inada DREAMWAVE HCP-11001A User manual

ENGLISH
ᖆᡞϜН
Ὶ㜴
●Please read this Operating Manual before use.
●Keep this manual nearby so that you can refer to it anytime.
●This product is designed for home use.
●!ٻңࠊ፝ၐಡᎨ᠟ҐᐈձКьȄ
●!፝஡ҐᐈձКь׃๢ԇܼܺР߰ڦңϟ೏ȂпറϛϟሰȄ
●!Ґᐡ༊ܼঢ়৴ٻңȄ
●!ℬ䛕⏺嶤枲嶨㣙ℬ䛕嶡㞻–҉
●!嶤ⶳ㣙ℬ䛕嶡㞻–⭒✱↊䵎⣕Ⅼ※ℬ䛕冲㦒㐫䠱⣝㝦的ₒ⪴Ὰ㞣Ὸ梭҉
●!㣙㣧⁲柽※ⵣ䛕҉
Thank you for purchasing the Inada DreamWave.
We hope the Inada DreamWave will be a valued partner in your
daily health preservation for many years to come.
དᗃ்ᒶᗋ!Jobeb!EsfbnXbwf!ȞჳГݱ୞ȟ!ࡹኟැȄ
שউוగҐ౱ࠣ֊ܼ߰ӼԒпࡤȂϬ்࣐СளᎵҢޠًգȄ
㋌巏㉕憶廚䯟䛝!ⴹ儻癢㩓㒶㘖㪲҉
㋬㣙⁔♮㎽ῧ㉕㷥憉䠱−つ吜󱂂҉
HCP-11001A
HCP-11001D
HCP-11001E
Operating Manual
Warranty card provided separately
ℬ䛕嶡㞻–
▓柱↊↛┎
ᐈձКь
ѫߤߴڿћ

●Please read this Operating Manual before use.
●Keep this manual nearby so that you can refer to it anytime.
●This product is designed for home use.
Thank you for purchasing the Inada DreamWave.
We hope the Inada DreamWave will be a valued partner in your
daily health preservation for many years to come.
HCP-11001A
HCP-11001D
HCP-11001E
CONTENTS
SAFETY PRECAUTIONS ··················1
MAIN FEATURES ······························4
COMPONENTS & DESCRIPTION ····5
BEFORE USE ······································9
POSITION ADJUSTMENT ·············11
AFTER USE ······································ 14
MASSAGE PROGRAMS & ············ 15
SELECTION
PRESET PROGRAMS ····················· 17
MANUAL SELECTION MODE ····· 19
TROUBLESHOOTING ··················· 23
FAQ ··················································· 26
CARE AND STORAGE ··················· 27
CUSTOMER SERVICE AND ·········· 28
WARRANTY
REGULAR MAINTENANCE ··········29
FOR SAFETY
SPECIFICATIONS ··························· 30
Operating Manual
Warranty card provided separately
ENGLISH

SAFETY PRECAUTIONS
1
SAFETY PRECAUTIONS
Be sure that you have read these SAFETY PRECAUTIONS thoroughly before using your Inada DreamWave for the  rst time. The Operating
Manual contains important information about how to use the chair safely and correctly, avoiding possible damage to property or injury
to persons using the chair and others. First of all, you should understand well the meaning of the indications and symbols described
below, which are used throughout the Operating Manual to highlight important safety instructions. Please adhere to all precautions.
Descriptions of each chair component can be found on pages 5-8.
Types of Indications
Warning This action could result in serious injury or death.
Caution This action could result in personal injury or damage to property.
Types of Symbols and Description
Prohibited
Prohibited.
Do not
disassemble
Do not disassemble.
No wet hands
Do not handle with wet hands.
Do not wet
Do not use in a location where the chair may become wet.
Prohibited
Do not use in a bathroom.
Required Action
Required action. Unplug
the chair
Unplug the power plug from the wall outlet.
Remember to keep this Operating Manual in an easily accessible place.
Safety Precautions: Installation
Caution
Prohibited
● Do not install the chair in an area of high humidity, such as a bathroom or sauna.
→Could result in electric shock or damage to the chair.
Prohibited
● Never connect the ground wire to gas pipes, water pipes,
telephone lines, or lightning rods.
Required Action
●Install on a flat, level surface only.
→ Chair could tip over accidentally if placed on an uneven surface,
resulting in an accident.
Safety Precautions: Installation
Warning
Electrical
grounding ●Space Requirements
This product must be grounded. If it should malfunction or breakdown, grounding provides a path of least
resistance for electric current in order to reduce the risk of electric shock. This product is equipped with a
cord having an equipment-grounding conductor and a grounding plug.
The plug must be plugged into an appropriate outlet that is properly installed and grounded in accordance
with all local codes and ordinances.
• Improper connection of the equipment-grounding conductor can result in the risk of electric shock.
Check with a quali ed electrician or serviceman if you are in doubt as to whether the product is properly
grounded. Do not modify the plug provided with the product if it will not  t the outlet; have a proper
outlet installed by a quali ed electrician. This product uses on a normal Alternating Current(AC) circuit
and has a grounding plug that looks like the plug illustrated in the  gure to the right. Make sure that the
product is connected to an outlet having the same con guration as the plug. No adapter should be used
with this product.
Required Action
●Always unplug this appliance from the electrical outlet immediately after using and before cleaning.
Caution
Prohibited
●Do not operate under blanket or pillow. Excessive heating can occur and cause re, electric shock, or injury to persons.
●
Use this appliance only for its intended use as described in this Operating Manual. Do not use attachments not recommended by the manufacturer.
●Never operate this appliance if it has a damaged cord or plug, if it is not working properly, if it has been dropped or damaged, or dropped into
water. Return the appliance to a service center for examination and repair.
●Do not carry this appliance by supply cord or use cord as a handle.
●Never operate the appliance with the air openings blocked. Keep the air openings free of lint, hair, and the like.
●Never drop or insert any object into any opening.
●Do not use outdoors.
●Do not operate where aerosol (spray) products are being used or where oxygen is being administered.
●Children should be supervised to ensure that they do not play with the appliance.
Required Action
● An appliance should never be left unattended when plugged in. Unplug from outlet when not in use, and before putting on or taking o parts.
●Close supervision is necessary when this appliance is used by, on, or near children, invalids, or disabled persons.
●Keep the cord away from heated surfaces.
●To disconnect, turn all controls to the o position, then remove plug from outlet.
●Keep children away from extended foot support (or other similar parts).
●Connect this appliance to a properly grounded outlet only. See Grounding Instructions.
●
Thisapplianceisnotintendedforusebypersons(includingchildren)withreduced physical,sensoryor mentalcapabilities,orlackofexperienceandknowledge,
unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.

