In-Ex 300 User manual

OWNER’S MANUAL
FOR THE
Spreader 300
In-Ex™
P O Box 1010, 145 Harts Road
Palmerston North
Ph: 06 354 6060
Fax: [phone]
E-Mail: [e-mail]

2
YOUR SAFETY IS IN-EX’s PRIMARY CONCERN
▪It is important that you understand that any loads or attachments whether fastened to or placed on
a vehicle or ATV will alter the stability and handling characteristics of that vehicle or ATV.
▪FAILURE TO FOLLOW THESE RULES CAN RESULT TO SEVERE INJURY OR DEATH TO
OPERATORS OR BYSTANDERS.
▪We take this opportunity to remind you about the simple, basic and common sense rules of safety
when using spray tanks or other equipment.
▪NEVER EXCEED THE LOAD LIMIT CAPACITY OF THE ATV OR OTHER VEHICLE.
▪Spray tanks or other equipment must be filled to a level where the gross weight is within the load
limit of the ATV or other vehicle.
▪ALWAYS EXERCISE EXTREME CAUTION WHEN OPERATING EQUIPMENT, ESPECIALLY ON
UNDULATING TERRAIN.
▪Operators MUST BE AWARE that they have a responsibility to ensure that anyone using this
equipment is familiar with the manufacturers safe operating instructions.
▪PLEASE BE CAREFUL!
SAFETY PRECAUTIONS
Before attempting to install or operate the equipment, read and understand the manual thoroughly. Failure to
comply with this instruction constitutes improper use and will invalidate the warranty.
Throughout this manual there are highlighted text boxes containing warnings, cautions and notes.
Warnings are mandatory instructions to prevent serious injury or permanent damage.
Cautions are advisory instructions to ensure reliable operation of the equipment.
Notes are for convenient operation
Do not overload your spreader. The maximum permissible payload is 250 Kg.
Never use dirty product or product with stones or lumps.
Ensure that your towing vehicle is adequate for the task. The maximum tare weight is 350 Kg.
If using the spreader over hilly terrain the payload should be reduced to ensure that the spreader stability is
not compromised.
Never allow anyone to ride on or in the spreader.
Keep the spreader in good condition. Cleanliness and maintenance are essential for safe and trouble free
operation.
Never leave product in the hopper or store the spreader without cleaning it.

3
IN-EX Spreader 300
OWNER’S MANUAL
(Pt.No.2400-6950 Issue 5, August 2022)
TABLE OF CONTENTS
2 Safety Precautions
3 Table of Contents
4 Description
Specifications
Order Information
Warranty
6Operation
Calibration
7 Operating the Spreader
Adjusting the Spread Pattern
8Fitting the Rain Cover
Maintenance
Before Use
After Each Use or Daily when in Use
Hints
9 Parts Diagram
10 Parts List

4
DESCRIPTION
The IN-EX Spreader 300 is a ground-driven spreader designed for application of pelleted fertilisers. It can also
be used for application of other products such as grass seed and magnesium oxide. The uniquely designed
300-litre translucent non-corrosive polyethylene hopper is specially profiled for good product flow and ease of
filling. The convenient flexible polypropylene cover is easy to remove, install and store if not required. A high-
quality stainless steel agitator and shutter ensures even flow of product to the spinner. A unique spinner
design ensures wide, even spread of product over 180 degrees (Urea). The heavy-duty galvanised frame is
fitted with chunky turf tyres as standard. The drive train uses high quality steel and a double sealed self-
aligning bearing and heavy-duty gearbox for maximum durability. The drive can be disconnected using a
convenient pin clutch. The dual control levers allow instant setting of product feed rate and product control.
Specifications
(Specifications subject to change without notice)
Dry Weight 90 Kg
Dimensions W1430mm, H1200mm, L1700mm
W1450mm (Wide wheel models)
Capacity 300 litre (250Kg Urea)
Drive Ground driven (single wheel)
Wheels 18x950x8 Chunky turf tyres
Tyre Pressure 12 PSI
Clutch Removable Pin
Control Adjustable stainless steel slide with index handle
Agitator Mechanical arm, stainless steel
Spinner Galvanised steel with three-position adjustable vanes
Hopper Non-corrosive polyethylene, ergonomically designed for ease of filling and inspection
Hopper Cover Lightweight polypropylene fabric
Frame Galvanised steel
Gearbox Heavy duty with double sealed bearings
Gearbox oil 400ml SAE30
Axle Bearings Sealed ball races
Axle grease General Purpose
Application Rate 140Kg per hectare @ 10 kph (nominal, Urea)
Spread width 18M (nominal, Urea @ 15 Kph)
Towing speed 15 Kph (Maximum recommended)
Order Information
IN-EX Spreader 300 part number: 3005
WARRANTY
1WARRANTY AND LIABILITY
Use of the equipment
1.1 You must satisfy yourself as to the suitability of the equipment for your intended use(s) of the
equipment.
Your relationship with the retailer
1.2 Where you consider you have a warranty claim (or any other claim) in relation to the
equipment, you must contact the retailer who sold you the equipment, not C-Dax directly. The
retailer is responsible for liaising with C-Dax in respect of your claim.
Warranty
1.3 C-Dax warrants to the original purchaser that the equipment is sold free from defects in
materials and workmanship for a period of 12 months from date of first retail sale (6 months
from date of first retail sale if the equipment is sold in the U.K.) subject to the terms set out
below.

