IKEA MUTEBO User manual

MUTEBO en

ENGLISH 7

3
1x 1x
1x
1x
1x1x 1x
MUTEBO
www.ikea.com
°C
°C

4
2 3
14A
MAX 1h 15minMAX
2 3
1
2 3
14
1 min
1 sec
1
2
3
4
F
E
B
C
D
+ (...) min
AMAX 23 h 59 min

5
4
6
2
1
3 5
3 5
4
9
2
1
6
7
8
~950 ml
MAX
MAX
5
2
4
3
1

6
6
7
11
12
1
42
3 5
9
10
8
85ºC
+
150ºC

Product description
General overview
21
10
9
3
5
4
3
2
1
5
4
6
7
8
1Control panel
2Display
3Water drawer
4Socket for the food sensor
5Heating element
6Lamp
7Fan
8Descaling pipe outlet
9Shelf support, removable
10 Shelf positions
Control panel
Control panel overview
1 2 3 4 5 6
1ON / OFF Press and hold to turn the appliance
on and o.
2Menu Lists the appliance functions.
3Favourites Lists the favourite settings.
4Display Shows the current settings of the
appliance.
5Lamp
switch To turn the lamp on and o.
6Fast Heat
Up
To turn on and o the function: Fast
Heat Up.
Display indicators
Display with key functions.
ENGLISH 7
To download the full version visit www.ikea.com

150°C
12:30
15min START
85°C
F E CD B
A
A. Time of day
B. START/STOP
C. Temperature
D. Heating functions
E. Timer
F. Food sensor (selected models only)
Basic indicators - to navigate on the display.
To conrm the selection / setting.
To go one level back in the menu.
To undo the last action.
To turn the options on and o.
Sound alarm function indicators - when the
set time of cooking ends, the signal sounds.
The function is on.
The function is on. Cooking stops automatically.
Sound alarm is o.
To set the function: Delayed start.
To cancel the setting.
Daily use
Heating functions
STANDARD
True Fan Cooking: Even baking, tenderness,
drying
Conventional Cooking: Traditional baking
Frozen Foods: French fries, potato wedges,
spring rolls
Pizza Function: Baking pizza
Bottom Heat: Baking cakes
Grill: Toasting, grilling
Turbo Grilling: Roasting meat, browning
True Fan Cooking, Conventional Cooking:
When you set the temperature below 80 °C
the lamp automatically turns o after 30 sec.
SPECIALS
Preserving: Preserving vegetables
Dehydrating: Drying sliced fruit, mush‐
rooms
Plate Warming: Preheating plates
Defrost: Defrosting
Au Gratin: Making gratins, browning
Slow Cooking: Preparing tender roast
Keep Warm: Keeping food warm
Moist Fan Baking: Baking
STEAM
Easysteam: Steaming, stewing, gentle crisp‐
ing, baking, roasting
Steam Regenerating: Reheating on a plate
Bread Baking: Bread, bread rolls
Dough Proving: Proving yeast dough
Full Steam: Vegetables, side dishes, sh
Humidity High: Custards, ans, terrines,
sh
Humidity Low: Meat, poultry, oven dishes,
casseroles
ENGLISH 8
To download the full version visit www.ikea.com

Notes on: Moist Fan Baking
This function was used to comply with the
energy eciency class and ecodesign
requirements. Tests according to:
BS EN 60350-1
The oven door should be closed during
cooking so that the function is not
interrupted and the oven operates with the
highest energy eciency possible.
When you use this function the lamp
automatically turns o after 30 sec.
This function is designed to save energy
during cooking. When you use this function,
the temperature in the cavity may dier
from the set temperature. The heating
power may be reduced.
Water hardness
You can change the water hardness level in
the menu: Settings / Setup / Water hardness.
Water hardness level Test paper
1 - soft
2 - moderately hard
3 - hard
4 - very hard 1)
1) When the tap water hardness level is 4, ll the water
drawer with still bottled water.
Troubleshooting
If you encounter an issue with your
appliance, check "Troubleshooting" chapter
in the full version of the User Manual
available on: www.ikea.com.
Product Information Sheet according to UK Ecodesign and
Energy Labelling Regulations
Supplier's name IKEA
Model identication MUTEBO 505.570.39
Energy Eciency Index 61.9
Energy eciency class A++
Energy consumption with a standard load, conventional mode 1.09 kWh/cycle
Energy consumption with a standard load, fan-forced mode 0.52 kWh/cycle
Number of cavities 1
Heat source Electricity
Volume 70 l
Type of oven Built-In Oven
Mass 35.5 kg
BS EN 60350-1 - Household electric cooking appliances - Part 1: Ranges, ovens, steam ovens and grills - Methods for measur‐
ing performance.
ENGLISH 9
To download the full version visit www.ikea.com

Menu structure
Menu
Menu item Application
Assisted Cooking Lists automatic programmes.
Cleaning Lists cleaning programmes.
Favourites Lists the favourite settings.
Options To set the appliance conguration.
Settings Setup To set the appliance conguration.
Service Shows the software version and conguration.
Submenu for: Cleaning
Submenu Application
Drying Procedure for drying the cavity from the condensation remaining after a use of the
steam functions.
Tank emptying Procedure for removing the residual water from the water drawer after use of the steam
functions.
Steam Cleaning Light cleaning.
Steam Cleaning Plus Thorough cleaning.
Descaling Cleaning of the steam generation circuit from residual limestone.
Rinsing Procedure for rinsing and cleaning the steam generation circuit after frequent use of the
steam functions.
Submenu for: Options
Submenu Application
Light Turns the lamp on and o.
Child Lock Prevents accidental activation of the appliance. When the option is on, the text Child Lock
appears in the display when you turn on the appliance. To enable the appliance use,
choose the code letters in the alphabetical order. Access to the timer, the remote opera‐
tion and the lamp is available with the option on.
Fast Heat Up Shortens the heat up time. It is available only for some of the appliance functions.
Cleaning Reminder Turns the reminder on and o.
Time indication Turns the clock on and o.
Digital clock style Changes the format of the displayed time indication.
Submenu for: Setup
Submenu Description
Language Sets the appliance language.
Display brightness Sets the display brightness.
Key tones Turns the tone of the touch elds on and o. It is not possible to mute the tone for: .
Buzzer volume Sets the volume of key tones and signals.
Water hardness Sets the water hardness.
Time of day Sets the current time and date.
ENGLISH 10
To download the full version visit www.ikea.com

Submenu for: Service
Submenu Description
Demo mode Activation / deactivation code: 2468
Software version Information about software version.
Reset all settings Restores factory settings.
ENGLISH 11
To download the full version visit www.ikea.com
*

867380092-A-082023