SAFETY PRECAUTIONS
2
Safety Precautions: Before Use
Warning
Prohibited
●The following persons must not use this massage chair:
◎Persons who have been instructed by a doctor to avoid massage therapy. Ex. Thrombosis, severe aneurism, acute varicosity, or dermatitis and/or skin
infection including in ammation of the hypodermis. ◎Persons with suspected acute neck sprain (whiplash injury)
●Do not use a power supply other than the one specied.
→May result in  re or electric shock.
●Do not use with any type of transformer device.
→May result in damage to the chair or electric shock.
●Do not use the chair if the power cord or plug is damaged, or if the wall outlet connection is loose.
→May result in electric shock, short circuit, or combustion.
●Before each use, check for holes or tears in the fabric of the active area. Also, check the other parts for tearing. Unplug the chair and contact your
local distributor for assistance. Never use the chair with the fabric of the active area removed or with holes or tears in the fabric, because doing
so is extremely dangerous.
→Using the chair with holes or tears in the fabric could result in injury or electric shock.
Required Action
●Persons with any of the following conditions should seek medical advice before using the chair:
◎Serious heart conditions ◎Sensory impairment caused by serious peripheral circulatory disorders due to diabetes and other diseases
◎Osteoporosis, spinal fractures, acute pain and/or symptoms thereof ◎Persons being treated for personal injuries
◎High fever (38°C (100°F) or higher) Ex. Strong acute in ammation illness caused by fatigue, chills, blood pressure  uctuation, or asthenia
◎Persons in the early stages of pregnancy, or immediately after giving birth
◎Persons who have electronic medical device(s) easily susceptible to electromagnetic interference Ex. pacemaker
◎Abnormal or curved spine ◎Persons planning to use the chair for treatment or for rehabilitation purposes
◎ Persons with malignant tumor(s) ◎Persons under bed rest orders
◎Persons with acute gastro-intestinal complaints or ailments such as gastritis, enteritis, or hepatitis
◎Persons under a doctor's care, or those experiencing unusual physical discomfort
◎Joint dysfunction due to rheumatism, gout, or other diseases ◎Persons with symptoms such as qualm, dizziness, or tinnitus
◎In ammation due to sprains, muscle strain, or other injuries ◎Persons with thecitis or suspected thecitis ◎Persons with thermoanesthesia
●
Elderly people and persons with weak bones should seek medical advice before using the chair, even if they do not have a specic disease.
●If your condition does not improve after use, consult a doctor or specialist.
Caution
Prohibited
●Do not use the chair in any way not prescribed by the Operating Manual. Do not use the chair together with any other therapeutic device or with
an electric blanket.
→May result in injury or have a negative e ect on health.
●Do not move the chair while someone is in it.
→Accident or injury may result if the chair tips over.
●Do not sit down on the chair while the seat back is reclined.
→Any sudden impact on the leg rest could cause damage to the mechanism. Also, an accident or injury may result if the chair tips over.
●Do not use with anything other than the accessories supplied with this product.
Required Action
●Before plugging the power cord into the wall outlet, make sure that the main POWER switch is set to OFF.
→May result in damage to the chair or electric shock.
●Make sure that the plugs on the power cord are inserted fully into the cord connector and the wall outlet.
→May result in electric shock, short circuit, or combustion.
●Before using the chair for the rst time, turn on all the switches in order as indicated in this Operating Manual to check that the chair is operating
properly.
●Start o with a lighter massage.
→Starting with a deep massage may result in injury. Elderly people and persons with weak bones should be especially careful when selecting
massage intensity.
●For safety, rst check the position of the mechanism. If the mechanism is not in the storage position, turn the main POWER switch ON and check that
the mechanism returns to its storage position before sitting down slowly. For the storage positions, see page 7.
●Do not climb onto, stand on, sit on or otherwise subject the leg rests to a heavy load.
→Personal injury or damage to the chair may result if the chair tips over.
●If you use the chair after it has not been used for a long time, read this Operating Manual again thoroughly and check if the chair operates
properly.
Safety Precautions: During Use
Warning
Prohibited
●Do not wrap the power cord or the remote control cord around the chair, or place the chair on top of either cord. Do not scratch, tear, treat,
unduly twist, stretch or bend the power cord or the remote control cord.
→The cords may be damaged, resulting in  re or electric shock.
●Do not spill water and/or other liquids on the chair or remote control.
→May result in electric shock, short circuit, or combustion.
●Children should not use the chair. It is advisable to keep children and pets away from the chair (especially from behind the reclining sheat
back or under the leg rest). Children aged 14 years or over should use only the Youth Program. In such a case, an adult must attend the child.
→Could result in accident or injury.
●Do not use the chair while more than one person is sitting in it. In particular, do not use the chair while holding a small child (or baby).
→ Could result in accident or injury.
●Do not use the chair while your body is wet, or with wet hands.
→ Could result in electric shock or damage to the chair.
●Do not use the chair if the fabric is torn. If it is, unplug the power plug from the wall outlet.
→ Could result in an accident, injury or electric shock. Contact your local distributor for repairs.
●Do not release your hands suddenly while lifting the chair by hand.
●Do not use the heater continuously for two hours or longer.
→ May result in low-temperature burn.
Required Action
●Make sure no one, especially children or pets, is around the chair before starting a massage program or when lowering or raising the reclining
seat back. Be careful that people or objects are not caught behind the seat back or under the leg rest.
→ Could result in accident or injury.
●If a person or object is trapped, press the recline button to return the chair to a safe position.
Model number Power supply
HCP-11001A AC120V~
HCP-11001D AC220-240V~
HCP-11001E AC110V~

