ILVE ULTRACOMBI Operating instructions

ULTRACOMBI
Tri-mode oven
hot air - steam - microwave
cod. EI33960050000EN
11/2018
INSTALLATION,
USER AND MAINTENANCE INSTRUCTIONS
EN

2
INDEX
IMPORTANT SAFETY WARNINGS
ELECTRICAL CONNECTIONS
INSTALLATION INSTRUCTIONS
PRODUCT DESCRIPTION
Supplied Accessories
Cooking Accessories
INSTRUCTIONS FOR USE
Display TFT:
Icon legend
First start of the oven
Settings
Screen lock
Turning the oven on and off
Setting the cooking function
Functions listi
Setting the cooking function
Cooking process
Cooking function setting
Cookware / Material
Steam cooking
CLEANING - CARE - MAINTENANCE
Cleaning
Emptying and Washing the tank
PROBLEM SOLVING
Error messages
3
13
15
16
17
19
21
21
21
22
23
24
25
26
27
28
29
30
31
32
33
34
38
39
39

3
IMPORTANT SAFETY WARNINGS
As well as being shown on the cover, the data plate is ap-
plied to the oven door frame and is visible with the door
open.
These warnings refer to different types of appliances. Pay
attention in properly identifying the type you own (see the
data plate).
These warnings are valid for the countries mentioned in
the plate.
Before using the cooker, read carefully the following in-
structions and keep in a safe place for future reference.
This multifunction oven complies with current statutory sa-
fety standards. Inappropriate use can, however, lead to
personal injury and material damage.
I.L.V.E. SpA cannot be held liable for any damages cau-
sed by failure to observe these instructions for safety and
warnings.
NOTE: This oven has been designed to defrost, reheat and
cook foodstuff in domestic households and residential en-
vironments. The multifunction oven is intended exclusively
for residential use and must always be operated for its
intended purpose: it must not be modied or tampered
with in any way.
Any other usage is not allowed and could be dangerous.
It is not intended for use outdoors.
Persons who lack physical, sensory or mental abilities or
experience with the multifunction appliance , so that they
cannot safely operate it, should not use it without supervi-
sion or instruction by a responsible person.
It is important that they recognise and understand the
dangerous consequences of incorrect operation of the
appliance.
Appliances’ data
CAUTION
INTENDED USE
1
2

4
IMPORTANT SAFETY WARNINGS
PRECAUTIONS TO AVOID POSSIBLE EXPOSURE TO EXCESSI-
VE MICROWAVE ENERGY
Do not attempt to operate this oven with the door open
since open-door operation can result in harmful exposure
to microwave energy. It is important not to damage or
tamper with the safety interlocks
Do not place any object between the oven front and the
door or allow soil or cleaner residue to accumulate on the
sealing surfaces.
WARNING: Do not operate the oven if it is damaged. It is
particularly important that the oven door closes properly
and that there is no damage to the (1) door (bent), (2)
hinges and latches (broken or loosened), (3) door seals
and sealing surfaces. If the door and the sealing gaskets
are damaged, the oven shall not be used until repaired
by a properly qualied service technician ( trained by the
manufacturer or by the Customer Service ).
WARNING: It is dangerous for anyone without suitable trai-
ning to perform maintenance and repair operations re-
quiring removal of any casing or barrier against exposure
to microwaves. During installation, maintenance and re-
pair work, the appliance must be disconnected from the
mains electricity supply. Never open the casing of the ap-
pliance. Tampering with electrical connections or com-
ponents and mechanical parts is highly dangerous to the
user and can cause operational faults.
ATTENTION: Do not heat liquids or other foods in sealed
containers, jars or bottles because they could explode.
This appliance must be used only in a domestic hou-
sehold. The mains supply must be tted with all devices
required
3
4
5
6
7

5
IMPORTANT SAFETY WARNINGS
by the statutory rules of installation.
When the oven is operated in microwave mode it is inten-
ded to heat food and drinks. Do not use the microwa-
ve mode for drying owers, herbs, bread, rolls or other
ammable materials like sponges, slippers, cushions or
pads lled with cherry kernels, wheat grain, lavender or
gel, such as those used in aromatherapy. When heated,
these pads could catch re and cause injury by burning
even after they have been removed from the oven.
If smoke is observed do not open the oven door: swi-
tch the appliance off and disconnect it from the mains
electricity supply. Do not open the door until the smoke
has dispersed to stie any ames.
- Activate the system lock to ensure that children cannot
switch on the multifunction oven inadvertently
- Supervise the children if they are in close vicinity to the
multifunction oven. Do not allow them to play with the
appliance.
-Danger of suffocation.
Packaging, e.g. plastic wrappings, must be kept out of
the reach of babies and children. Whilst playing, children
could become entangled in packaging or pull it over their
head and suffocate. Keep children away from this kind of
materials.
-Danger of burning.
Children’s skin is far more sensitive to high temperatures
than that of adults. The door surface, the control panel
and the ventilation openings get hot. Make sure that chil-
dren do not attempt to open the door when the applian-
ce is in operation. Keep children well away from the ap-
pliance until it has cooled down and there is no danger
of burning.
CHILDREN
8
10
9

