IMS NANO easy User manual

1

2

3
Information of the device
Designation: NANOeasy
Manufacturer: IMS Robotics GmbH
Am Bauhof 6
D-01458 Ottendorf-Okrilla, Germany
Phone: [phone]
Fax: [phone]
Email: [email protected]
Website: www.ims-robotics.de
User information: Version 13.08.2021
Translation of the original instruction
Article number: 041 02 000 / 041 03 000

4
Introduction
The user information shall help the operator to work safely and correctly with the
renovation system and to facilitate maintenance of the IMS equipment. These
instructions must therefore be given full attention.
Warranty terms
All information and instructions for the operation and maintenance of the IMS
NANOeasy cutter take into consideration our experience and technical expertise to
date to the best of our knowledge. We reserve the right to make technical
modifications within the context of further development of the device described in this
operating manual.
During the warranty period (1 year), the customer may undertake only those repairs
to the system as described in this Operating Manual. Otherwise the warranty for the
entire unit will become null and void.
All wearing items (e.g. bearings, discs, cutter tools and similar) are not covered by
the warranty granted by the manufacturer.
The rubber bellows of the bracing bladder and the lift drive are also wearing parts.
The manufacturer does not assume any warranty in the event of damages from wear
(abrasion, sharp-edge fragments, etc.).

5
Table of contents
1Intended Use ..................................................................................................................... 6
2Safety regulations ............................................................................................................. 7
2.1 General safety regulations.......................................................................................... 7
2.2 Special safety regulations........................................................................................... 7
2.3 Explanation of symbols and notes.............................................................................. 8
3Technical data and specifications for the machine ....................................................... 9
4Operation ........................................................................................................................ 10
4.1 General ..................................................................................................................... 10
4.2 Extension DN 150 for NANOeasy (optional) .......................................................... 13
4.3 Start-up ..................................................................................................................... 14
4.3.1 Control wheel NANOeasy ................................................................................... 18
4.4 Operation during work ............................................................................................. 19
4.4.1 Operating the IMS cutter NANOeasy .................................................................. 19
4.4.2 Recovering the cutter in case of malfunction....................................................... 19
4.5 Finishing work.......................................................................................................... 22
4.6 Cutter tools ............................................................................................................... 24
4.6.1 Cutter tools overview NANOeasy........................................................................ 24
4.6.2 Changing the NANOeasy cutter tool ................................................................... 25
5Maintenance and repair................................................................................................. 26
5.1 Cleaning ................................................................................................................... 26
5.2 Care and maintenance .............................................................................................. 26
6Repairs............................................................................................................................. 27
6.1 Repair of air motor IMS cutter NANOeasy ............................................................. 27
6.1.1 Overview of air motor spare parts NANOeasy .................................................... 27
6.1.2 Disassembly of NANOeasy air motor and reassembly........................................ 28
6.2 Way-valves............................................................................................................... 30
6.2.1 Overview of directional valve spare part ............................................................. 30
6.2.2 Replacing the way-valves..................................................................................... 31
6.2.2.1 Replacing directional valves WV 1 –2 (lift, bracing bladder) .................... 31
6.2.2.2 Replacing the directional valve WV 3 (cutter air) ....................................... 32
7EC Declaration of Conformity ...................................................................................... 34
8Accessory overview NANOeasy .................................................................................... 35

6
1 Intended Use
Operational safety of the equipment supplied is ensured only when used as intended.
The intended use includes following the regulations contained in these operating
instructions as well as compliance with all maintenance and service tasks.
The IMS cutter NANOeasy must only be used for cutting work for the restoration of
pressureless pipes or lines. The device can be used to open inliners after restoration
and remove obstacles (roots, protruding seals, minor offsets, or the like). The
machine may not be used for unintended purposes.
Unauthorised structural changes to the equipment may cause damage to the
machine thus representing a hazard to persons. IMS is not liable for resulting
damages. In the event of damage the operating company remains responsible and
responsibility cannot be transferred to IMS.

