imilab W13 User manual
IMILAB Sma Watch W13
User Manual
Please refer to this manual before using the product.
V0.0.1
Scan the QR code to
view the manual in more languages
Notes:
1.1 The Company resees the right to modify the contents of the
manual without prior notice. In general, the functions may va in some
versions of the software.
1.2 Before using the product, please use the included charging cable to
charge this product for not less than 2 hours.
1.3 Before using the product, please connect with your mobile app to
synchronize the time and set your personal information.
1.4 The product is IP68 waterproof, but please keep away from deep sea
diving, hot water, tea or other corrosive liquids, otherwise it may cause
damage to the watch. Any problems caused by these factors will not be
covered by the product warranty and free repair seice.
01 How to wear
For daily use, wear the watch at about one-nger distance from
your wrist bone and comfoably tighten the strap.
Note: Excessively loose wear may aect the data capture of the
hea rate sensor.
02 How to download & connect to APP
02.1 Press and hold the side button to power on the watch, slide down
the watch home page from the top, open Settings - APP Download -
Download QR Code, scan the QR code with your mobile phone,
download and install "Imilab Fit" APP.Or you can scan the QR code below
to download from the mobile app market for installation.
02.2 Open the "Imilab Fit" App, select "Add Device" on the Devices page,
and then follow the on-screen instructions.
21
02.3 How to make Bluetooth calls
(1) Android mobile: When the APP is successfully bound to the watch
and the data is synchronized, it will automatically prompt whether to
pair with IMISW13 (ID-xxxx), Then it can be paired directly.
(2) The iOS mobile (iOS 13 or above) suppos one-key connection
prompt. When the APP is successfully bound to the watch and the data
is synchronized, it will automatically prompt IMISW13 (ID-xxxx) would
like to piar with your iPhone, Then it can be paired directly.
(3) For some iOS and Android mobile phone: When the APP is
successfully bound to the watch, in order to use the Phone function, you
need to manually enter the phone Settings - Bluetooth - search audio
Bluetooth IMISW13 (ID-xxxx). Click to pair the audio Bluetooth IMISW13
(ID-xxxx) , the Phone function can only be used normally after
successful pairing.
Tips:
(1). Please upgrade the app to latest version to get a better experience.
(2). Andorid 5.0 and IOS 9.0 or above system are compatible with the
App.
(3). For the rst time connection with iphone, “Pair” reminder will
pop-up, click to pair, then incoming calls and instant messages will be
pushed.
(4). For the rst time connection with android, “Permissions” reminder
will pop-up, please follow up the guidance and allow permissions to
ensure all functions working properly.
(5). To connect successfully, please turn on mobile phone’s bluetooth,
GPS and network.
(6). If the device cannot be searched or connected during use, please
reset or turn o the watch to t again.
03 Operating Instructions
a. Control panel: Slide the Home screen from the top to down.
b. Message: Slide the Home screen from the bottom to the top.
c. Main Menu Page: Slide right from the main page. You can change the
menu styles by double click on upper button or change on setting page.
d. Open shocut inteace: Slide the Home screen from right to left.
e. You can switch the watch face by rotating the digital crown in the
Home screen.
f. Power on/o: Press and hold the digital crown button for 3 seconds on
the watch screen.
g. During normal operation: Press the digital crown to return to the
upper level function inteace; when in the watch face screen, press the
digital crown again to light up/o the screen.
h.Rota crown function: The list theme can be scrolled up and down by
rotating the crown, and the Home screen can be scrolled left and right
by rotating the crown.
i. Press the down button to enter the spos list.
04 Function introduction
.
Notes:
1.1 The Company resees the right to modify the contents of the
manual without prior notice. In general, the functions may va in some
versions of the software.
1.2 Before using the product, please use the included charging cable to
charge this product for not less than 2 hours.
1.3 Before using the product, please connect with your mobile app to
synchronize the time and set your personal information.
