3” x 4.3”
► WEIGHT: 37 lbs
L1200D
$749 $2,149
“The ikan flourescent lighting systems provide
an excellent value for the dollar in a no-fuss package.”
Pete Bauer/DV Info Net.
5

S800D
S800D
S800D
Chroma Key Wall
Lighting Setups
S800D
S600D S600D
Subject
S400D
L600D
S400D L600D
L600D
S400D S400D
S200D
S200D
Here are four scenarios to help you with your lighting.
Figure 1. Lighting with a Chroma Key wall.
Figure 2. Lighting News anchors.
Figure 3. Lighting a 2 light interview.
Figure 4. Lighting an interview set.
1. 2. 3.
4.
Couch
Desk
Person/Subject
Legend
Camera
6

SL100 Fluorescent Soft Box
$249
The SL100 soft box light is an affordable fluorescent lighting
solution. The fluorescent bulb provides cool, energy
efficient light and the soft box gives you an easy to use
light. Perfect for many scenarios.
Package Includes:
▪ 85 Watt Compact Fluorescent Light
▪ Power cable
▪ Soft Box
Options:
▪ Carrying case
(Holds 2 lights)
▪ Daylight Temperature bulbs
▪ Light stands
7
!
The fluorescent bulb
provides cool, energy efficient light!
