NATHAN JAMES Theo 66501 User manual

Theo Bookcase
Let’s build the
23-0310
60
6
0
M
I
N
U
T
E
A
S
S
E
M
B
L
Y
Scan me!
Free Lifetime
Warranty
SKU 66501

2
This should be easy, just follow
our instructions and you will be
back to Netflix in no time.
Ok, let’s
get rolling
What’s included
What you need
• Some of your favourite bubbly
or your preferred relaxant
• Use the packaging carton as
a working surface to prevent
product damage during assembly
• Phillips head screwdriver
(not included)
• Drill (not included)
• 1/4” Drill bit (not included)
• 5/16” Drill bit (not included)
Description Qty
ABookcase Frame Support
(Top with Wall Mount) 2
B Side Frame Base Support 2
C Open Shelf 3
D Left Back Side Panel 1
E Left Front Side Panel 1
F Right Back Side Panel 1
G Right Front Side Panel 1
H Back Panel 1
I Top Panel 1
J Bottom Panel 1
K Adjustable Shelf for Cabinet 1
L Door 2
60:00
Estimated time for assembly
Scan me!
Free Lifetime
Warranty
Toll-free at 1-866-619-1004
[email protected]
Nathanjames.com/help
366
lbs (max capacity)
75
lbs per
open shelf &
cabinet top
(x4)
Weight Limitation
33
lbs per
adjustable shelf
& cabinet bottom
(x2)

3
The goods
A
E
I
B
F
J
C
G
K
D
H
L

4
What’s included
Description Qty
1 M6*15 mm Bolt 12
2 Knob 2
3 M6*30 mm Cam Bolt 4
4 15*9.5 mm Cam Lock 4
5 M4*40 mm Screw 4
6 M4*20 mm Bolt 2
7M4.2*32 mm Screw
(for Non-drywall Anchor) 2
8 M6*30 mm Non-drywall Anchor 2
9 M8*30 mm Wooden Dowel 16
10 M4*14 mm Screw 16
11 Hinge 4
12 Allen Key 1
13 Metal Shelf Pin 4
14 Drywall Anchor 2
15 M4.2*50 mm Screw
(for Drywall Anchor) 2

5
The goods
IMPORTANT
1. Do not tighten bolts / screws completely until all bolts / screws are lined up and
inserted into holes.
2. Do not over tighten screws and bolts to avoid stripping.
3. Please use hand tools to assemble this product. Do not use power tools.
1
6
11
2
7
12
3
8
13
4
9
14
5
10
15

6
Now insert the Wooden Dowels (9) into the sides of the Left
Back Side Panel (D), Left Front Side Panel (E), Right Back Side
Panel (F), and Right Front Side Panel (G).
Let’s get this thing fired up! Screw the
Cam Bolts (3) into the Top Panel (I).
Step 1
Step 2
I
3
3
9
9
9
9
9
9
9
9
9
9
9
9
9
9
9
9
3
3
D
E
F
G

7
Now let’s put those pieces
together! Align the Left Side
Panels (D)(E) and the Right
Side Panels (F)(G) on top of
the Top Panel (I). The Cam
Bolts you inserted in the last
step should align with the
holes in the side panels. Use
Cam Locks (4) to secure the
panels in place.
Slide the Back Panel
(H) into the groove
in the back of the
cabinet. Next, attach
the Bottom Panel (J) to
the rest of the cabinet
using M4*40 mm
Screws (5).
Step 3
Step 4
DE
F
G
H
4
4
4
4
I
D
F
I
5
5
55J
D E
G
F

8
You’re halfway there!
Screw both Bookcase
Frame Supports
(A) and Side Frame
Base Supports
(B) together using
M6*15 mm Bolts (1).
Line up the bookcase
Shelves (C) and the
Side Supports (A)(B)
and screw together
using M6*15 mm Bolts
(1). Consider this your
workout for the day.
X2
Step 5
Step 6
A
A
B
11
1
1
1
1
1
B
A
1
1
1
C
C
C
EJ

9
Grab a friend and have
them help you lift the
bookcase right side up!
Step 7
IMPORTANT TIP
To prevent parts from breaking while placing
the bookcase unit upright be sure to:
1) Have at least 2 people grab the bookcase
on each side prior to lifting to an upright
position. (Do not grab & move the bookcase by
the top and bottom ends)
2) When rotating the bookcase to an upright
position, try not to use the feet as a pivot point
to avoid applying stress on the components.