3
SAFETY PRECAUTIONS
SAFETY PRECAUTIONS
Safety Precautions: During Use
Caution
Prohibited
●Do not use the chair unclothed.
●Do not use the chair for purposes other than massage, or other than the ordinary uses of a chair.
→ Could result in accident or injury.
●Do not use the chair to massage the head, chest, stomach, and/or joints (knees, elbows).
→May result in nausea or injury. Place a soft towel behind your neck if you want to avoid intense stimulation of the area.
●Do not place your hands into the roller tracks, or the moving parts of the reclining seat back or other areas. Do not sit wearing hard objects,
such as a hair accessory, necklace, watch, bracelet or ring.
→May result in personal injury.
●Do not place your legs anywhere other than the active area (leg mechanism) described in this Operating Manual.
●Do not place anything other than legs and feet on the leg rest.
→May result in personal injury.
●Do not place anything other than upper arms and forearms in the Upper-Arm and Forearm Units. Do not place anything other than shoulders
against the Shoulder Massage Unit.
→May result in personal injury.
●Do not operate the massage chair or leave it operating when there is no one in it.
→ Could result in accident or injury.
Required Action
● In an emergency, or if you nd any abnormal condition, push the EMERGENCY STOP button on the remote control to stop operation immediately.
●If you get acute pain or other unusual physical discomfort while using the chair, immediately discontinue the use of the chair and seek medical
advice.
●If you feel the massage is too strong, reduce the stimulation according to this Operating Manual. If this solution does not work, stop using and
contact your local distributor.
→May result in injury if you continue use with high stimulation under such circumstances.
●If you feel that the massage is too intense after removing the buer pad, stop use immediately and reinstall the buer pad.
→May result in personal injury.
●Do not operate a massage without the back pad.
●Do not fall asleep in the chair during a massage session.
→May result in personal injury.
●
Keep massage sessions to no longer than 30 minutes. Do not exceed 5 minutes for an area-specic massage of any particular part of the body.
→Continuous use for extended periods of time can result in over-stimulation, which could cause the opposite of the desired e ect, or even injury.
Limit the massage time to a total of about 30 minutes in a day.
* For children aged 14 years or over, use only the Youth Program and only one session per day.
●If your leg or foot comes out of the leg rest during the massage, do not try to force it back in.
→Undue force may result in damage to the mechanism.
●If your arm comes out of the Upper-Arm Unit or Forearm Unit during the massage, do not try to force it back in.
→Undue force may result in damage to the mechanism.
●The heater is located under the seat and back of the chair. Person who cannot feel heat should be careful when using the heater.
Unplug
the chair ●If there is a power outage or the possibility of a power outage, stop operation immediately and turn the main POWER switch to OFF. Unplug
the power plug from the wall outlet.
→Accident or injury may result if the chair is still in operating mode when the power resumes.
●
If there is a threat of lightning, stop operation immediately and turn the main POWER switch to OFF. Unplug the power plug from the wall outlet.
●If an operation does not start, or if you nd any abnormality, stop the chair immediately and turn the main POWER switch to OFF to prevent an
accident. Unplug the power plug from the wall outlet. Contact your local distributor for inspection or repairs.
→Electric shock or  re caused by a short circuit may result if the chair is left plugged in under such circumstances.
Safety Precautions: After Use or When Not in Use
Caution
Prohibited
●Be sure to turn the main POWER switch to OFF after every use and to unplug the power plug from the wall outlet.
→An accident or injury may result if children or pets play with the chair.
●Do not use a power cord for anything other than the chair.
●After using the chair, be sure to fully return the reclining seat back to the upright position.
●Wipe the chair o after every use, and store the chair in a place with low humidity.
●Do not place any object on the chair.
Unplug
the chair ●Hold the power plug when unplugging from the wall outlet. Do not pull on the power cord.
→May result in electric shock or  re caused by short-circuiting.
●
Before cleaning the chair, make sure to unplug the power plug from the wall outlet. Do not plug or unplug the power plug with wet hands.
●If the chair is left unused for a while, be sure to unplug it from the wall outlet.
→Insulation degradation by dirt or moisture may cause electric shock, or  re due to short-circuit.
Others Precautions
Warning
Prohibited
●Do not stand on the chair. Do not make a major impact or sit on any part of the chair other than the seat.
→Personal injury or damage to the chair may result if the chair tips over.
Do not
disassemble
●Do not try to repair any malfunction of the chair. Contact your local distributor for assistance.
●A damaged power cord is dangerous. If the power cord is damaged, contact your local distributor for replacement.
●Do not modify or remodel the chair.
→May result in  re, electric shock, or injury.
Caution
Required Action
●If you lend, sell, or otherwise transfer the chair to another party, make sure to include this Operating Manual.
Note
Before disposing of the product or its accessories, consult your local authorities about the proper procedure.

