Immergas UE AUDAX PRO 12 V2 Operating instructions

Instructions and recommendations
Installer
User
Maintenance technician
*1.044471ENG*
*1.044471ENG*
IE MAGIS PRO
121416V2

2
INDEX
Dear Customer..........................................................................................................................................................................................................4
General Recommendations.....................................................................................................................................................................................5
Safetysymbolsused..................................................................................................................................................................................................6
Personal protectiveequipment ...............................................................................................................................................................................6
1 Installingtheindoorunit .......................................................................................................................................................... 7
1.1 Descriptionof theproduct.............................................................................................................................................................................7
1.2 Installationwarnings.....................................................................................................................................................................................7
1.3 Indoorunitmaindimensions......................................................................................................................................................................11
1.4 Minimum installationdistances ................................................................................................................................................................12
1.5 Antifreeze protection...................................................................................................................................................................................13
1.6 Indoorunit connectionunit........................................................................................................................................................................14
1.7 Hydraulic connection ..................................................................................................................................................................................15
1.8 Connectingthechillerline ..........................................................................................................................................................................16
1.9 Electrical connection ...................................................................................................................................................................................16
1.10 Roomchrono-thermostats(Optional).......................................................................................................................................................20
1.11 MODBUStemperatureand humidity roomprobes (Optional) ..............................................................................................................21
1.12 Remotezonecontrol (Optional)..................................................................................................................................................................22
1.13 Dominus (Optional).....................................................................................................................................................................................22
1.14 Humidistat ON/OFF(Optional).................................................................................................................................................................22
1.15 Externaltemperatureprobe (Optional).....................................................................................................................................................23
1.16 Temperature control setting........................................................................................................................................................................24
1.17 Systemlling.................................................................................................................................................................................................25
1.18 Operatinglimits............................................................................................................................................................................................26
1.19 Indoorunit start-up(ignition) ....................................................................................................................................................................27
1.20 Circulationpump .........................................................................................................................................................................................28
1.21 Kitsavailable onrequest...............................................................................................................................................................................29
1.22 Main components.........................................................................................................................................................................................30
2 Instructionsforuse andmaintenance ..................................................................................................................................... 31
2.1 General recommendations..........................................................................................................................................................................31
2.2 Cleaningandmaintenance..........................................................................................................................................................................32
2.3 Control panel ................................................................................................................................................................................................33
2.4 Systemuse......................................................................................................................................................................................................33
2.5 Fault andanomaly signals............................................................................................................................................................................37
2.6 Parameters andinformationmenu.............................................................................................................................................................45
2.7 Indoorunit shutdown ..................................................................................................................................................................................50
2.8 Restore central heatingsystem pressure.....................................................................................................................................................50
2.9 Draining the system .....................................................................................................................................................................................50
2.10 Antifreeze protection...................................................................................................................................................................................50
2.11 Prolongedinactivity.....................................................................................................................................................................................50
2.12 Cleaning the case ..........................................................................................................................................................................................50
2.13 Permanentshutdown ...................................................................................................................................................................................50
2.14 Useofthe remotezonepanel (Optional).....................................................................................................................................................50
3 Instructionsformaintenanceandinitialcheck....................................................................................................................... 52
3.1 General recommendations..........................................................................................................................................................................52
3.2 Initialcheck...................................................................................................................................................................................................52
3.3 Yearlyappliance check andmaintenance...................................................................................................................................................52
3.4 Coilmaintenance .........................................................................................................................................................................................53
3.5 Hydraulic diagram .......................................................................................................................................................................................54
3.6 Wiring diagram ............................................................................................................................................................................................55
3.7 System lter ...................................................................................................................................................................................................63
3.8 Troubleshooting ...........................................................................................................................................................................................63

