IIKKEELLIITTEE VVIIDDEEOO CCAASSEE
SSUUPPPPLLEEMMEENNTTAALL IINNSSTTRRUUCCTTIIOONNSS FFOORR
##66003388..8833 SSOONN DDCCRR--SSRR119900,, 220000,, 229900,, 330000
This supplemental set of instructions describes additional features specific
to your housing model. Prior to testing the system in the water, please read this
supplement along with the general instruction manual to become familiar with
its features and functions.
Ikelite Video Cases are slightly negative
in salt water for stability. This housing has
been water pressure tested at the factory
and has a working depth of 60m (200').
HHOOUUSSIINNGG CCOONNTTRROOLLSS____________________________
• Power On/Off / Mode
• Start/Stop
• Power Zoom
• Photo
• LCD Screen Control #1
• LCD Screen Control #2
• LCD Screen Control #3
• LCD Reversing Circuit On/Off
MMAAIINN OO--RRIINNGG ##00110099__________________________
O-rings last several years if
properly maintained. Control seals
should not need to be replaced as
long as the control shafts are kept
clean and lightly lubricated.
#6038.83 Sony DCR-SR190, 200, 290, 300
Base
Bottom Bar
On/Off
for Reverse
Circuit
Start/
Stop
Snap Shot
Power Zoom
Port
Power
Mirror
Lid Snap
Touch
Pa d
PPRREEPPAARRAATTIIOONN
PPAACCKKAAGGEEDD WWIITTHH HHOOUUSSIINNGG____________________________________________________________________________________________________
• External UR/Pro Color Filter
• Internal Lens Shade
• Silicone Lubricant
CCOOLLOORR FFIILLTTEERR__________________________________________________________________________
The installation and usage of the external UR/Pro
color filter is described in the general instruction manual.
LLEENNSS SSHHAADDEE______________________________________________________________________________
The internal lens shade helps block light reflection/
refraction caused by the interaction of the external color
filter and the port.
Carefully thread the lens shade on the front of the
camera lens. The lens threads are very fine; DDOO NNOOTTcross thread. It should screw on
very easily. If it is difficult to turn, you are cross threading.
Completely thread the lens shade into the camera to avoid any potential
clearance or sealing problems when the camera is installed and the housing is sealed.
LLCCDD MMOONNIITTOORR // EEXXTTEERRNNAALL MMIIRRRROORR__________________________________________________________________________________
The camera's LCD monitor can be viewed from the rear of the housing, using the
external mirror featured on the side of the housing.
Open the LCD monitor on the camera, rotate 180°, and then press it back against
the side of the camera. The external mirror is hinged so that it can be opened to reflect
the image from the camera's LCD monitor for viewing from the rear of the housing.
During transportation, please remember to close the mirror by pressing it against
the rubber on the lid snap.
BBAATTTTEERR AANNDD TTAAPPEE____________________________________________________________________________________________________________________
Install a fully charged Sony battery on the camera:
Sony NP-FP50, NP-FP60, NP-FP90
Other brand batteries may not fit inside the housing.
Make sure you have loaded an appropriate digital cassette tape in the camera.
OOPPTTIIOONNAALL WWIIDDEE AANNGGLLEE LLEENNSS____________________________________________________________________________________
The housing’s port accepts optional 67mm threaded waterproof Wide-Angle lenses
such as the Ikelite #6420 W-20, Epoque DCL-20 and Inon UWL-100 Type 2 and Sea&Sea
(58070). These waterproof lenses secure to the outside of the lens port.
Should you elect to use the optional Ikelite #6420 W-20, Epoque, Inon or Sea&Sea
lens, carefully thread the waterproof lens on the front of the lens port. The lens threads
are very fine; DDOO NNOOTTcross thread. It should screw on very easily. If it is difficult to
turn, you are cross threading.
IINNTTEERRNNAALL WWIIDDEE--AANNGGLLEE LLEENNSS OOPPTTIIOONN________________________________________________________________________________
Special ports are available for use with the Raynox HD-5050 Pro high definition
wide-angle lens. optional ports sold separately as dome port #9304 or flat lens port
#9304.1. Raynox HD-5050 Pro lens not included. Lens nnoottavailable for purchase
through Ikelite.
External
Color Filter
Internal
Lens Shade

IIMMAAGGEE RREEVVEERRSSIINNGG CCIIRRCCUUIITT____________________________________________________________________________________________________
The image reversing circuit is mounted inside the housing. The circuit reverses
(flips) the image and words on the LCD screen so that when the image is reflected
in the external mirror, it appears correct left-to-right.
Secure the camera to the tray and partially slide the camera and tray inside the
housing so you can then connect the cable from the reversing circuit to the Remote
port on the camera. The reversing circuit will automatically turn ON when connected
to the camera and the camera is ON; the image and words in the LCD screen will
appear in reverse.
OOnn//OOffff SSwwiittcchh
An on/off switch is featured on the reversing circuit. Use the reversing circuit
control on the housing to access the on/off switch on the circuit. The circuit will
automatically turn ON when connected to the camera and the camera is ON.
When turning the camera OFF, there is a 5-minute standby power down delay
on the camera that occurs when the reversing circuit is ON during power down.