6
Danger of injury.
The door can support a maximum weight of 8 kg. Do not
let children sit on the door, lean against it or swing on it.
They could injure themselves
ATTENTION. Accessible parts may get very hot during ope-
ration.
Children under 8 years of age must be kept away from
the appliance unless they are constantly supervised.
The appliance may be used by children 8 years and ol-
der and by persons who lack physical, sensory or mental
abilities or experience with the multifunction appliance ,
with supervision or instruction by a responsible person. It is
important that they recognise and understand the dan-
gerous consequences of incorrect operation of the ap-
pliance. Children must not play with the appliance. Chil-
dren must not be allowed to clean the oven unsupervised
ATTENTION: when the appliance is operated in combina-
tion mode children should use it under adult supervision,
because of the high temperatures that will develop.
Do not attempt to operate the oven with the door open,
tampering with the safety interlock switches. Do not ope-
rate the oven if any kind of objects get trapped between
the door and the oven front plate. Always keep the inner
side of the door clean(J) using a damp cloth and non
abrasive cleaners. Don’t let food residues accumulate
between the mating surfaces of the door and the oven
front plate.
Do not operate the oven if the mains supply cable or the
plug are damaged, because this could cause an electric
shock. If the mains supply cable is damaged, it must be
replaced by the manufacturer’s customer service or by a
qualied person, in order to avoid any risk.
IMPORTANT SAFETY WARNINGS
11
12
13

7
To avoid overheating and the following risk of a re, it is
recommended to attend the oven when cooking food-
stuff in disposable containers made of plastic, cardboard
or other ammable material, or when small quantities of
food are reheated
Do not put very cold dishes or food directly onto the inner
door glass when it is hot: the thermal shock could make it
crack.
When the oven is operated in “Microwave only” mode,
it must not be preheated without a food load inside the
cavity, nor shall it be turned on empty, because arcing
could be generated.
Before starting the oven, make sure that the utensils and
containers are suited for microwave operation ( see the
relevant page: “Containers for different cooking modes”).
The appliance gets hot during use. Do not touch the hea-
ting elements inside the oven cavity.
When reheating liquids ( water, coffee, milk , etc.) it is pos-
sible that, due to “delayed boiling”, the liquid reaches a
temperature higher than the boiling point, so that – when
removing the container- it can form eruptive bubbles and
cause injuries to the user. To avoid this, always place a
glass or plastic utensil ( e.g. a spoon) into the cup or con-
tainer. Care should be taken when handling the contai-
ner.
Do not reheat liquors or spirits, nor big quantities of oil, be-
cause they could catch re.
After reheating baby milk or food ( in bottles or jars) sha-
ke or stir thoroughly and check the temperature to avoid
scalding. The temperature of the container is not an in-
IMPORTANT SAFETY WARNINGS
14
15
16
17
18
19
20
21

8
dication of the temperature of the food or liquid in it. It is
recommended to stir and shake the food also in order
to ensure a uniform temperature. When using commer-
cially available baby bottle sterilisers, always check that
the containers are lled with the correct quantity of water
indicated by the manufacturer.
Do not use steam cleaners to clean the inside of the ap-
pliance.
Do not use abrasive cleaners or sharp metal tools to cle-
an the door glass. They could scratch the glass surface
and result in cracking it.
All microwave ovens are tested and certied in complian-
ce with the latest safety and electromagnetic compatibi-
lity standards . However, as a precaution, manufacturers
of pace-maker devices recommend to keep a minimum
distance of 20- 30 cm between an operating microwa-
ve oven and the pace-maker, in order to avoid any in-
terference to the pace-maker device. If for any reason
there should be a suspect of interference, immediately
switch the microwave operation off and contact the ma-
nufacturer of the pace-maker.
In case of overheating of the appliance ( prolonged use,
use without load, etc.) the oven could be switched off by
a safety thermostat. After cooling down the oven will resu-
me its regular operation.
When the appliance is operating, the door and the ac-
cessible surfaces may become hot.
IMPORTANT SAFETY WARNINGS
22
23
24
25
26