4
MAIN FEATURES
MAIN FEATURES
Main Features
From your palms to the soles of your feet
Full-Body Massage Function
Deep relaxation is made possible by modern
technologies working together for the Full-Body
Massage Function.
The Shoulder Massage Unit and the Upper-Arm
and Forearm Units give a gentle massage from
your shoulders to your palms.
For massaging of your back, buttocks, and
calves, variable massage techniques and unique
programming deliver a sensation as close to
human hands as you can find. The length of the
leg rest can be adjusted by moving the Foot Unit
up or down, which enables the leg rest to give a
gentle massage to your feet and legs from any
angle.
Optical sensors enable the
Automatic Shiatsu Point Locator
Function
This automatically locates Shiatsu points, which vary
from person to person, before starting a massage,
allowing for an effective massage that tailors itself
to your size and shape.
Easy-to-read massage guide
Remote Control Display Panel
The remote control features a clear, easy-to-read
display panel that enables you to monitor your
massage. The display guides you through each step
of your massage, displaying information about each
massage action.
Easy to adjust to the most comfortable position
Automatic Reclining Function
The seat back can be reclined to any angle between
approx. 120° and 165° from the floor. The angle of the
leg rest can be adjusted by approx. 90° according to
your preference.
With state-of-the-art technology
Various Course Functions
Healthcare programs, Well-Being programs, that
allow you to select the optimal and Deep Relaxation
programs according to your purpose and Manual
Selection mode that accommodates your particular
needs are provided.
Vibration Massage Function
Vibration mechanisms are located in the seat and
chair back. The soothing vibrations add to your
sense of calm.
DreamWave Function
The seat rocks approximately 1.6 inches either side
of center. The gentle rhythm of the DreamWave
promotes thorough relaxation.
Full-Body Stretch Function
The Full-Body Stretch Function is a combination of
bending your upper body backward with reclining
of the seat back and twisting with the air cushions
provided with the seat.
Back 3-D Mechanism
The intensity of massage can be adjusted with an
air-actuated 3-D massage mechanism.
Heater Function
The heater located under the seat and back to warm
your seat and lower back.
Youth Program Setting
The Youth Program provides a low-stimulation
massage for children aged 14 years or over. For this
program, the adjustable range of the roller shoulder
positions during an Automatic Shiatsu Point Locator
operation is extended to cover lower positions, to
fit the shoulder positions of young people.
Benefits
As a therapeutic massage device in the general households, the Inada DreamWave
provides the following benefits:
● Relaxes muscles ● Relives minor muscle aches and pains

5
COMPONENTS & DESCRIPTION
Armrests
COMPONENTS & DESCRIPTION
Chair
Shoulder Massage Unit
Rollers
(Storage roller positions are inside
the upper part of the seat back.)
Upper-Arm Units
Seat
Calf Unit
Foot Unit
Forearm Units
Leg Rest
Back Pad
Smart Phone Pocket

6
COMPONENTS & DESCRIPTION
Reclining
Seat Back
Reclining Safety
Mechanism
Control Box
Cord Connector
Plug
Power Cord
Wheel
Power Connector
Main POWER
Switch
Counter Weight for the
Shoulder Massage Unit
A weight for adjusting the
position of the Shoulder
Massage Unit is housed inside.
Remote
Control
Pocket for
the Remote
Control
Leg

