iLoq K55S User manual

Document ID
238126
05/2023
Rev 1.0
iLOQ Oy
www.support.iloq.com
K55S Key Fob
User Guide
iLOQ K55S Key Fob

1. Contents ................................................................................................................. 2
2. Safety Information.................................................................................................. 3
2.1 Safety signs .................................................................................................... 3
2.2 Warnings......................................................................................................... 3
6. Overview ................................................................................................................. 4
7. Care and Maintenance .......................................................................................... 4
3. Before the first use................................................................................................. 5
4. Operating instructions of the K55S.1 Key Fob .................................................... 5
4.1 LED functions in the K55S.1 Key Fob........................................................... 6
4.2 Charging the K55S.1 Key Fob....................................................................... 7
4.3 Battery charging specifications .................................................................... 7
4.4 Programming the K55S.1 Key Fob ............................................................... 7
4.5 Fob App.......................................................................................................... 7
4.6 AK50.1-AK50.9 Color Markers ...................................................................... 7
5. Disposal of Decommissioned Products ............................................................... 8
8. Compliance ............................................................................................................ 9
1. Contents
2
K55S Key Fob
User Guide
K55S Key Fob

2. Safety Information
2.1 Safety signs
Sign Description
General notice sign. Indicates particularly important
information about the installation and deployment.
Read these instructions carefully before using products.
This information is to ensure your safety and long
lifetime of the products.
2.2 Warnings
Sign Description
Warning! K55S / P55S contains a non-replaceable rechargeable
battery. Disposal of a battery into fire or a hot oven, or
mechanically crushing or cutting of a battery can result in an
explosion.
Warning! Leaving a battery in an extremely high temperature
environment can result in an explosion or the leakage of
flammable liquid or gas.
Warning! A battery subjected to extremely low air pressure may
result in an explosion or the leakage of flammable liquid or gas.
3
K55S Key Fob
User Guide
K55S Key Fob

3. Overview
The iLOQ K55S.1 Key Fob is a programmable device for opening doors equipped with iLOQ 5 Series
locking systems. The K55S.1 Key Fob is reusable and can be reprogrammed for use in a different system
after being reset to the factory settings.
4. Care and Maintenance
• The product is designed to be maintenance-free. It does not require any regular maintenance.
• Do not use the K55S.1 Key Fob for other purposes except those mentioned in these instructions.
• Using the K55S.1 Key Fob for other purposes may damage it.
• The K55S.1 Key Fob is to be kept secure so that only an authorized person can use it.
• In case of losing the K55S.1 Key Fob, contact the administrator of the locking system. Block listing
of the lost K55S.1 Key Fob is done with the iLOQ Manager software. The affected locks are then
reprogrammed.
• Maximum temperature range for use: -20 - +60C
• Maximum temperature range for charging: 0 - +45C
• Ingress protection rating: IP68. Keep the K55S.1 Key Fob clean and dry. If the K55S.1 Key Fob is wet or
dirty, use a soft cloth for drying and cleaning.
• For more detailed technical information, see the K55S.1 Key Fob datasheet.
• The K55S.1 Key Fob is an electronic product including a Lithium Ion rechargeable battery.
Appropriate recycling as WEEE waste must be followed.
• For customer claims, technical support etc, please contact your administrator. Your
administrator will contact the appropriate iLOQ partner for support.
• Recharge the K55S.1 Key Fob if operation is abnormal. During charging, the K55S.1 Key Fob resets.
If abnormal operation continues, contact the locking system administrator.
• You can update the K55S.1 Key Fob data and time using the iLOQ Fob App application.
4
K55S Key Fob
User Guide
K55S Key Fob

5. Before the first use
To ensure correct operation, charge the K55S.1 Key Fob before the first use.
6. Operating instructions of the K55S.1 Key Fob
1. Touch the iLOQ Reader Knob or iLOQ Online Reader with the bottom of the K55S.1 Key Fob to
activate the lock.
2. Wait until the K55S.1 Key Fob shows a green light to indicate that the cylinder is unlocked.
The K55S.1 Key Fob shows an amber light while communicating.
5
K55S Key Fob
User Guide
K55S Key Fob
If access is denied, the
K55S.1 Key Fob will show
a red light.
Check your access rights
with the locking system
administrator.

3. Turn the iLOQ Reader Knob to operate the lock (open or close).
6.1 LED functions in the K55S.1 Key Fob
Light indicators Description
• Amber light while programming • Key Fob communicating with lock.
• Green light after amber • Access granted. Lock can be opened or closed.
• Red light after amber • Access denied.
• Red blinks once a minute for 0.1 seconds • Battery empty. Charge battery.
• Red blinks quickly twice a minute for 0.1 seconds • Key Fob is missing valid time, contact
administrator.
• Blue light • Key Fob communicating with Fob App
6
K55S Key Fob
User Guide
K55S Key Fob
After 5 to 15 seconds, the cylinder will
automatically be locked. When the cylinder
is locked, the iLOQ Reader Knob cannot be
rotated.
When locking a door, try to rotate the iLOQ
Reader Knob clockwise and counterclockwise to
make sure that the knob is in the locked position
and the door remains closed.