3
3.9 P.C.B. programming ................................................................................................................................................................................... 64
3.10 First ignitionparameter setting ..................................................................................................................................................................75
3.11 Pump anti-block function ...........................................................................................................................................................................75
3.12 ree-wayanti-blocksystem.......................................................................................................................................................................75
3.13 Radiators antifreeze function .....................................................................................................................................................................75
3.14 Photovoltaicfunction...................................................................................................................................................................................75
3.15 Outdoorunitdisablefunction.....................................................................................................................................................................75
3.16 Divertervalve management(summer /winter).........................................................................................................................................75
3.17 Anti-legionellafunction(if pairedwitha storage tank unit)....................................................................................................................76
3.18 Automatic venting function ........................................................................................................................................................................76
3.19 Preheating function .....................................................................................................................................................................................76
3.20 Screed heaterfunction..................................................................................................................................................................................77
3.21 Dehumidication function .........................................................................................................................................................................78
3.22 Outdoor UnitTestmode Function..............................................................................................................................................................78
3.23 OutdoorUnitPumpDown Function .........................................................................................................................................................78
3.24 Puer in preheating function ......................................................................................................................................................................78
3.25 Night modefunction....................................................................................................................................................................................78
3.26 System setpointcorrectionfunction ..........................................................................................................................................................78
3.27 Heating/ cooling selector function.............................................................................................................................................................79
3.28 DHW recirculationfunction.......................................................................................................................................................................79
3.29 Casing removal .............................................................................................................................................................................................80
4 Technical data.......................................................................................................................................................................... 83
4.1 Technicaldata table(single-phase) .............................................................................................................................................................83
4.2 Technical data table (three-phase) ..............................................................................................................................................................85
4.3 MagisPro12V2productche(in compliance with Regulation811/2013).............................................................................................87
4.4 MagisPro12V2T product che(in compliance with Regulation 811/2013)..........................................................................................88
4.5 Magis Pro12 V2- 12V2Tparameters.........................................................................................................................................................88
4.6 Magis Pro14 V2productche (incompliancewith Regulation811/2013).............................................................................................90
4.7 MagisPro14 V2Tproduct che(in compliancewith Regulation811/2013)..........................................................................................91
4.8 Magis Pro14V2- 14V2T parameters.........................................................................................................................................................91
4.9 MagisPRO16 V2product che(incompliance with Regulation811/2013) ...........................................................................................93
4.10 MagisPro16V2T productche (incompliancewith Regulation811/2013)..........................................................................................94
4.11 Magis Pro16V2- 16 V2T parameters.........................................................................................................................................................94
4.12 Magis Pro12V2 productchepaired with SuperTrioTop(in compliance with Regulation811/2013) ..............................................96
4.13 Magis Pro12V2Tproductche pairedwithSuper TrioTop (incompliancewith Regulation811/2013)...........................................97
4.14 Magis Pro12V2- 12V2T pairedwith SuperTrioTopparameters..........................................................................................................97
4.15 Magis Pro14V2product chepairedwith SuperTrioTop(incompliance with Regulation811/2013) ..............................................99
4.16 Magis Pro14 V2T product chepairedwith Super Trio Top(in compliance withRegulation811/2013) .........................................100
4.17 Parametri Magis Pro14 V2- 14V2Tpaired with Super Trio Top ..........................................................................................................100
4.18 Magis Pro16V2productchepaired with Super Trio Top(in compliancewith Regulation811/2013) ............................................102
4.19 Magis Pro16V2T product chepaired withSuperTrioTop(in compliance withRegulation811/2013) .........................................103
4.20 Magis Pro16 V2 -16 V2T pairedwith Super Trio Topparameters ........................................................................................................103
4.21 Parametersforlling in the packageche................................................................................................................................................105

4
Dear Customer
Congratulations for having chosen atop-qualityImmergas product, able toassurewell-being and safety for along periodof time. AsanIm-
mergas customeryou canalsocounton aQualied Authorised Aer-Sales TechnicalAssistanceCentre,preparedandupdated toguarantee
constant eciency of your appliance. Read the following pages carefully: you will be able to draw useful tips on the proper use of the device,
compliance withwhich will conrmyour satisfaction withtheImmergas product.
For assistance and routine maintenance, contact Authorised Technical Service Centres: they have original spare parts and are specically
trained directlybythemanufacturer.
ermal systems must undergo periodic maintenance and scheduled checks of the energy eciency in compliance with national,
regionalorlocalprovisionsinforce.
e company IMMERGAS S.p.A., with registered oce in via Cisa Ligure 95 42041 Brescello (RE), declares that the design, manufac-
turing and aer-salesassistance processescomplywith the requirements ofstandard UNIENISO 9001:2015.
For further details on the product CE marking, request a copy of the Declaration of Conformity from the manufacturer, specifying the
appliance modelandthe language ofthecountry.
e manufacturer declines all liability due to printing or transcription errors, reserving the right to make any modications to its tech-
nicaland commercialdocuments withoutforewarning.