7
COMPONENTS & DESCRIPTION
COMPONENTS & DESCRIPTION
Remote Control
Warning
● Do not spill water and/or other liquids on the remote control.
● Do not handle the remote control with wet hands.
● Do not sit on the remote control. Do not drop or step on the remote control. Do not pull the remote control cord forcibly.
● Do not use pointed or hard objects to push the buttons or display on the remote control.
→ May result in damage to the remote control.
Remote Control Display
Information, such as massage action descriptions, status
of progress, and the intensity and speed of the massage
in progress, is displayed with both characters and
symbols. (See next page.)
Preset Programs
For selecting a program with the corresponding course
name
ROLLER Buttons
During Preset Programs, roller shoulder positions can
be adjusted using [ ] and [ ] immediately after the
Shiatsu points are located.
In Manual Selection Mode, roller positions can be
adjusted using [ ] and [ ].
BACK 3-D Buttons
For adjusting the intensity of massage stimulation on
the back, use [＋] and [−].
EMERGENCY STOP Button
Use this button to shut the chair off immediately in an
emergency or if there is a malfunction during operation
of the chair.
The rollers will stop immediately.
AIR LEVEL Button
For adjusting the intensity of air pressure in 3 settings
(high, medium, and low) during Preset Programs
VIBE OFF Button
Cancels vibration operation during any Preset Program.
POWER Button
For turning the remote control power ON or OFF.
Pushing the POWER button while the chair is activated
causes the rollers to return to their storage positions
before the chair is shut off.
The button is lit in green while the power to the remote
control is on, in orange while the power is off, and in red
while the chair is stopped in an emergency.
If pressed during a Preset Program, your chair will
automatically resume to an upright position.
LEG REST Buttons
Use [ ] and [ ] to adjust the angle of the leg rest.
RECLINE Buttons
Use [ ] and [ ] to adjust the angle of the reclining seat
back.

8
COMPONENTS & DESCRIPTION
Remote Control Display
Information, such as massage action descriptions, status of progress, and the intensity and speed of the
massage in progress, is displayed with both characters and symbols.
Characters and symbols on the display move from right to left.
Example: While the Shiatsu Point Locator sensors are being activated, the display shows the following text:
“Locating Shiatsu Points...”
Remote Control Display
Remote Control/Inside the Panel
Speed Button
For adjusting the roller speed in three steps during
Kneading, Tapping 1, and Kneading & Tapping.
Basic Operation Buttons
Width Button
For adjusting the width of the rollers in three steps.
MUTE Button
For turning the speaker of the remote control ON or OFF.
Air Massage Buttons
You can select from among [Shoulder], [Arm], [Seat], and
[Foot].
* The intensity of air massage can be adjusted in three steps
(high, medium, and low).
Back Vibe Button
For back vibration operation.
* The intensity of vibration can be adjusted in two steps (high
and low).
Heater Button
For controlling the heat functions in the seat and back.
Rolling Button
You can select from between Full and Partial Rolling.

9
BEFORE USE
At least
65 cm
(26 inch.)
At least
40 cm
(16 inch.)
BEFORE USE
● This product is shipped with the reclining seat back in its fully reclined position and with the armrests and leg rest removed.
Before use, be sure to attach the armrests and leg rest (refer to the insertion sheet attached) then raise the seat back to its
upright position.
● Do not expose the chair to sudden change of heat. If the room where the chair is to be used is cold, turn the heat up slowly. If
the chair is moved from a cold place into a heated room, wait one hour before using the chair.
→ Condensation could occur in the moving parts of the product, which may compromise performance.
Installation
Allow for at least 65 cm (26 inch.) clearance behind the chair and 40 cm (16 inch.) in front of the chair when
installing, so as to be able to recline the seat back fully without obstruction.
Caution ● Do not install the chair in an area of high humidity, such as a bathroom or sauna.
● Only install on a flat, level surface.
● Do not use in areas of high debris or dust content. Do not use where ambient temperature is 40°C (104°F) or
over.
● Do not install the chair where it can come into contact with direct heat, such as direct sunlight or a radiator.
● To avoid damaging floor surfaces and to cut down on the noise of
the chair, it may be better to install the chair on a carpeted surface or
to lay a piece of carpet under the chair. (Do not use electric blanket.)
● The product is very heavy, so please be careful when unloading it so
as not to damage floor surfaces.
● Install the chair at least 1 m (40 inch.) away from TVs, radios, and/or
other audio or video equipment. Interference from these devices
can cause problems.
● The load to the floor per 1 cm2 (0.16 in2) is approximately 2.5 kg
(5.5 lbs.) with a person weighing 100 kg (220 lbs.) sitting on the chair.
Main Power Connection
① Plug the power
cord into the cord
connector located at
the back of the chair
first. Then plug the
other end into the
wall outlet. ② Set the main POWER
switch located at the
back of the chair to
ON.
A text message should
appear on the remote
control display screen.
* If the main POWER switch is turned on while the rollers are stopped in the middle of the movement, they will automatically return to
their storage position (upper part of the reclining seat) then stop.
The seat will also move for adjustment of the initial position then stop.
Warning ● Do not use with any type of transformer device.
→ May result in damage to the product or electric shock.
Caution ● Before plugging the power cord into the wall outlet, make sure that the main POWER switch is set to OFF.
● Make sure that the plugs on the power cord are inserted fully into the cord connector and the wall outlet.
● Before using the chair for the first time, turn on all the switches in order as indicated in this manual to check
that the chair is operating properly.

