ILVE ROMA Series User manual

EN
cod. EI33960160000EN
35/2019
RANGECOOKER
USER MANUAL 2019
ROMA - MILANO - MAJESTIC ROMA - MAJESTIC MILANO
06 - 07 - 08 - 09 - 10 - 12 - 15
INSTALLATION AND MAINTENANCE
Appliance details Make a note of these important details here, you will need them for your warranty
Serial number
Date of purchase Retailer

3
USER
INDEX
IMPORTANT SAFETY WARNINGS
First system startup of the oven
Models with Induction
Read carefully before using
Using the appliance
Pracautions
In case of malfunction
INSTRUCTIONS FOR USE
First system startup of the hob
Use of a griddle pan
Positioning placement of the burners
Use of the Coup de Feu
Use of fry-top a gas
Use of the inductive electric plate
Use of the 2 Zone Induction
Use of the multifunction electric oven - MP Models
Use of the multifunction electric oven - MP Models
Functions list
Use of the conventional electric oven - MP Models
Functions list
MP models with 5 key programmer MP
5-button electronic programmer E3
Display TFT touch - Icons legend
Display TFT touch - Settings
Mod. multifunction oven E3 with TFT touch
Cooking function setting
Mod. multifunction oven E3 with TFT touch
Cooking process
5
11
12
12
13
14
15
16
16
18
19
20
21
22
25
25
32
33
34
35
39
42
43
44
Mod. multifunction oven E3 with TFT touch - Fun-
ctions list
Mod. oven static with TFT touch - Functions list
Optional
CLEANING AND MAINTENANCE
Replacing the bulb
Door removal
Cleaning the door and glasses
Recommendations for cleaning the hob top
Recommendations for cleaning the oven and the
front panel
Maintenance and cleaning of total black burners
with nanotechnological coating
PROBLEM SOLVING
Guide for the resolution
Induction Hob Malfunction
TFT display errors
Child Lock
COOKING CHART
NOTES
45
46
47
48
48
49
50
51
52
53
54
54
55
56
57
58
62

4

5
USER
IMPORTANT SAFETY
WARNINGS
As well as being shown on the packaging, the data plate is
applied to the oven door frame and is visible with the door
open.
These warnings refer to different types of appliances. Pay
attention in properly identifying the type you own (see the
data plate).
These warnings are valid for the countries mentioned in
the plate.
Before using the cooker, read the instructions booklet care-
fully. This contains very important information concerning
safety during installation, use and maintenance.
The instructions booklet must be kept with care for later
consultation.
The electrical safety of this cooker is guaranteed only if it is
correctly earthed and installed by a qualied installer. The
manufacturer is not responsible for damage caused by an
incorrect installation.
Before powering the appliance, check that the techni-
cal features shown on the data plate match those of
the electrical system perfectly. Installation / regulation
must be carried out by qualied personnel.
All gas appliances must conform to current gas safe
regulations.
Appliances’ data
CAUTION
1
2
3
4

6
IMPORTANT SAFETY
WARNINGS
When using a gas appliance, heat and dampness are ge-
nerated inside the kitchen. A good aeration of the kitchen
must be guaranteed by keeping the natural aeration vents
open or by installing a cooker hood. An intensive and pro-
longed use of the appliance may result in the need of sup-
plementary aeration, such as opening a window or incre-
asing the power of the hood. An intensive and prolonged
use of the appliance may result in the need of supplemen-
tary aeration, such as opening a window or increasing the
power of the hood (if present).
The installation cable is supplied without a plug and needs
to be installed to a suitable termination block (cooker out-
let) in accordance with IE regulations.
When the appliance is not in use for a prolonged time, di-
sconnect the electric power, switch off the main switch and
turn off the gas.
Do not block ventilation or heat dissipation slits.
If the power cable is damaged it must be replaced exclu-
sively by a service center approved by the manufacturer.
The appliance must be used only for the purposes for whi-
ch it was intended. Any other use (for example, heating
a room) is incorrect and therefore dangerous. The manu-
facturer declines all responsibilities for damage caused by
similar incorrect uses.
The appliance is not destined to be activated by means of
an external timer or a remote control.
5
6
7
8
9
10
11