1.4 The product is IP68 waterproof, but please keep away from deep sea
diving, hot water, tea or other corrosive liquids, otherwise it may cause
damage to the watch. Any problems caused by these factors will not be
covered by the product warranty and free repair seice.
01 How to wear
For daily use, wear the watch at about one-nger distance from
your wrist bone and comfoably tighten the strap.
Note: Excessively loose wear may aect the data capture of the
hea rate sensor.
02 How to download & connect to APP
02.1 Press and hold the side button to power on the watch, slide down
the watch home page from the top, open Settings - APP Download -
Download QR Code, scan the QR code with your mobile phone,
download and install "Imilab Fit" APP.Or you can scan the QR code below
to download from the mobile app market for installation.
02.2 Open the "Imilab Fit" App, select "Add Device" on the Devices page,
and then follow the on-screen instructions.
02.3 How to make Bluetooth calls
(1) Android mobile: When the APP is successfully bound to the watch
and the data is synchronized, it will automatically prompt whether to
pair with IMISW13 (ID-xxxx), Then it can be paired directly.
(2) The iOS mobile (iOS 13 or above) suppos one-key connection
prompt. When the APP is successfully bound to the watch and the data
is synchronized, it will automatically prompt IMISW13 (ID-xxxx) would
like to piar with your iPhone, Then it can be paired directly.
(3) For some iOS and Android mobile phone: When the APP is
successfully bound to the watch, in order to use the Phone function, you
need to manually enter the phone Settings - Bluetooth - search audio
Bluetooth IMISW13 (ID-xxxx). Click to pair the audio Bluetooth IMISW13
(ID-xxxx) , the Phone function can only be used normally after
successful pairing.
Tips:
(1). Please upgrade the app to latest version to get a better experience.
(2). Andorid 5.0 and IOS 9.0 or above system are compatible with the
App.
(3). For the rst time connection with iphone, “Pair” reminder will
pop-up, click to pair, then incoming calls and instant messages will be
pushed.
(4). For the rst time connection with android, “Permissions” reminder
will pop-up, please follow up the guidance and allow permissions to
ensure all functions working properly.
(5). To connect successfully, please turn on mobile phone’s bluetooth,
GPS and network.
(6). If the device cannot be searched or connected during use, please
reset or turn o the watch to t again.
03 Operating Instructions
IMISW13(ID-C5C6)
a. Control panel: Slide the Home screen from the top to down.
b. Message: Slide the Home screen from the bottom to the top.
c. Main Menu Page: Slide right from the main page. You can change the
menu styles by double click on upper button or change on setting page.
d. Open shocut inteace: Slide the Home screen from right to left.
e. You can switch the watch face by rotating the digital crown in the
Home screen.
f. Power on/o: Press and hold the digital crown button for 3 seconds on
the watch screen.
g. During normal operation: Press the digital crown to return to the
upper level function inteace; when in the watch face screen, press the
digital crown again to light up/o the screen.
h.Rota crown function: The list theme can be scrolled up and down by
rotating the crown, and the Home screen can be scrolled left and right
by rotating the crown.
i. Press the down button to enter the spos list.
04 Function introduction
.
Notes:
1.1 The Company resees the right to modify the contents of the
manual without prior notice. In general, the functions may va in some
versions of the software.
1.2 Before using the product, please use the included charging cable to
charge this product for not less than 2 hours.
1.3 Before using the product, please connect with your mobile app to
synchronize the time and set your personal information.
1.4 The product is IP68 waterproof, but please keep away from deep sea
diving, hot water, tea or other corrosive liquids, otherwise it may cause
damage to the watch. Any problems caused by these factors will not be
covered by the product warranty and free repair seice.
01 How to wear
For daily use, wear the watch at about one-nger distance from
your wrist bone and comfoably tighten the strap.
Note: Excessively loose wear may aect the data capture of the
hea rate sensor.