10
BEFORE USE
Checking the Seat Cover
Check for holes or tears in the back pad and other parts.
Check also that the zippers located at both sides of the
back pad are securely zipped.
Back Pad
Lift the Shoulder Massage Unit
up to check for holes or tears in
the cover of the back pad.
Zipper
Shoulder
Massage Unit
Check that the zipper
is securely zipped.
Warning ● Before each use, check for holes or tears in the cover of the back pad. Also, check the other parts for tearing.
Stop using the chair immediately if you find even the smallest tear. Unplug the chair and contact your local
distributor.
How To Move
First, raise the reclining seat back and set the main POWER switch to OFF. Then
unplug the power cord from the outlet. Grip the lower parts of the both armrests,
as illustrated, lift the chair, and move.
Caution ● Do not move the product while someone is in it.
● During moving, be fully careful not to pinch your feet.

11
POSITION ADJUSTMENT
RECLINE
LEG REST
How to Sit
When the chair is off, the rollers are normally drawn back into the left and right sides of the upper part of the
seat back (Storage Position). For safety reasons, first check the positions of the rollers. If they are in any position
other than storage positions, set the main POWER switch to ON before sitting down to allow the rollers to
return to their storage position. When you finish checking, sit down slowly in the center of the seat.
Caution ● Do not sit down on the chair with the leg rest raised.
→ Any sudden heavyweight on the leg rest could cause damage to the mechanism. Or, accident or injury
may result if the chair tips over.
● Before using, raise the reclining seat back to its fully upright position. Then recline the seat back slowly to
the most comfortable position, remembering to start off with a lighter massage.
How to Use the Reclining Seat Back
■ To raise the reclining seat back:
Press and hold the RECLINE [ ] button on the remote control. Release the button when the seat back
reaches your desired position.
The button may be released after 2 seconds and the chair will continue to auto-restore to the upright
position.
■ To lower the reclining seat back:
Press and hold the RECLINE [ ] button on the remote control. Release the button when the seat back
reaches your desired position.
The button may be released after 2 seconds and the chair will continue to auto-recline to the full reclined position.
● The leg rest is raised in conjunction with the movement of the reclining seat back. As soon as reclining of the seat back stops, the
leg rest also stops.
● If the main POWER switch at the back of the chair is set to ON, the reclining angle of the seat back can be adjusted.
Warning ● Make sure no one, especially children or pets, is in the way when lowering the reclining seat back.
Be careful not to stand or place any object behind the seat.
How to Use the Leg Rest
■ To raise the leg rest:
Press and hold the LEG REST [ ] button on the remote control.
The button may be released after 2 seconds and the leg rest will continue to raise.
■ To lower the leg rest:
Press and hold the LEG REST [ ] button on the remote control.
The button may be released after 2 seconds and the leg rest will continue to lower.
● If the main POWER switch at the back of the chair is set to ON, the angle of the leg rest can be adjusted.
Warning ● Make sure no one, especially children or pets, is in the way when lowering the leg rest.
Be careful that people and/or objects are not caught under the leg rest.
● Do not release hands suddenly while lifting the leg rest by hand.
Caution ● Do not place anything other than legs and feet on the leg rest.
POSITION ADJUSTMENT

12
POSITION ADJUSTMENT
Foot Slide Adjustment Function
■ How to Move the Foot Unit Downward
To slide the Foot Unit of the leg rest to move it downward, push it down with your feet.
Warning ●
Be careful not to get hands, feet, or objects caught between the leg rest units or between the leg rest and the
chair during a foot slide operation.
→ Accident, personal injury, or damage to the chair may result if hands, feet, or objects are caught.
How to Use the Shoulder Massage Unit
Place the Shoulder Massage Unit in a proper position.
If it is not placed properly, the Automatic Shiatsu Point Locator may not function properly.
Position both ends of the Shoulder
Massage Unit on your shoulders.
Proper Position of
the Shoulder Massage Unit
To raise the unit:
Push up the headrest of the
Shoulder Massage Unit.
To pull down the unit:
Pull down the lower parts of the
Shoulder Massage Unit.
■How to Use the Chair Without the Shoulder Massage Unit
You can have your shoulders massaged by the rollers and not by the Shoulder Massage Unit, by securing the Shoulder Massage
Unit at the upper part of the seat back.
① Flip the side of the Shoulder
Massage Unit over, as
illustrated. The lock belts for
the Shoulder Massage Unit are
initially positioned at the rear
of the Shoulder Massage Unit.
* The lock belts are located at
the both sides of the unit. ② Pull out the belts on both
sides. Move the Shoulder
Massage Unit upward to
the upper part of the seat
back. ③ Fasten the buttons located at the rear
of the both sides of the back pad to the
holes of the belts. ④ Sit on the chair,
as illustrated, and
start a massage.