6.2 Charging the K55S.1 Key Fob
To charge the K55S.1 Key Fob, use the USB Micro-B connector.
6.3 Battery charging specifications
Unit Value
• Voltage • 5 V
• Current • 100 mA
• Charging time • 3 hours
• Capacity • 150 mAh. Full battery has nominal capacity for
5000 lock openings at room temperature.
Light indicator Meaning
• Solid red light • Battery charging
• Solid green light • Battery fully charged
6.4 Programming the K55S.1 Key Fob
A K55S.1 Key Fob can be programmed by the locking system administrators. Contact the administrators if you
need to have your access rights changed. Also contact the administrators if you lose your K55S.1 Key Fob.
This is important so administrators can block list your lost K55S.1 Key Fob to prevent unauthorized access.
6.5 Fob App
The iLOQ Fob App can be used to update the K55S.1 Key Fob data and time. The Fob App can be freely
downloaded from app stores and used without credentials. The Fob App connects to the K55S.1 Key Fob
with Bluetooth. More information can be found from the Fob App user manual.
6.6 AK50.1-AK50.9 Color Markers
• The AK50.1-AK50.9 Color Markers can be used to personalize K55S.1
Key Fobs. To replace the Color Marker, remove the old one with a suitable
tool and replace it with a new one.
7
K55S Key Fob
User Guide
K55S Key Fob

7. Disposal of Decommissioned Products
Never discard an electrical appliance in household waste. Follow
the local laws and regulations for safe and environmentally friendly
product disposal.
Before discarding products, bear in mind that most iLOQ products
are reusable. All programmable products can be reset to factory
settings, after which they can be reused in another system.
Recycling instructions of decommissioned products are depicted below.
Decommisioned product Sorting
Decommissioned iLOQ fittings, mounting accessories and thumb
turn knobs can be recycled as scrap metal.
Decommissioned iLOQ products containing electronics and circuit
boards, such as iLOQ Lock Cylinders, keys, net bridges, door
modules, key and RFID readers, and relay cards, must be recycled
at an electrical and electronic equipment collection point.
iLOQ products containing batteries and accumulators, such as key
fobs, programming keys and clock circuits, should be recycled at a
regional collection point for batteries and small accumulators.
Most iLOQ packaging materials are suitable for cardboard and
plastic recycling.
8
K55S Key Fob
User Guide
K55S Key Fob

8. Compliance
The products mentioned inside this user guide are in conformity with the requirements of the directives
declared on this page.
CE
SIMPLIFIED EU DECLARATION OF CONFORMITY:
Hereby, iLOQ Oy declares that the radio equipment type H50S Padlocks are in compliance with Directive
2014/53/EU. The full text of the EU declaration of conformity is available at the following internet address:
https://www.iloq.com/en/company/patents-and-approvals/
Communication standard: NFC 13,56 MHz Load modulation (ASK) ISO/IEC 14443A, no transmitter.
FCC
This device contains licence-exempt transmitter(s)/receiver(s) that comply with Innovation, Science and
Economic Development Canada’s licence-exempt RSS(s) and complies with part 15 of the FCC Rules.
Operation is subject to the following two conditions:
1. This device may not cause harmful interference.
2. This device must accept any interference received, including interference that may cause undesired
operation of the device.
Note: This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
• Consult the dealer or an experienced radio/TV technician for help.
The radiated output power of the device in Bluetooth mode is far below the Health Canada’s RF exposure
guideline, Safety Code 6 and in FCC 47 CFR part 2 (2.1093) radio frequency exposure limits. The maximum
Specific absorption rate is 0.03 W/kg. Nevertheless, the device should be used in such a manner that the
potential for human contact during normal operation is minimized.
9
K55S Key Fob
User Guide
K55S Key Fob

10
K55S Key Fob
User Guide
K55S Key Fob
Changes or modifications made to this equipment not expressly approved by iLOQ Oy may void the FCC
authorization to operate this equipment.
System Frequency Maximum SAR ERP output Power EIRP output power
[dBm]
• Bluetooth • 2402 – 2480 MHz • 0.68 mW (-1.65
dBm) • 1.12 mW (0.5 dBm)
• NFC • 13.56 MHz • 0.03 W/kg
(SAR1g)
UKCA
Hereby, iLOQ Oy declares that the radio equipment type H50S Padlocks are in compliance with the UK
relevant statutory requirements. The full text of the declaration of conformity is available at the following
internet address: https://www.iloq.com/en/company/patents-and-approvals/
