IMI NORGREN F64G Installation and operating instructions

01/22
I&M/en 8.240.100.01
Our policy is one of continued research and development. We therefore reserve the right to amend,
without notice, the specifications given in this document. (1999 - I&M8074d) © 2020 IMI International s.r.o.
F64G Filter
Installation & Maintenance Instructions
Fluid: Compressed air
Maximum pressure:
Guarded transparent bowl: 10 bar (150 psig)
Metal bowl: 17 bar (250 psig)
Operating temperature*:
Transparent bowl: –20° ... +50°C (0° ... +125°F)
Metal bowl: –20° ... +80°C (0° ... +175°F)
* Air supply must be dry enough to avoid ice forma-
tion at temperatures below +2°C (+35°F).
Particle removal: 5 µm, 25 µm or 40 µm lter element
Air quality: Within ISO 8573-1, Class 3 and Class 5
(particulates)
Typical ow with 40 µm element, 6,3 bar (90 psig)
inlet pressure and 0,5 bar (7 psig) droop from set: 70
dm3/s (148 scfm)
Automatic drain connection: 1/8”
Automatic drain operating conditions:
Pressure: 0,7 bar (10 psig). Drain opens when bowl
pressure drops below 0,2 bar (3 psig).
Minimum air ow: 1 dm3/s (2 scfm) required to close
drain
Nominal bowl size:0,2 litre (7 uid oz)
Materials:
Body: Zinc
Bowl:
Metal: Aluminium
Transparent, optional: Polycarbonate
Metal bowl liquid level indicator lens, standard:
Grilamid
Metal bowl sight glass, optional:Pyrex
Element: Sintered plastic
Elastomers: Synthetic rubber
Replacement Items
Service kit, contains required items circled:
4380-200
Prismatic sight glass 4380-040
Pyrex sight glass 4380-041
Filter element, 5 µm 4338-01
Filter element, 40 µm 4338-02
Manual drain 684-84
Automatic drain 3000-97
Mechanical service Indicator (1) 5797-50
Installation
1. Install unit vertically in air line -
• vertically (bowl down),
• with air ow in direction of arrow on body,
• upstream of regulators, lubricators, and cycling valves,
• as close as possible to the air supply when used as a
main line lter,
• as close as possible to the device being serviced
when used as a nal lter.
2. Before assembling the basic unit into the yoke the port
seal o-rings should be lightly smeared with o-ring grease.
3. Locate clamp ring under lugs on top of yoke, offer basic
unit into yoke with directional arrows correctly aligned
(an interference t prevents assembly if misaligned)
before engaging and fully tightening the clamp ring.
4. Turn bowl or bowl guard fully clockwise into
body before pressurizing. Lock symbols on
body and bowl guards must align.
5. Auto-drain units may be tted with a short
drain pipe and connector, minimum 5 mm
bore, to the G1⁄8 bottom outlet.
A B
C
Servicing
1. Open manual drain to expel accumulated
liquids. Keep liquids below bafe (53).
2. To operate automatic drain manually, li
operating pin in bottom outlet with a blunt
rod.
3. Clean or replace lter element when dirty.
Disassembly
1. Shut off inlet pressure. Reduce pressure in
inlet and outlet lines to zero.
2. For ease of maintenance the unit can be re moved
from the yoke by unscrewing the clamp ring, which
will jack the unit out downwards.
3. Li and turn the lter bow counterclockwise and
remove with bowl o-ring.
4. Disassemble in general accordance with the item
numbers on exploded view. Do not remove the drains
or the service indicator unless replacement is neces-
sary. Remove and replace only if they malfunction.
Cleaning
1. Partial cleaning of the lter element is possible
by washing the element in soapy water and blow-
ing out thoroughly with compressed air. Replace-
ment by a clean element is
recommended. Clean plastic bowl and lens (45)
with warm water only. Clean other parts with
warm water and soap.
2. Rinse and dry parts. Blow out internal passages in
body with clean, dry compressed air.
3. Inspect parts. Replace those found to be damaged.
Replace plastic bowl with a metal bowl if plastic
bowl shows signs of cracking or cloudiness.
Assembly
1. Lubricate o-rings with o-ring grease.
2. Assemble the unit as shown on the exploded view.
3. Torque Table
Torque in
Item N-m (Inch-Pounds)
55 (Filter guide) 2,0 ... 2,7 max (18 ... 25)
4. Assemble bafe (53), contact + 1/4 turn.
5. Turn bowl or bowl with guard fully clockwise
into body.
Caution
Water vapor will pass through these units and could
condense into liquid form downstream as air temper-
ature drops. Install an air dryer if water condensation
could have a detrimental effect on the application.
Technical features
Option selector
Port
2 1/4”
3 3/8“
4 1/2“
6 3/4
Option
D Service indicator
N None
Bowl
D Metal
P Transparent with guard
R Metal with Pyrex sight glass
Element
1 5 µm
2 25 µm
3 40 µm
Thread
A PTF (1/8 PTF gauge ports)
B ISO Rc taper (1/8 ISO Rc gauge ports)
G ISO G parallel (1/8 ISO Rc gauge ports)
N No thread (basic unit)
F64G – ˙˙˙ – ˙˙˙
Drain
A Automatic
M Manual
Q Manual 1/4 turn
55
56 8
7
62
4
3
5
1
48
32
47
18
31
30
29
43
44
46
45
40
36
38
37
41
42
39
33
35
34
26
22
24
23
27
28
25
19
21
20
54
53

I&M/en 8.240.100.02
Our policy is one of continued research and development. We therefore reserve the right to amend,
without notice, the specifications given in this document. (1999 - I&M8074d) © 2020 IMI International s.r.o.
F64G Filter
Installation & Maintenance Instructions
01/22
WARNING
These products are intended for use in industrial
compressed air systems only. Do not use these
products where pressures and temperatures can
exceed those listed under Technical Data.
Polycarbonate plastic bowls can be damaged and
possibly burst if exposed to such
substances as certain solvents, strong
alkalies, compressor oils containing ester-based
additives or synthetic oils. Fumes of these substances
in contact with the polycarbonate bowl, externally or
internally, can also result in damage. Clean with warm
water only.
Use metal bowl in applications where a plastic bowl
might be exposed to substances that are incompati-
ble with polycarbonate.
Before using these products with uids other than
air, for non industrial applications, or for life-support
systems consult Norgren.
