IMG STAGE LINE AKB-210DSP User manual

ELECTRONICS FOR SPECIALISTS ELECTRONICS FOR SPECIALISTS ELECTRONICS FOR SPECIALISTS ELECTRONICS FOR SPECIALISTS
AKB-210DSP Bestellnummer 38.0220
INSTRUCTION MANUAL
Active S eaker Module
with DSP Technology

User manual revision 5
2
Table of contents
Product description .................................................................................................................................. 3
Type remarks ........................................................................................................................................ 3
Key features .......................................................................................................................................... 3
Applications........................................................................................................................................... 4
Connections........................................................................................................................................... 5
System information ................................................................................................................................. 7
Description ............................................................................................................................................ 7
Hardware Architecture......................................................................................................................... 8
Digital audio input................................................................................................................................ 8
Audio performance data...................................................................................................................... 8
Remote control ..................................................................................................................................... 9
Product overview ...................................................................................................................................... 9
Hardware part .....................................................................................................................................10
Sub out.............................................................................................................................................12
Linking ..............................................................................................................................................12
Software installation..........................................................................................................................13
Control panel.......................................................................................................................................13
Input options.......................................................................................................................................14
Filter design.........................................................................................................................................15
Graph Area...........................................................................................................................................16
Filter Definition Area ..........................................................................................................................16
Settings window..................................................................................................................................17
Work flow.............................................................................................................................................17
Measurement...................................................................................................................................17
Designing filters ..............................................................................................................................20
Download .............................................................................................................................................21
Save Files .............................................................................................................................................21
Examples..................................................................................................................................................23
Example 1: 2 channel stereo setup..................................................................................................23
Example 2: Stereo setup with active subwoofer.............................................................................25
Technical data.........................................................................................................................................27

User manual revision 5
3
Product description
Type remarks
Firmware version 2.4 (Oct 2011)
Key features
Compact design
Personal Computer controlled
Pop free start and stop control
Stereo analogue input
Subwoofer output
Fully user customised filtering
Button panel controlled
Remote controlled
Link communication master / slave (only with two modules)
Low signal to noise ( 100dB)
Optional features, by adding a digital audio board.
SPDIF stereo audio input
Input sample rates up to 192kHz
Link communication trough SPDIF link cable (one cable for audio and link)
USB audio input
Low signal to noise ( 104dB)
-The first time the is used all biquads are zero, so there are no
filters installed. Connecting any speakers and audio input at this point
may cause some damage to them.
-Take notice on what changes you make, changing a 2channel filters to flat
can damage your speakers because both channels may be full range!
-After updating the firmware please be sure to also download the latest
version of the manual from our website

User manual revision 5
4
Applications
With one module the following applications can be set up, further explained in the “Hardware
part” chapter:
Stereo passive filtered system
Briged mode for single subwoofer (max 140Watt short term into 8 Ohms)
Mono/mid 2 way setup (tweeter + sub)
When two modules are used the following applications can be set up, also explained in
“Hardware part”:
2 way active filtered stereo system
2 channel system with active subwoofer
2 channel system, both modules in bridge mode for more power
All setups are possible with both analogue and optional with the digital audio inputs SPDIF and
USB.
Note that all setups have the ability to use an extra channel by connecting an active subwoofer
to the subout. By this you will have the opportunity to build a 3 way system.

User manual revision 5
5
Connections
F u
Figure 1
Overview of the connections on the front of the
un i Function
1
1 Amplifier output, for slave speaker in stereo setup
4
4 Analogue input left channel
5
5 Analogue input right channel
6
6 Subwoofer output
7
77
7 On/Off switch
8
8a USB control input