POSITION ADJUSTMENT
13
POSITION ADJUSTMENT
How to Use the Shiatsu Pads for Shoulders and Feet
The Shiatsu Pad for Shoulders (strong) are placed inside the Shoulder Massage Unit.
If you feel that the massage given by the Shoulder Massage Unit is too strong, replace it with the Shiatsu pads
(light).
If you feel the massage is too strong, remove the Shiatsu pads.
*The Shiatsu Pads for
Shoulders (strong) L
and R are symmetrical
opposites. Use Pad L for
the left shoulder and Pad
R for the right shoulder.
Shiatsu Pad for
Shoulders (strong) R
Shiatsu Pad for
Shoulders (strong) L
Shiatsu Pad for
Shoulders (light)
Disengage the Velcro at the rear of the cover of the shoulder massage section, turn the cover over, then
attach the Shiatsu pads at any place where the Velcro is provided, according to your preference.
* For easy replacement of the Shiatsu pads, raise and place the Shoulder Massage Unit at the upper part of the seat back.
Add the Shiatsu Pad for feet if you feel that the massage is too light.
Remove the Shiatsu Pad for feet if you feel that the massage is too strong.
Shiatsu Pad for Foot L Shiatsu Pad for Foot R
How to Install the Massage Buffer Pad (Thin or Thick)
The buffer pad is not required for the use of your massage chair, and this massage chair is shipped from the
factory with no buffer pad installed.
If the back massage is too intense, your can add the acccessory buffer pad.
Most users find that the addition of a buffer pad is unnecessary, but this is a matter of your personal preference
and massage comfort.
If you wish to the buffer pad, please follow the instructions below.
Zipper
Velcro
Back Pad Back Pad
Buffer Pad
Back Pad
① Unzip the zipper located at one
side of the back pad. ② Disengage the Velcro located at the rear of the back pad. ③ Replace the buffer pad.
Caution ● Before use, check that the zippers located at both sides of the back pad are securely zipped.
Velcro
Velcro

14
AFTER USE
How to Use the Upper-Arm/Forearm Units
Place your arms in the Upper-Arm and Forearm
Units, as illustrated.
Be careful not to place your elbows where the
air cushions are.
● Do not fall asleep in the chair during a massage.
→ May result in personal injury.
● If you begin to experience marked pain or other
unusual physical discomfort while using the
product, seek medical advice immediately and
discontinue use of the product.
* Be careful not to place your
elbows where the air cushions are.
* Place your arms in the
Upper-Arm and Forearm
Units with your palm down.
The auto-adaptive width mechanism of the
Upper-Arm and Forearm Units enable them to
stretch out by 4° at maximum so that they can fit
the body type of the user.
How to Use the Heater
Press the Heater button once to turn on back (b) and seat (s) heat. Press again
to activate only the back (b) heat. Press a third time to activate only seat (s)
heat.
Pressing a fourth time will turn off all heat.
● The heater turns itself off automatically about 2 hours after it is turned on.
● Without the remote control power on, it is possible to turn the heater on or off if the main
POWER switch at the rear of the chair is set to ON.
Button
Indication
(b: back,
s: seat)
Speaker on the Remote Control
The sound from the speaker can be muted or reactivated with the MUTE
button behind the panel of the remote control.
While the sound is muted, the symbol shown on the right is displayed on
the display of the remote control.
Button Indication
AFTER USE
Caution ● Be sure to set the main POWER switch to OFF after every use and to unplug the chair from the wall outlet.
→ Accident or injury may result if children or pets play with the product.
● After using the chair, be sure to return the reclining seat back to the upright position and lower the leg rest
to its lowest position.
● Wipe the product off after every use, and store it in a place free of excess humidity.
● Do not pull on the power cord to unplug the product from the wall outlet; make sure to grasp the plug
firmly when unplugging.
● If you will not be using the product for some time, be sure to unplug it from the wall outlet.

15
MASSAGE PROGRAMS & SELECTION
MASSAGE PROGRAMS & SELECTION
Massage
Courses
PRESET
PROGRAMS
A total of 16 Preset Programs
provide massages to meet your
desired purpose and application
according to the preset menus.
MANUAL
SELECTION
MODE
You can combine your favorite
massage types. You can also adjust
the speed, intensity, and roller
positions.

16
MASSAGE PROGRAMS & SELECTION
1Full Body
For a comprehensive full-body Healthcare massage.
This program is recommended for persons who feel fatigue
or lack of energy.
2Full Body Air
For a comprehensive full-body massage focused on air
massage.
This program is recommended for persons who prefer
softer massage.
3Youth
A program for young people.
This program is recommended for persons who prefer
softer massage or for children aged 14 years or over.
4Quick
This program provides a quick massage to refresh the
entire body.
5Morning
For morning massage.
This program is recommended for persons who have a bad
morning or who have not recovered from their fatigue.
6Night
For night massage.
It is recommended to use this before going to bed.
7Stretch
For stretching operations.
This course is focused on curving and twisting motions.
8DreamWave
For a DreamWave massage.
This program is recommended for persons who need
relaxation.
● The duration of each course varies depending on height, body
type, reclining angle, and other factors related to the user.
HEALTHCARE
PROGRAMS
WELL-BEING
PROGRAMS
For relaxation of muscles
In order to select the
Deep Relaxation version
of any of the Healthcare
Progarms, depress and hold
the program button for
2 seconds.
For refreshing or relaxing
In order to select the
Deep Relaxation version
of any of the WELL-BEING
Progarms, depress and hold
the program button for
2 seconds.

