BEFORE YOU BEGIN
Thank you for selecting the MARCY Upright Magnetic Bike PL-43211 by
IMPEX INC. For your safety and benefit, read this manual carefully before
using the machine. As a manufacturer, we are committed to provide you
complete customer satisfaction. If you have any questions, or find there are
missing or damaged parts, we guarantee you complete satisfaction through
direct assistance from our factory. To avoid unnecessary delays, please
call our TOLL-FREE customer service number. Our Customer Service
Agents will provide immediate assistance to you.
1
Toll-Free Customer Service Number
1-800-999-8899
Mon. - Fri. 9 a.m. - 5 p.m. PST
www.impex-fitness.com
[email protected]m

IMPORTANT SAFETY NOTICE
PRECAUTIONS
This exercise machine is built for optimum safety. However, certain
precautions apply whenever you operate a piece of exercise equipment. Be
sure to read the entire manual before you assemble or operate your machine.
In particular, note the following safety precautions:
1. Keep children and pets away from the machine at all times. DO NOT
leave children unattended in the same room with the machine.
2. Only one person at a time should use the machine.
3. If the user experiences dizziness, nausea, chest pain, or any other
abnormal symptoms, STOP the workout at once. CONSULT A PHYSICIAN
IMMEDIATELY.
4. Position the machine on a clear, leveled surface. DO NOT use the machine
near water or outdoors.
5. Keep hands away from all moving parts.
6. Always wear appropriate workout clothing when exercising. DO NOT wear
robes or other clothing that could become caught in the machine. Running
or aerobic shoes are also required when using the machine.
7. Use the machine only for its intended use as described in this manual. DO
NOT use attachments not recommended by the manufacturer.
8. Do not place any sharp object around the machine.
9. Disabled person should not use the machine without a qualified person or
physician in attendance.
10. Before using the machine to exercise, always do stretching exercises to
properly warm up.
11. Never operate the machine if the machine is not functioning properly.
12. The Maximum Weight Capacity is 300 lbs.
13. Read all warnings posted on the exercise bike.
14. Inspect the exercise bike for worn or loose component prior to use.
Tighten/replace any loose or wore components prior to use.
15. Care should be taken in mounting or dismounting the exercise bike.
16. This exercise bike is for consumer and home use only.
WARNING: BEFORE BEGINNING ANY EXERCISE PROGRAM, CONSULT
YOUR PHYSICIAN. THIS IS ESPECIALLY IMPORTANT FOR INDIVIDUALS
OVER THE AGE OF 35 OR PERSONS WITH PRE-EXISTING HEALTH
PROBLEMS. READ ALL INSTRUCTIONS BEFORE USING ANY FITNESS
EQUIPMENT. IMPEX INC. ASSUMES NO RESPONSIBILITY FOR
PERSONAL INJURY OR PROPERTY DAMAGE SUSTAINED BY OR
THROUGH THE USE OF THIS PRODUCT.
SAVE THESE INSTRUCTIONS. 2

WARNING LABEL REPLACEMENT
The Warning Label shown here has been placed on the Rear Stabilizer. If the label is missing or
illegible, please call customer service at 1-800-999-8899 for replacement. Apply the label in
location shown.
3

HARDWARE PACK
Part# Description Identifier
#15 M10 x 3” Carriage Bolt (Qty 2)
#31 M10 x 2 3/8” Carriage Bolt (Qty 2)
#16 Ø 1” Bent Washer (Qty 4)
#17 M10 Acorn Nut (Qty 4)
#19 Ø 7/8” Bent Washer (Qty 3)
#18 M8 x 5/8” Allen Bolt (Qty 3)
#30 Bracket (Qty 1)
#27 M8 x ¾” Allen Bolt (Qty 1)
#26 T-shaped Handle Adjustment Knob (Qty 1)
#11 Seat Post Lock Knob (Qty 1)
Tools:
Allen Wrench (Qty 1)
Angled Wrench (Qty 1)
Crossing Wrench (Qty 1)
4

ASSEMBLY INSTRUCTION
NOTE: It is strongly recommended two or more people assembling this machine to
avoid possible injury.
STEP 1 (See Diagram1)
A.) Attach the Rear Stabilizer (#3) to the Main Frame (#1). Secure it with two M10 x 3”
Carriage Bolts (#15), ∅1” Bent Washers (#16), and M10 Acorn Nuts (#17).
B.) Attach the Front Stabilizer (#2) to the Main Frame. Secure it with two M10 x 2 3/8” Carriage
Bolts (#31), ∅1” Bent Washers (#16), and M10 Acorn Nuts (#17).
C.) Plug the Roller Caps (#28) onto both ends of Front Stabilizer (#2). Plug the Rear Stabilizer
End Caps (#29) onto both ends of Rear Stabilizer (#3). Set the bike firmly on a flat
surface. If the surface is uneven, rotate the Rear Stabilizer End Caps to level the bike.
DIAGRAM 1
5

STEP 2 (See Diagram 2)
A.) Note: In able to hold the Handlebar Post (#4) while connecting the cables and wires,
extra help may be needed.
B.) Attach the Handlebar Post (#4) to the Main Frame (#1). Connect the Middle Computer
Sensor Wire (#21) from the bottom of Handlebar Post to the Lower Computer Sensor
Wire (#22) from the main body of the bike.
C.) Slide the cable wire from the Upper Tension Connector (#20) in between the opening
on the wire holder on the Lower Tension Connector (#23). Pull the Upper Tension
Connector upward and slide the wire through the slot on the bracket.
D.) Drop down the Connector so the fitting sits firmly on top of the bracket.
E.) Secure the Handlebar Post (#4) to the Main Frame (#1) with three M8 x 5/8” Allen
Bolts (#18) and Ø 7/8” Bent Washers (#19).
F.) Connect Middle Computer Sensor Wire (#21) to Upper Computer Sensor Wire (#24).
G.) Slide the Computer (#6) onto the plate on the Handlebar Post.
6

STEP 3 (See Diagram 3)
A.) Attach the Seat (#8) to the Seat Post (#7). Secure it with three Ø 5/8” Washers (#12),
Spring Washers (#13), and M8 Aircraft Nuts (#14).
B.) Insert the Seat Post into the opening on the Main Frame (#1). Use a Seat Post Lock
Knob (#11) to secure the Seat Post at desired height.
C.) Attach the Handle Bar (#5) to the Handlebar Post (#4). Secure it with a Bracket
(#30), M8 x ¾” Allen Bolt (#27), and a T-shaped Knob (#26). Use the Knob to adjust
the position of the Handlebar. DIAGRAM 3
7

STEP 4 (See Diagram 4)
A.) Thread the Left Pedal (#9) counterclockwise into the left Crank (#25).
Thread the Right Pedal (#10) Clockwise into the Crank on the other side.
DIAGRAM 4
8
