inbody BAND 2 User manual

User's Manual

User's Manual Contents
About Your InBody BAND 2
Precautions
Parts and Functions

Product Components
InBody BAND 2
How to Use Your InBody BAND 2

Charging
Powering On
Turning Screen On
Navigating the Display
Using the App
InBody Test
Measuring Steps
Heart Rate Monitoring
EZTrainingTM
Sleep Analysis
 Notications
Replacing the Strap
Specications
Warranty

3 4
About Your InBody BAND 2
The InBody BAND 2 is a wearable body composition analyzer that measures muscle mass, body fat mass,
and body fat percentage. The InBody BAND 2 also counts steps, measures heart rate, calculates calories
burned, and tracks sleep.
•Disclaimer: The InBody BAND 2 is not a medical device. It cannot determine the presence of an illness or
disease. The examination of a medical professional is required for diagnosis.

3 4
Precautions
•Testresultsmayvarydependingontheenvironmentandmeasurementconditions.
•Ifpossible,avoidtakingmeasurementsincoldweather.
•Thisproducthasbeentestedinacontrolledenvironmentandiswater/dust-proofinspecificconditions(meets
therequirementsofIP68ratingspecifiedinInternationalStandardIEC60529-DegreesofProtectionprovidedby
Enclosures [IP Code]). However, under certain conditions, the product may be damaged when submerged in water.
•Donotdisassembleproductorapplyelectricitytotheproduct.Thismayresultinelectricshock,injury,product
malfunction or inaccurate results; and will void the manufacturer’s warranty.
•Donotopenbyforce,disassemble,crush,bend,deform,punctureorsmashtheproduct.
•Donotusetheproductifdamaged.Itmaycausefire,burns,injuryorelectricshock.
•Donotimmersetheproductinseawaterorchemicalsolutions(suchassoapwater).
•Donotleavetheproductinthebathorhotwater.
•Donotleaveorusetheproductunderwater;orexposetohigh-pressurewater(waterfromthefaucet,waterfalls,
waves, etc.).
•Donotbendtheproductexcessively.Thismaydamagetheproduct.
•Iftheproductdropsorshockisapplied,thebatteryunitmaybedamagedordeformed,resultinginleakage.
•Pleasekeeptheproductawayoutofreachofchildrenandpets.Placingtheproductinyourmouthisdangerous
and may result in choking or battery explosion.
•Donotleavetheproductinahot,humidenvironment,liketheinsideanautomobileorsteamroom.Theexterior
may become deformed, may cause a malfunction or explosion.
•Donotexposetheproducttodirectsunlightforextendedperiodsoftimeoruseinhighlyhumidlocation,suchas
the bathroom.
•Donotalterormodifybatteries,insertforeignobjects,immerseorexposebatteriestowaterand/orotherliquids.
•Chargethebatterybeforeitcompletelydischarges,asbatterylifewilldecreaseifleftunchargedforalongperiod
of time.
•Batterylifemayvaryslightlydependingonproductusage.
•Donotcoverorwraptheproductwhileitisinuseorcharging.Theremaybethecauseofafire.
•Donotusetheproductifyouareallergictometal,rubberorsiliconematerials.
•Periodicallycleananddrytheproduct,especiallyinareasthatcomeintodirectcontactwiththeskin.
•Youmayexperienceanallergicreactionifyouweartheproducttootightlyorhavesensitiveskin.
•Youmayexperienceanallergicreactioniftheproductisexposedtoirritantssuchassoaporsweatoveralong
period of time.
•Keepthestrapinacleananddry.
•Keeptheelectrodecomponentsoftheproductawayfromelectricallyconductivematerials.Electrostaticcharges,
such as static electricity, may damage product or cause it to malfunction.
•Donotusedevicewhiledriving.
•Thestrapmaybediscoloredordeformedbydirectsunlight,water,oilorcosmetics.
•Donotusedevicewhileitischarging.
•IftheUSBcableisdamaged,discontinueuse.
•Thisdevicehasbeenapprovedforelectromagneticcompatibility,homeuse(ClassB)andmaybeusedinall
regions.
•Thereisapossibilityofinterferenceduringoperationofradioequipment.Incaseofmedicalemergenciesuseyour
mobile phone to get help.
Please observe the following precautions and use the product in a safe manner in order to prevent an
accident from occurring.
CAUTION

