Indexator LINK Series User manual

User User
Usermanual
LINK
Swingdamper-184M523T
–184
–184HD
S-184HD
Swingdamper-184HD
SwingdamperS-184HD
5002822en
1102029|3777|2017-08-21

Content
Introduction.............................................................................................3
Storageanddistriutionofthemanual......................................................3
Guaranteeandclaims...........................................................................3
Otherinformation...............................................................................3
Safetyinstructions....................................................................................4
General............................................................................................4
Descriptionofwarningtexts...................................................................4
Product-specificwarnings......................................................................5
Safety.............................................................................................6
Description..............................................................................................8
General............................................................................................8
Link................................................................................................10
Swingdamper....................................................................................11
SwingdamperM52..............................................................................12
Description..............................................................................................13
Brakekit(swingdamperonly).................................................................13
Installation..............................................................................................15
Maintenance............................................................................................17
Maintenanceoverview..........................................................................17
Repairinstructions..............................................................................19
Removingproductfromcranetipandrotator...............................................20
Technicaldata..........................................................................................21
Link–184..........................................................................................21
2©IndexatorAB11020292017-08-2113:36

Introduction
Introduction
Thismanualisintendedforinstallationengineers,maintenancepersonnelorusersofthe
product.
Asinstallationandmaintenancepersonnelortheenduser,itispresumedthatyouhave
asicknowledgeofmechanicsandhydraulics.
Readthroughthemanualcarefullyandensurethatyouunderstanditscontentpriorto
installing,repairingorusingtheproduct.
Installationandmaintenancemayonlyeperformedyauthorisedpersonnel.
Storageanddistributionofthemanual
Themanualispartoftheproductandshouldalwaysekeptinaneasily-accessileplace,
forexample,inthedriver'sca.Replaceanylostmanualsimmediately.
Guaranteeandclaims
Contactyourdealer.
IndexatorABcannoteheldresponsileforunauthorisedrepairsand/ormodifications
madetotheproduct.
Otherinformation
Theinformationinthismanualwascorrectatthetimeofgoingtoprint.Noliailityis
acceptedforanyerrorsoromissionsinthismanual.Everyefforthaseenmadetoensure
thatthecontentisaccurateandcomplete.
IndexatorABreservestherighttomaketechnicalimprovementsandmodificationstothe
productaspartoffurtherdevelopment,andwithoutchangingtheproduct'sasicfunctions.
Theseimprovementsandmodificationsdonotnecessarilymeanthatthemanualwillneed
updating.Contactyourlocaldealerforinformationaoutanychanges.
Copyingthismanualinwholeorinpartisnotallowedwithoutwrittenauthorisationfrom
IndexatorAB.Therestrictionappliestoallformsofcopying,includingprinting,digitising,etc.
11020292017-08-2113:36©IndexatorAB3

Safetyinstructions
Safetyinstructions
General
Anypossileriskshaveeenminimisedforthisproduct.Noprotectiveorsafetydevices,
howeverwelldesignedtheyare,canreplacethecareandalertnessofthemachineoperator.
Readthroughthemanualcarefullyandensurethatyouunderstanditscontentefore
usingtheproduct.Carelessnessduringinstallation,repairorusecanresultinserious,even
life-threateninginjury.
Descriptionofwarningtexts
Termsregardingpersonalsafetyareclassedinthreelevelsaselow,dependingonthe
severityoftheconsequencesofanaccident.
DANGER
ADangermeansthatanaccidentwilloccuriftheregulationsarenotfollowed.The
accidentwillcauseseriouspersonalinjuryorevendeath.
Warning
AWarningmeansthatanaccidentmayoccuriftheregulationsarenotfollowed.
Theaccidentmaycauseseriouspersonalinjuryorevendeath.
Caution
ACautionmeansthatanaccidentmayoccuriftheregulationsarenotfollowed.An
accidentmayleadtopersonalinjury.
Termsregardingothersafety(property,processesorenvironment)andmanagementare
classedaselow.
Important
Importantmeansthatanaccidentmayoccuriftheregulationsarenotfollowed.The
accidentmayleadtodamagetoproperty,processesortheenvironment.
Additionalinformationismarkedaselow.
Attention
N.B.isimportantadditionalinformationthathelpsyouunderstandorcarryoutaparticular
action.
4©IndexatorAB11020292017-08-2113:36

Safetyinstructions
Product-specificwarnings
Transportationandtransfer
Caution
ARiskofpersonalinjury.Alwaysusealiftingaidwhenliftingtheuninstalled
product.
Important
Riskofproductdamage.Whenmoving,theproductmusterelievedfromthecrane
arm/tool'sownweighttoavoidreakage.
Beforeuse
Warning
ARiskofcrushing.Beforeusecheckthatnopersoniswithinthemachineworking
area.
Duringwork
Warning
ARiskofcrushing.Theareaunderhangingloads/toolsisastrictlyprohiitedarea.
Caution
ARiskofpersonalinjury.Watchoutforfallingojects.
Attention
Riskofcollisionetweentoolandasemachine.Fittedtoolswillchangetheasicmachine's
geometry.Exercisecautionduringworking.
Attention
Riskofproductdamage.Ensurethattheworkingareaissufficientforhandlinghanging
loads.Avoidlettingtheproductcomeintocontactwiththeendpositioninthecranetip.
Duringmaintenance
Warning
ARiskofpersonalinjury.Thetorquefromtheadjustmentdevicecausespotential
energytouildup,whichcanhaveanexplosiveeffectifascrewisdamaged.
Standtothesideoftheadjustmentdevicewhentightening.
11020292017-08-2113:36©IndexatorAB5