7
USER
IMPORTANT SAFETY
WARNINGS
The use of any electrical appliances requires that a
number of fundamental rules must be respected:
A. Never touch the appliance when you have wet or damp
hands or feet;
B. Never use the appliance barefoot;
C. The installation cable is supplied without a plug and ne-
eds to be installed to a suitable termination block (co-
oker outlet) in accordance with IE regulations;
D. Do not expose the appliance to atmospheric agent-
s(rain, sun, etc...);
E. Be careful: accessible parts can become very hot
during the use.
Keep children less than 8 years old far from the cooker
if it is not continuously watched. This appliance may be
used by children of 8 years of age or older, by people
with reduced physical, sensory or mental abilities, or
with lack of experience and knowledge only if they are
under adequate surveillance or if they have been ade-
quately instructed about the use of the cooker and if
they are aware of the possible dangers. Children must
not play with the cooker. The operations of cleaning and
of maintenance must not be made by children without
surveillance.
CAUTION: During the use of the appliance some parts
may become very hot. Keep out of reach of children.
Absolutely do not touch the elements inside the oven
during the use.
12
13
14

8
IMPORTANT SAFETY
WARNINGS
Before cleaning the appliance or carrying out maintenan-
ce, disconnect the power supply by switching off the cooker
control switch.
In case of breakdown or malfunction, switch off the
appliance and do not attempt any repairs. Repairs
must only be performed by an authorized service cen-
ter. Always request original parts. Failure to comply
with these instructions may compromise the applian-
ce’s safety.
Never place unstable or deformed pans on the bur-
ners or on the electric hotplates as they could topple
accidentally.
When the appliance is not being used, make sure the
knobs are exactly in the “ ”/“ ”/ position.
Don’t leave the hotplate on with no pans on it, as it
would reach the temperature fast and possibly dama-
ge the appliance and your countertops.
The electric plates remain hot after using them. Be careful
not to touch them.
Inammable liquids, like alcohol or gasoline, must be
kept away from the appliance.
Should you use small household appliances near the
cooking top, please make sure that the electrical cable
is not in contact with hot parts of the appliance.
To ensure correct function of gas appliances, make
sure that the room is correctly ventilated and installa-
tion is carried out by qualied gas safe technicians in
accordance with current regulations.
15
16
17
18
19
20
21
22
23

9
USER
IMPORTANT SAFETY
WARNINGS
The materials used in producing our appliance are compa-
tible with the environment and therefore recyclable.
The packaging waste must not be left within reach of
children, and must be disposed by using the appropria-
te recycling channels. To scrap your appliance, use your
retailer and/or your local council’s facilities; remember to
make your appliance unusable before scrapping it.
If the rotation of the gas knobs is difcult, don’t do anything.
Close off the gas and call the After Sales Service for advi-
ce.
Do not use a steam cleaner to clean the inside parts of the
oven.
Don’t use any abrasive detergent or sharp device to clean
the oven glass door. This may cause damage or breakage.
Don’t modify the appliance.
Be careful: fat spillage, objects or oils on the appliance
may cause a re.
The appliance must be used by responsible people
Be careful: the use of inappropriate or unsuitable pro-
tections such as tin foil can cause res and/or damage.
Be careful: cooking with fat or oil can be dangerous or
cause res.
Fire danger: do not store items on the cooking surfaces.
Be careful: in the case of re never attempt to extin-
guish a ame/ re with water, but turn the appliance
off and cover the ame with a lid or with a reproof
cover.
24
25
26
27
28
29
30
31
32
33
34

10
IMPORTANT SAFETY
WARNINGS
Be careful: do not use gas burners if the ame is un-
stable.
Ensure that the ame diffusers are properly positioned in
their seats with their respective caps.
Do not leave the cooker unguarded during any cooking
that can spit fats or oils.
Do not touch the heating elements while the appliance is
on. Let it cool down before cleaning.
Do not use plastic or foil on the hot cooking zones.
Do not cover the burners or the hob with tinfoil.
Do not use the appliance’s surface as a work top, sharp
objects might scratch it.
Be careful: do not use frying pans, saucepans, grills or
stones for grilling of a greater size than the maximum ones
indicated for each single burner; above all they must not
cover more than one burner at the same time.
The heat accumulation might damage the cooker.
In case of liquid spilling over, remove it from the hob.
Do not place empty saucepans on the cooking areas.
The cooking areas, must not work empty, without saucepans.
35
36
37
38
39
40
41
42
43
44
45

