IMI norgren F64C Installation and operating instructions

01/22
IM/en 8.240.105 01
Our policy is one of continued research and development. We therefore reserve the right to amend,
without notice, the specifications given in this document. (1999 - I&M8089d) © 2020 IMI International s.r.o.
F64C, F64H Filter
Installation & Maintenance Instructions
Fluid: Compressed air
Maximum pressure:
Guarded transparent bowl: 10 bar (150 psig) Metal
bowl: 17 bar (250 psig)
Operating temperature*:
Transparent bowl: –20° ... +50°C (0° ... +125°F) Metal
bowl: –20° ... +65°C (0° ... +150°F)
* Air supply must be dry enough to avoid ice formation
at temperatures below +2°C (+35°F). Particle remov-
al: Down to 0,01 µm
Air quality: Within ISO 8573-1, Class 1.7.2 Maximum
remaining oil content in outlet air: 0,01 mg/m3 at
+21°C (+70°F)
with an inlet concentration of 17 ppm Maximum ow
at 6,3 bar (90 psig) inlet pressure**: 16 dm3/s (34
scfm) F64C, 28 dm3/s (60 scfm) F64H
** to maintain stated oil removal performance. Auto-
matic drain connection: 1/8”
Automatic drain operating conditions: Minimum
pressure: 0,7 bar (10 psig). Drain openswhen bowl
pressure drops below 0,2 bar (3 psig)
Minimum air ow:
1 dm3/s (2 scfm) required to close drain Nominal bowl
size:0,2 litre (7 uid oz) Materials:
Body: Zinc
Bowl:
Metal: Aluminium
Transparent, optional: Polycarbonate
Metal bowl liquid level indicator lens, standard:
Grilamid
Metal bowl sight glass, optional:Pyrex Element:
Composite materials
Elastomers: Synthetic rubber
Mechanical service indicator materials:
Body: Transparent Nylon
Internal parts: Acetal
Spring: Stainless steel
Elastomers: NBR
REPLACEMENT ITEMS
Service kit
contains required items circled: 4380-200
Prismatic sight glass 4380-040
Pyrex sight glass 4380-040
Pyrex sight glass 4380-041
Filter element:
F64C 4344-01
F64H 4344-02
Manual drain 684-84
Automatic drain 3000-97
Mechanical service Indicator (1) 5797-50
INSTALLATION
1. Install unit vertically in air line -
• vertically (bowl down),
• with air ow in direction of arrow on body,
• upstream of regulators, lubricators, and cycling-
valves,
• as close as possible to the air supply when used asa
main line lter,
• as close as possible to the device being serviced
when used as a nal lter.
2. Before assembling the basic unit into the yoke the
port seal o-rings should be lightly smeared with
o-ring grease.
3. Locate clamp ring under lugs on top of yoke, offer-
basic unit into yoke with directional arrows correct-
ly aligned (an interference t prevents assembly if
misaligned) before engaging and fullytightening
the clamp ring.
4. Turn bowl or bowl guard fully clockwise into body
before pressurizing. Lock symbols on body andbowl
guards must align.
5. Auto-drain units may be tted with a short drain
pipe and connector, minimum 5 mm bore, to
theG1⁄8 bottom outlet.
6. Push bowl, or bowl with guard, into body and turn-
fully clockwise before pressurizing.
7. Install a Norgren general purpose lter with a 5
μm element upstream of the oil removal lter to
obtainmaximum element service life.
8. Turn bowl into body until arrowhead on bowl is
aligned with or to the right of the arrowhead on
the body.
SERVICING
1.Open manual drain to expel accumulated liquids.
Keep liquids below element (58, 60).
2. To operate automatic drain manually, li operating-
pin in bottom outlet with a blunt rod.
3. Replace lter element when pressure drop acrosse-
lement exceeds 0,7 bar (10 psig). The mechanical-
service indicator shows approximately full red.