5
1.4 C-Dax will at its option repair or replace the defective equipment (or part of the equipment) or
notify the retailer of the equipment to refund the purchase price for such defective equipment
to you in the event of a breach of this warranty, subject to the terms set out below.
Liability
1.5 Except for the warranty set out in clause 1.2 above, all warranties and representations
(including those expressed or implied by law) in respect of the equipment or advice relating to
the equipment provided to you by C-Dax are excluded to the extent permitted by law.
1.6 Notwithstanding anything else in this manual, C-Dax’s maximum liability to you (in the event
that such liability exists) in respect of any breach of warranty, any matter set out in this
manual, or for defective equipment or advice relating to the equipment provided is limited at
C-Dax’s option to:
(a) repairing or replacing the equipment (or part of the equipment); or
(b) notifying the retailer of the equipment to refund the price for the equipment paid by
you.
1.7 Notwithstanding anything else in this manual, in no event will C-Dax be liable, whether in
contract, tort (including negligence) or otherwise:
(a) where you have altered or modified the equipment, misused or misapplied the
equipment, or the equipment has been subjected to any unusual, excessive or non-
recommended use, service or handling (including as set out in this manual);
(b) where the equipment is not transported, stored, handled or used in accordance with any
directions given by C-Dax (or the retailer) to you (including as set out in this manual);
(c) where the equipment:
(i) has been subject to neglect, accident or hireage, or the damage arises from fair
wear and tear, battery damage or chemical attack;
(ii) has been built to a customer’s specifications; or
(iii) has been dismantled, repaired or serviced other than by an authorised service
agent of C-Dax;
(d) for loss or damage caused by any factors beyond C-Dax’s control; or
(e) for any loss of profit or revenue, or for any special, indirect, incidental or consequential
damage, loss or injury of any kind suffered by you.
1.8 Where C-Dax elects to repair or replace the equipment it will use reasonable endeavours to do
so as soon as practicable but will not be liable for any delay in doing so.
1.9 You agree that the transactions entered into between you and the retailer (and C-Dax) are for
the purposes of trade and that, having regard to all relevant circumstances of the transactions,
it is fair and reasonable that the provisions of the Consumer Guarantees Act 1993 (NZ) do not
apply to those transactions to the fullest extent permitted by law.

6
OPERATION
The product to be spread is placed in the hopper. When the spreader is towed forward, the right hand wheel
drives through the pin clutch and gearbox to turn the spinner in a clockwise direction. When the shutter handle
is pulled forward, the shutter at the bottom of the hopper rotates to an open position. The size of the opening is
set by a shutter stop lever, which locates into one of nine pre-set positions.
An extension of the spinner boss is connected to a stainless steel agitator arm inside the bottom of the hopper.
The agitator ensures that product flows continuously out of the hopper to the spinning disk.
A delivery chute on the bottom of the hopper ensures that product is delivered to the correct spot of the disk so
that the deflectors distribute the product over a wide angle behind and to each side of the spreader.
The drive from the wheel to the gearbox may be disengaged by removing a pin from the axle. The pin may
then be stowed by inserting it into a holder on the side of the frame.
A fabric hopper cover with an elastic band sewn into the outer edge to grip the lip of the hopper can be fitted to
prevent rain and debris from entering the hopper.
CALIBRATION
Shut the Shutter Control Handle to the closed position.
To calibrate your spreader, place a measured amount of product (10 Kg) in the hopper.
Set the Shutter Stop Lever to the position (1-9) indicated in the Calibration Guide below. Hole position 9
(shutter fully open) is denoted by two holes vertically one above the other.
Ensure the drive pin is correctly inserted into the hole in the drive axle.
Tow the spreader at the desired speed and pull the Shutter Control Handle forward.
When the product has been exhausted, measure the distance covered and band width in metres. It is
recommended that this be done over an area where the product can be seen on the ground so that the spread
width can be measured.
Check the application rate using the following formula:
Rate (Kg/ha) = Product applied (Kg) x 10,000
Distance travelled (metres) x spread width (metres).
Adjust either the Shutter Stop Lever or the speed of travel until the desired application rate is achieved.
NOTE
Because of variations in product characteristics, speedometer calibration and driving speed, the information in
the calibration guide should be regarded as a starting point only. It is recommended that the spreader be
calibrated before use.

