1 INTRODUCTION
Important information: Read the manual carefully before using the device. Inappropriate utilization
may cause damages to the device. Keep these instructions in a safe place and pass them to any
future user.
The TE292 filter plate is intended for use with the Image Engineering LE7 V2 illumination device, iQ-
LED software, and the camSPECS software. Refer to the user manuals for each of these products
for detailed operating instructions.
The TE292 bundle includes the filter plate, calibration plate, and calibration plate thumb nut.
2 OPERATING INSTRUCTIONS
1. Remove the packaging material and insert the TE292 into the test chart holder of the LE7 as
pictured:
2. Power up the LE7 and connect the USB cable between the LE7 and the host computer.
3. Using the iQ-LED software, create an E illuminant at near full power and save to the LE7 as
described in the iQ-LED user manual.
4. Disconnect the LE7 USB cable.
5. Connect the EX2 spectrometer calibrator USB cable between the host computer.
6. From the control panel on the LE7, select the E illuminant saved to the LE7 earlier.
7. Launch the camSPECS software and perform the calibration as described in the camSPECS
user manual.
8. To perform camera spectral sensitivity measurements, proceed as described. The camera
exposure will depart from the typical settings suggested and should be optimized as described in
the camSPECS user manual.
3 MAINTENANCE
TE292 does not need any special maintenance. However:
•Do not touch or pollute the surfaces of the filters.
•Remove dust on the filters with pressurized-air spray.
•Remove undesired fingerprints or oils on the filters carefully with a soft and dry tissue