7
2 Safety regulations
2.1 General safety regulations
1.) The accident prevention instructions (German UVV/BGV A-D) must be complied
with when operating the device.
2.) The device must only be operated by personnel who have been instructed how
to use it and who have read and understood these operating instructions.
Inadequate knowledge may cause damages on the device and hazards for the
operator.
3.) The presence of persons inside the shaft and below the suspended load when
lowering the IMS NANOeasy cutter into shaft structures is prohibited.
4.) Observe all accident prevention regulations for working on pipelines, earth-
moving machines, winches and lifting and towing devices, as well as the safety
regulations for pipeline construction work.
2.2 Special safety regulations
1.) The cutter motor must not be operated without a cutter tool. Operation without
or with other, unmodified cutter tools may destroy the cutter drive.
2.) Cutter tools must be checked for imbalance (e.g. missing cutting edges). The
cutter drive may otherwise be destroyed.
3.) Compressed air must be able to escape when carrying out cutting work in dead
end pipes. In this case, a pipe eel can be run parallel to the bracing bladder.
However, the pipe eel must not collide with the lifting unit.
4.) The cutter motor starts to turn as soon as it is switched ON. Never attempt to
grab the cutter tool! Stopping the cutter tool with your foot or any other means is
not permitted.
5.) No attempt should be made to reach between the bladder and the pipe wall
while the bracing bladders are being inflated.
6.) The IMS NANOeasy cutter must not be operated outdoors without the auxiliary
pipe. The bracing bladder must also not be located in front of an open
branch/connecting piece.

8
7.) The air-powered cutter motor may be operated only while using hearing
protection.
8.) Before moving the chassis you must always make sure that the locking pins for
the handle section have properly engaged.
2.3 Explanation of symbols and notes
The accident prevention regulations as well as the general and special safety
stipulations must be observed when operating the unit.
Important information, such a safety related notices, will be
marked with the appropriate symbol. Comply with the notices to
avoid accidents and damages to the equipment!

9
3 Technical data and specifications for the machine
Name: NANOeasy
Item number: 041 02 000/041 03 000
Main dimensions: 1030 × 775 × 500 mm (W × D × H)
Weight: approx. 35 kg
Applications: Pipes with nominal diameters from 70 mm to 100 mm
(inside diameter)
Protection class: IP 54 (protected against access by small tools/wires and
access by small tools/wires)
Temperature range: +5 to max. +40 °C (41 °F to max. 104 °F)
Power supply: 100 - 240 VAC, 50/60 Hz, max. 1.0 A
Supply air: Dirt-free (particles < 5 micrometres)
Temperature range 5 °C to max. 40 °C
(41 °F to max. 104 °F)
Residual water separated
Residual oil < 5 mg/m³
Supply line pressure 7 - 10 bar (102 –145 PSI)
min. volume flow 1 m³/min (35 CFM)

10
4 Operation
4.1 General
The IMS NANOeasy cutter is a device for performing cutting work for the purpose of
pressureless pipe or line renovation. The device can be used to open inliners after
renovation and remove obstacles (roots, protruding seals, minor offsets or the like).
To start up the IMS NANOeasy cutter first set up the cutter itself and the necessary
media. The cutter consists of the following assemblies:
1
Control wheel
2
Monitor
3
Chassis
4
Hose assembly with cutter drive and camera
5
Cable drum
6
Cutter motor

11
3
4
5
6
2
1
4

12
The device serial number is located on the chassis.
All assemblies have a minimum protection class of IP 54. This means that the
assemblies are protected against:
-Penetration of wires
-Dust
-surrounding splash water
The media must have the following properties:
Power supply: 100 –240 VAC, 50/60 Hz, max. 1.0 A
Supply air: Dirt-free (particles < 5 micrometres)
Temperature range 5 °C to max. 40 °C
(41 °F to max. 104 °F)
Residual water separated
Residual oil < 5 mg/m³
Supply line pressure 7 –10 bar (102 –145 PSI)
Min. volume flow 1 m³/min (35 CFM)

13
4.2 Extension DN 150 for NANOeasy (optional)
Due to an additional extension, the IMS cutter NANOeasy can be used in the nominal
diameter range of more than 100 mm up to 150 mm.
For this, the extension has to be pushed over the cutter drive from the cutting tool
side and fastened to the crimp sleeve of the cutter drive by means of 4 set screws
M4x6.
When using the extension DN 150, the NANOeasy tool extension must be installed!
Mounting direction
Fix the extension to the crimp sleeves of the cutter drive
using the 4 set screws M4x6

