iMediSync iSyncMe Installation guide

Quick Manual
&

iSyncWave Components
R
(Right)
L
(Left)
1
2
3
4
5
6
2iSyncWave Quick Manual

iSyncWave Component Glossary
Reference electrode ear clip
* Make sure to disconnect the auxiliary ear clip before storing the device
to avoid damage to the device or accessories
Reference Electrode
USB C Connector terminal
USB-C charging port
Electrode for measuring brain activity through the scalp
Electrode
Tool to replace brush electrodes
Strap for securing the iSyncWave
Chin Strap
Electrode tool
Function LEDOperation State
Power Button
Power On
Charging
Measurement
Power Off
on
on
off
off
Hold until LED blinks
(>2 seconds)
USB-C connection
* Approx. 7 hours available when charging for 132 minutes
* Automatic shutdown after
10 minutes if not used
Green: 30% charged
Magenta: less than 30% charged
Green: 100% charged
Magenta: less than 100% charged
Hold for three seconds
* When the battery is less than 10% the app will alert you
※ The product shape can be changed to improve the quality without notice.
11
2
3
4
5
6
3
iSyncWave Quick Manual
※ Cause iSyncMe and iSyncWave are the same product, they will be referred to as iSyncWave
in the description below.

Fp1Fp2
1 2
3 4
STEP 1 Measurement Preparation
It is strongly recommended to
clean the forehead and earlobes.
While looking straight ahead place Fp1 & Fp2
electrodes (shown above) on the forehead.
Place the device on from front to the back
as if you are combing your hair.
Ensure that the front
electrodes are approximately one
finger (1/2inch) from your eyebrows.
Remove all accessories before
taking a measurement. (Please avoid
coffee or heavy drinking for 24 hours)
front left electrodefront right electrode
4iSyncWave Quick Manual

z
z
z
5 6
STEP 1 Measurement Preparation
Attach the reference electrode
to the earlobe with the label facing
forward then secure the chin strap.
[Upright Posture]
It is recommended to sit in
a comfortable vertical posture
without straining your neck muscles.
[Caution]
Be careful not to fall asleep
during a measurement.
Ensure that T3 & T4 electrodes
are approximately one finger -width
(~1/2 inch) above the tops of the ears.
T3T4
5
iSyncWave Quick Manual

STEP 2 Starting the App
iSyncWave. A blue light will appear and
depending on the power level the light
will change to a green or a red light.
iSyncWave ON
Open the iSyncWave or
iSyncMe App on a compatible tablet.
Starting APP
Press the power button
Store
Selecting brain wave measurementLog in
Can be downloaded from the
Log in to the app using
your ID and password. Select EEG Measurement.
1 2
3 4
6iSyncWave Quick Manual

STEP 2 Checking the impedance before the measurement
Select new for adding a client. Select
re-visitation for previously existing clients.
Selecting a client
Turn on iSyncWave device. On the tablet
select the bluetooth ( ) to connect.
App & device connection
Device connection
On the tablet's connection screen,
select iSyncWave to connect.
Connection error
If the iSyncWave is not visible or not connected,
press the refresh ( ) at the top right of
tablet and make sure iSyncWave is turned on.
5 6
7 8
7
iSyncWave Quick Manual

STEP 3 Checking impedance
Select the “START” button to
check the impedance.
Measurement preparation 1 Measurement preparation 2
Select the "Settings" ( ) in the upper right
corner to choose continuous measurement*
or timer measurement*
For best signal quality, continue to the next screen
only when electrodes are not in the red state.
Check measurement settingsConfirming the signal state
Before recording the measurement
Select the "Play" button on the top
right to check EEG signal quality.
Ensure the electrodes are well
attached to the scalp.
21
3 4
8iSyncWave Quick Manual

12
3
STEP 4 Brainwave measurement
When settings are correct,
close your eyes and then select the
record button ( ) to start the measurement.
Eyes closed measurement
When the timer has completed
open your eyes for the remainder
of the recording.
Eyes open measurement
Completing the measurement
E
C
E
O
Analyzes the results.
Select "Results"Analysis of the results
takes about 10 minutes.
* Continuous measurement:
A measurement without a time limit
* Timer measurement:
A measurement for a set amount
of time Default is 2 minutes and 30 seconds
9
iSyncWave Quick Manual

