Immergas VICTRIX OMNIA Operating instructions

Instructions and recommendations
Installer
User
Maintenance technician
*1.042016ENG*
*1.042016ENG*
IE VICTRIXOMNIA

2

3
INDEX
Dear Customer.................................................................................. 4
General Recommendations............................................................. 4
Safety symbols used.......................................................................... 6
Personal protective equipment ....................................................... 6
1 Boiler installation ........................................................7
1.1 Installation warnings........................................................... 7
1.2 Main dimensions................................................................ 11
1.3 Minimum installation distances ...................................... 11
1.4 Antifreeze protection......................................................... 12
1.5 Installation inside the recessed frame (Optional).......... 13
1.6 Boiler connection group (Optional)................................ 13
1.7 Gas connection................................................................... 14
1.8 Hydraulic connection........................................................ 15
1.9 Electrical connection......................................................... 16
1.10 Remote controls and room chrono-thermostats
(Optional) ........................................................................... 17
1.11 External temperature probe (Optional).......................... 18
1.12 Immergas ue systems ...................................................... 18
1.13 Tables of resistance factors and equivalent lengths of
“Green Range” ue system components ......................... 20
1.14 Outdoor installation in partially protected area ............ 22
1.15 Internal installation using a recessed frame with
direct air intake .................................................................. 24
1.16 Concentric horizontal kit installation............................. 25
1.17 Concentric vertical kit installation .................................. 26
1.18 Separator kit installation................................................... 28
1.19 C9 adaptor kit installation ................................................ 29
1.20 Ducting of ues or technical slots.................................... 31
1.21 Conguration type B, open chamber and fan
assisted for indoors............................................................ 31
1.22 Flue exhaust to ue/chimney............................................ 32
1.23 Flues, chimneys and chimney caps.................................. 32
1.24 Water treatment plant lling ............................................ 33
1.25 System lling....................................................................... 33
1.26 Filling the condensate drain trap..................................... 33
1.27 Gas system start-up............................................................ 34
1.28 Boiler start-up (Ignition) .................................................. 34
1.29 Circulation pump............................................................... 35
1.30 WAVE 3 Circulation pump............................................... 36
1.31 Kits available on request.................................................... 38
1.32 Main components .............................................................. 39
2 Instructions for use and maintenance....................... 40
2.1 General recommendations ............................................... 40
2.2 Cleaning and maintenance ............................................... 42
2.3 Control panel...................................................................... 42
2.4 Boiler use............................................................................. 43
2.5 Fault and anomaly signals................................................. 44
2.6 Parameters and information menu.................................. 48
2.7 Boiler switch-o................................................................. 49
2.8 Restore central heating system pressure ......................... 49
2.9 Draining the system........................................................... 49
2.10 Emptying the D.H.W. circuit............................................ 49
2.11 Antifreeze protection......................................................... 49
2.12 Prolonged inactivity........................................................... 49
2.13 Cleaning the case ............................................................... 49
2.14 Permanent shutdown......................................................... 49
3 Instructions for maintenance and initial check ........ 50
3.1 General recommendations ............................................... 50
3.2 Initial check......................................................................... 50
3.3 Yearly appliance check and maintenance........................ 51
3.4 Hydraulic diagram............................................................. 53
3.5 Wiring diagram.................................................................. 54
3.6 Troubleshooting ................................................................. 55
3.7 Converting the boiler to other types of gas. ................... 56
3.8 Calibration type involving the replacement of a
component. ......................................................................... 56
3.9 Complete calibration function ......................................... 57
3.10 CO2 regulation................................................................... 58
3.11 Quick calibration ............................................................... 59
3.12 Flue test ............................................................................... 60
3.13 P.C.B. programming .......................................................... 61
3.14 Solar panels coupling function......................................... 65
3.15 "Chimney sweep” function ............................................... 65
3.16 Pump anti-block function................................................. 65
3.17 ree-way anti-block system............................................ 65
3.18 Radiators antifreeze function ........................................... 65
3.19 P.C.B. periodical self-check............................................... 65
3.20 Automatic venting function.............................................. 65
3.21 Screed heater function....................................................... 66
3.22 Casing removal................................................................... 67
4 Technical data............................................................. 68
4.1 Variable heat output........................................................... 68
4.2 Combustion parameters.................................................... 69
4.3 Technical data table ........................................................... 70
4.4 Key for data nameplate...................................................... 71
4.5 Technical parameters for combination boilers (in
compliance with Regulation 813/2013) .......................... 72
4.6 Product che (in compliance with Regulation
811/2013) ............................................................................ 73
4.7 Parameters for lling in the package che...................... 74