5
GENERALRECOMMENDATIONS
isbookcontainsimportantinformationforthe:
Installer (section 1);
User (section 2);
MaintenanceTechnician(section 3).
Forinstructionson the UEAUDAXPROV2outdoorcondensingunit, pleasereferto the relevantinstructionmanual;
• euser must carefullyreadthe instructions inthespecic section(section2).
• euser must limit operationsonthe applianceonly tothoseexplicitly allowedin the specicsection.
• Every operationcarriedoutontheheatpump(e.g.setup,inspection,installationandcommissioning),mustmandato-
rily be performed by authorised personnel alone and in possession of a technical engineering or professional degree
qualifying them to perform these tasks. ey must also have attended a refresher course acknowledged by competent
authorities.isparticularlyappliestopersonalspecialised inC.H.andair-conditioningsystemsandqualiedelectri-
cians who, due to their specialised training, skills and experience are experts in the correct installation and mainte-
nanceofC.H.,coolingandair-conditioning systems.
• eappliancemustbe installed byqualied andprofessionallytrained personnel.
• einstructionbooklet isan integraland essentialpart oftheproductandmust begivento the newuser in thecase oftransfer
orsuccessionofownership.
• It must be stored with care and consulted carefully, as all of the warnings provide important safety indications for installa-
tion, useandmaintenancestages.
• In compliance with the legislation in force, the systems must be designed by qualied professionals, within the dimensional
limits established by the Law. Installation and maintenance must be performed in compliance with the regulations in force,
according tothemanufacturer's instructionsandbyprofessionally qualied sta,meaning sta withspecic technical skills
in the plantsector,asprovidedforby Law.
• Improperinstallationorassemblyof the Immergasdevice and/orcomponents,accessories,kits and devices can cause unex-
pected problemsforpeople,animals andobjects.Readthe instructions provided with the product carefully toensureproper
installation.
• isinstructionsmanual providestechnical informationforinstalling Immergasproducts.Asfortheotherissues relatedto
the installation of products (e.g. safety at the workplace, environmental protection, accident prevention), it is necessary to
complywiththe provisionsofthestandardsinforceand the principlesofgoodpractice.
• AllImmergas productsareprotectedwith suitable transportpackaging.
• ematerial must bestoredina dry placeprotected fromthe weather.
• Damaged productsmust notbeinstalled.
• Maintenance must be carried out by skilled technical sta. For example, the Authorised Service Centre that represents a
guarantee ofqualications andprofessionalism.
• e appliance must only be destined for the use for which it has been expressly declared. Any other use will be considered
improperand thereforepotentiallydangerous.
• If errors occur during installation, operation and maintenance, due to non-compliance with technical laws in force, stand-
ardsor instructions containedin this booklet (orhoweversupplied bythemanufacturer),the manufacturerisexcludedfrom
anycontractual and extra-contractual liability foranydamages andthedevice warrantyisinvalidated.
• In theeventofmalfunctions,faultsorincorrect operation,turn the appliance oandcontactan authorisedcompany(e.g.the
Authorised Technical Assistance Centre, which has specically trained sta and original spare parts). Do not attempt to
modifyor repairtheappliance alone.

6
SAFETY SYMBOLSUSED
GENERICHAZARD
Strictly follow all of the indications next to the pictogram. Failure to follow the indications can generate hazard situations
resulting inpossibleharmto the health oftheoperatoranduser ingeneral, and/orpropertydamage.
ELECTRICALHAZARD
Strictlyfollowallofthe indications next tothepictogram.e symbolindicatesthe appliance’selectricalcomponentsor,in
thismanual, identiesactions that cancause an electrical hazard.
WARNINGFORINSTALLER
Read the instructionbooklet carefullybeforeinstallingtheproduct.
WARNINGS
Strictly follow all of the indications next to the pictogram. Failure to follow the indications can generate hazard situations
resulting inpossibleminorinjuries tothehealth ofboththe operatorandthe useringeneral,and/orslightmaterialdamage.
ATTENTION
Read and understand the instructions of the appliance before carrying out any operation, carefully following the instruc-
tions given. Failureto observethe instructions mayresultin malfunctionof the unit.
INFORMATION
Indicates useful tipsoradditional information.
EARTHTERMINALCONNECTION
esymbolidenties the appliance’searth terminal connection point.
DISPOSALWARNING
e user must not dispose of the appliance at the end of its service life as municipal waste, but send it to appropriate
collectioncentres.
PERSONALPROTECTIVEEQUIPMENT
SAFETYGLOVES
EYE PROTECTION
SAFETY FOOTWEAR