TECHNICAL FEATURES
Option selector
Port
2 1/4”
3 3/8“
4 1/2“
6 3/4
Servive life indicator
D Mechanical service life
indicator
N Without indicator
Drain
A Automatic
M Manual
Q Manual, 1/4 turn
Bowl
D Metal
P Transparent with guard
R Metal with Pyrex sight glass
Thread
A (1/8 PTF gauge ports)
B (1/8 PTF gauge ports)
G ISO G parallel (1/8 ISO Rc gauge
ports)
N No thread (basic unit)
Element
0 Coalescing
F64˙– ˙˙˙ – ˙˙˙
Bowl/
Element
C Standard
H High ow
F64C, F64H Filter
Installation & Maintenance Instructions
01/16
IM/en 8.240.10501
Our policy is one of continued research and development. We therefore reserve the right to amend,
without notice, the specifications given in this document. (1999 - I&M8075e) © 2015 IMI International s.r.o.
Fluid: Compressed air
Maximum pressure:
Guarded transparent bowl: 10 bar (150 psig)
Metal bowl: 17 bar (250 psig)
Operating temperature*:
Transparent bowl: –20° ... +50°C (0° ... +125°F)
Metal bowl: –20° ... +65°C (0° ... +150°F)
* Air supply must be dry enough to avoid ice
formation at temperatures below +2°C (+35°F).
Particle removal: Down to 0,01 µm
Air quality: Within ISO 8573-1, Class 1.7.2
Maximum remaining oil content in outlet air:
0,01 mg/m3 at +21°C (+70°F)
with an inlet concentration of 17 ppm
Maximum flow at 6,3 bar (90 psig) inlet
pressure**: 16 dm3/s (34 scfm) F64C, 28 dm3/s
(60 scfm) F64H
** to maintain stated oil removal performance.
Automatic drain connection: 1/8”
Automatic drain operating conditions:
Minimum pressure: 0,7 bar (10 psig). Drain
openswhen bowl pressure drops below 0,2 bar
(3 psig)
Minimum air flow:
1 dm3/s (2 scfm) required to close drain
Nominal bowl size:0,2 litre (7 fluid oz)
Materials:
Body: Zinc
Bowl:
Metal: Aluminium
Transparent, optional: Polycarbonate
Metal bowl liquid level indicator lens, standard:
Grilamid
Metal bowl sight glass, optional:Pyrex
Element: Composite materials
Elastomers: Synthetic rubber
Mechanical service indicator materials:
Body: Transparent Nylon
Internal parts: Acetal
Spring: Stainless steel
Elastomers: NBR
Replacement Items
Service kit,
contains required items circled: 4380-200
Prismatic sight glass 4380-040
Pyrex sight glass 4380-041
Filter element:
F64C 4344-01
F64H 4344-02
Manual drain 684-84
Automatic drain 3000-97
Mechanical service Indicator (1) 5797-50
Installation
1.Install unit vertically in air line -
• vertically (bowl down),
• with air ow in direction of arrow on body,
• upstream of regulators, lubricators, and
cyclingvalves,
• as close as possible to the air supply when
used asa main line filter,
• as close as possible to the device being
serviced when used as a final filter.
2. Before assembling the basic unit into the yoke
the port seal o-rings should be lightly smeared
with o-ring grease.
3. Locate clamp ring under lugs on top of yoke,
oerbasic unit into yoke with directional
arrows correctly aligned (an interference fit
prevents assembly if misaligned) before
engaging and fullytightening the clamp ring.
4. Turn bowl or bowl guard fully clockwise into
body before pressurizing. Lock symbols on
body andbowl guards must align.
5. Auto-drain units may be fitted with a short
drain pipe and connector, minimum 5 mm
bore, to theG1⁄8 bottom outlet.
6. Push bowl, or bowl with guard, into body and
turnfully clockwise before pressurizing.
7. Install a Norgren general purpose filter with a
5 µm element upstream of the oil removal filter
to obtainmaximum element service life.
8. Turn bowl into body until arrowhead on bowl
is aligned with or to the right of the arrowhead
on the body.
A B
C
Servicing
1. Open manual drain to expel accumulated
liquids.Keep liquids below element (58, 60).
