TurfEx TS-95 Operating instructions

Walk-Behind Drop Spreader
TS-95
Owner's Manual and Installation Instructions
Original Instructions
November 1, 2017
Lit. No. 76754, Rev. 00
CAUTION
Read this document before operating or
servicing the spreader.
This document supersedes all editions with an earlier date.
This document is for TurfEx®TS-95 walk-behind drop spreaders with
serial numbers PF-101257 and higher, or
serial numbers PG-101265 and higher.

Lit. No. 76754, Rev. 00 November 1, 2017

Lit. No. 76754, Rev. 00 3 November 1, 2017
TABLE OF CONTENTS
PREFACE..................................................................................................................................................................5
Owner's Information............................................................................................................................................5
SAFETY ....................................................................................................................................................................7
LOADING ..................................................................................................................................................................9
ASSEMBLY............................................................................................................................................................. 10
CALIBR ATION INFORMATION ............................................................................................................................. 11

Lit. No. 76754, Rev. 00 November 1, 2017

Lit. No. 76754, Rev. 00 5 November 1, 2017
PREFACE
This manual has been prepared to acquaint you with
the safety information, operation, and maintenance
of your new walk-behind spreader. Please read this
manual carefully and follow all recommendations. This
will help ensure profitable and trouble-free operation
of your spreader. Keep this manual accessible. It is a
handy reference in case minor service is required.
When service is necessary, bring your walk-behind
spreader to your distributor. They know your spreader
best and are interested in your complete satisfaction.
Register your spreader online at www.turfexproducts.com
OWNER'S INFORMATION
Owner's Name: _______________________________________________________________________
Date Purchased: ______________________________________________________________________
Outlet Name: ______________________________________________ Phone: ___________________
Outlet Address: _______________________________________________________________________
Spreader Type (Model):________________________________ Weight: ____________________ lb/kg
Spreader Serial Number:________________________________________________________________

Lit. No. 76754, Rev. 00 November 1, 2017

Lit. No. 76754, Rev. 00 7 November 1, 2017
SAFETY
SAFETY DEFINITIONS
NOTE: Indicates a situation or action that can lead
to damage to your spreader and vehicle or other
property. Other useful information can also be
described.
CAUTION
Indicates a potentially hazardous situation
that, if not avoided, may result in minor or
moderate injury. It may also be used to alert
against unsafe practices.
WARNING
Indicates a potentially hazardous situation
that, if not avoided, could result in death or
serious personal injury.
LABELS
Please become familiar with the labels on the
spreader.
NOTE: If labels are missing or cannot be read, see
your sales outlet.
Code Definition
YY 2-Digit Year
MM 2-Digit Month
DD 2-Digit Day
LL 2-Digit Location Code
#### 4-Digit Sequential Number
TS-95 Model Number

Lit. No. 76754, Rev. 00 8 November 1, 2017
SAFETY
SAFETY PRECAUTIONS
Improper installation and operation could cause
personal injury and/or equipment and property
damage. Read and understand labels and this
Owner's Manual before installing, operating, or making
adjustments.
WARNING
• Always make sure personnel are clear of
areas of danger when using equipment.
• Before working with the spreader, secure all
loose-fitting clothing and unrestrained hair.
• Do not climb into or ride on spreader.
• Never attempt to lift a unit with material in it.
• Always inspect unit for defects and replace any
broken, missing, or worn parts immediately.
• Always check areas to be spread to be sure
no hazardous conditions or substances are
in the area.
CAUTION
• Do not operate a spreader in need of
maintenance.
• Before operating the spreader, reassemble
any parts or hardware removed for cleaning
or adjusting.
• Before operating the spreader, remove
materials such as cleaning rags, brushes,
and hand tools from the spreader.
• Never use wet materials or materials with
foreign debris with this spreader. This unit
is designed to handle dry, clean free-flowing
material.
CAUTION
DO NOT leave unused material in
hopper. Material can freeze or solidify,
causing unit to not work properly.
Empty and clean after each use.
NOTE: Lubricate grease fittings after each use.
Use a good quality multipurpose grease.
PERSONAL SAFETY
• Wear only snug-fitting clothing while working on
your spreader.
• Do not wear jewelry or a necktie, and secure long
hair.
• Wear safety goggles to protect your eyes from dirt
and dust.
NOISE
Airborne noise emission during use is below 70 dB(A)
for the spreader operator.
VIBRATION
Operating spreader vibration does not exceed 2.5 m/s2
to the hand-arm or 0.5 m/s2to the whole body.