4
Dear Customer
Our compliments for having chosen a top-quality Immergas product, able to ensure well-being and safety for a long period of time. As an
Immergas Customer, you can also count on a qualied aer-sales service, prepared and updated to guarantee constant eciency of your
boiler. Read the followingpages carefully: youwillbe able todrawuseful tips on the correct useof thedevice, compliance ofwhich will conrm
yoursatisfaction withtheImmergas product.
For assistance and routine maintenance, contact Authorised Technical Service Centres: they have original spare parts and are specically
trained directly bythe manufacturer.
GENERALRECOMMENDATIONS
isbookcontainsimportantinformationforthe:
Installer (section 1);
User (section 2);
MaintenanceTechnician (section 3).
• eusermust carefully read the instructionsinthe specicsection(section2).
• eusermust limitoperationson theappliance only tothose explicitly allowedin thespecic section.
• Everyoperationcarried outontheheatpump(e.g. set up,inspection,installationandcommissioning),mustmandato-
rily be performed by authorised personnel alone and in possession of a technical engineering or professional degree
qualifying them to perform these tasks. ey must also have attended a refresher course acknowledged by competent
authorities.isparticularly appliestopersonalspecialised inC.H. andair-conditioningsystemsandqualiedelectri-
cians who, due to their specialised training, skills and experience are experts in the correct installation and mainte-
nanceofC.H.,coolingandair-conditioningsystems.
• eappliance must be installed byqualied and professionallytrained personnel.
• einstructionbooklet is anintegral andessential partoftheproductandmust begiventothe new userinthecase oftransfer
orsuccessionofownership.
• It must be stored with care and consulted carefully, as all of the warnings provide important safety indications for installa-
tion, use andmaintenance stages.
• In compliance with the legislation in force, the systems must be designed by qualied professionals, within the dimensional
limits established by the Law. Installation and maintenance must be performed in compliance with the regulations in force,
according tothemanufacturer's instructionsandby professionallyqualied sta,meaning sta with specictechnical skills
in theplantsector, as provided forbyLaw.
• Improperinstallationorassembly oftheImmergasdeviceand/orcomponents,accessories,kitsanddevices can causeunex-
pected problemsforpeople,animals and objects. Readthe instructionsprovidedwiththe productcarefully to ensure proper
installation.
• isinstructions manualprovides technicalinformationforinstalling Immergasproducts.Asforthe other issuesrelated to
the installation of products (e.g. safety at the workplace, environmental protection, accident prevention), it is necessary to
complywith theprovisionsofthestandards inforceandtheprinciples of good practice.
• AllImmergasproductsareprotectedwith suitabletransport packaging.
• ematerial mustbe storedina dry placeprotectedfromthe weather.
• Damaged products must notbe installed.
• Maintenance must be carried out by skilled technical sta. For example, the Authorised Service Centre that represents a
guarantee of qualicationsandprofessionalism.
• e appliance must only be destined for the use for which it has been expressly declared. Any other use will be considered
improperandthereforepotentially dangerous.
• If errors occur during installation, operation and maintenance, due to non-compliance with technical laws in force, stand-
ardsorinstructionscontainedinthis booklet(orhoweversuppliedby the manufacturer),the manufacturer is excludedfrom
anycontractual andextra-contractualliability foranydamages and thedevicewarrantyis invalidated.
• In theeventofmalfunctions, faultsorincorrect operation,turnthe applianceo and contact anauthorisedcompany (e.g.the
Authorised Technical Assistance Centre, which has specically trained sta and original spare parts). Do not attempt to
modifyorrepair the appliance alone.

5
e company IMMERGAS S.p.A., with registered oce in via Cisa Ligure 95 42041 Brescello (RE), declares that the design, manufac-
turing andaer-sales assistanceprocessescomplywiththe requirementsofstandardUNIENISO 9001:2015.
For further details on the product CE marking, request a copy of the Declaration of Conformity from the manufacturer, specifying the
appliance modelandthe language ofthecountry.
e manufacturer declines all liability due to printing or transcription errors, reserving the right to make any modications to its tech-
nicalandcommercial documentswithoutforewarning.

6
SAFETY SYMBOLS USED
GENERICHAZARD
Strictly follow all of the indications next to the pictogram. Failure to follow the indications can generate hazard situations
resulting in possibleharm tothe healthof the operatoranduser in general,and/orproperty damage.
ELECTRICALHAZARD
Strictlyfollowall oftheindications nexttothe pictogram. esymbolindicatesthe appliance’s electrical componentsor,in
thismanual, identies actionsthat can causean electrical hazard.
MOVING PARTS
esymbolindicates the appliance’s moving components thatcancause hazards.
DANGEROFHOT SURFACES
esymbolindicates the appliance’s veryhotcomponentsthat cancause burns.
WARNINGS
Strictly follow all of the indications next to the pictogram. Failure to follow the indications can generate hazard situations
resulting in possibleminorinjuriestothe healthofboth theoperatorandthe user in general, and/orslight material damage.
ATTENTION
Read and understand the instructions of the appliance before carrying out any operation, carefully following the instruc-
tions given.Failuretoobservethe instructionsmayresultin malfunctionof theunit.
INFORMATION
Indicates usefultipsoradditional information.
EARTHTERMINAL CONNECTION
esymbolidenties theappliance’searth terminal connectionpoint.
DISPOSALWARNING
e user must not dispose of the appliance at the end of its service life as municipal waste, but send it to appropriate
collectioncentres.
PERSONALPROTECTIVEEQUIPMENT
SAFETYGLOVES
EYE PROTECTION
SAFETY FOOTWEAR