2. To operate automatic drain manually, lift
operatingpin in bottom outlet with a blunt rod.
3. Replace filter element when pressure drop
acrosselement exceeds 0,7 bar (10 psig). The
mechanicalservice indicator shows
approximately full red.
Diassembly
1. Shut o inlet pressure. Reduce pressure in
inletand outlet lines to zero.
2. For ease of maintenance the unit can be
removedfrom the yoke by unscrewing the
clamp ring, whichwill jack the unit out down
wards.
3. Lift and turn the filter bowl counterclockwise
and remove with bowl o-ring.
4. Disassemble in general accordance with the
item numbers on exploded view. Do not
remove thedrains or the service indicator
unless replacementis necessary. Remove and
replace only if theymalfunction.
2
5
3
4
1
16
60
7
61
58
59
8
6
48
32
47
18
31
30
29
43
44
46
45
40
36
38
37
41
42
39
33
35
34
26
22
24
23
27
28
25
19
21
20
Technical features
Option selector
Port
2 1/4”
3 3/8“
4 1/2“
6 3/4
Servive life indicator
D Mechanical service indicator
N Without indicator
Bowl
D Metal
P Transparent with guard
R Metal with Pyrex sight glass
Element
0 Coalescing
Thread
A PTF (1/8 PTF gauge ports)
B ISO Rc taper (1/8 ISO Rc gauge ports)
G ISO G parallel (1/8 ISO Rc gauge ports)
N No thread (basic unit)
F64˙ – ˙˙˙ – ˙˙˙
Drain
A Automatic
M Manual
Q Manual 1/4 turn
Bowl/
Element
C Standard
H High flow
F64C, F64H Filter
Installation & Maintenance Instructions
01/16
IM/en 8.240.10501
Our policy is one of continued research and development. We therefore reserve the right to amend,
without notice, the specifications given in this document. (1999 - I&M8075e) © 2015 IMI International s.r.o.
Fluid: Compressed air
Maximum pressure:
Guarded transparent bowl: 10 bar (150 psig)
Metal bowl: 17 bar (250 psig)
Operating temperature*:
Transparent bowl: –20° ... +50°C (0° ... +125°F)
Metal bowl: –20° ... +65°C (0° ... +150°F)
* Air supply must be dry enough to avoid ice
formation at temperatures below +2°C (+35°F).
Particle removal: Down to 0,01 µm
Air quality: Within ISO 8573-1, Class 1.7.2
Maximum remaining oil content in outlet air:
0,01 mg/m3 at +21°C (+70°F)
with an inlet concentration of 17 ppm
Maximum flow at 6,3 bar (90 psig) inlet
pressure**: 16 dm3/s (34 scfm) F64C, 28 dm3/s
(60 scfm) F64H
** to maintain stated oil removal performance.
Automatic drain connection: 1/8”
Automatic drain operating conditions:
Minimum pressure: 0,7 bar (10 psig). Drain
openswhen bowl pressure drops below 0,2 bar
(3 psig)
Minimum air flow:
1 dm3/s (2 scfm) required to close drain
Nominal bowl size:0,2 litre (7 fluid oz)
Materials:
Body: Zinc
Bowl:
Metal: Aluminium
Transparent, optional: Polycarbonate
Metal bowl liquid level indicator lens, standard:
Grilamid
Metal bowl sight glass, optional:Pyrex
Element: Composite materials
Elastomers: Synthetic rubber
Mechanical service indicator materials:
Body: Transparent Nylon
Internal parts: Acetal
Spring: Stainless steel
Elastomers: NBR
Replacement Items
Service kit,
contains required items circled: 4380-200
Prismatic sight glass 4380-040
Pyrex sight glass 4380-041
Filter element:
F64C 4344-01
F64H 4344-02
Manual drain 684-84
Automatic drain 3000-97
Mechanical service Indicator (1) 5797-50
Installation
1.Install unit vertically in air line -
• vertically (bowl down),
• with air ow in direction of arrow on body,
• upstream of regulators, lubricators, and
cyclingvalves,
• as close as possible to the air supply when
used asa main line filter,
• as close as possible to the device being
serviced when used as a final filter.