7
INSTALLER
USERMAINTENANCETECHNICIAN
TECHNICALDATA
1 INSTALLINGTHEINDOORUNIT
1.1 DESCRIPTIONOFTHEPRODUCT.
Magis Pro12-14-16 V2isa heatpump consisting of:
- UI MP APindoorunit (hereinaer itwillonly bereferred toasindoorunit);
- UE AudaxPro12-14-16 V2outdoorcondensing unit (hereinaer itwillonly bereferred toasoutdoorunit).
Magis ProV2isperfectly operational onlyif the twounits arecorrectlypoweredandinterconnected.
e indoor unit was designed solely for wall mounted installations for heating and air conditioning (and to produce domestic hot water
fordomesticuse andsimilarpurposesonlyifpaired withastorage tank unit).
Fornormal operationismust bepairedwith the followingoutdoorunits:
- UE AUDAXPRO12V2;
- UE AUDAXPRO12V2T;
- UE AUDAXPRO14 V2;
- UE AUDAXPRO14 V2T;
- UE AUDAXPRO16V2;
- UE AUDAXPRO16V2T.
Accordingly,itisnecessarytocomplywithall oftherules regarding safetyand the useofboth appliances.
1.2 INSTALLATIONWARNINGS
Operatorswhoinstallandservicetheappliancemustwearthepersonalprotectiveequipment
requiredby applicable law.
eplaceofinstallationofthe appliance andrelativeImmergasaccessoriesmust havesuitable features (technicalandstructur-
al),such as toallowfor(alwaysin safe, ecientandcomfortableconditions):
- installation(according totheprovisionsof technical legislationandtechnical regulations);
- maintenanceoperations(includingscheduled, periodic, routine andspecial maintenance);
- removal (to outdoors in the place for loading and transporting the appliances and components) as well as the eventual re-
placementofthosewith appliances and/orequivalentcomponents.
Installation must be carried out according to regulation standards, current legislation and in compliance with local technical
regulations andthe required technical procedures.
e wall surface must be smooth, without any protrusions or recesses enabling access to the rear part. ey are not designed to
beinstalledon plinths oroors(Fig. 1).

8
INSTALLERUSERMAINTENANCETECHNICIANTECHNICALDATA
OK
1
eapplianceoperateswithR410Arefrigerantgas.
isgasisODOURLESS.
Paythe utmost attention
Strictly follow the instruction handbook of the outdoor unit before installation and any type
ofoperationonthechillerline.
e manufacturer declines all liability in the event of damage caused by appliances removed from other systems or for any
non-conformities with such equipment.
Onlya professionallyenabledcompanyis authorised toinstall Immergas appliances.
Check the environmentaloperatingconditions ofallpartsrelevantto installation,referringto this booklet.
If installing akitor servicingthe appliance, alwaysempty the system’scircuitrstsoas nottocompromisetheappliance’selec-
tricalsafety(Parag. 2.9).
Alwaysdisconnectthe appliancefromvoltageand, depending onthetype ofoperation,decreasethe pressure and/orbring itto
zero inthesystem circuit.
Beforeinstalling the appliance,ensurethatitisdeliveredin perfectcondition;ifin doubt, contactthe supplier immediately.
Packing materials (staples, nails, plastic bags, polystyrene foam, etc.) constitute a hazard and must be kept out of the reach of
children.
If the appliance is installed inside or between cabinets, ensure sucient space for routine servicing; for minimum installation
distances, see Fig. 4.
Keep all ammableobjectsawayfromthe appliance(paper, rags,plastic, polystyrene, etc.).
Fortheaforementionedreasons, werecommend notplacing furnishings,furniture,etc. undertheindoorunit.
Any modicationto theappliance thatis notexplicitly indicatedinthis section ofthebooklet isforbidden.

9
INSTALLER
USERMAINTENANCETECHNICIAN
TECHNICALDATA
Inanycongurationdonoinstalltheindoorunitandoutdoorunitataltitudesabove2000m.
Installationstandards
isappliance canbeinstalled outdoorsina partially protected area.
Bypartially protected area,we mean onein which the unit isnotdirectly exposed totheelements(rain,snow,hail, etc.).
istypeof installationis possiblewhenpermitted bythelawsinforcein the appliance's countryof destination.
Donotinstallontheverticalprojectionofhobs.
Do not install in places/rooms that constitute public areas of apartment buildings, internal
stairwaysorotherescaperoutes(e.g.oorlandings,entrancehalls,etc.).
Topreventelectrocution,reorinjury,alwaysswitchotheunit,disabletheprotectiveswitch
and, if smoke escapes or if the unit is extremely noisy, contact the Authorised Aer-Sales
TechnicalAssistanceCentre.
Donotinstallnearsourcesofheat.
Using specic kits, the indoor unit can be paired with other Immergas products and installed inside an outdoor wall using the specic
Container SuperTriorecessedframe ormountedonan indoorwallin the Domus ContainerSuper Trio.
Payattentionnottogeneratesparksasfollows:
– Donotremovethefuseswhiletheunitison.
– Donotunplugtheunitwhileitison.
Itisrecommendedtoinstalltheoutlethighup.Laythecablesinsuchawaythattheydonotget
tangled.
Installing thewallrecessedframe kit must guaranteethe indoorunitstable, ecientsupport.
e recessed frame kit ensures appropriate support only if installed correctly (according to the rules of good practice), following the in-
structionsonitsinstructionsleaet.
erecessed frame fortheindoorunitis nota supporting structure andmust notreplace the wall removed. Itis necessarytopositionthe
boilerinsidethewall.
Forsafety reasons againstanyleaksit isnecessarytoplaster the housingcompartmentof the indoorunitinthe brickwall.
Wall mounting of the indoor unit must guarantee stable and ecient support for the genera-
tor.
e plugs (standard supply) are only to be used to x the indoor unit to the wall; they only ensure adequate support if inserted correctly
(according to technical standards) in walls made of solid or semi-hollow brick or block. In the case of walls made from hollow brick or
block, partitions with limited static properties, or in any case walls other than those indicated, a static test must be carried out to ensure
adequatemount.
ese appliances areused toheat waterto belowboilingtemperaturein atmospheric pressure.