7
INSTALLER
USERMAINTENANCETECHNICIAN
TECHNICALDATA
1BOILER INSTALLATION
1.1 INSTALLATIONWARNINGS
Operatorswhoinstallandservicetheap-
pliance must wear the personal protec-
tive equipment required by applicable
law.
isboilerhas beendesignedforwall-mountedinstalla-
tion only; for central heating and production of domes-
tic hotwaterfordomesticuse andsimilar purposes.
e place of installation of the appliance and relative
Immergas accessories must have suitable features (tech-
nical and structural), such as to allow for (always in safe,
ecientandcomfortableconditions):
- installation (according to the provisions of technical
legislation and technical regulations);
- maintenance operations (including scheduled, peri-
odic, routine andspecial maintenance);
- removal (to outdoors in the place for loading and
transporting the appliances and components) as well
as the eventual replacement of those with appliances
and/or equivalentcomponents.
e wall surface must be smooth, without any protru-
sions or recesses enabling access to the rear part. ey
are not designed to be installed on plinths or oors
(Fig. 1).
By varying the type of installation the classication of
theboileralsovaries,precisely:
- Type B23 or B53 boiler if installed using the relevant
terminal for air intake directly from the room in
which theboiler has beeninstalled.
- Type C boiler if installed using concentric pipes or
othertypesof pipes envisionedforthesealedchamber
boilerforintakeofairandexpulsionofue gas.
Only professionally enabled companies are authorised
toinstallImmergasgasappliances.
Installation must be carried out according to regulation
standards, current legislation and in compliance with
local technical regulations and the required technical
procedures.
OK
1
Itisnotpermittedto installboilers thatareremovedand
decommissionedfromothersystems.
e manufacturer declines all liability for damages
caused by boilersremovedfromothersystemsorforany
non-conformities of such equipment.
Check the environmental operating conditions of all
parts relevant to installation, referring to the values
shown in thetechnical datatablein this booklet.
Installation of the boiler when powered
by LPG or propane air supply must com-
ply with the rules regarding gases with a
greaterdensitythanair(remember,asan
example, that it is prohibited to install
plants powered with the above-men-
tionedgas inroomswheretheoorisata
lowerquotathanthecountrylevel).

8
INSTALLER
USERMAINTENANCETECHNICIAN
TECHNICALDATA
If installinga kitor servicing the appliance,always emp-
tythesystem’sdomestichotwatercircuitrstsoas notto
compromisethe appliance’selectricalsafety(Parag. 2.9,
2.10).
Always disconnect the appliance from voltage and, de-
pending on the type of operation, decrease the pressure
and/or bringit to zerointhegasandDHWcircuits.
If the boiler is connected to a low temperature direct
area, it is necessary to check the necessary ow rate and,
if necessary,add abooster pump.
Beforeinstallingtheappliance,ensure thatitis delivered
in perfect condition; if in doubt, contact the supplier
immediately.
Packing materials (staples, nails, plastic bags, polysty-
renefoam, etc.)constitute a hazardandmust be keptout
ofthereachofchildren.
If the appliance is installed inside or between cabinets,
ensure sucient space for routine servicing; for mini-
muminstallationdistances, seeFig. 3.
It is just as important that the intake
grids and exhaust terminals are not ob-
structed.
Check that no ue gas recirculation is
foundintheair sample points.Allowthe
appliance to reach the maximum heat
output;theCO2valuemeasuredintheair
must be less than 10% of that measured
ontheuegas.
Keep allammable objectsawayfromtheappliance (pa-
per, rags, plastic,polystyrene, etc.).
e minimum distance for exhaust pipes from amma-
blematerials mustbe atleast 25 cm.
Donotplacehouseholdappliancesunderneath theboil-
er as they could be damaged if the safety valve inter-
venes, if the drain trap is blocked, or if there are leaks
from the hydraulic connections; otherwise, the manu-
facturer cannot be held responsible for any damage
causedto thehouseholdappliances.
For the aforementioned reasons, we recommend not
placingfurnishings, furniture, etc. undertheboiler.
In the event of malfunctions, faults or incorrect opera-
tion, turn the appliance o and contact an authorised
company (e.g. the Authorised Technical Assistance
Centre, which has specically trained sta and original
spare parts).
Donotattempttomodify orrepairthe appliancealone.
Any modication to the appliance that is not explicitly
indicated inthis section of thebooklet isforbidden.