14
4.3 Start-up
-Attentively read these operating instructions
-Check the assemblies and accessories for completeness, and the media for the
required qualities
-Transport the chassis to the desired work location (shaft, inspection opening or
the like). Place the chassis in horizontal position. This is also the required
working position for the chassis, since the water separator will otherwise not
work correctly.
-Unwind the hose assembly from the cable drum (as far as necessary to be able
to apply the cutting operation); the hose assembly must not be pulled over
sharp edges or kinked
-Check the required cutter tool for imbalance (e.g. missing cutting edges; if OK,
then fasten cutter tool on the cutter motor (see 4.6.2 Changing the NANOeasy
cutter tool)
-Connect the control wheel to the cable drum (all switches on the control unit
must be switched OFF!)
Connection for the
control wheel

15
-The cable drum features an analogue and digital video output. Choosing
between analogue and digital video signal can be done with the changeover
switch. Attention! The analogue and digital video signal cannot be used
simultaneously. When switching to the digital video signal, neither the analogue
video socket nor the monitor on the control wheel can be used!
Analogue video output
Changeover switch analogue/digital video signal
USB port (digital video output)

16
-Connecting the monitor to the control wheel
-Connect the cutter to the electrical supply; the LED (green) on the power supply
unit must light; otherwise the power supply assembly is defective (replacement
required)
-The camera light must be on
-Connect the supply line from the compressor to the coupling disc on the stand
-Insert the cutter drive into an auxiliary tube (approx. 0.50 m long, nominal
diameter 70 –100 mm)).
BNC video connection Monitor power supply

17
Operating the device without an auxiliary pipe may irreparably
damage the bracing bladder!
-All switches on the control wheel must be in the “Off” or “Stop” position.
-Switch the compressor ON
-Put on/insert ear protectors
-Switch on the air motor and check the function of the cutter motor
-Switch off the air motor.
-Deflect the lifting unit toward to top or button using the switch on the control
wheel
-Operate the switch on the control wheel to check the function of the bracing
bladder. To do so operate the switch for the bladder and wait until the bladder
has clamped. Once the bladder has clamped completely set the switch to relief
and wait until the bladder has relieved its tension. The middle position (stop) of
the switch for the bracing bladder fixes the current pressure and thus the actual
position.

18
4.3.1 Control wheel NANOeasy
1
BNC video port
2
Connection cable control wheel to cable
drum
3
Lift the lifting unit
4
Bracing bladder Bracing/Stop/Relief
5
Supply hose clamping fixture
6
Light camera potentiometer
7
Cutter motor On/Off
8
Lower lifting unit
9
Internal power supply for monitor
10
Monitor
10
9
1
2
3 4 5 6 7 8

19
4.4 Operation during work
4.4.1 Operating the IMS cutter NANOeasy
-Carefully insert the cutter drive into the pipe
-Push the cutter drive to the work location; when sliding through bends, turn the
cutter head in the direction of curvature by rotating the supply hose and then
deflect the lifting unit so that the bend can be pushed through without using
force; in case of new pipelines apply a lubricant (e.g. Prima lubricant for
connecting sleeve systems); creases in lined pipes should be removed prior to
insertion.
-If not yet done so, brace control wheel on supply hose
-Position at the cutting point without contacting the pipe
-Turn on the switch for the bracing bladder and centre the cutter in the pipe
-Switch the cutter motor ON
-Cut away material to be removed through slow rotation, swivelling, advancing
and retracting using the control wheel
4.4.2 Recovering the cutter in case of malfunction
Under certain conditions it may no longer be possible to pull the cutter out of the pipe
or to empty the lift when the bracing bladder is inflated.
Such malfunctions occur in case of:
-Defective control wheel
-Defect in the electric system of the cutter
-Defect of directional valve(s) of the cable drum
-Power failure
-Air supply failure

20
In such cases the lifting unit and the bracing bladder need to be emptied manually.
This is realised using direction valve 1 and directional valve 2. The directional valve
are marked accordingly.
The directional valves are located inside the cable drum. To get to the directional
valves, first remove the cover plate in the centre of the cable drum using the 3
countersunk screws M4×8.
Directional valve 1 (lifting unit)
Directional valve 2 (bracing bladder)