User manual revision 5
6
9
99
9 Master trigger output, slave trigger input
Right channel trough
1
110
10 Main Fuse
1
11 ~230 volt input
D v on y
Digital version only:
2
22
2 SPDIF audio input
3
3 SPDIF audio output
Audio trough for slave module
8
8b USB audio input
F u
Figure 2
Overview of the connections on the back of the
un i
un iFunction
Function
1
1 Transformer connection
2
2 JP1, Bridge jumper
3
33
3 J4, Stereo Left channel output
2 channel Low channel
Pin1 (left) Speaker
Pin 2 (right) Speaker +
4
4 J2, Stereo Right channel output
2 channel High channel
Pin1 (left) Speaker
Pin 2 (right) Speaker +
5
5 J3, Connection of banana plugs
Physically the same as connector J2
6
6 Transformer connection
7
7 Control panel flat cable connector

User manual revision 5
7
System information
F u
Figure 3
Description
The is
a plate amp for use in powered speaker systems. As an active speaker
controller,a can form the basis of a powerful active two way monitor.Instereo mode
one will power an active master/passive slave pair. Finally,the module may also be
used as a one way 140W amplifier. All signal processing, including volume control, is done
using the on board DSP (digital signal processor).
Figure 3 shows the block diagram of the amplifier. When two modules are used, the second unit
slaves to the first unit (master) through a link cable. The link cable (a stereo mini jack cable)
carries both the right audio channel and control data. This way, both units respond to the
master’s control panel.
A PC controls the through the USB port. This connection is used to upload the
configuration and filter settings. An optional board permits use of the USB link for audio as well
as an SPDIF link. In digital mode, master/slave linking is done through the SPDIF in/out
connections instead of the mini jack cable.

User manual revision 5
8
Hardware Architecture
The standard version of the has a stereo analogue audio input. This analogue
signal is converted to digital, processed by the DSP and then converted back to
analogue. A microcontroller controls the DSP, reads the control panel and communicates
with the PC and/or another that may be attached.
Digital audio input
The optional digital input board plugs into the main PCB and carries two RCA connectors, SPDIF
in and SPDIF through. Incoming SPDIF is linked through directly to the output and sent to the
DSP through an asynchronous sample rate converter (ASRC) for jitter removal. The USB part
adds a hub and an audio device which in turn also transmits audio over the ASRC to the DSP.
The ASRC chip scans its input for whichever signal is active. In a stereo setup and in digital
mode the SPDIF through cable doubles as a master/slave link, obviating the need for the mini
jack cable. The mini jack cable remains functional though and does not have to be removed.
Audio performance data
MBW 20kHz, unless otherwise noted. All filters set to unity. Noise levels unweighted.
Item Symbol Min Typ Max Unit Notes
Input level Vin 2.2 V
Input impedance 10k Ohm Analogue cinch inputs
LS1 100* W Into 4 Ohms
LS2 100* W Into 4 Ohms
LS1 50 W Into 8 Ohms
Output level
LS2 50 W Into 8 Ohms
100 dB ADCSignal/Noise SNR
104 dB DAC
Total harmonic
distortion+Noise
THD+N 0.05 0.07 %
20Hz<f<20kHz.
Pout<PR/2
Analogue sampling rate Fs 48 kHz
0 0 34,03 cmDelay per channel
0 0 1000 us
Set in software, not
for subout channel
Supported digital sampling
rates
Fs 32, 44.1, 48, 88.2,
96, 192
kHz All input rates
converted to 48kHz
Gain 20 dB volume at 0dB
Analogue Latency 1,12 ms
SPDIF latency 3,58 ms
* 100Watts is the maximum of the total unit

User manual revision 5
9
Remote control
The master unit is fitted with small keypad which can be placed in the front of the loudspeaker
cabinet. Volume and idle/on is controlled by the pushbuttons and by an infra red remote
control. When 2 modules are used only one control panel is needed, cause the
trigger communication between master and slave.
There is also a touch panel available . This can replace the standard control
panel.
The use of an Inferred remote control adds the ability to switch input channels with the up and
down buttons of the remote. The uses a standard RC 5 TV protocol for
Infrared control.
Product overview
Before you can use the in your particular setup, you first have to set the right
settings. This is done by pc software, called DSP filter design.
Please do not connect any speakers to your system yet!
When you want to set up a system with the you apparently know what you
want. So with this information you can setup your system as follows:
Stereo setup, in this setup you use one module for driving
two (passive filtered) speakers.
Bridged setup, the possibility to bridge both amplifiers on the will
enable you to get more power at higher loads. This setup is especially useful
for driving a subwoofer
2 channel setup. A 2 channel setup will allow you to make a two way active
speaker. Each amplifier of the will drive one driver of the
speaker, i.e. high, mid or low.
In this setup you will need one per speaker.
A combination of the above mentioned setups is
also possible, for example a stereo setup with an active subwoofer with an
in bridge mode, see Figure 4.