9
INSTALLER
USERMAINTENANCETECHNICIAN
TECHNICALDATA
Installationstandards
is boiler can be installed outdoors in a partially pro-
tectedarea.
Apartiallyprotected area is onein whichtheboilerisnot
exposed to the direct action of the weather (rain, snow,
hail, etc.).
is type of installation is possible when permitted by
the laws in force in the appliance's country of destina-
tion.
Installation of gas appliances, ue ex-
haust pipes and combustion air intake
pipes is forbidden in places with a re
risk (for example: garages, closed park-
ing stalls), and in potentially dangerous
places.
Do not install on the vertical projection
ofhobs.
Do not install in places/rooms that con-
stitute public areas of apartment build-
ings, internal stairways or other escape
routes (e.g. oor landings, entrance
halls, etc.).
Installation is also forbidden in places/
rooms that constitute public areas of
apartment buildings such as cellars, en-
trance halls, attics, los, etc., unless oth-
erwise provided for by local regulations
in force.
ese boilers, unless properly isolated,
are not suitable for installation on walls
madeofcombustiblematerial.
Installing the wall recessed frame kit must guarantee
theboilerstable, ecientsupport.
e recessed frame kit ensures appropriate support only if in-
stalled correctly (according to the rules of good practice), follow-
ing theinstructions onits instructionsleaet.
erecessedframe forthe boileris notasupporting structureand
must not replace the wall removed. It is necessary to position the
boilerinsidethewall.
For safety reasons against any leaks it is necessary to plaster the
boilerhousing inthe brickwall.
e installation of the boiler on the wall
must guarantee a stable and eective
supporttothegeneratoritself.
e plugs (standard supply) are only to be used to x the boiler to
the wall; they only ensure adequate support if inserted correctly
(according to technical standards) in walls made of solid or
semi-hollow brick or block. In the case of walls made from hollow
brick or block, partitions with limited static properties, or in any
case walls other than those indicated, a static test must be carried
outtoensureadequatesupport.
ese boilersareusedtoheat watertobelowboilingtem-
peraturein atmospheric pressure.
ey must be connected to a central heating system and
domestic hot water circuit suited to their performance
and capacity.
Riskofdamageduetocorrosioncaused byunsuitable
combustionairandenvironment.
Spray, solvents, chlorine-based detergents, paints, glue,
ammonium compounds, powders and similar cause
productandueductcorrosion.
Check that combustion air power supply is free from
chlorine,sulphur, powders, etc.
Make sure that no chemical substances are stored in the
placeofinstallation.

10
INSTALLER
USERMAINTENANCETECHNICIAN
TECHNICALDATA
If you want to install the product in beauty salons, paint
workshops, carpenter’s shop, cleaning companies or
similar, choose a separate installation area that ensures
combustion air supply that is free from chemical sub-
stances.
Make sure the combustion air is not fed from chimneys
that were used with gas boilers or other heating devices.
In fact, these may cause an accumulation of soot in the
chimney.
Riskofmaterialdamageaerusingspraysandliquidsto
searchforleaks
Leak sprays and liquids clog the reference hole P. Ref.
(Fig. 41)ofthe gas valve, damaging itirreparably.
During installation and maintenance, do not use spray
orliquidsin the upperareaofthe gas valve(side referring
to the electric connections).
Fillingthecondensatedraintrap
On rst lighting of the boiler, ue gas
maycomeoutthecondensatedrain;aer
a few minutes’ operation check that this
no longer occurs. If this is the case, the
draintrapiscorrectlylledwithconden-
sate up to a height that does not allow the
uegastopass.
TypeBopenchamberboilersmustnotbe
installedinplaceswherecommercial,ar-
tisan or industrial activities take place,
whichuseproductsthatmaydevelopvol-
atile vapours or substances (e.g. acid va-
pours, glues, paints, solvents, combusti-
bles, etc.), as well as dusts (e.g. dust
deriving from the working of wood, coal
nes, cement, etc.), which may be dam-
aging for the components of the appli-
anceandjeopardisefunctioning.
Unless otherwise provided for by local
regulations in force, in congurations
B23 and B53, the boilers must not be in-
stalled in bedrooms, bathrooms or bed-
sits.Moreover,theymustnotbeinstalled
in placeswheresolidfuelheat generators
arepresentandinadjoiningrooms.
e installation rooms must be perma-
nentlyventilated,incompliancewiththe
local regulations in force (at least 6 cm²
for every kW of installed heat input, ex-
cept in the event of any increases needed
for electro-mechanical vacuum cleaners
orotherdevicesthatcouldputtheinstal-
lationroomundervacuum).
Install the appliances in B23 and B53 conguration in
non-residential premises and which are permanently
ventilated.
Failure to comply with the above implies
personal responsibility and invalidates
the warranty.