11
USER
When using the oven for the rst time, let it work empty for
about 1 hour (200 °C on the Roasting Oven setting), pos-
sibly leaving the kitchen windows open and with the range
hood on.
When you rst turn the oven on, a bad smell is emitted due
to production residues such as grease, oils or resins.
When the oven has cooled clean it following the instructions
in the «Cleaning and care section».
After the indicated time the oven is ready to perform its rst
cooking.
IMPORTANT SAFETY
WARNINGS
First system
startup of the
oven

12
• Only qualied technicians should install the appliance.
The technician will not be held responsible for any da-
mages caused by electrical malfunctions.
• The hob must be installed in the appropriate inset.
• The appliance should be used solely for cooking foods,
excluding any other domestic or industrial uses.
• Remove the adhesive labels from the glass on the hob.
• Do not modify or alter the appliance.
• Do not use the hob as a worktop.
• The appliance must be connected and installed in com-
pliance with current local regulations.
• Do not use extension cables for connections.
• This appliance is not intended for use by persons (inclu-
ding children) with reduced physical, sensory or men-
tal capabilities, or lack of experience and knowledge,
unless they have been given supervision or instruction
concerning use of the appliance by a person respon-
sible for their safety. Children should be supervised to
ensure that they do not play with the appliance.
• WARNING: Accessible parts may become hot during
use. To avoid burns young children should be kept away.
IMPORTANT SAFETY
WARNINGS
Models with Induction
Read
carefully
before using

13
USER
• After use, turn off the cooking zone.
• Make sure that fatty substances and oil do not dirty the
appliance’s surfaces.
• WARNING: during and after use, the hob’s surface will
be very hot.
• Make sure that the power cable does not come into con-
tact with the glass or a pot.
• Magnetized objects such as credit cards, oppy disks,
and calculators should not be placed near the appliance
when it is being used.
• Do not use any type of metallic object except the pots
used for induction.
• Do not cover the cooking zone with inammable mate-
rials.
• The appliance should only be used by capable person-
nel.
• Keep children away from the appliance.
• Metallic objects such as knives, spoons, forks or lids
should not be placed on the hob as they can become
overheated.
• Caution: The appliance is not designed to operate with
an external timer or a remote control system
• Warning: Do not use steam appliances to clean the hob
IMPORTANT SAFETY
WARNINGS
Models with Induction
Using the
appliance

14
Precautions
• Unsuitable pots could ruin the surface of the hob.
• Do not use abrasive substances to clean the appliance.
• Avoid dropping heavy objects on the hob.
• Place pots on the hob delicately.
Make sure that the appliance’s ventilation complies with
the instruction manual.
IMPORTANT SAFETY
WARNINGS
Models with Induction

15
USER
• When a malfunction occurs turn off and disconnect the
appliance.
• If cracks appear on the hob top glass or it is broken,
disconnect the appliance and contact your authorized
service centre.
• Any repairs should be made by authorized personnel.
• Make sure that the pot is in the middle of the cooking
zone. Ideally, the bottom of the pot should cover the en-
tire cooking zone.
• The magnetic eld produced by the induction hob could
affect the proper working of pacemakers. Detailed infor-
mation should be obtained from your doctor.
• Avoid placing synthetic materials or aluminium objects
in contact with the cooking zone.
In case of
malfunction
Suggestions
IMPORTANT SAFETY
WARNINGS
Models with Induction