2. Before assembling the basic unit into the yoke
the port seal o-rings should be lightly smeared
with o-ring grease.
3. Locate clamp ring under lugs on top of yoke,
oerbasic unit into yoke with directional
arrows correctly aligned (an interference fit
prevents assembly if misaligned) before
engaging and fullytightening the clamp ring.
4. Turn bowl or bowl guard fully clockwise into
body before pressurizing. Lock symbols on
body andbowl guards must align.
5. Auto-drain units may be fitted with a short
drain pipe and connector, minimum 5 mm
bore, to theG1⁄8 bottom outlet.
6. Push bowl, or bowl with guard, into body and
turnfully clockwise before pressurizing.
7. Install a Norgren general purpose filter with a
5 µm element upstream of the oil removal filter
to obtainmaximum element service life.
8. Turn bowl into body until arrowhead on bowl
is aligned with or to the right of the arrowhead
on the body.
A B
C
Servicing
1. Open manual drain to expel accumulated
liquids.Keep liquids below element (58, 60).
2. To operate automatic drain manually, lift
operatingpin in bottom outlet with a blunt rod.
3. Replace filter element when pressure drop
acrosselement exceeds 0,7 bar (10 psig). The
mechanicalservice indicator shows
approximately full red.
Diassembly
1. Shut o inlet pressure. Reduce pressure in
inletand outlet lines to zero.
2. For ease of maintenance the unit can be
removedfrom the yoke by unscrewing the
clamp ring, whichwill jack the unit out down
wards.
3. Lift and turn the filter bowl counterclockwise
and remove with bowl o-ring.
4. Disassemble in general accordance with the
item numbers on exploded view. Do not
remove thedrains or the service indicator
unless replacementis necessary. Remove and
replace only if theymalfunction.
2
5
3
4
1
16
60
7
61
58
59
8
6
48
32
47
18
31
30
29
43
44
46
45
40
36
38
37
41
42
39
33
35
34
26
22
24
23
27
28
25
19
21
20
Technical features
Option selector
Port
2 1/4”
3 3/8“
4 1/2“
6 3/4
Servive life indicator
D Mechanical service indicator
N Without indicator
Bowl
D Metal
P Transparent with guard
R Metal with Pyrex sight glass
Element
0 Coalescing
Thread
A PTF (1/8 PTF gauge ports)
B ISO Rc taper (1/8 ISO Rc gauge ports)
G ISO G parallel (1/8 ISO Rc gauge ports)
N No thread (basic unit)
F64˙ – ˙˙˙ – ˙˙˙
Drain
A Automatic
M Manual
Q Manual 1/4 turn
Bowl/
Element
C Standard
H High flow

IM/en 8.240.105 02
Our policy is one of continued research and development. We therefore reserve the right to amend,
without notice, the specifications given in this document. (1999 - I&M8089d) © 2020 IMI International s.r.o.
F64C, F64H Filter
Installation & Maintenance Instructions
01/22
DIASSEMBLY
1. Shut off inlet pressure. Reduce pressure in inletand
outlet lines to zero.
2. For ease of maintenance the unit can be removed-
from the yoke by unscrewing the clamp ring,
whichwill jack the unit out down wards.
3. Li and turn the lter bowl counterclockwise and
remove with bowl o-ring.
4. Disassemble in general accordance with the
item numbers on exploded view. Do not remove
thedrains or the service indicator unless replace-
mentis necessary. Remove and replace only if
theymalfunction.
CLEANING
1. Element (58, 60) cannot be cleaned. Clean plastic
bowl and lens (45) with warm water only.
Cleanindicator (1) with dry, clean cloth.
Clean otherparts with warm water and soap.
2. Rinse and dry parts. Blow out internal passages in
body (6) with clean, dry com pressed air.
3. Inspect parts. Replace those found to be damaged.
Replace plastic bowl with a metal bowl if plas-
ticbowl shows signs of cracking or cloudiness.