10
INSTALLERUSERMAINTENANCETECHNICIANTECHNICALDATA
ey must beattachedto aheatingsystemsuitable fortheircapacity and voltage.
“Anti-Legionella” heat treatment of the Immergas storage tank (only if paired with a storage tank unit and function enabled
whenthe systemisprovidedwith temperaturecontrol).
estoragetank unitmust alsobeinstalledin an environmentin which the temperaturecannotfall below0°C.
Anti-Legionella canonly beactivated iftheoptional DHW electrical resistance isinstalled;
eanti-Legionella functionisprogrammeddirectly onthecontrol panel.
During this phase, the temperatureof the waterinsidethe tankexceeds60°C with the subsequentrisk ofburns.
Keep thisdomestichotwatertreatmentundercontrol(and inform the users)to preventunforeseeabledamage topeople,animals, things.
If required install athermostaticvalveonthedomestichotwateroutlet topreventscalding.
eapplianceisbuilttoalsooperateincoolingmode.
Ifcoldwaterproduction,duringsummer,couldinterfereanddamagethecentralheatingonly
systems, necessary precautions must be taken to prevent that an unintentional production of
coldwaterenterstheheatingonlysystem.
eminimumwatercontentrequiredwithinthesystemis50litres;otherwise,itwillbeneces-
sarytoinstallaninertialstoragetank(optional).
For proper system operation, make sure that the minimum ow rate in operating conditions
neverdropsbelow750l/h.
When the circulation within each room central heating loop is controlled by remotely operated valves, it is important to guar-
anteethe minimumwatercontent(50 litres), evenif all the valvesare closed.
When the circulation within each or certain room central heating loops is controlled by remotely operated valves, it is impor-
tantto guaranteetheminimumow rate, evenif all the valves areclosed. Itisnecessary tohavealoopthatisalways openon the
system(by-pass ornon-intercepted zone),toallowsomefunctionssuchas,forexample,theantifreezefunction.
Failuretocomplywiththeaboveimpliespersonalresponsibilityandinvalidatesthewarranty.
Data nameplatepositioning
2

11
INSTALLER
USERMAINTENANCETECHNICIAN
TECHNICALDATA
1.3 INDOORUNITMAIN DIMENSIONS
702
340
70
55
4
206
120
121
141
440
780
60 720
780
26
5070555570
45
55
40
358 82
3
Key (Fig. 3):
V - Electricalconnection
RR - Systemlling
RU - Storagetankunitreturn
MU - Storagetankunit ow
R - Systemreturn
M - Systemow
LP - Chiller line- liquid phase
GP - Chillerline- gaseous phase
Height
(mm)
Width
(mm)
Depth
(mm)
780 440 340
CONNECTIONS
LINE
CHILLERLINE
D.H.W. SYSTEM
LP GP RR R- M RU-MU
SAE 3/8” SAE 5/8” G 1/2” G 1” G 1”

12
INSTALLERUSERMAINTENANCETECHNICIANTECHNICALDATA
1.4 MINIMUMINSTALLATIONDISTANCES
4
Key (Fig. 4):
A - 450 mm
B - 350 mm
C - 30 mm
D - 30 mm
E - 350mm