Therefore to avoid the 5-minute power down delay, turn the camera OFF and also
turn the circuit OFF to power down the camera immediately.
FFuunnccttiioonnss LLoocckkeedd OOuutt
When the reversing circuit is ON, some camera functions may be locked out. To
correct for such a problem, temporarily turn the circuit OFF, change the function on
the camera, and then turn the circuit back ON.
The camera’s Microphone is also disabled when the reversing circuit is on.
FFIINNAALL PPRREEPPAARRAATTIIOONN__________________________________________________________________________________________________________________
Remove the lens cap and cord from the camera. Otherwise, they may interfere
with the housing seal.
The camera's auto focus feature is utilized underwater. For best results, move in
close to your subject and use the wide angle range to shoot thru as little water as
possible. The full zoom range is accessible underwater.
Turn the camera’s built-in flash OFF. Chart shows recommended initial settings
underwater.
WWHHIITTEE BBAALLAANNCCEE__________________________________________________________________________________________________________________________
Initially set the white balance to Auto. Use the touch screen controls on the
housing to change white balance.
CCoolloorr FFiilltteerr::When using the color filter (during the day), set camera white balance
to Indoor for 0-15 foot depth. For 15-80 foot depth, set white balance to Outdoor.
VViiddeeoo--LLiittee::When using optional Video Lite at NIGHT, set the camera white balance
to the Indoor position. During the DA , use the Outdoor setting for subjects beyond
4-5 feet and the Indoor setting for closer subjects.
CCAAMMEERRAASSEETTTTIINNGG
Power On/Off – Camera (On)
Zoom Lever – Wide Angle Setting
Focus – Auto Mode
Exposure – Auto Mode
Program AE – Auto Mode
Shutter Speed – 1/60 Normal
White Balance – Auto Mode (see section)
Steady Shot – Off
Built-in Flash – Off
IINNSSTTAALLLLAATTIIOONN
CCAAMMEERRAA TTRRAA________________________________________________________________________________________________________________________________
The camera mounts to the tray, which extends from the back plate
of the housing. DDOO NNOOTTremove the tray from the back plate.
Position the camera against the two
stabilizing pins on the tray and secure with
the camera mounting bolt. The camera
should fit easily on the tray and should
be parallel with the sides of the tray.
Make certain that the lens shade has been
threaded completely into the camera to avoid
any potential clearance or sealing problems when
the camera is installed and the housing is sealed.
IINNSSEERRTTIINNGG TTHHEE CCAAMMEERRAA________________________________________________________
Check that the o’ring is clean and properly positioned on the lip of the clear
housing back plate. Check that the lens shade is completely threaded into the camera.
Once the camera is mounted to the tray as shown above, pull the housing
controls out to provide clearance for installing the camera. Partially slide the camera
into the housing so you can connect the reversing circuit cable to the Remote port
on the camera. Make sure the lens shade on the front of the camera fits into the
port recess in the front of the housing.
DDOO NNOOTTforce this installation; the camera and tray should slide easily into place
so the housings back plate o’ring is resting against the main housing body. In this
position the lid snaps can be positioned over the lid hooks on the housing back plate
and snapped into position to seal the housing.
HHOOUUSSIINNGG CCOONNTTRROOLLSS__________________________________________________________________________________________________________________
Slide the housing controls back in place making sure they properly align with the
camera functions.
Operate each control to see how it works with the camera. Some controls such
as start/stop will be used frequently. Other controls may seldom be utilized. Refer to
your camera owner's manual for the proper function of each camera control. Look
thru the back to be sure that you can see into the viewfinder.
When using the housing controls, especially the start/stop, do NOT use excessive force
because you could damage the camera.
CCAAUUTTIIOONN
RReemmoovvee tthhee lleennss ccaapp aanndd ccoorrdd ffrroomm tthhee ccaammeerraa.. OOtthheerrwwiissee,, tthhee ccoorrdd mmaayy
iinntteerrffeerree wwiitthh tthhee hhoouussiinngg sseeaall..
IIff tthhee hhoouussiinngg ccoonnttrroollss aarree nnoott pprrooppeerrllyy ppoossiittiioonneedd,, tthheeyy ccoouulldd iinntteerrffeerree wwiitthh tthhee hhoouussiinngg sseeaall..
MMAANNUUAALL FFOOCCUUSS OOPPEERRAATTIIOONN________________________________________________________________________________________________
Manual focus may be preferred in low light levels or when the subject possesses
little contrast. Set the focus switch to Manual to cancel the auto focus. If you want
to manually adjust the focus, use LCD touch screen. To reactivate the auto focus, set
the focus switch to Auto.
IIKKEELLIITTEE UUNNDDEERRWWAATTEERR SSSSTTEEMMSS
5500 WWeesstt 3333rrdd SSttrreeeett •• PPOO BBooxx 8888110000 •• IInnddiiaannaappoolliiss,, IINN 4466220088 UUSSAA •• 331177..992233..44552233
EEmmaaiill:: iikkeelliittee@@iikkeelliittee..ccoomm•• wwwwww..iikkeelliittee..ccoomm
6038.83-01-0707
Camera Mounting Bolt
Camera Tray
O’ring
Back Plate
Internal Lens Shade
Stabilizing
Pins