02 How to download & connect to APP
02.1 Press and hold the side button to power on the watch, slide down
the watch home page from the top, open Settings - APP Download -
Download QR Code, scan the QR code with your mobile phone,
download and install "Imilab Fit" APP.Or you can scan the QR code below
to download from the mobile app market for installation.
02.2 Open the "Imilab Fit" App, select "Add Device" on the Devices page,
and then follow the on-screen instructions.
02.3 How to make Bluetooth calls
(1) Android mobile: When the APP is successfully bound to the watch
and the data is synchronized, it will automatically prompt whether to
pair with IMISW13 (ID-xxxx), Then it can be paired directly.
(2) The iOS mobile (iOS 13 or above) suppos one-key connection
prompt. When the APP is successfully bound to the watch and the data
is synchronized, it will automatically prompt IMISW13 (ID-xxxx) would
like to piar with your iPhone, Then it can be paired directly.
(3) For some iOS and Android mobile phone: When the APP is
successfully bound to the watch, in order to use the Phone function, you
need to manually enter the phone Settings - Bluetooth - search audio
Bluetooth IMISW13 (ID-xxxx). Click to pair the audio Bluetooth IMISW13
(ID-xxxx) , the Phone function can only be used normally after
successful pairing.
Tips:
(1). Please upgrade the app to latest version to get a better experience.
(2). Andorid 5.0 and IOS 9.0 or above system are compatible with the
App.
(3). For the rst time connection with iphone, “Pair” reminder will
pop-up, click to pair, then incoming calls and instant messages will be
pushed.
(4). For the rst time connection with android, “Permissions” reminder
will pop-up, please follow up the guidance and allow permissions to
ensure all functions working properly.
(5). To connect successfully, please turn on mobile phone’s bluetooth,
GPS and network.
(6). If the device cannot be searched or connected during use, please
reset or turn o the watch to t again.
03 Operating Instructions
a. Control panel: Slide the Home screen from the top to down.
b. Message: Slide the Home screen from the bottom to the top.
c. Main Menu Page: Slide right from the main page. You can change the
menu styles by double click on upper button or change on setting page.
d. Open shocut inteace: Slide the Home screen from right to left.
e. You can switch the watch face by rotating the digital crown in the
Home screen.
f. Power on/o: Press and hold the digital crown button for 3 seconds on
the watch screen.
g. During normal operation: Press the digital crown to return to the
upper level function inteace; when in the watch face screen, press the
digital crown again to light up/o the screen.
h.Rota crown function: The list theme can be scrolled up and down by
rotating the crown, and the Home screen can be scrolled left and right
by rotating the crown.
i. Press the down button to enter the spos list.
04 Function introduction
.
85%
21
Notes:
1.1 The Company resees the right to modify the contents of the
manual without prior notice. In general, the functions may va in some
versions of the software.
1.2 Before using the product, please use the included charging cable to
charge this product for not less than 2 hours.
1.3 Before using the product, please connect with your mobile app to
synchronize the time and set your personal information.
1.4 The product is IP68 waterproof, but please keep away from deep sea
diving, hot water, tea or other corrosive liquids, otherwise it may cause
damage to the watch. Any problems caused by these factors will not be
covered by the product warranty and free repair seice.
01 How to wear
For daily use, wear the watch at about one-nger distance from
your wrist bone and comfoably tighten the strap.
Note: Excessively loose wear may aect the data capture of the
hea rate sensor.
02 How to download & connect to APP
02.1 Press and hold the side button to power on the watch, slide down
the watch home page from the top, open Settings - APP Download -
Download QR Code, scan the QR code with your mobile phone,
download and install "Imilab Fit" APP.Or you can scan the QR code below
to download from the mobile app market for installation.
02.2 Open the "Imilab Fit" App, select "Add Device" on the Devices page,
and then follow the on-screen instructions.
02.3 How to make Bluetooth calls
(1) Android mobile: When the APP is successfully bound to the watch
and the data is synchronized, it will automatically prompt whether to
pair with IMISW13 (ID-xxxx), Then it can be paired directly.