13
INSTALLER
USERMAINTENANCETECHNICIAN
TECHNICALDATA
1.5 ANTIFREEZEPROTECTION
Minimum temperature0°C
In theseconditions,the indoorunitisprotectedagainst freezingupto an ambienttemperature of0°C.
If the indoorunitis installed inaplace wherethetemperaturedropsbelow0°C, the appliancecanfreeze.
To preventtheriskoffreezing followtheinstructionsbelow:
Follow the supplier's instructions for the life cycle duration and possible disposal of the anti-
freeze liquid.
eexcessive use ofglycol couldjeopardisethe properfunctioning oftheappliance.
- protect thecentral heatingcircuitfromfreezingbyinsertinga good-qualityantifreeze liquid intothiscircuit,which isspecially suited
forcentral heatingsystemsand which ismanufacturerguaranteed nottocause damage tothe heatexchangerorother componentsof
the indoor unit. e antifreeze liquid must not be harmful to one's health. e instructions of the manufacturer of this liquid must be
strictlyfollowedregarding the necessarypercentagewithrespect tothe minimumtemperatureatwhichthe system mustbekept.
- thematerials used forthe central heatingcircuitof Immergasindoorunitresistethyleneand propyleneglycolbased antifreezeliquids
(if the mixtures arepreparedperfectly).
- An aqueoussolutionmustbemadewith potentialpollutionclassof water2 (EN 1717:2002 orlocal standards in force).
Minimum temperature-15°C
Protect the domestic hot water circuit against freezing by using an accessory that is supplied on request (antifreeze kit) comprising two
electric heating elements, the relevant wiring and a control thermostat (carefully read the installation instructions contained in the ac-
cessory kitpack).
eantifreezesystems described in this chapterareonlyto protect the indoorunit.e presence ofthese functions anddevices
does notexcludethe possibilityofpartsof the circuits outsidetheindoorunit fromfreezing.
If theindoorunit isinstalledin placeswherethetemperaturedropsbelow0°C, the domestichotwaterconnectionpipes must be
insulated(if paired with storagetank unit).
e warranty does not cover damage due to interruption of the electrical power supply and failure to comply with that stated on the pre-
viouspages.
- indoor unit andoutdoorunit areproperlyconnectedto each otherand totheelectrical powersupplycircuits;
- theunitsarecontinuouslypowered;
- theindoorunitis notin“o”mode;
- theunitsarenotinanomaly (Parag. 2.5);
- theantifreeze unit and/or kit essentialcomponentsare notfaulty.
Indoorunit anti-freeze protection (both0°C and-15°C)isonlyensuredif:
In the previously mentionedconditionsand withtheadditionoftheantifreeze kit,theindoorunit isprotectedagainstfreezing
upto atemperature of-15°C.

14
INSTALLERUSERMAINTENANCETECHNICIANTECHNICALDATA
1.6 INDOORUNITCONNECTIONUNIT
- ehydraulicconnectionunitis supplied asperstandardwithMagisPro V2. Makethe hydraulicconnectionasshownbelow, making
sure toprotect the system owandreturn pipes with theirsuppliedinsulatingsheaths.
- eR410Acircuitwallconnectionunitissuppliedas an extra kit. Connect the circuit, followingthe instructions provided in the out-
doorunitinstructionsbooklet.
5
e hydraulicconnectionkit includes (Fig. 5):
N°1 - Adjustable expansion bolts
N°2 - Indoorunit support hooks
N°1 - G1”storagetank unitreturnpipe(RU)
N°1 - G1”storagetank unitowpipe (MU)
N°1 - G1/2”system llingpipe (RR)
N°1 - G1/2”ball valve(RR)
N°1 - G1”systemreturnpipe(R)
N°1 - G1”systemowpipe (M)
N°1 - G1”ball valve(M)
N°2 - Insulating sheathfor systempipes (R- M)
N°4 - G1”telescopic ttings (RU-MU -R)
Gaskets, screwsand seal O-Ring
e R32circuit wall connectionkit (optional) includes:
N°1 - SAE3/8”liquidphase chiller linepipe(LP)
N°1 - SAE5/8”gaseous phasechiller linepipe(GP)
Alreadyinstalled onthe module:
N°1 - Systemshut-o cock withG 1”lter(R)

15
INSTALLER
USERMAINTENANCETECHNICIAN
TECHNICALDATA
1.7 HYDRAULIC CONNECTION
In order not to void the warranty, before making indoor unit connections, carefully clean the heating system (pipes, radiators,
etc.) with special pickling or de-scaling products to remove any deposits that could jeopardise proper hydronic module opera-
tion.
LP GP
RU MU
RR
R
M
RU MU RR RM
LP GP
6
Key (Fig. 6):
V - Electricalconnection
RR - Systemlling
RU - Storagetankunitreturn
MU - Storagetankunit ow
R - Systemreturn
M - Systemow
LP - Chiller line- liquid phase
GP - Chillerline- gaseous phase
Atreatmentofthe heating and watersystemwaterisrequired,incompliance with thetechnicalstandardsin force,in orderto protect the
systemandthe appliancefromdeposits (e.g. scale),slurryorother hazardousdeposits.
Waterconnections must bemadein arationalwayusing the couplingsonthe indoorunittemplate.
emanufacturerdeclinesall liabilityin theeventof damagecaused bytheinstallationofanautomatic lling system.
In order to meet the system requirements established by EN 1717 in terms of pollution of drinking water, we recommend installing the
IMMERGAS anti-backow kit to be used upstream of the cold water inlet connection of the indoor unit. We also recommend using cat-
egory 2 heat transfer uid (ex: water + glycol) in the internal unit primary circuit (heating and/or cooling circuit), as dened in standard
EN 1717.
To preserve the duration of appliance eciency features, in the presence of water whose features can lead to the deposit of lime
scale,installationof the“polyphosphatedispenser” kitis recommended .