11
INSTALLER
USERMAINTENANCETECHNICIAN
TECHNICALDATA
1.2 MAIN DIMENSIONS
1
2
2
Key (Fig. 2):
V - Electric connection
M - Systemow
SC - Condensate drain (minimum internal diame-
ter Ø13mm)
AC - Domestichot water outlet
G - Gas supply
AF - Domestic hotwater inlet
R - Systemreturn
1 - Boiler directhydraulic connection
2 - Wall-mounted hydraulic connection with Im-
mergasDINtemplate
Height
(mm)
Width
(mm)
Depth
(mm)
738 400 247
CONNECTIONS
GAS DOMESTIC HOT
WATER SYSTEM
GAC AF R M
3/4" 1/2" 1/2" 3/4" 3/4"
1.3 MINIMUMINSTALLATION DISTANCES
3
Key (Fig. 3):
A - 450mm
B - 350 mm
C - 30 mm
D - 30mm
E - 350mm

12
INSTALLER
USERMAINTENANCETECHNICIAN
TECHNICALDATA
1.4 ANTIFREEZEPROTECTION
Minimum temperature-5°C
e boiler is equipped as standard with an antifreeze function
that starts the pump and burner when the water temperature in-
sidetheboilerdropsbelow4°C.
In these conditions the boiler is protected against freez-
ing toan ambienttemperatureof-5°C.
If the boiler is installed in a place where the temperature
drops below-5°C, theappliance can freeze.
Toprevent theriskoffreezingfollowtheinstructionsbelow:
e excessive use of glycol could jeopardise the proper
functioning ofthe appliance.
- Protect the central heating circuit from freezing by inserting a
good-quality antifreeze liquid into this circuit, which is espe-
cially suited for central heating systems and which is manufac-
turer guaranteed not to cause damage to the heat exchanger or
other components of the boiler. e antifreeze liquid must not
be harmful to one's health. e instructions of the manufactur-
er of this liquid must be followed scrupulously regarding the
percentage necessary with respect to the minimum tempera-
tureat whichthesystem must bekept.
- e materials used for the central heating circuit of Immergas
boilers resist ethylene and propylene glycol based antifreeze
liquids (ifthe mixturesarepreparedperfectly).
Minimum temperature-15°C
- Protect the domestic hot water circuit against freezing by using
an accessory that is supplied on request (antifreeze kit) com-
prising two electric heating elements, the relevant wiring and a
control thermostat (carefully read the installation instructions
contained in theaccessory kitpack).
In these conditions the boiler is protected against freez-
ing totemperatureof-15°C.
Boilerantifreezeprotectionisthus ensured onlyif:
- the boiler is correctly connected to gas and electricity power
supply circuits;
- theboileris constantly powered;
- theboileris notin“o”mode;
- theboileris notinanomalyconditions (Par. 2.5);
- theessentialcomponentsoftheboiler arenotfaulty.
e warranty does not cover damage due to interruption of the
electrical power supply and failure to comply with that stated on
the previous page.
If the boiler is installed in places where the temperature
falls below 0°C the domestic hot water and central heat-
ing attachment pipes and the condensate drain pipe
mustbe insulated.
e freezing protection systems described in this chap-
ter are installed only for the protection of the boiler. e
presenceofthesefunctionsanddevices does notexclude
the possibility of parts of the system or domestic hot wa-
tercircuitoutside the boilerfromfreezing.

13
INSTALLER
USERMAINTENANCETECHNICIAN
TECHNICALDATA
1.5 INSTALLATIONINSIDETHE RECESSED
FRAME OPTIONAL
e boiler is designed for installation inside the Immergas re-
cessed frame(suppliedasoptional).
e necessary parts for this type of installation (bracket) must
also be purchased separatelyasoptional kit.
To installproceedasfollows:
- Install the bracket (2) insidetherecessedframexing it with the
screws(3)inthe pre-drilledholes (Fig. 4).
- Wall-mount the boiler (4) by inserting the hooks of the bracket
(2)in therelativeseats(Fig. 5).
- e boiler (4) is now mounted inside the recessed frame (1)
(Fig. 6).
1
2
3
3
4
1
4
2
2
5
1
4
6
1.6 BOILER CONNECTION GROUP
OPTIONAL
e connection unit consisting of all the necessary parts to per-
form the hydraulic and gas system connections of the appliance
comes as optional kit, perform the connections in accordance
with the type of installation to be made and respecting the ar-
rangementshownin(Fig. 7):
1
3
G
V
M
AC
R
SC
AF
2
7
Key (Fig. 7):
V - Electric connection
G - Gas supply
AC - Domestichot water outlet
AF - Domestic hotwater inlet
SC - Condensate drain (minimuminternal diameter Ø13mm)
M - Systemow
R - Systemreturn
1 - Systemllingcock
2 - Systemdraining valve
3 - 3-bar safety valve draintting