7
Calibration Guide
(Average Speed 10 Kph)
Product
Rate
(Kg/ha)
Shutter Setting
(Lever Position)
Nominal Spread
(Metres)
Urea or DAP
50
4
15
Urea or DAP
75
5
15
Urea or DAP
100
6
15
Super phosphate
100
7
12
30% Potassic Super
100
8
10
Rye Grass
30
3
4
Magnesium Oxide
Magnesium Oxide powder is applied at a rate determined by the number of cows to be treated. When
spreading this product, calculate the weight of powder to be applied and apply this amount using shutter
setting 4 or 5. Because this product may set hard if left exposed to air, it must not be stored in the machine
even for a short time. Load the spreader only with the amount required to be spread and clean all traces of
product from the machine after use.
OPERATING THE SPREADER
When the spreader has been correctly calibrated, the hopper may be filled to the required level and spreading
commenced.
To reduce agitator damage to product and to ensure that product is not forced past the agitator shaft when
towing the spreader to the area to be treated, the drive to the gearbox should be disconnected by removing
the pin from the drive axle until spreading is to be commenced. The pin can be stowed by inserting it through a
receptacle provided on the right hand side of the hopper frame.
WARNING
To prevent damage to the spreader do not tow the spreader at speeds in excess of 15 Kph.
To prevent inadvertent operation of the shutter while the spreader is in transit it is recommended that the
Shutter Stop Lever be moved to Position 1 to lock the shutter closed.
To prevent the shutter from vibrating closed when the spreader is operated over rough ground, the Shutter
Control Handle friction may be increased by tightening the adjustment nut at the bottom of the Handle.
Adjusting the Spread Pattern
The spreader has been set up for spreading pelletised fertiliser. When spreading lighter products or products
with a high powder content it may be necessary to adjust the deflectors on the spinner to centralise the spread
pattern. To shift the pattern to the left (facing forward) the inside end of the vanes should be moved anti-
clockwise. To shift the pattern to the right (facing forward) the inside end of the vanes should be adjusted
clockwise. These positions are highlighted in the diagram on the following page.
Shift to the left setup
Default setup
Shift to the right setup

8
Fitting the Rain Cover
To fit the rain cover to the hopper, loop one corner of the cover over a corner of the hopper then stretch the
cover over the opposite corner of the hopper so that the elastic edge holds it in place. Then stretch the third
corner over the hopper rim followed by the last corner. Ensure that the cover is properly stretched over the
hopper rim before moving off.
MAINTENANCE
The following maintenance actions are mandatory for reliable use of the spreader.
Before Use
Check the tyre pressures and charge with air as required. The correct pressure is 12 psi. (80 Kpa)
Remove the gearbox drive pin and turn the spinner by hand to ensure that it is free to turn without
interference.
Check the hopper to ensure that no debris is inside.
Check for any loose fasteners and tighten as required.
If the spreader has not been used for some time, grease the bearings (pay particular attention to the pin clutch
bearing).
Check the gearbox for leaks. If leaks are detected it will be necessary to drain and replenish the gearbox with
400ml of SAE 30 oil.
CAUTION
To replenish the gearbox the spreader may be inverted to place the filler plug uppermost. However in doing so
extreme care must be taken to prevent damage to the spinner and deflectors.
After Each Use or Daily when in Use
Remove all traces of product from the spreader by brushing or washing. Pay particular attention to areas
where product has accumulated and built up. Remove by scraping if necessary taking care not to damage the
surface finish of the spreader or its components.
If washing do not direct high-pressure water onto the gearbox, axle or wheel bearing seals.
After washing, grease the bearings (three places) and apply water displacing fluid such as WD 40 or LPS3 to
all metal parts.
Check for damaged or worn components and replace as required.
HINTS
When greasing the pin clutch bearing in the axle assembly, leave the pin in place. This will assist the grease to
fully enter the scroll in the axle and prevent the axle from being displaced if the bearing housing should be
over pressurised with grease.
If the drive axle is removed from the axle housing for any reason care must be taken to ensure that both the
axle scroll and bronze bush are clean and free of debris before reassembly.
To remove the agitator from the hopper knock out the roll pin or remove the bolt, which attaches the agitator
shaft to the spinner flange assembly then withdraw the agitator from inside the hopper.
When ordering replacement parts always quote the spreader model and the Part Number of the required part.