User manual revision 5
10
Stereo
audio in Right speaker
Left speaker
V l m
o n
V l m Up
I R ce r
n O f
Control
Panel
r
Figure 5
Hardware part
Stereo setup: Connect the module to your pc by a USB cable and select on witch side of the
room your master module will be, the speaker with the . When
your master is the left channel the slave will become the right channel. The
slave speaker can be connected by the banana plugs on the .
e
eFigure
Figure 4 4

User manual revision 5
11
Bridged setup: Connect the module to your pc by a USB cable and select where the master
module is placed, master module is left or right audio or functions as a sub
woofer. When you use 2 for a stereo bridged setup you will also
have to initialise the second (slave) module, see example in the last chapter
of this document. In bridged mode the jumper (see Figure 2) must be placed
and the speaker must be connected between J4 speaker+ and J2 speaker+. In
all other setups the jumper is not placed! When you want to set the master
as right channel with analogue input you will have to change the input
cinches, left in the right cinch and right in the left. This is because only the
right channel is linked trough, so if you want the left channel to be linked
trough you just switches left and right. For digital sources the left and right
channel are linked.
2 Channel: Connect the module to your pc by a USB cable and select what kind of 2
channel you want to setup. When you want to set the master as right
channel with analogue input you will have to change the input cinches, left
in the right cinch and right in the left. This is because only the right channel
is linked trough, so if you want the left channel to be linked trough you just
switches left and right. For digital sources the left and right channel are
linked. An example is given in the last chapter of this document.
V l m
Do n
V l m U
I R ce er
nO f
Stereo
audio in
Control
Panel
trigger +
right ch
LF HF LF HF
r
Figure 6

User manual revision 5
12
Sub-out
On all setups there is also the ability to use the Line out sub. This can source an active
subwoofer module. The sub output has up to 6 biquads for filtering that can exclude the use of
an external subwoofer filter.
Linking
When 2 modules are used these two can be linked by a trigger cable. This cable holds device
data and also carries an audio channel on analogue source. If the digital board is installed then
the SPDIF link cable can be used to communicate between the 2 modules. This cable is placed
from master SPDIF out to slave SPDIF in cinch. The trigger cable is no longer needed in this
setup. On USB audio input on the master the SPDIF output is also used for linking master to
slave.

User manual revision 5
13
Software installation
System requirements:
•Pentium class or higher
•64MB RAM
•USB1.0 or higher
All files are compressed in the setup.zip file. This zip file contains a DLL file for communication
and a .EXE file, which represents the DSP filter design program.
1. Unzip the setup.zip file on your hard disk
2. Open the “ DSP filter design.EXE” by double clicking the file
Control panel
Now the program is ready for use. You see
the following window, called the control
panel.
F u
F uFigure
Figure 7 7
When the program is running connect your to your pc
by the USB cable. Windows will automatically detect and
install the
and the USB audio device (digital version only).When the
installation is done the connected window will appear and the connec
tion light will turn green. You can also manually make a connection
by the “connect” button, on the bottom right of the control panel.
Now you can adapt the settings of the real time through USB. On the left
of the control panel you see the Force input and active input groups. This shows you the
settings of the audio inputs of the , and lets you control these inputs (only when
digital audio board is added).
Audio can be provided in 3 ways, analogue, SPDIF and USB audio. The selection of any of these
inputs can be automatic, “auto detect”. This means that when any of the inputs is presented
there will be switched to this channel automatically. This is done by setting the analogue input
F u
F uFigure
Figure 8 8