5 6
WARNING
NOTES
•BecauseBluetoothusesthesamefrequencyastheBAND,indirectinterferencemayoccurbetweendevices.
•UsersareliableforanyproblemsoccurringfromdatatransmissionorillegaluseofBluetooth.
•Individualswithmedicalimplantdevicessuchaspacemakersoressentialsupportdevicessuchaspatient
monitoring systems should not take the InBody Test.
•Theelectricalcurrentusedformeasurementsarenotharmfultothehumanbody,however,womenwhoare
pregnant should consult with a specialist.
•Useasoftclothtocleantheproductonceaweek
•Productspecificationsandusermanualsaresubjecttochangewithoutnotice.

5 6
InBody BAND 2
Hand Electrodes
Wrist Electrodes
Clip
Display
Strap
Charging Cable
Quick User Guide
Safety Information and Warranty
Parts and Functions
Product Components
InBody BAND 2

7 8
InBody BAND 2 Screen Layout
The InBody BAND 2 has different displays for each function.
Date and Time:
Displays date, day of week, and time
InBody Test:
MeasuresPercentBodyFat(PBF)
and SkeletalMuscleMass(SMM)
Heart Rate:
Measures heart rate
Activity Minutes :
Duration of
walking/running
Distance :
Daily walking and running
distance
Calories Burned :
Calories burned from
activities
Battery Display :
Current remaining
battery life
EZTraining™ :
Counts exercise sets
Step Count :
Measures the number of
steps taken today
min
km
kcal

7 8
1. Charge the InBody BAND 2 by connecting the
device to the included charging cable and plugging
the USB connector into a USB port.
2. Once the InBody BAND 2 is securely connected
to the charging cable, it will automatically turn on
while charging.
* It takes approximately one hour to fully charge the
battery.
* Bluetooth function is not available while charging.
-Ifthepowerisoff,puttheInBodyBAND2onyour
wrist, then press and hold the upper and lower
electrodes on the InBody BAND 2 for about three
seconds.
How to Use
Charging
Powering On
Turning Screen On
-Towakethescreen,pressthebothelectrodeson
the InBody BAND 2.
-Alternatively,youcanraiseyourwristtowakethe
screen by enabling “Auto View”
-Howtoenable“AutoView”
InBody Wear app > Menu > Device Settings >
Enable Auto View
* Auto View : To wake screen, raise arm wearing the
InBody BAND 2.

9 10
Using the InBody Wear App
 Downloading the App
  Search for "InBody Wear " in the Apple App Store or the Google Play Store and download .
Sign Up and Sync
 1. Open the InBody Wear app and press Sign Up.
Navigating the Display
 Youcanipthroughthedisplaybysimplytappingthedisplayortouchingbothelectrodesatthesametime.
2. Press InBody BAND 2 to pair your device with the app. Once it is successfully paired with the app, press
Next.

9 10
 5.Inputgender,height(cmorft/in),age,weight,andnickname.Oncenished,pressDone.
 4.EnteryourEmailaddressandcreateandconrmapassword.Selectthecheckboxtoacceptthetermsand
conditions & privacy policy and press Done.
3. Select Country for your country calling code. Enter your mobile phone number and press Conrm.

11 12
 Transferring Data
 At the InBody Wear App main screen, swipe the entire screen down to automatically update the InBody Test
 results as well as heart rate monitoring data, walking step count data and sleep analysis data stored on your
 InBody BAND 2.
Press Skip or Let’s get started! to continue. Once you have completed registration, you may take the
InBody Test.