9
Do not cook or reheat eggs in their shells using microwave
power, because they could explode even after the co-
oking has ended.
For safety reasons, this multifunction oven may only be
used when it has been built in. This is necessary to ensure
that all electrical components are shielded.
This multifunction oven must not be used in a non-statio-
nary location (e.g. on a ship).
Oils and grease could easily catch re if overheated.
Always supervise the appliance when using oils and gre-
ase. Never attempt to extinguish with water burning oils
and grease. Switch off the appliance and stie the a-
mes carefully using a lid or with a special re-safe blan-
ket. Flammable objects situated in the vicinity of the oven
may start burning if exposed to high temperatures. Do not
use the appliance to heat the ambient.
Plastic cutlery or dishes not suited for microwave energy
could melt due to the high temperatures reached, and
may burn and damage the oven. Only use dishes suited
for use with microwave power. Follow the directions provi-
ded by the manufacturer: when using plastic dishes inside
the oven, plase make sure that they resist to heat and
steam. If they are not, they could melt or be damaged.
Be aware that cooking, reheating and defrosting times
when using microwave power are often considerably
shorter than when using conventional functions. Too long
heating times lead to food desiccation and a possible
combustion.
IMPORTANT SAFETY WARNINGS
28
29
30
31
27

10
Cleaning
Lamp 33
32 • The appliance must be cleaned regularly and any
food residues must be removed. Failing to clean the
oven may cause deterioration of the surfaces. This can
have a negative effect on the durability of the applian-
ce and cause possible risk situations. Clean the oven
interior, inside of the door and door seal as soon as the
oven has cooled down.
• Clean the front of the appliance and the door sealing
surfaces with a soft cloth with warm water and a clea-
ning agent.
• To clean metal surfaces, use a usual cleaning agent.
• Clean stubborn dirt with a special oven cleaner.
• Clean all accessories after each use and let them dry.
Use a soft cloth with warm water and a cleaning agent.
WARNING!
Before you change the lamp:
Ensure the appliance is switched off before replacing the
lamp to avoid the possibility of electric shock.
CAUTION: The lamp and the lamp glass cover can be hot.
Put a soft cloth on the bottom of the interior of the ap-
pliance. It prevents damage to the lamp glass cover and
the cavity. Always use the same lamp type.
Replacing the lamp
Turn the lamp glass cover counterclockwise to remove it.
- Clean the glass cover.
- Replace the lamp with a suitable 25W Halogen lamp.
- Re-install the glass cover.
During installation, maintenance and repair work, the ap-
pliance must be disconnected from the mains electricity
supply
IMPORTANT SAFETY WARNINGS

11
Steam cooking
Do not operate the oven if the glass lamp cover has been
removed. Steam could reach electrically live parts and
cause a short-circuit; also electrical components could
get damaged.
If the multifunction oven is installed behind a furniture pa-
nel (e.g. a door), ensure that the door is never closed whilst
the appliance is in use. Heat and moisture can build up
behind a closed furniture panel and cause subsequent
damage to the multifunction oven, the housing unit and
the oor. Do not close the door until the appliance has
cooled down completely.
WARNING! Danger of burning.
-The multifunction oven becomes hot when in use. You
could burn yourself on the heating elements, oven inte-
rior, cooked food, oven accessories or hot steam. Wear
oven gloves when placing food in the oven or removing it
and when adjusting oven shelves etc. in a hot oven. Take
care when putting cooking containers into the oven or
removing them not to spill the contents.
-Do not open the oven door during steam cooking. Hot
steam may come out, there is a risk of getting burnt or to
damage the appliance.
- Never line the interior of the oven cavity with e.g. foil or
lm. Do not put containers, pans and pots directly on the
bottom of the cavity.
IMPORTANT SAFETY WARNINGS
34
35

12
The packaging is intended to protect the appliance from
damage during transportation.
The packaging materials are easily recyclable becau-
se they have been selected according to environmental
friendly criteria.
Recycling them reduces the need for raw materials and
reduces the volume of waste.
Electrical and electronic appliances often contain va-
luable materials. They also contain materials which, if
handled or disposed of incorrectly, could be potentially
hazardous to human health and to the environment. They
are, however, essential for the correct functioning of your
appliance. Please do not therefore dispose of it with your
household waste.
Please dispose of it at your local
community waste collection /
recycling centre or contact your
Dealer for advice.
Ensure that it presents no danger to
children while being stored for di-
sposal.
DISPOSAL OF THE PACKAGING MATERIAL