10
Ok, we will admit this is our least favorite step also. At
one point, you may find this step tricky but it’s worth the
20 second meltdown—because everything will look SO
clean at the end…you’ll forget all about the assembly!
With that being said, it’s time to attach this baby to
the wall! We’ll be using screws and anchors to secure
it. See the following pages for detailed instructions on
how to do this.
Step 8
Please note...
Part 7 & 8 are for non-drywall
applications. Part 14 & 15 are
for drywall applications.
See following pages for more
details.
14
14
14
8
8
8
7
7
7
15
15
15

11
8
7
Step 8 (cont.)
Non-drywall application
Mark it
Chose your desired location on the wall,
have your friend hold the bookcase in place and
use a pencil to mark where the anchors will go.
1/4” Drill bit
Move bookcase to the side and following the marks you
just made, with a 1/4” drill bit, drill 2 holes into the wall.
Insert the anchors
Go ahead and tap the wall anchors into place in the new
holes that you just drilled.
If you’re feeling strong, just go ahead and push it in.
All about the angle
Insert 1 screw through each metal bracket and
into the drywall anchor. Tilt your phillips head
screwdriver, and secure but do not over tighten.

12
Step 8 (cont.)
Drywall application
Mark it
Chose your desired location on the wall,
have your friend hold the bookcase in place and
use a pencil to mark where the anchors will go.
5/16” Drill bit
Move bookcase to the side and following the marks you
just made, with a 5/16” drill bit, drill 2 holes into the wall.
Insert the anchors
Go ahead and tap the wall anchors into place in the new
holes that you just drilled.
If you’re feeling strong, just go ahead and push it in.
All about the angle
Insert 1 screw through each metal bracket and
into the drywall anchor. Tilt your phillips head
screwdriver, and secure but do not over tighten.

13
Step 8 (cont.)
How to use drywall anchors
1. Drill hole with 5/16” bit
3. Begin tightening 4. Tighten to 100%
2. Pinch and insert

14
If you’re feeling faint, now’s the
perfect time to grab a La Croix or
drink of choice to get you through
these last two steps.
Attach the Hinges (11) to the Doors
(L) with M4*14 mm Screws (10). Do
this for both Doors (L).
Next, insert the Metal Shelf Pins
(13) into the cabinet at your desired
height, then slide the Cabinet Shelf
(K) into place.
Step 9
K
13
L
11
11
10
10
X2

15
Attach the Doors (L) to the base of the cabinet by
securing the Hinges (11) with M4*14 mm Screws
(10). Finally, attach the Knobs (2) to the doors
using M4*20 mm Bolts (6).
This calls for pizza! You deserve it.
Step 10
10
10
10
10
2
6
L
2
L
6
11
11

16
Is your cabinet door looking
crooked or unevenly spaced?
Then you’ve come to the right place. Follow the illustrations below
to get your cabinet door aligned and ready for action.
If your door is too low or too high…
Loosen the height screws, then move the door up or down to make it level.
If the space between your doors is o…
Loosen the side-to-side screws, then screw counter-clockwise
to make the gap wider or clockwise to close any gaps.
If you need to adjust the depth of the doors…
Adjust the in-and-out screws until the door is aligned with the side of the cabinet.

17
Tip from one friend
to another:
If you want to adjust the
height of the shelf position,
remove all metal pins on
either side and then install
the metal pins after you
adjust the height of the shelf.

18
Give us a call 1-866-619-1004 or shoot us a message
at [e-mail] we will issue you a free
replacement with zero hassle.
We really don’t want you to go through the hassle of re-packaging your item
and sending it back, because let’s be honest…nobody has time for that.
No heartburn,
when we handle the return
Our way Their way
Give us a call
Replacement
Replacement
You
Re-package item
Schedule pick up
Track package
You

19
We want your Theo Bookcase with Storage Cabinet to last as long as possible,
so we recommend that you tighten the screws 2 weeks after assembly and for
added safety check the tightness of all screws every 2 months.
For proper care and treatment of wood and metal please check our website
at NathanJames.com/products
DO NOT use for commercial purposes
DO NOT climb bookcase
DO NOT exceed weight limit
DO NOT leave spilled liquid on shelves
DO NOT use bookcase if damaged
DO NOT make temporary repairs
DO NOT use outdoor
Proper use
Safety rst, fun later
Safe use of this product
starts with you.
Use this bookcase responsibly with the primary
concern for your safety. Follow assembly
instructions carefully and inspect product upon
receipt and each use.
Nathan James and its parent companies cannot
be held legally responsible for any injuries
or death resulted from failure to follow
instructions or improper use of this product.
Do not modify the
structure of this
product in any way.
Our products have been tested to meet specific
safety measures as they were originally
intended to be sold. Any modifications will
present the risk of creating significant safety
issues which NJ will not be responsible for.

20
Brooklyn Burdon
Founder, Nathan James
Did we do alright? Please spread the love!
If you are happy with your product, tell your friends
and family about us or even better leave us a review
online. Spreading the word gives us the opportunity
to make more people happy and keep our
prices low for your next purchase.
We are only in business
if you’re happy
For starters, thanks for being you.
Toll-free at 1-866-619-1004
[e-mail]
NathanJames.com/help
We do our best to ensure your furniture arrives without any problems, but occasionally mistakes
happen—as humans we are imperfect beings. In the event that a part is damaged or missing, we
will be more than happy to provide you with replacement part(s) for free.
Warranty
This product comes with a lifetime warranty from the date of purchase. Please use your phone to
scan the QR code to register your product or visit https://goo.gl/i9dk3q