11 12
 Measuring using only the InBody BAND 2
 1.Pressandholdbothelectrodesuntilthetesticon()startsblinkingonthedevice.
 2.Placeyourfingersonbothelectrodes,whenthetesticon()startsblinkingonthedevice.
 3.Afterthetestiscompleted,theresultwillcomeuponthedevice.
 *TochangetheresulttoSkeletalMuscleMass(SMM)
 InBodyWearapp>Menu>DeviceSettings>EnableMuscleMass.
 *WhenmeasuringusingonlytheInBodyBAND2,theInBodyTes t measurementswillbebasedonthe
 weightsaved.
InBody Test
 Measuring with the InBody Wear App
 1.Pressonthebottomrightofthemainscreen.
 2.InputyourcurrentweightandpressInBody Testtostartthemeasurement.
 3.Placeyourfingersonbothelectrodes,whenthetesticon()startsblinkingonthedevice.
 *Itisrecommendedthatyoumaintainthesamepostureandmeasurementtimeforthemostaccurate
 measurements.
 4.Aftermeasurementsarecompleted,theresultsareautomaticallysavedintheapp.
 *Makesureyourhandsdonotcomeincontactwitheachotherwhentesting.


13 14
EZTrainingTM
1. Open the InBody Wear App.
2. Select the EZTraining™ menu on the main screen.
3. Choose from 12 different exercises displayed.
(You can select exercise set count and duration by tapping the ◀ ▶ arrows after selecting an exercise.)
4. Press Start Activity button.
5. The exercise is counted if the correct form is used while wearing the InBody BAND 2.
Measuring Steps
1. Wear your InBody BAND 2 on your wrist while carrying out your activities.
2. Your InBody BAND 2 automatically measures your steps.
3. When your InBody BAND 2 is synced with the InBody Wear app, the step data will be automatically
transferred to the app.

13 14
Sleep Analysis
1. If you wear your InBody BAND 2 while sleeping, it will analyze your sleep pattern.
2. To view your sleep analysis results, select the Sleep menu on the main screen.
3. Sleep analysis results are divided into the following categories: deep sleep, light sleep and awake.
Heart Rate Monitoring
   
1. Enter Heart Rate mode on your InBody BAND 2.
2. Place two fingers on the electrodes.
3. The heart rate measurement takes about 10 seconds.
4. When your InBody BAND 2 is synced with the InBody Wear app, the result will be automatically transferred
to the app on the app.
Notifications
 Step Alarm
1. Select Step Alarm in the Profile menu at the bottom of the main screen.
2. Select start time, end time or and repeat interval.
3. If walking is not detected during the set time, your InBody BAND 2 will vibrate.

15 16
 Goal Alarm
1. Enable Goal Alarm in the Profile menu at the bottom of the main screen.
2. You can set your goal (number of walking steps, calories) by selecting the flag icon in the Activity screen.
 Time Alarm
1. Select Time Alarm in the Profile menu at the bottom of the main screen.
2. Tap the Add button on the top right to set alarm time, day of the week, repeat cycle, repeat count, vibration
strength, and name of alarm.

15 16
 WearMe Alarm
By enabling WearMe Alarm, you can get your InBody BAND 2 to alert you when you have not worn it for a set
time.
1. Select WearMe Alarm in the Profile menu at the bottom of the main screen.
2. Set start time, end time and time interval.
 Call/SMS Alarm
1. Select Call/SMS Alarm in the Profile menu at the bottom of the main screen.
2. Select items you’d like to receive notification for.
Replacing the Strap
1. Support the back of the InBody BAND 2 electrodes with your index finger.
2. Remove the strap by pushing the LCD screen downward with your thumb and pushing the strap upward with the
other hand.
3. Remove the other strap in the same way.
4. Mount the strap by pushing it downward.