Lit. No. 76754, Rev. 00 9 November 1, 2017
LOADING YOUR SPREADER
Material Weights
Material Density
(lb/ft3)
Fertilizer See product information on
bag or bulk material.
LOADING
SPREADING TIPS
• Use care when operating spreader near
pedestrians.
• For a heavier pass, walk slower.
• Adjust material flow by rotating the cam wheel to
either increase or decrease gate slide movement,
see below.
WARNING
Never remove spreader from vehicle with
material in it as this could cause damage to
the frame assembly.
WARNING
Do not overload spreader. Use chart below
to calculate weight of material. Weights of
material are an average for dry materials. CAUTION
DO NOT leave unused material in hopper
for long periods of time. Fertilizers are
hygroscopic and will attract atmospheric
moisture and harden up. Empty and clean
after each use.
CAUTION
Read and adhere to fertilizer
manufacturer's material package
labeling including Material Safety
Data Sheet requirements.
5
10
15
25
30 40
35
45
20
Calibration Indicator Marks

Lit. No. 76754, Rev. 00 10 November 1, 2017
ASSEMBLY INSTRUCTIONS
1. Tires are not fully inflated when shipped. Inflate
tires with a manual pump.
ASSEMBLY
2. Insert rod end into gate slide. Lock in place with
hairpin clip and washer as shown in Figure 1.
3. Assemble the upper handle assembly to main
frame (see Figure 3). Simultaneously insert rod
into upper handle as shown in Figure 2.
4. Attach clear protective cover to hopper.
WARNING
Use safety glasses and gloves when inflating
and installing the tires. Use manual pump
only to inflate. Refer to the tire sidewall for
manufacturer's recommended pressure. Do
not exceed the maximum inflation pressure.

Lit. No. 76754, Rev. 00 11 November 1, 2017
CALIBRATION INFORMATION
Setting # Pounds
Dropped
Distance Setting # Pounds
Dropped
Distance
1 0 100' 24 45.5 1000'
2 0 100' 25 50.8 1000'
3 0 100' 26 56.6 1000'
4 0 100' 27 67.6 1000'
5 0 100' 28 69.6 1000'
6 0 100' 29 76.0 1000'
7 0 100' 30 81.0 1000'
8 0 100' 31 83.2 1000'
9 0 100' 32 98.0 1000'
10 0.05 1000' 33 104.6 1000'
11 0.13 1000' 34 127.2 1000'
12 0.70 1000' 35 134.4 1000'
13 1.12 1000' 36 148.4 1000'
14 2.50 1000' 37 160.0 1000'
15 5.25 1000' 38 171.2 1000'
16 6.75 1000' 39 180.0 1000'
17 13.3 1000' 40 208.0 1000'
18 17.8 1000' 41 236.0 1000'
19 21.7 1000' 42 273.0 1000'
20 27.5 1000' 43 286.8 1000'
21 28.1 1000' 44 327.6 1000'
22 32.25 1000' 45 350.0 1000'
23 38.8 1000'

Copyright © 2017 Douglas Dynamics, LLC. All rights reserved. This material may not be reproduced or copied, in whole or in part, in
any printed, mechanical, electronic, film, or other distribution and storage media, without the written consent of TrynEx International, LLC.
Authorization to photocopy items for internal or personal use by TrynEx International outlets or spreader owner is granted.
TrynEx International reserves the right under its product improvement policy to change construction or design details and furnish equipment
when so altered without reference to illustrations or specifications used. TrynEx International may require or recommend optional equipment
for spreaders. TrynEx International offers a limited warranty for all spreaders and accessories. See separately printed page for this important
information. The following are registered (®) trademarks of Douglas Dynamics, LLC: TurfEx®.
Printed in U.S.A.
A DIVISION OF DOUGLAS DYNAMICS, LLC
Tr ynE x Inter natio nal
531 Ajax Drive
Madison Heights, MI 48071-2429
www.turfexproducts.com
Lit. No. 76754, Rev. 00 November 1, 2017
This product conforms to EU Machinery Directive 2006/42/EC.