16
INSTALLERUSERMAINTENANCETECHNICIANTECHNICALDATA
1.8 CONNECTINGTHECHILLERLINE
As far as connecting the cooling line is concerned, all the instructions contained in the outdoor unit instructions booklet must be fol-
lowed.
Make the connectionsdirectly ontheindoorunitcouplings, orusethe rear outlet kit (optional).
1.9 ELECTRICALCONNECTION
einternal unithasan IPX4D degree ofprotection;electricalsafetyof theappliance isachieved onlywhenitis properlyconnected toan
ecientearthingsystem,as specied bycurrentsafetystandards.
e manufacturer declines any responsibility for damage or physical injury caused by failure to connect the indoor unit to an
ecientearthingsystemor failure tocomplywiththe IEC referencestandards.
Connectioncables must respecttheprearranged routes.
Use3 clips(c) (notsupplied)togrouptheindividualcables(max. 1.5 mm2intothe lowerterminal board.
Usethespecicfairleads(d)onthele side, making sure toputatmost2 multi-polarcables(max 3x 1mm2) ineachfairlead.
e gure 7 shows cables in a hypothetical connection. To make the connections based on your own requirements, see the instructions
below.
Openthecontrolpanelconnectionscompartment
Fig. 7.
To carry outelectrical connections,allyouhavetodoisopentheconnectionscompartmentas follows.
1. Removethefrontpanel.
2. Disassemblethecover.
3. Loosen the screws (a).
4. Removethe cover(b) fromthecontrolpanel(c).
Atthis point,you canaccessthe terminalboard.
Also ensure that the electrical installation corresponds to maximum absorbed power specications as shown on the indoor unit da-
ta-plate.
Indoorunits are supplied complete witha“Y” type powersupplycableH 05 VVF 3 x 0,75 mm2withoutplug.
epowersupplycablemustbeconnectedtoa230V±10%/50HzmainssupplyrespectingL-N
polarity and earth connection; this network must also have a multi-pole circuit breaker with
classIIIovervoltagecategoryincompliancewithinstallation regulations.
ToprotectfrompossibledispersionsofDCvoltage,itisnecessarytoprovideatypeAdieren-
tialsafetydevice.
Ifthepowercable isdamaged,contactaqualiedcompany(e.g.theAuthorisedTechnical As-
sistanceCentre)foritsreplacementtoavoidahazard.
epowercablemust belaid asshown(Fig. 7).
If the fuses onthecircuit boards needtobereplaced, this must also bedoneby qualied personnel:use aF3.15AH250Vfuseon the P.C.B.
Forthemain powersupplyto the appliance, neveruseadapters, multiplesockets orextensionleads.
Make the variouselectricalconnections accordingto yourneeds (Fig. 8, 9):
Outdoor unit electricalconnection
e indoor unit must be coupled to an outdoor unit by connecting terminals F1 and F2 as shown in the wiring diagram (Fig. 9). e in-
doorunitis poweredat230V, regardless oftheoutdoorunit.
Conguretheindoorunit parametersasindicatedinparagraphParag. 3.9.
Photovoltaicsysteminstallation
Connectingtheproduct toa photovoltaicsystem enhancesuse oftheoutdoorunitwhen thephotovoltaicpanels areoperating.Carryout
theconnectionasindicated(Fig. 8).

17
INSTALLER
USERMAINTENANCETECHNICIAN
TECHNICALDATA
Dehumidiers
Carryoutthe connectionas indicated(Fig. 9).To completethe connectionoperations,insertthe 2-relayBoardoptional kit.
c
c
d
2
1
a
b
a
a
a
1
1
1
7

18
INSTALLERUSERMAINTENANCETECHNICIANTECHNICALDATA
Verticalterminalblock electricalconnectiondiagram.
1
1
1
5
4
2 3
8
Termina l 87
0V Close Winter
230V Open Summerwith cooling
Key (Fig. 8):
1 - Open/Close
2 - Close
3 - Open
4 - 2-pointvalve
5 - 3-point valve
E15 - DHW integration resistance (optional)
E16 - Systemintegrationresistance (optional)
K15 - DHWintegration resistance relay(not supplied)
K16 - Systemintegrationresistance relay(not supplied)
M10-1 - Zone 1pump (optional)
M10-2 - Zone2 circulatorpump(optional)
M10-3 - Zone 3circulatorpump(optional)
M31-2 - Zone 2 mixingvalve (optional)
M52 - Hotcold three-way(optional)
S39 - Solarinlet
S41 - Outdoor unitdisablefunction
ezone3 dehumidier, if any,willbemanagedby means ofthe congurablerelayinterface kit,which the zone3 mixerwillalsobecon-
nectedto.
A3rdzone(mixed)can also bemanagedon the system bymeans ofthecongurablerelayinterface kit (optional).
In this case, the zone3pumpmustbe connected accordingto diagram(M10-3).