User manual revision 5
14
as the standard source. During analogue in the other two inputs are scanned for any valid
signal. The first channel that contains any valid audio is selected and becomes the new input
source. But if you put in the USB cable but you want to use the analogue input you can force
the analogue input to be used. This can be done for all inputs, the options Analogue, SPDIF and
USB Audio.
When the module selects one of the inputs this is shown by the active input lights.
Under the Setup select part the system setup can be selected. There can be chosen between:
2-channel Stereo Bridged
Master on the left Master on the left Master on the left
Master on the right* Master on the right* Master on the right*
Mid/Sub, L+R Sub, L+R
Side, L R
* Only on digital audio board, for analogue version cinches has to be changed like described in
‘Hardware part’.
The output signal of the subout channel is controlled in the “Subout control” panel. Normally
this will be set to L+R to use one subwoofer, but if you want to use a subwoofer on both sides
you can set the subout to only use left or right input signal.
The last thing that can be controlled in this window is volume. This can be done by setting the
scrollbar to a desired position or by typing the value in the volume field, this value is send when
pressed “enter”.
All of the configurations made here will be redirected from master to slave, when presented. So
there is no need to connect the slave module to the pc.
The slave module is always the opposite of the master, so master left will set the slave to right.
This is done automatically because the module knows whether it is master or slave.
Only when the module is switched off by remote all settings, like volume and setup, are stored
in memory.
Input options
Use this dialog to match the input sensitivity of the
analogue input to the full scale output level of your
analogue source (max. 2.2V). This helps prevent
annoying loudness jumps when switching between
digital and analogue sources.
Gain can be changed in steps of one dB and only for the
analogue input.
F u
Figure
9

User manual revision 5
15
Filter design
When you want to make some filters for
your module they can be designed in
the “Filter design”. Under view there can
be switched between the control panel
and the filter design window.
The following pages will give you a
widespread instruction of the
possibilities of the program.
r
Figure 1 11
F u
Figure 10

User manual revision 5
16
Graph Area
The magnitude tab shows the imported driver responses, filters, individual biquads, individual
filtered driver responses and the sum.
Colour Function
Blue, thin Measured woofer response
Green, thin Measured midrange response
Red. thin Measured tweeter response
Blue, thick Filtered woofer response
Green, thick Filtered midrange response
Red, thick Filtered tweeter response
Light blue, thick Response of filter, selected channel only
Orange, thick Response of selected biquad
Black, thick Sum response
Having all of these on at the same time quickly produces an intractable mess so these graphs
can be separately enabled or disabled in the filter definition area.
The impulse or step tabs show the time domain response of the imported drivers and the sum
response, and are used to demarcate the anechoic portion.
Filter Definition Area
The three channel tabs, labelled Tweeter, Woofer and Subwoofer are functionally identical. The
top left frame is used to import response files. The “select” button opens a file. The “show”
checkbox turns display of the measured graph on or off. The Common Settings box controls
global gain (for each channel), delay, and the visibility of plots.
The amplified channels have up to 12 biquads, selected using the “Biquad Section” radio
buttons in the middle. The Subwoofer lineout has only 6 biquads sections, for only simple filter
settings. To the right is a settings area specific to the type of function selected. Unused
biquads are set to unity.
The selected biquad is edited by selecting a function and setting relevant parameters.
The delay has a maximum value of 1000us for channel 1 and 2. The subwoofer channel does
not include any delay. Distance is calculated by sound speed/delay distance, maximum
distance is therefore 340,29meters/0,001secondes 34,029cm. Note that the minimum step
size is 0,726cm cause the sample rate of 46875Hz.
The sample frequency is not the standard 48kHz because of internal clock source also needed
for USB connection.