12
3
Cleaning iSyncWave
iSyncWave
a) Make sure the iSyncWave LED is turned off before cleaning. If the power is on,
press and hold the power button for about 3 seconds to power off the headset.
* Electrode cleaning is recommended after every measurement.
Setting menu iSyncWave Setting
b) The electrodes and the inside of the iSyncWave come into contact with skin or hair,
so clean them after each use. At this time, do not use ammonia, acetone or other solvents
(corrosive/abrasive detergents) for cleaning. (Do not use detergents and liquids)
c) Brush/ Flat Electrodes and LEDs: Gently clean the surface of the electrodes
with a very soft brush such as a makeup brush.
d) Exterior: clean using a soft cloth such as cotton or gauze.
e) Excessive bending of the brush electrode during the cleaning process or excessive cleaning
with other solvents causes wear of the electrode and shortens the lifespan of the electrode.
User management | Service inquiry |
App version | Terms of service |
iSyncWave setting
Setting the time for eyes closed |
Setting the time for eyes open |
Setting the number of cycles
10 iSyncWave Quick Manual

1
Electrode (Brush / Flat) component quality
Brush
The electrode coating
is intact
Flat
The electrode coating
is intact
Brush
Less than 2 electrode
coatings are peeled off
Good
Flat
Less than 1/3 of electrode
coating is peeled off
Brush
More than 3 electrode
coatings are peeled off
Replacement suggested
Flat
More than 1/3 of the
electrode coating is
peeled off
Electrode replacement reference
Excellent
11
iSyncWave Quick Manual

Precautions when using iSyncWave
a) After approximately 180-200 uses of iSyncWave, electrodes may need to be replaced.
(Refer to page 24 and replace if worn prematurely)
How to replace electrodes
a) Remove the electrodes by gripping the sides of the electrode base and
pulling the electrode out.
b) Push the electrode into the metal ring until it is secure.
For brush electrodes use the black side of the electrode tool to push the electrode in place
without damaging the electrode coating.
b) After using the iSyncWave, please thoroughly clean the electrodes.
(If the electrodes are not cleaned, it may cause premature wear.)
c) Use only iMediSync’s electrodes to maintain product specifications.
d) The surface of the electrode should be gently cleaned with a very soft cloth or brush.
Electrode replacement reference
For inserting
brush electrodes
For electrode
replacement
Electrode Tool
2
3
12 iSyncWave Quick Manual

Customer Support
Please check the following items before requesting customer support
for equipment problems
a) Try reconnecting Bluetooth and Wi-Fi.
d) When a malfunction of the equipment is suspected, reset the equipment by turning
the power button off for 15 seconds and then on again.
If the same symptom still occurs, please contact iMediSync customer support team (C/S).
e) We provide a one-year free warranty from the date of purchase for equipment failures
that occur under normal conditions. [However, iSyncWave is not under warranty if the customer
arbitrarily disassembles, remodels, or replaces consumable parts. It is also not under warranty if
malfunctions are due to negligence such as submersion, external damage, etc..]
※ This warranty promises free repair under the period and conditions specified herein.
Therefore, this warranty does not limit the customer's legal rights. If you have any questions
about repairs after the warranty period, please contact iMediSync customer support team (C/S).
b) Try powering the tablet off and on.
c) Check that the app is up-to-date.
1
13
iSyncWave Quick Manual

14 iSyncWave Quick Manual
2
Customer Support
Product Warranty
Product name: Model name:
Product number(S/N):
Purchasing date: Purchasing place:
Guaranteed period: one year from the purchasing date
Customer information: (company name)
(name) (contact number)
This product was released after strict quality management and testing.
Manufacturing request and seller: iMediSync Inc.
Head office:
iMediSync, 15F, 411, Teheran-ro, Gangnam-gu, Seoul, Republic of Korea, 06160
E-mail: [email protected]

IFU-1003 (Rev.0)