(2) The iOS mobile (iOS 13 or above) suppos one-key connection
prompt. When the APP is successfully bound to the watch and the data
is synchronized, it will automatically prompt IMISW13 (ID-xxxx) would
like to piar with your iPhone, Then it can be paired directly.
(3) For some iOS and Android mobile phone: When the APP is
successfully bound to the watch, in order to use the Phone function, you
need to manually enter the phone Settings - Bluetooth - search audio
Bluetooth IMISW13 (ID-xxxx). Click to pair the audio Bluetooth IMISW13
(ID-xxxx) , the Phone function can only be used normally after
successful pairing.
Tips:
(1). Please upgrade the app to latest version to get a better experience.
(2). Andorid 5.0 and IOS 9.0 or above system are compatible with the
App.
(3). For the rst time connection with iphone, “Pair” reminder will
pop-up, click to pair, then incoming calls and instant messages will be
pushed.
(4). For the rst time connection with android, “Permissions” reminder
will pop-up, please follow up the guidance and allow permissions to
ensure all functions working properly.
(5). To connect successfully, please turn on mobile phone’s bluetooth,
GPS and network.
(6). If the device cannot be searched or connected during use, please
reset or turn o the watch to t again.
03 Operating Instructions
a. Control panel: Slide the Home screen from the top to down.
b. Message: Slide the Home screen from the bottom to the top.
c. Main Menu Page: Slide right from the main page. You can change the
menu styles by double click on upper button or change on setting page.
d. Open shocut inteace: Slide the Home screen from right to left.
e. You can switch the watch face by rotating the digital crown in the
Home screen.
f. Power on/o: Press and hold the digital crown button for 3 seconds on
the watch screen.
g. During normal operation: Press the digital crown to return to the
upper level function inteace; when in the watch face screen, press the
digital crown again to light up/o the screen.
h.Rota crown function: The list theme can be scrolled up and down by
rotating the crown, and the Home screen can be scrolled left and right
by rotating the crown.
i. Press the down button to enter the spos list.
04 Function introduction
.
Crown
Button
Spo modes: 100 spos modes are
suppoed: outdoor running, cycling, badminton,
table tennis, tennis, hiking, walking, basketball,
soccer, baseball, volleyball, cricket, rugby, eld
hockey, dancing, indoor cycling, sit-ups,
treadmill, gymnastics, rowing, jumping Jacks,
freestyle training, outdoor walking, indoor
running, etc.
Status: Record the number of steps, distance,
and calories for the day. More detailed
information analysis and data records can be
viewed in the APP.
Bluetooth Calling: While the watch and your
phone are connected via Bluetooth, you can
make Bluetooth calls on the watch.
Call logs:Record your call histo.
Contacts: You can add contacts
synchronously in the APP.
Switch: BT Bluetooth switch (control call
function).
Hea rate monitor: Measure the current hea
rate value; the watch can record and
display the hea rate value for 24 hours,and
automatically monitor the hea rate eve 10
minutes. More detailed analysis and data records
can be viewed in the APP. (The value is for
reference only and cannot be used as a medical
basis.)
Sleep: Record and display the total sleeping
hours, deep sleep and light sleep of the
previous night. More detailed analysis and data
records can be viewed in the APP.
Blood oxygen: Test the current blood oxygen
value; it monitors blood oxygen throughout the
day, more detailed analysis and data records
can be viewed in the APP. (The value is for
reference only and cannot be used
as a medical basis.)
SOS: You can add contacts in "SOS call" on
the APP side.
Weather: Display the current weather
conditions and the weather for the next 3 days.
The weather information will be displayed
once connecting to the APP. If the watch
is disconnected for a long time, the weather
information will not be updated.
Music control: After connecting to the mobile
phone, you can click “play/pause/previous/next
song” on the sma watch to control the music
from mobile phone, and the volume can be
adjusted.
Notications: Message reminders, sync
notication from your phone, save up to
8 latest messages .