16
Keep children away during the operation of the gas hob. Do not use the appliance as a
heating source.
To keep the appliance efcient and safe, maintenance must be entrusted to specialized
technicians or to the after-sales service staff.
Choose pans with lids to increase energy efciency and use the correct sized pan based
on the quantity of food to cook.
Position the ame divider “b” correctly. To do this, align the 4 teeth “c” of the ame
divider with the recess “d” of the aluminium Cup “a”.
The index above the knobs will help you to nd the corresponding burner. Press the
knob by turning it anti- clockwise and bring it to the ignition position; keep the knob
pressed for about 5 seconds so that upon its release the ame remains alight (in case
of unsuccessful ignition repeat the operation).
BE CAREFUL
General notes
IMPORTANT
Lighting the burners
Symbol Function
off
maximum
minimum
index
INSTRUCTIONS FOR USE
First system startup of the hob
●
●
●
b
a
b
c
d

17
USER
Identify the knob with the help of the index near the knobs. Press and turn the knob to
the symbol (maximum) for 5 seconds. Once the burner is on, by turning the knob coun-
terclockwise it gets to its rst block that corresponds to the middle middle ring.
By applying a bit of force, the rst block is exceeded and the outer ring goes out leaving
only the little central burner turned on called AUXILIARY. To adjust the auxiliary burner
on minimum, rotate the knob counterclockwise until it stops. At this point, to turn the
burner back on, rotate the knob clockwise up to the desired value.
Recommended pans ac-
cording to burner size:
Burner ignition of Triple
Ring DUAL burners.
Symbol Function
off
maximum
minimum
index
INSTRUCTIONS FOR USE
First system startup of the hob
●
●
●
●
●
Burners ID Diameter of pan Ø (cm)
Medium SR 10/20
Large R 20/24
Fish Burner P Oval pans (380 x 185)
Wok TC/DCC 22/28
Dual Ring DUAL 24/30

18
If you want to use a griddle pan a few things must be taken into account:
- it is possible to preheat the grid on the burner’s maximum power for no more than 10
minutes;
- we recommend cooking foods with reduced power;
- keep at least a distance of 150 mm from the side wall to the griddle pan’s rim;
- do not position the griddle pan on more than one burner at the same time.
Griddle pan
Correct
Be careful: wrong
Be careful: wrong
INSTRUCTIONS FOR USE
Use of a griddle pan

19
USER
INSTRUCTIONS FOR USE
Positioning placement of the burners
BE CAREFUL: always check that the burners are properly positioned, with a uniform
ame that is not noisy.
RIGHT WRONG
Positioning of the
burners
BURNERS
Medium
Large
Dual Ring
Fish burner
Always check that the
screws below the burner
are xed

20
The large “Coup de Feu” solid cast iron plate made of concentric rings allows you to rest
the pan (or even several pans) directly on the surface (g. B, C). It is heated by means of
a gas burner (g. A). The plate is designed to provide a moderately intense heat which
is well distributed over the surface.
This is ideal for slow cooking and particularly for sauces, browning and grilling, heating
dishes or keeping them warm. Switch the burner on 15/20 minutes before use to allow
the cast iron plate to accumulate heat.
You will then be able to use the plate even when switched off for a further 10/15 minutes.
The middle of the plate is the area where the highest temperatures are reached where-
as the outer part is cooler. By simply moving the pan from the middle to the outside of
the plate, you can obtain different cooking intensities without regulating the ame. Pan
dimensions permitting, several dishes can be cooked at the same time (g. C). If neces-
sary it can be used as a handy top, providing ample space for resting pots and pans.
The hotplate should be cleaned while still warm using the products normally used in the
kitchen for metal surfaces. Rub with a wire pad, following the direction of the satin nish.
Dry well immediately. If you want to give the plate a better appearance, after cleaning,
apply a coat of a specialist cleaning paste / cream.
The hotplate may sometimes present phenomena of surface oxidation due to the pre-
sence of humidity, but above all due to lack of use. You are therefore advised to use
it frequently to prevent any oxidation. Never leave the hotplate damp. If the oxidation
phenomenon still appears, use lightly abrasive paper to remove the oxidation, taking
care to rub gently, always in the direction of the plate satin nish.
Do not cook food directly on the plate surface. Always use suitable containers.
COUP DE FEU
Operation of the
appliance
Cleaning the Coup de
Feu plate
INSTRUCTIONS FOR USE
Use of the Coup de Feu
Fig. A Fig. B Fig. C