14
INSTALLER
USERMAINTENANCETECHNICIAN
TECHNICALDATA
1.7 GAS CONNECTION
Our boilers are designed to operate with methane gas (G20) LPG
andpropaneair(50%air- 50% propane).Powersupplypipesmust
bethe same as or largerthan theboilertting.
Before connecting the gas line, carefully clean inside all
the fuel feed system pipes to remove any residue that
couldimpairboilereciency.
Also make surethegascorresponds to thatforwhichthe
boileris prepared (seeboiler data nameplate).
If dierent, the boiler must be converted for operation
with the other type of gas (see converting appliance for
othergas types).
It isalsoimportanttocheck thedynamic
pressure of the mains (methane or LPG)
used to supply the boiler, which must
comply with EN 437 and its attachment,
as insucient levels may reduce genera-
tor output and cause discomfort to the
user.
Static/dynamic network pressures high-
erthan thoserequiredfor regular opera-
tion may cause serious damage to the ap-
pliance control elements; in this case
shutthegaslineo.
Donotoperatethedevice.
Have the device checked by experienced
personnel.
According to the local regulation in force, make sure
that a gas cock is installed upstream of each connection
between the appliance and the gas system. is cock, if
supplied bythe appliance’s manufacturer, can be direct-
ly connected to the appliance (i.e. downstream from the
pipesconnectingthe systemtotheappliance),according
tothemanufacturer’sinstructions.
e Immergas connection unit, supplied as an optional
kit, also includes the gas cock, whose installation in-
structionsareprovided inthe kit.
In any case, make sure the gas cock is connected proper-
ly.
e gas supply pipe must be suitably dimensioned according to
current regulations in order to guarantee correct gas ow rate to
the burner even in conditions of maximum generator output and
toguaranteeappliance eciency(technicalspecications).
e coupling system must conform to standards in force (EN
1775).
e appliance is designed to operate with fuel gas free
from impurities; otherwise it is advisable to t special
lters upstream of the appliance to restore the purity of
thefuel.
Storagetanks(in caseofsupplyfromLPG depot).
- NewLPGstoragetanks may containresidual inertgases (nitro-
gen) that degrade the mixture delivered to the appliance casing
functioninganomalies.
- Dueto thecompositionoftheLPG mixture, layering ofthemix-
ture components may occur during the period of storage in the
tanks. is can cause a variation in the caloric value of the
mixture delivered to the appliance, with subsequent change in
its performance.

15
INSTALLER
USERMAINTENANCETECHNICIAN
TECHNICALDATA
1.8 HYDRAULIC CONNECTION
In order not to void the condensation module warranty
before making the boiler connections, carefully clean
the heating system (pipes, radiators, etc.) with special
pickling or descaling products to remove any deposits
that couldcompromise correctboiler operation.
3barsafetyvalve
edrainofthesafety valve mustalways beproperlyconveyedto a
draining funnel; consequently, in case of valve operation, the
leaked uid willendup in thesewersystem.
Condensatedrain
To drainthe condensateproduced by theappliance,itisnecessary
toconnect to thedrainagesystem bymeans of acidcondensatere-
sistantpipes, with aninternal Øofat least13mm.
esystem connectingthe appliance tothe drainagesystem must
be carried outin such awayas topreventocclusionand freezing of
theliquidcontainedinit.
Before appliance ignition, ensure that the condensate can be cor-
rectly removed. Aer rst ignition, check that the drain trap is
lledwithcondensate.
Also, comply with national and local regulations on discharging
wastewaters.
In the event condensate is not discharged into the wastewater
drainage system, a condensate neutraliser must be installed to
ensurecompliance withtheparametersestablishedbythe legisla-
tion in force.
A treatment of the heating and water system water is required, in
compliance with the technical standards in force, in order to pro-
tect the system and the appliance from deposits (e.g. scale), slurry
orotherhazardous deposits.
In ordernottovoidthe heatexchangerwarranty,youarerequired
tocomplywithwhat has beenprescribed(Par. 1.24).
Water connections must be made in a rational way using the cou-
plingsonthe boilertemplate.
emanufacturerdeclinesallliabilityintheeventofdamage
causedbytheinstallationofanautomaticllingsystem.
In order to meet the system requirements established by EN 1717
in terms of pollution of drinking water, we recommend installing
theIMMERGAS anti-backowkit tobe usedupstream ofthecold
water inlet connection of the boiler. We also recommend using
category 2 heat transfer uid (ex: water+glycol) in the boiler's pri-
marycircuit(C.H. circuit),asdened in standardEN 1717.
To preserve thedurationofapplianceeciency features,
in the presence of water whose features can lead to the
deposit of lime scale, installation of the “polyphosphate
dispenser”kit is recommended .