Safetyinstructions
Safety
Riskarea
Thesizeoftheriskareadependsontheapplicationandisdeterminedytheapplication
manufacturer.Theriskareamusteatleastasigasthelargestload,orasthewidthof
thetoolonahorizontalplane.Themanufacturermustprovideclearwarningsaoutthis.
DANGER
ANopersonnelarepermittedintheareaunderhangingloads/tools.Itisastrictly
prohiitedarea.
STOP
STOP
STOP
STOP
STOP
STOP
6©IndexatorAB11020292017-08-2113:36

Safetyinstructions
Caution
ARiskofskinirritation/allergicreactions.Therecaneanumerofchemical
preparationsontheproduct.Useprotectivegloveswhenhandling.
11020292017-08-2113:36©IndexatorAB7

Description
Description
General
Theproductisalinkoraswingdamper.
Theproductisdesignedtoefittedetween
therotatorandthecranetip.
Theproductisdesignedtoeusedfor
positioningfreely-hangingverticalloads.
Image1Link
1.Link
2.Hosecontrol
8©IndexatorAB11020292017-08-2113:36

Description
Image2Swingdamper
1.Link
2.Hosecontrol
3.Brakes
11020292017-08-2113:36©IndexatorAB9

Description
Link
Image3Link
1.Link
2.Hosecontrol
3.Hosereel
4.Tube
5.Pin
6.Spacer
7.Nut
10©IndexatorAB11020292017-08-2113:36

Description
Swingdamper
Image4Swingdamper
1.Link
2.Hosecontrol
3.Hosereel
4.Tube
5.Pin
6.Spacer
7.Nut
8.Brakedisc
.Brakeblock
11020292017-08-2113:36©IndexatorAB11

Description
SwingdamperM52
1.Link
2.Hosecontrol
3.Hosereel
4.Tube
5.Pin
6.Spacer
7.Nut
8.Brakedisc
.Brakeblock
12©IndexatorAB11020292017-08-2113:36

Description
Description
Brakekit(swingdamperonly)
Brakefunction
Therakekitisdesignedtoraketheswingingmovementintheactualdirection.Toensure
correctfunctioning,cleangreaseandoilfromtherakedisc.
Warning
1.Lockingring
Lockingringsareasafetydetailwhichstoppartseingthrownoutfromthesprungrake
unitifascrewisdamaged.Itisimportantthatthelockingringiscorrectlyinplaceduring
adjustment/tightening.Onlywhentherakeunitspringsarenotpressurised(loosely
adjusted)maythelockingringseremoved,forexamplewhenchangingtherakelocks.
Adjustment
1.Lockingnut
2.Screwjoint
3.Flangenut
4.Screw
Forsafetyreasons,keepthelockingringsinposition.Loosenthelockingnutefore
tightening.Holdtheflangenutandtightenthescrew.Themaximumtighteningtorque
forthescrewjointis30Nm.Wearincreasesiftighteningtorquetoohigh.Afteradjusting,
thescrewjointislockedythelockingnut.
11020292017-08-2113:36©IndexatorAB13

Description
AdjustingM52
Maximumtighteningtorque75Nm.
Changingtherakelock
Image8S-184
1.Lockingring
2.Lockingnut
Image9-184
1.Lockingring
2.Lockingnut
Loosenthelockingnut.Loosenthescrewjoint.Removethelockingringsandchange
therakelocks.
Cupspringsassemledasperfigure1.Ifreassemlyiscarriedoutinanyotherway,partsof
therakekitcanprotrude,andcanedamagedduringswingingytherotator/cranetip.
Rememertoassemlethelockingringseforetightening.Positionthelockingringsso
thattheycaneasilyeaccessedwiththetool/pliers.Itisimportantthatthelockischanged
ingoodtimesothatthesteelplategluedtothelockdoesnotru/damagetherakedisc.
ReplacingrakelockM52
Loosenthescrewjoint.
Removethecupspringsandreplacelocks.
Reinstallinreverseorder.
14©IndexatorAB11020292017-08-2113:36

Installation
Installation
11020292017-08-2113:36©IndexatorAB15

Installation
16©IndexatorAB11020292017-08-2113:36

Maintenance
Maintenance
Maintenanceoverview
Important
Irregularmaintenancecanleadtoproductdamage.
Preventativemaintenance,asrequired
BrakingpowerCheck,adjustment
Every50hours
BushingsLurication
Every250hours
AttachmentCheckforcracks,changeif
necessary
BushingsCheckthesizeofplay,
possilechange
PinTightenthenut
Every600hours
BrakekitCheckforwear,clean
components,andmake
replacementswhere
necessary
BrakediscsCheckforwear,clean
components,andmake
replacementswhere
necessary
11020292017-08-2113:36©IndexatorAB17

Maintenance
Connectagreasegunwithsufficient
luricationtothegreasenipples.Keepon
pumpinguntilyouseegreaseetweenthe
pinandthelink.
Image13Bushings
18©IndexatorAB11020292017-08-2113:36

Maintenance
Repairinstructions
Attachment
Ifthereisafractureintheattachment,thelinkmustereplaced.Contactyourdealerfor
moreinformation.
Bushings
1.Disassemletheproduct.
2.Pressouttheushingsusingahydraulicpress.
3.Pressinthenewushings.
11020292017-08-2113:36©IndexatorAB19

Maintenance
Removingproductfromcranetipandrotator
1.Placetherotatoronaflatsurface.
2.Tiearopeorsimilararoundtheproductandfixituponthemachine'spoint,orotherhigh
location,sothattheproductcannotfallwhenthecranetipisloosened.
Caution
ARiskofcrushinginjuries.Checkthattheproductcannotfalleforeitis
loosenedfromthecranetip.
3.Removetheupperpinsothattheproductisloosenedfromthecranetip.
4.Removetheupperpinsothattheproductisloosenedfromtherotator.
5.Removetheproduct.