13
ATTENTION
Rules for installa-
tion
ATTENTION
The instructions below are intended for the skilled techni-
cian who will install the appliance, regulate it and perform
technical maintenance and who will ensure that these
operations are carried out in the most correct way possi-
ble, in compliance with the regulations in force.
Important: the appliance must be disconnected from
the electric socket before performing all regulating or
maintenance operations.
• Installation must be carried out in a workmanlike man-
ner, fully complying with the legislation in force regarding
electrical installations. Otherwise, the manufacturer di-
sclaims any responsibility. You will nd your appliance’s
wiring diagram in this booklet.
• The appliances are prepared for connection to the vol-
tage shown on the data plate.
• Before connecting the appliance to the mains check
that:
-the electromagnetic switch or the socket are able to
support the appliance’s load (see dataplate);
-the power supply system must have an efcient groun-
ding system.
The appliance is supplied with a cable but without a plug:
the connection must be made taking into account that
the green-yellow cable is the ground conductor and
it must never be interrupted. The socket must be visible
and easily reachable so that the appliance can easily
be disconnected. For direct connection to the mains, it is
necessary that:
-the relief valve and domestic system can support the
equipment’s load (see data plate)
ELECTRICAL CONNECTIONS

14
ATTENTION
-the socket or omnipolar switch, with a minimum 3 mm
contact opening, must be easily reachable once the ap-
pliance has been installed.
- means for disconnection must be incorporated in the
xed wiring in accordance with the wiring rules
The yellow-green ground wire must never be interrupted
even by the switch. The power cable should be positio-
ned so that it does not come into contact with surfaces
that have a temperature of 50 °C higher than the environ-
ment. In case replacement of the power cable is neces-
sary, contact the customer service.
ELECTRICAL CONNECTIONS

15
INSTALLATION INSTRUCTIONS
Oven data
Important points
The serial plate is positioned on one side of the front plate of the oven, and is visible
opening the door; it shows all data necessary for the installation, e.g. model number
nominal voltage and power input.
First check the dimensions of the furniture opening: they must be exactly equal to those
shown in the picture. Make sure that the laminated surfaces or veneered panels be
manufactured using heat-resistant glue. If they are not, they could get warped or de
tach especially in the narrowest parts of the furniture.
Also check that the oor of the built-in niche must be solid and able to carry the weight
of the appliance.
All screws and bits needed to fasten the oven in the furniture are supplied with the
product.
All dimensions are indicated in mm.
80
450
560
560
450
557
22
596
455
570
80
550
min. 100

16
1 2
4
3
6
5
9
8
7
Control panel
TFT touch Display
Drawer for water load
Food probe socket
Grill heater
Oven lamp
Convection heater and fan
Boiler with lid
Rack supports
1
2
4
3
6
5
9
8
7
PRODUCT DESCRIPTION

17
PRODUCT DESCRIPTION
- Supplied accessories
Wire rack
For cookware, trays and roasting
Pyrex glass tray
For microwave cooking and drip pan use
Steam cooking set
Wire frame supporting 2 dedicated trays:
- perforated tray, allows steam to reach the food comple-
tely
- shallow tray, to collect condensation water dripping down

18
Food probe
To reheat and cook food selecting core temperature
PRODUCT DESCRIPTION
- Supplied accessories
Jug
To ll the water tank for steam cooking and to collect the
water when emptying the tank
Silicon pipe
To be used with the jug when emptying the tank

19
PRODUCT DESCRIPTION
- Cooking Accessories
Baking tray (if applicable):
Insert the baking tray in the wire frame as
shown.
Lift the outer part of the frame and push it into
the cavity to slide beyond the corner.
NOTE: the barrier indicated by the red arrow-
must be oriented upwards and shows the back
side of the frame.
Frame with baking trays fully inserted

20
PRODUCT DESCRIPTION
- Cooking Accessories
Pyrex glass tray
When using the glass tray put it on the upper
part of the frame (the lower tray is not neces-
sary). Insert the frame as seen before
Wire rack
Lift the outer part of the rack and push it into
the cavity to slide beyond the corner.
Select the desired level suitable for the cooking
function
NOTE: the barrier indicated by the red arrow-
must be oriented upwards and shows the back
side of the rack.