16
INSTALLER
USERMAINTENANCETECHNICIAN
TECHNICALDATA
1.9 ELECTRICALCONNECTION
eappliance has anIPX5D protectiondegree;electricalsafety of
the appliance is achieved only when it is connected properly to an
ecientearthing system, as specied by currentsafetystandards.
e manufacturer declines any responsibility for dam-
age or physical injury caused by failure to connect the
boilertoanecientearthingsystem orfailureto comply
with theIEC referencestandards.
Openthecontrolpanel connectionscompartment
(Fig. 8)
To carry out electrical connections, all you have to do is open the
connectionscompartmentasfollows.
Removethe casing:
1. Loosen thescrew(a)atthebottom.
2. Rotate the control panel and then loosen the screw (b) that se-
cures thecontrolpanel’s(d)cover.
3. Press thethree hooks (c) onthecover(d).
4. Removethecover(d)fromthe controlpanel(e).
Atthispoint,it ispossibletoaccessthe terminalboard (f).
Also ensure that the electrical installation corresponds to maxi-
mum absorbed power specications as shown on the boiler data
nameplate.
e boilers are supplied complete with a “Y” type H 05 VVF
3 x 0.75 mm2powersupplycable,withoutplug.
e power supply cable must be connect-
ed to a 230V ±10% / 50Hz mains supply
respecting L-N polarity and earth con-
nection; this network must also have a
multi-pole circuit breaker with class III
overvoltage category in compliance with
installation regulations.
No appliance pipes must ever be used to earth the elec-
tricsystem ortelephonelines.
To protect from possible dispersions of
DC voltage, it is necessary to provide a
typeAdierentialsafetydevice.
If the power cable is damaged, contact a
qualied company (e.g. the Authorised
Technical Assistance Centre) for its re-
placementtoavoidahazard.
epowercablemustfollowtheprescribed route(Par. 1.6);
If the network fuse on the connection terminal board needs re-
placing, thismust alsobe donebyqualiedpersonnel: usea 3.15 A
fastfuse.
For the main power supply to the appliance, never use adapters,
multiplesockets or extensionleads.
Installationwithsystemoperatingatdirect lowtemperature
e boiler can directly supply a low-temperature system by set-
ting the ow temperature adjustment range “t0” and “t1”
(Par. 3.13). In this case, it is suitable to add a specic safety kit (opt-
tional)made upofa thermostat(with adjustabletemperature).
e thermostat must be positioned on the system ow pipe at a
distance ofat least 2 metres fromtheboiler.
1
a
3
c
d
b2
c
c
3
3
4
e
f
8

17
INSTALLER
USERMAINTENANCETECHNICIAN
TECHNICALDATA
1.10 REMOTECONTROLS ANDROOM
CHRONOTHERMOSTATS OPTIONAL
eboileris preparedfortheapplicationofroomchrono-thermo-
stats or remote controls, which are available as optional kits
(Fig. 9).
All Immergas chrono-thermostats are connected with 2 wires
only.
Carefully read the user and assembly instructions contained in
the accessory kit.
Disconnect power to the unit before
makinganyelectrical connections.
9
On/O Immergasdigitalchrono-thermostat.
e chrono-thermostat allows:
- set two room temperature value: one for day (comfort tempera-
ture) andonefornight(reducedtemperature);
- set a weekly programmewith four daily switchonandswitch o
times;
- selecting the required function mode from the various possible
alternatives:
• manualmode (with adjustabletemperature);
• automatic mode (withsetprogramme);
• forced automatic operation (momentarily changing the tem-
perature oftheautomatic program).
echrono-thermostat is poweredbytwo1.5V LR6 typealkaline
batteries.
“ComandoAmicoRemoto”(Remote ControlDevice) V2
(CARV2)withclimatechrono-thermostatfunction.
In addition to the functions described in the previous point, the
CARV2 panel enables the user to control all the important infor-
mation regarding operation of the appliance and the heating sys-
tem with the opportunity to easily intervene on the previously set
parameters, without having to go to where the appliance is in-
stalled.
e panel is provided with self-diagnosis to display any boiler
functioninganomalies.
e climate chrono-thermostat incorporated into the remote
panel enables the system ow temperature to be adjusted to the
actual needs of the room being heated, in order to obtain the de-
sired room temperature with extreme precision and therefore
with evidentsaving inrunning costs.
e CARV2 is fed directly by the boiler by means of the same 2
wires used for the transmission of data between the boiler and de-
vice.
“ComandoAmicoRemoto”(Remote ControlDevice) V2 orOn/
O chrono-thermostatelectricalconnection (Optional).
e operations described below must be
performed aer having removed the
voltage from the appliance.
Any On/O roomthermostatorchrono-thermostatmustbecon-
nectedto terminals 44/40and41, eliminating jumperX40.
Make sure that the On/O thermostat contact is of the “clean”
type, i.e. independent of the mains voltage, otherwise the P.C.B.
would be damaged.
Any Comando Amico Remoto (remote control) V2 must be con-
nected to terminals 44/40 and 41, eliminating jumper X40 on the
P.C.B. (Fig. 40).
eboilercanonlybe connectedtooneremotecontrol.
If the Comando Amico Remoto remote control V2 or any
other On/O chrono-thermostat is used arrange two
separate lines in compliance with current regulations
regardingelectricalsystems.
Ensure elimination of this risk before making the boiler
electrical connections.