ASSEMBLY
1. Lubricate o-rings with o-ring grease.
2. Assemble the unit as shown on the exploded view.
3. Arrows on indicator (3) and body (6) must point
insame direction. Push bowl, or bowl with guard,
intobody and turn fully clockwise.
4. Torque Table
Torque in
Item N-m (Inch-Pounds)
58, 60 (Element) 0,5 to 1 (5 to 9)
5. Turn bowl or bowl with guard fully clockwise into
body.
CAUTION
Water vapor will pass through these units and could
condense into liquid form downstream as air temper-
ature drops. Install an air dryer if water condensation
could have a detrimental effect on the application.
WARNING
Polycarbonate plastic bowls can be damaged and
possibly burst if exposed to such substances as
certain solvents, strong alkalies, compressor oils con-
taining ester-based additives or synthetic oils. Fumes
of these substances in contact with the polycar-
bonate bowl, externally or internally, can also result in
damage. Clean with warm water only.
Use metal bowl in applications where a plastic bowl
might be exposed to substances that are
incompatible with polycarbonate.
Before using these products with uids other
than air, for non industrial applications, or for
life-support systems consult Norgren.
F64C, F64H Filter
Installation & Maintenance Instructions
Our policy is one of continued research and development. We therefore reserve the right to amend,
without notice, the specifications given in this document. (1999 - I&M8075e) © 2015 IMI International s.r.o.
IM/en 8.240.10502
01/16
Cleaning
1. Element (58, 60) cannot be cleaned. Clean
plastic bowl and lens (45) with warm water
only. Cleanindicator (1) with dry, clean cloth.
Clean otherparts with warm water and soap.
2. Rinse and dry parts. Blow out internal
passages in body (6) with clean, dry com
pressed air.
3. Inspect parts. Replace those found to be
damaged.Replace plastic bowl with a metal
bowl if plasticbowl shows signs of cracking or
cloudiness.
Assembly
1. Lubricate o-rings with o-ring grease.
2. Assemble the unit as shown on the exploded
view.
3. Arrows on indicator (3) and body (6) must
point insame direction. Push bowl, or bowl
with guard, intobody and turn fully clockwise.
4. Torque Table
Torque in
Item N-m (Inch-Pounds)
58, 60 (Element) 0,5 to 1 (5 to 9)
5.Turn bowl or bowl with guard fully clockwise
into body.
Caution
Water vapor will pass through these units and
could condense into liquid form downstream as
air temperature drops. Install an air dryer if water
condensation could have a detrimental eect on
the application.
WARNING
Polycarbonate plastic bowls can be damaged
and possibly burst if exposed to such
substances as certain solvents, strong
alkalies, compressor oils containing ester-based
additives or synthetic oils. Fumes of these
substances in contact with the polycarbonate
bowl, externally or internally, can also result in
damage. Clean with warm water only.
Use metal bowl in applications where a plastic
bowl might be exposed to substances that are
incompatible with polycarbonate.
Before using these products with fluids other
than air, for non industrial applications, or for
life-support systems consult Norgren.
Use in potentially explosive atmospheres
Code of device according EC
directive 94/9/EC Ex II 2 GD c TX
• Only non-ammable gasese to be used as a
medium.
• Surface temperature dependant on process
fluid temperature and ambient temperature
must be below the ignition temperature of the
flammable gas or dust.
• Earth unit and/or pipework to avoid
electrostatic discharge.
• Precautions should be taken to prevent hazard
from adiabatic compression.
• Use wet cloth for cleaning.
• Protect the unit from object falling onto it.
• Avoid contact with corrosive environment.
• For servicing the unit it is recommended to
carry out this work outside of the danger
zone.
• For details of ignition hazard assessment
contact Norgren.
2
5
3
4
1
16
60
7
61
58
59
8
6
48
32
47
18
31
30
29
43
44
46
45
40
36
38
37
41
42
39
33
35
34
26
22
24
23
27
28
25
19
21
20