Alarm: 8 alarm reminders can be set, the watch
will vibrate and the screen will be bright.
Pressure: Measure the current pressure, the
watch can record and display the pressure
value 24 hours a day. More detailed
information analysis and data records can be
viewed in the APP. (Values are for reference
only and cannot be used as medical basis).
Mood: Test the current mood. More detailed
information analysis and data records can be
viewed in the APP. (The values are for
reference only and cannot be used as
medical basis).
testing
Respirato rate: Measure the current
respirato rate. (Values are for reference
only and cannot be used as medical basis).
Breathing training: You can set the
breathing rhythm and time, and follow the
training prompts to complete the breathing
training.
Games: Bird game.
Voice assistant: Double-click the down button
to enter the voice assistant, double click the
voice assistant to wake up the phone function.
(Note: The watch needs to be connected to the
mobile phone via Bluetooth before it can be
used.)
Other functions: Stopwatch/ Flashlight/Tim-
er/Find phone.
testing
Sound setting: Turn on/o enteainment
sound: play music/ watch videos from wechat
moments, watch TV/movies etc, control the
watch play sound.(The main control is the
third-pay playback sound)Ringtone for
incoming calls: control whether the sound of
the watch is on or o.
Always-on Display:When always-on screen
mode is on, always show a clock when your
watch isn't in use. ( Power consumption will be
increased)
Settings: Watch face/Theme/Always-On
Display/Brightness/Screen Time/Sounds/
Info/O/Reset/QR Code/Password
Brirhtness
Watch face
05 Other functions
Sedenta reminder, do not disturb, lower batte reminder, incoming
call reminder, shake to take photo, nd watch, online watch face/custom
watch face, 12/24 time system, unit setting, raise to wake, physiological
cycle reminder, goal reminder.
06 Charge the batte
1. Place the watch on the charging head and keep the charging contacts
on the back of the watch completely attached to the metal contacts on
the charging head.
2. Connect the charging cable to a standard USB charger purchased
through regular channels with an output voltage of 5V and an output
current of 0.5A and above.
If the watch cannot be turned on after being left for a long time, please
wipe the charging contact plate of the charging cable clean when using
it again to avoid sweat or moisture residue.
07 Warranty
1. In case of any quality issues caused by the manufacturing, material
and design of this product during normal use, the motherboard is
covered by a one-year warranty from the date of purchase, and the
batte and charging cable are covered by a six-month warranty.
2. No warranty will be available for malfunction caused by the user's
personal reasons, for example,
1) Malfunction caused by unauthorized disassembly, modication of the
watch, etc.
2) Malfunction caused by inadveent dropping during use.
3) All man-made damage or due to third-pay fault, misuse ( for
example, ingress of water, external shock crack, scratches and damage
to peripheral components, etc.), will not be covered by the warranty.
3. For repair and maintenance within the warranty, please provide the
warranty card with the date of purchase and the stamp of the place of
purchase.
4. Customers who need product repair seice should take the product
to our company or our distribution point.
5. All features of the product are subject to the actual product.
NOTE: This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to pa 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful inteerence in a residential installation. This equipment
generates; uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause
harmful inteerence to radio communications. However, there is no
guarantee that inteerence will not occur in a paicular installation. If
this equipment does cause harmful inteerence to radio or television
reception, which can be determined by turning the equipment o and
on, the user is encouraged to t to correct the inteerence by one or
more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit dierent from that to
which the receiver is connected.
-Consult the dealer or an experienced radio/TV technician for help.
Changes or modications not expressly approved by the pay
responsible for compliance could void the user's authority to operate the
equipment.
Specifications
IMILAB Smart Watch W13
Model
Battery Capacity 300mAh
Battery Type Li-ion
Charging Voltage 5 V
Water & Dust Proof IP68
Working Temperature -20°C ~ 45°C
FCC ID 2APA9-IMISW13
IMISW13
Table of contents
Other imilab Watch manuals