17
PRESET PROGRAMS
PRESET PROGRAMS
Preset Programs
● Sixteen automatic programs provide a variety of different massages to relieve fatigue.
●
With the Preset Program buttons, you can choose your favorite program, which will provide a carefully crafted
massage suited to your needs.
Various Adjustments
Changing Courses
Before the course in progress finishes, you can change it to another course. After a total duration of 30 minutes, the course in
progress stops even if not completed.
*
It may take some time to change courses because the air bags for the BACK 3-D function must be deflated before changing the course.
Switching from One Preset Program in Progress to Another
When one Preset Program button is pressed while another Preset Program is in progress, the rollers return to their storage
positions, then the selected program stars after Automatic Shiatsu Point Locator completes a new body scan. You can adjust the
shoulder position during Automatic Shiatsu Point Locator operation.
Switching from a Preset Program to Manual Selection Mode
When one of the buttons for Manual Selection Mode is pressed while a Preset Program is in progress, the Preset Program
immediately stops, and the selected operation starts. To select an air massage or back vibration operation, press the POWER
button to stop the preset program in progress before the selection.
Stopping in the Middle of a Massage
To stop mid-massage, press the POWER button. The rollers will return to their storage positions, a seat will automatically return
to the upright position and the massage will stop.
In an emergency or if there is some malfunction during operation of the chair, press the STOP button. The rollers will stop
immediately. After confirming safety, press the POWER button. The rollers will return to their storage positions and stop.
Caution ● If you feel the massage is too strong, reduce the stimulation according to this Operating Manual. If this
solution does not work, stop using and contact your local distributor.
→ May result in injury if you continue use with high stimulation under such circumstances.
● Do not place hands or feet into the roller tracks, into the space between the seat back and the seat or into
the moving parts. Do not sit wearing hard objects, such as hair accessories, necklace, watch, bracelet, or ring.
● If your leg or foot comes out of the leg rest during the massage, do not try to force it back in.
■BACK 3-D Buttons
The intensity of back massage can be continuously adjusted with [
＋
] and [
−
].
■AIR LEVEL Button
The intensity of air massage is initially set to Medium.
Each time the button is pressed, the intensity changes in the order of High, air
massage canceled, Low, then Medium.
(The intensity of air massage for the Youth Program is initially set to Low.)
* If the program is changed, the intensity of air massage is reset to its initial
setting (MED).
■VIBE OFF Button
The vibration function included in a program can be canceled with the
VIBE OFF button, according to your preference.
To reactivate the vibration function, press the VIBE OFF button again.
■Air Massage Buttons
The intensity of air massage can be adjusted by area.
Each time the button located behind the panel of the remote control is pressed, the
intensity changes in the order of High, air massage canceled, Low, then Medium.
* If the program is changed, the intensity of air massage is reset to its initial
setting (MED).
■Back Vibe Button
The intensity of a back vibration operation can be adjusted with the Back Vibe
button located behind the panel of the remote control. The intensity of back
vibration is initially set to Low.
Each time the button is pressed, the intensity changes in the order of High,
vibration canceled, and Low.

18
PRESET PROGRAMS
Caution ● Keep massage sessions to no more than 15 minutes in length. Area Specific Massage of any particular area
on the body to no more than 5 minutes.
→ Continual use for extended periods of time can result in over-stimulation, which could cause the opposite
of the desired effect, or even injury.
Set 30 minutes in total for reference per day and keep appropriate intervals between each massage
session.
* For children aged 14 years or over, use only the Youth Program and only one session per day.
❶Press the POWER button.
If no selection is made within 2 minutes, the power will
automatically shut off.
❷Press the desired button.
● Press and hold the program button for 2 seconds
selects the Deep Relaxation version of the massage
course.
● If you desire you can combine a sequence of 2
programmed massage courses by following these
steps: after selecting your first programmed Massage
Course, immediately select your second massage
course choice while all the buttons on the remote
are flashing. You have about 5 seconds to select
your second programmed course. When 2 massage
programs have been strung together, the button of
the first selected course is glow continuously while
the second selected course flashes intermittently.
Note: the youth course cannot be part of a combined
massage.
● Once a programmed course is selected the chair will
automatically reclined to a massage starting position.
❸The ROLLER positions can be
adjusted.
With the ROLLER buttons, the vertical position of the
rollers can be adjusted. If no adjustment is required, do
not use these buttons.
❹The program starts.
The progress of the program is indicated on the display
of the remote control with the program name.
* The progress of the program may not be indicated if the
operation is combined with other operations.
❺Program completed.
When the massage program finishes, the rollers return
to their storage positions (upper part of the seat back).
Then the power to the remote control is shut off.
However, reclining of the seat back, angle adjustment
of the leg rest, and ON/OFF of the heater are still
enabled.
When 2 courses have been combined, at the conclusion
of the first selected course, the second selected course
commences and the button for the second course
changes from flashing intermittenly to a steady glow.
The second course then commences.