19
INSTALLER
USERMAINTENANCETECHNICIAN
TECHNICALDATA
1
9
Key (Fig. 9):
A13 - Systemmanager (optional)
A16-1 - Zone 1dehumidier (optional withdehum. management board)
A16-2 - Zone 2dehumidier (optional withdehum. management board)
A17-1 - Zone1 humiditysensor (optional)
A17-2 - Zone2 humiditysensor (optional)
A17-3 - Zone3 humiditysensor (optional)
A23 - Outdoor unit
A32-1 - Zone 1 remote panel (optional)
A32-2 - Zone 2remote panel (optional)
A32-3 - Zone 3remote panel (optional)
B2 - Storage tankprobe(optional)
B3-1 - Zone 1ow probe(optional)
B3-2 - Zone 2ow probe(optional)
B3-3 - Zone 3ow probe(optional)
B4 - External probe(optional)
B13 - Central heatingprobe(optional)
E7-2 - Zone2 safetythermostat (lowtemperature)(optional)
E7-3 - Zone3 safetythermostat (lowtemperature)(optional)
R8 - Storagetankresistance
S20-1 - Zone 1room thermostat(optional)
S20-2 - Zone 2room thermostat(optional)
S20-3 - Zone 3room thermostat(optional)
S36-1 - Zone1 humidistat(optional)
S36-2 - Zone 2humidistat (optional)
S36-3 - Zone 3humidistat (optional)
S44 - CentralHeating/Cooling Selector
X40-1 - Zone 1 roomthermostat jumper
1 - Service connector
A16-1 andA16-2dehumidierscanbeconnectedonlyaer installing 2-relayboard (optional).
Removejumper X40-1 beforetheelectrical connectionof the roomthermostatzone1.
eTAinputs,40-1 etc...,must beelectrically decoupled;e.g.a singlecommandcannotpilotmultipleinputs.
With A13 available,the zonedevices must notbe connected.
eroom thermostatsofzone2,zone3and contactS44cannot beinstalledsimultaneously.
Itis notpossibleto install the followingprobes atthesame time:
- Central heatingprobe;
- Zone 3probe.
Horizontalterminalblock electricalconnectiondiagram.

20
INSTALLERUSERMAINTENANCETECHNICIANTECHNICALDATA
1.10 ROOM CHRONOTHERMOSTATS OPTIONAL
eindoorunitispreparedforthe applicationof roomchrono-thermostats, whichareavailable asoptionalkits.
Amaximumof 3temperaturecontrollers can beapplied directly tothe appliance.
AllImmergas chrono-thermostatsare connectedwith 2wires only.
Carefullyread the userandassemblyinstructionscontainedin theaccessorykit.
Disconnectpowertotheunitbeforemakinganyelectricalconnections.
On/O Immergas digitalchrono-thermostat.
e chrono-thermostat allows:
- set two roomtemperature value:oneforday(comfort temperature) and onefornight(reducedtemperature);
- set aweeklyprogrammewith four dailyswitchon andswitcho times;
- selecting the requiredfunctionmode fromthe various possiblealternatives:
• manualmode(withadjustabletemperature);
• automatic mode(with set programme);
• forced automatic operation(momentarilychangingthe temperatureof the automaticprogram).
echrono-thermostatispoweredby two 1.5V LR6 type alkalinebatteries.
On/Ochrono-thermostatelectricalconnection(Optional).
eoperationsdescribedbelowmustbeperformedaerhavingremovedthevoltagefromthe
appliance.
On/O ambient thermostat or chrono-thermostat: must be connected to the 40-1 / 41 terminals, eliminating the X40-1 jumper for zone
1and 40-2 /41forzone2 and40-3/42forzone3.
Make sure that the On/O thermostat contact is of the “clean” type, i.e. independent of the mains voltage, otherwise the P.C.B. would be
damaged.
econnections must bemadeon the terminal boardinsidethe appliance’scontrol panel(Fig. 9).
If the area remotepanel oranyotherOn/O chrono-thermostat isused, arrangetwo separatelines in compliance with current
regulations regarding electrical systems.
Noindoorunit pipes must everbeused toearth the electric system ortelephonelines.
Ensureeliminationofthisrisk beforemakingthe indoorunitelectricalconnections.