18
INSTALLER
USERMAINTENANCETECHNICIAN
TECHNICALDATA
1.11 EXTERNAL TEMPERATURE PROBE
OPTIONAL
e boiler is designed for the application of the external tempera-
tureprobe (Fig. 10),whichisavailableasan optional kit.
Refer to the relative instruction sheet for positioning of the exter-
nal probe.
eprobecanbe connected directlyto theboilerelectricalsystem
and allows the max. system ow temperature to be automatically
decreased when the external temperature increases, in order to
adjust the heat supplied to the system according to the change in
externaltemperature.
eexternal probe always operates whenconnected, regardless of
the presence or type of room chrono-thermostat used and can
workin combinationwith Immergaschrono-thermostats.
e correlation between system ow temperature and external
temperature is determined by the position of the central heating
selector switch on the boiler control panel (or on the CARV2 con-
trol panel if connected to the boiler) according to the curves
shown in thediagram (Fig. 11).
e electric connection of the external probe must be made on
terminals 38 and 39 on the terminal board in the boiler control
panel (Fig. 40).
45
31
58
10
Correctionlawoftheowtemperaturedependingonthe
externaltemperatureanduseradjustmentofthecentral
heatingtemperature.
(*)
11
*Positionofthe centralheatingtemperaturecontrol.
1.12 IMMERGASFLUESYSTEMS
Immergas supplies various solutions separately from the boilers
regardingtheinstallationofair intake terminals and ueexhaust,
which arefundamental forboiler operation.
e boiler must be installed with an original Immergas
“GreenRange”inspectionableair intakesystemandvis-
ible ue gas extraction system made of plastic, with the
exception of the C6conguration, as required by the
regulations in force and by the product’s approval. is
ue system can be identied by the specic identica-
tion mark bearing the following indication: “only for
condensation boilers”.
For non-original ue system, refer to the technical data
ofthe appliance.
e plastic pipes cannot be installed outdoors, for tracts
longerthan40 cm, withoutsuitable protectionfromUV
rays andotheratmosphericagents.
Resistance factors and equivalentlengths
Each uecomponenthasa ResistanceFactorbasedonexperimen-
tal tests and speciedinthe table below.
e Resistance Factor for individual components is independent
from the type of boiler on which it is installed and has a dimen-
sionless size.
It is however, conditioned by the temperature of the uids that
pass through the pipe and therefore, varies according to applica-
tions forair intakeorue exhaust.
Each single component has a resistance corresponding to a cer-
tain length in metres of pipe of the same diameter; the so-called
equivalent length, can be obtained from the ratio between the rel-
ative ResistanceFactors.
Allboilershavean experimentallyobtainablemaximumResist-
anceFactor equalto 100.
e maximum Resistance Factor allowed corresponds to the re-
sistance encountered with the maximum allowed pipe length for
each typeofTerminalKit.
is information allows calculations to be made to verify the pos-
sibilityofsetting upvariousuecongurations.
To dimension the ue ducting using commercial com-
ponents, refer to the table of combustion parameters
(Par. 4.2).

19
INSTALLER
USERMAINTENANCETECHNICIAN
TECHNICALDATA
A
B
12
Positioningthegaskets (black)for“greenrange” uesystems.
Positionthegasket correctly(forbends andextensions) (Fig. 12):
- gasket(A) with notches, touse forbends;
- gasket(B) withoutnotches, to useforextensions.
If necessary, to ease the push-tting, spread the elements with
commonly-usedtalc.
Extensionpipesandconcentricelbowspush-ttings.
To install push-tting extensions with other elements of the ue,
proceed as follows:
- Install theconcentric pipe orelbowwith themale side(smooth)
onthefemale side (with lip seal)tothe end stopon theprevious-
ly installed element in order to ensure sealing eciency of the
coupling.
If the exhaustterminal and/orextensionconcentricpipe
needs shortening, consider that the internal duct must
always protrude by 5 mm with respect to the external
duct.
For safety purposes, do not obstruct the
boiler intake/exhaust terminal, even
temporarily.
e various parts of the ue system must
be checked to ensure that they have been
laid in such a way as to prevent the cou-
pledparts fromdetaching,in particular,
the ue exhaust duct in the Ø80 separa-
torkitconguration.Iftheconditionde-
scribed above is not adequately guaran-
teed, it will be necessary to use the
appropriate retaining clamp kit.
When installing horizontal pipes, a minimum inclina-
tion of 1.5% towards the boiler must be maintained, and
asectionclipwithpinmust be installed every 3 metres.
Installationinsidetherecessedframe
In thismode,installthe ueaccordingto yourneeds usingthe ap-
propriate pre-sectionsintheframe toexit fromits clearances.

20
INSTALLER
USERMAINTENANCETECHNICIAN
TECHNICALDATA
1.13 TABLES OFRESISTANCE FACTORSANDEQUIVALENT LENGTHSOF“GREENRANGE”FLUE
SYSTEM COMPONENTS
TYPEOF DUCT
Resistance
factor
(R)
Equivalent
length
in mofconcentric
pipe Ø 80/125
Concentricpipe80/125Øm1 2,1 1
90° concentric bend80/125Ø 3,0 1,4
Concentric bend 45°Ø80/125 2,1 1
Terminal complete with concentric horizontal intake-exhaust
Ø 80/125 2,8 1,3
Terminal complete with concentric vertical intake-exhaust
Ø 80/125 3,6 1,7
90° concentric bendØ80/125with inspection 3,4 1,6
Stubpipewithinspection Ø 80/125 3,4 1,6