User manual revision 5
17
Settings window
The settings window is under File > Settings… Measurement sampling rate sets the sample rate
used in the imported response files (typically 48kHz). Processor sampling rate is that of the
DSP hardware. Note that this setting does not control the sampling rate of the
hardware. Rather, it informs the filter design application of what that sampling rate is. In short,
leave this at the standard value.
The select button opens a file dialogue box witch is not used in this application.
Work flow
Measurement
Measuring using the DSP unit set to “flat”
Perform impulse response measurements for each driver separately. Save the entire impulse
record truncation can be done later on the filter design program.
Measuring using an external amplifier
A separate amplifier may also be used for measuring the drivers, provided the amplifier’s
output impedance is as low as the DSP unit’s.
Importing response data
Select the tab for the channel you want to import and click “select”. The filter designer expects
the impulse response measurement as a text file with one sample per line.
There is no restriction on the absolute gain of the impulse response data. The only thing that
matters is that the absolute gain be the same for all three measurements. The filter designer
computes a gain offset based on all loaded responses to centre them collectively on the vertical
scale.
Truncating response data
Switch to the impulse or step response graph.

User manual revision 5
18
r
rFigure
Figure 1
112
12
The first echo is apparent at 5ms. Zoom in until you see only the anechoic portion of the
impulse response. Dragging the mouse, left button down, from left to right marks a zoom area.
Dragging from right to left zooms out. Dragging with the right button down pans the plot left
and right.

User manual revision 5
19
r
Figure 1 13
Click “truncate”. Anything currently outside the display is drawn in grey and not processed.
You will notice that in the frequency graph a portion of the low frequency response is also
drawn in grey. This is to remind the user that insufficient information is available to make
*any* correction below this frequency. A way of obtaining quasi anechoic low frequency
measurements is making close up measurements. Working with such measurements requires
a good deal of interpretation but it is doable.
Important: Avoid making any corrections for which no anechoic data is available. If reflections
are included, they are guaranteed to dominate the measurement at low frequencies, and you
will end up making corrections for circumstances that are highly specific to the room in which
the measurement was made. Power response data can only be made in a proper echo chamber
or preferably, by collating a large number of anechoic off axis measurements. A reverberant
measurement in a normal live room just won’t do.
The steps of loading and truncating data can be repeated at any time. This can be particularly
practical when combining close up and far field measurements during the filter design phase.
The window in Figure 13 shows the result of this. The small knot of corrections made around
70Hz is based on close up data first loaded separately. The LF section of the test mule is quite
smooth apart from one internal standing wave.

User manual revision 5
20
Designing filters
Biquad function Parameters Use
Unity Section is not used
LPF1 Cut off frequency (always 3dB) First order lowpass
LPF2 Cut off frequency (asymptotically)
Q
Second order lowpass. A Q of 0.71
corresponds to butterworth. 0.5
corresponds to LR2. Two identical
sections with a Q of 0.71 form an
LR4 filter.
HPF1 Cut off frequency (always 3dB) First order highpass
HPF2 Cut off frequency (asymptotically)
Q
Second order highpass. A Q of 0.71
corresponds to butterworth. 0.5
corresponds to LR2. Two identical
sections with a Q of 0.71 form an
LR4 filter.
Shelf1 Centre Frequency (halfway point)
Gain
Direction
First order shelf. Useful for baffle
step correction
Shelf2
Centre Frequency (halfway point)
Gain
Q
Direction
Second order shelf. Useful for
correcting internal cabinet
resonances and for the midband
peak/dip combo of most midwoofer
speakers.
Asymmetric Shelf Pole frequency and Q
Zero frequency and Q
Equalising the bottom end of
closed box woofers with large
magnets
Boost/Cut Centre frequency
Q
gain
Dip/peak filter. For peaks, Q is
defined by the poles. For dips, Q is
defined by the zeros. Thus the same
filter with opposite gains will
cancel.
The first step is equalising the magnitude responses of the drivers flat over their entire useable
frequency range.
The weapons of choice are shelving filters, and boost/cut sections. A sharp peak followed by an
equally sharp dip can be corrected using a second order shelving filter with a high Q.
Exercise care when deciding what to correct. When correcting for diffraction errors, do not
exceed a Q of 3 lest the cure be worse than the ailment. Errors that are caused inside the driver,
or internal cabinet resonances that emanate through the same diaphragm, may be corrected
ruthlessly provided the measurement has sufficient resolution to pin them down.