17 18
InformationDisplayed

MeasurementCurrent

DataStorage
Dimensions

ChargingTime

Wristcircumference

Color

InputPower

Operatingenvironment

Transportationand
StorageEnvironment
FrequencyUsed
No.ofChannels
ModulationMethod
Wattage
WaterproofRating
Currenttime,PercentBodyFatorSkeletalMuscleMass(selectablefromtheapp),heartrate,
walkingsteps,activetime,caloriesburned,distancewalked/ran,notifications,EZTrainingTM,
andbatterylevel.
Below90μA
2weeks(dependingonusage)
0.7(W)x1.7(L)x0.4(H)inches
Approx.1hour
5.3-7.7inches
MidnightBlack,StoneGray,RedWine,ModernNavy
Operatingvoltage:3.7VDC,Chargingvoltage:5.0VDC
50-104° F,30-75%RH,70-106kPa
14-158° F,10-80%RH,50-106kPa(nocondensation)
2402MHzto2480MHz
40
GFSK
1mWandbelow
IP68
Specifications

17 18
Warranty

Product Service Standards
 • Complementary service is only available when a manufacturer defect or natural defect occurs within the
 warranty period.
 • Matters not specified here are subject to "Fair Trade Commission Notice of Consumer Dispute Resolution
 Standards".

Types of Compensation for Consumer Damages

Warranty Period
Types of Compensation for Consumer Damages
Types of Compensation for Consumer Damages
Repair Service
Available
If the same defect occurs up to 3 times Complementary
Repair
Exchange or refund
Repairs Avail-
able for a Fee
Refund after
deduction 10%
of the deprecia-
tion amount
Exchange or refund
Exchange or refund
If the same defect occurs up to 4 times
Undelivered products within 1 month of
service request
Repair is unavailable without repair compo-
nents
Repair Service
Not Available
Within Warranty
Period
After Warranty
Period
Within 10 days of product purchase, performance or func-
tional defects that occur during normal use that require
repairs.
Within 1 month of product purchase, performance or
functional defects that occur during normal use that require
repairs.
Within Warranty
Period
Exchange or refund
Exchange or comple-
mentary repair
After Warranty
Period
Repairs Avail-
able for a Fee
Note
If the product is changed or damaged due to disassembly or repair by unlicensed
personnel, warranty service will be voided.
Product Name Model Name
Date of
Purchase DayMonthYear
1YearFromDateofPurchase
Product Serial
Number
Vendor Warranty
Period
[Component Retention Period Within 3 YEAR] [Component Warranty Period:
1YearfromDateofPurchase(ExcludesStrap)]
Ifthedateofpurchasecannotbeconrmed,thewarrantyperiodwillbeginthree
months from the date manufactured.
This warranty is only available in USA, and cannot be reissued. Please keep in a safe
place.

19 PB
ForanyproblemswithyourInBodyBAND2,pleasecontactusatthefollowing:
InBodyUSA
13850CerritosCorporateDrive,UnitC,Cerritos,CA90703
Website:http://www.inbody.comEmail:[e-mail]
Reproduction,adaptation,ortranslationofthismanualisprohibitedwithoutpriorwrittenconsentfromInBody
Co.,Ltdunderthecopyrightlaws.Thismanualmighthavetypographicalerrors,anditscontentcanbechanged
withoutapriornotice.InBodyCo.,Ltd.shallnotbeliableforanyerrors,incidental,orconsequentialdamages
thatoccurredbynotcomplyingwiththecontentoftheUser'sManual.
InBodyCo.,Ltdreservestherighttomodifytheappearance,specifications,andetc.oftheInBodyBAND2to
improvethequalityoftheproduct,withoutpriornoticeforreasonsofperformanceimprovement.

Services Available for a Fee
Instances of Product Damage from Consumer Misconduct
  • damage caused by carelessness (falling, flooding, shock, breakage, unreasonable operation, etc.)
  • damage from consumer’s failure to observe the instructions and precautions as described in the
  user's manual.
Other Instances
  • Defects from natural disasters (fire, flood, abnormal power surge, etc.)
  • Consumable parts have reached the end of their lifespan (battery, strap already worn)
Product Disposal
  Customer Guide for Environmentally Friendly Projects (Waste Products): This product
  must be discarded with e-waste. For more information on disposal and
  recycling electronic products, please reference local government policies.  