9
PARTS DIAGRAM

10
PARTS LIST
Item No.
QTY.
Part No.
Description
1
1
3500-5600
Frame-Spreader-CDIT300GT-GL
2
1
3800-1000
Gearbox-Ferroni-RV10-Ratio 1 to 2.78
3
1
5200-5200
Machined-Housing-Drive Axle-INEX300/INEX130-ZP
4
1
5200-6500
Machined-Shaft-Axle-CDIT300GT-ZP
5
1
1140-1200
Bearing-Ball-Pillow Block-Drive Axle-Spreaders
6
1
1140-4000
Bearing-Housing-Pillow Block-Drive Axle-Spreaders
7
1
8200-5200
Spinner-Mount-CDIT300/400/INEX300-ZP
8
1
1036-8240
Agitator-Spreader-CDIT300/400-In-Ex300/400-SS
9
1
7500-2120
Rota-Hopper-Spreader 300 -Natural-MDPE-In-Ex
10
1
9200-8900
Wheel-Turf-Keyed-18x950x8-4 Ply
11
1
9200-8700
Wheel-Turf-Bearing-18x950x8-4 Ply
12
1
7500-2795
Rota-Spout-Spreader-165/300/400-Natural-MDPE
13
1
2150-0025
Collar-Shaft-ID25-ZP
14
1
2250-7940
Cover-Shaft-Drive Axle-77mm Long-Spreader 300-PVC
15
4
2840-1120
Fastener-Bolt&Nut-Hex-8.8 Grade-M10x120-ZP
16
4
6500-8950
Profiled-Vane-Spinner-Spreader-CDIT300/400-Galv
17
1
8200-2100
Spinner-Disc-CDIT300/400/1300
18
1
5050-7940
Linkage-Shutter-In-Ex Spreader 300-ZP
19
2
3230-0008
Fastener-Retainer Cap-Starlock-8mm-Nickle Plated
20
1
6500-7770
Profiled-Shutter-CDIT300/400
21
1
4050-1600
Handle-In-Ex Spreader 300-ZP
22
1
3865-3800
Grip-Handle-7/8"-PVC-Black-Plastic
23
1
4050-4200
Handle-Indicator-In-Ex 300-ZP
24
1
7970-8100
Shroud-Spreader 300-MDPE-Natural
25
1
8250-1800
Spring-Compression-Crinkle Plate-ZP
26
5
3170-0010
Fastener-Nut-Nyloc-M10-ZP
27
9
3170-0008
Fastener-Nut-Nyloc-M8-ZP
28
8
3170-0006
Fastener-Nut-Nyloc-M6-ZP
29
4
3170-0012
Fastener-Nut-Nyloc-M12-ZP
30
1
5200-6300
Machined-Key-8x8-Ground Drive Spreaders
31
1
3290-0850
Fastener-Set Screw-Hex-8.8 Grade-M8x50-ZP
32
1
6500-9000
Profiled-Washer-Spinner Shaft-34.9x67x2mm-Stainless 304
33
8
3290-0616
Fastener-Set Screw-Hex-8.8 Grade-M6x16-ZP
34
4
3290-0820
Fastener-Set Screw-Hex-8.8 Grade-M8x20-ZP
35
2
3290-1240
Fastener-Set Screw-Hex-8.8 Grade-M12x40-ZP
36
2
3310-6012
Fastener-Washer-Flat-M12-ZP
37
3
3240-0018
Fastener-Rivet-Blind-Truss Head-3/16x18mm-Aluminium
38
6
3270-8012
Fastener-Self Tap-Screw-CSK-8Gx1/2"-Pozi-Stainless
39
2
3310-6010
Fastener-Washer-Flat-M10-ZP
40
2
3010-0810
Fastener-Grub Screw-Socket Head-M8x10-Stainless
41
1
3290-1225
Fastener-Set Screw-Hex-8.8 Grade-M12x25-ZP
42
1
3320-7010
Fastener-Washer-Shakeproof-External Star-M10-ZP
43
1
3310-5012
Fastener-Washer-Flat-Heavy-M12x32x3-Galv
44
1
5270-0003
Nipple-Grease-Straight-Short-M6-ZP
45
1
8800-3800
Tow-Coupling-Handle-Double Ended-1 78 x 50mm-ZP

11
46
1
6100-4860
Pin-Locking-8x57mm-ZP
47
2
2890-0812
Fastener-Cap Head-Allen-Screw-12.9 Grade-M8x12-Black
48
4
2810-0860
Fastener-Bolt&Nut-Hex-304 Grade-M8x60-Stainless
49
4
3310-6008
Fastener-Washer-Flat-M8-ZP
50
4
3310-2809
Fastener-Washer-Flat-M8x22x1.5-Grade 316-Stainless
51
1
5245-3905
Mount-Handle-Spreader 300-ZP
52
2
3290-1275
Fastener-Set Screw-Hex-8.8 Grade-M12x75-ZP
53
1
2250-4100
Cover-Hopper-Silver Fabric-Spreader CDIT300
