Infineon KIT-FPG1-T2G-B-E-2M User manual

User Guide Please read the Important Notice and Warnings at the end of this document 002-36609 Rev. **
www.infineon.com page 1 of 37 2022-11-07
restricted
KIT-FPG1-T2G-B-E-2M automotive
fingerprint evaluation kit guide
About this document
Scope and purpose
This document provides information on how to use the Infineon fingerprint evaluation kit
(KIT-FPG1-T2G-B-E-2M). The kit consists of an Infineon fingerprint evaluation board designed to work with the
Infineon fingerprint match module, the Infineon fingerprint sensor module, and the software used to evaluate
the hardware.
Intended audience
This document is intended for anyone who uses it to evaluate the Infineon fingerprint sensor.
Document conventions
Abbreviations and definitions
Convention Explanation
Bold Emphasizes heading levels, column headings, table and figure captions, screen names,
windows, dialog boxes, menus and sub-menus
Abbreviation Definition
CAN Controller Area Network
CMSIS Common Microcontroller Software Interface Standard
DAP Debug Access Point
EVB Evaluation Board
FPG Fingerprint
FPMM Fingerprint Matcher Module
FPSM Fingerprint Sensor Module
GPIO General Purpose Input Output
GUI Graphical User Interface
LIN Local Interconnect Network
SPI Serial Peripheral Interface
UART Universal Asynchronous Receiver Transmitter
USB Universal Serial Bus

User Guide 2 of 37 002-36609 Rev. **
2022-11-07
KIT-FPG1-T2G-B-E-2M automotive fingerprint evaluation kit guide
restricted
Table of contents
Table of contents
About this document . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Table of contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
1 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
2 Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
2.1 Functional overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
2.2 Block diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
3 Connection and settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
3.1 Power supply settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
3.2 RESET switch and RESET select header . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
3.3 USB-to-UART Bridge (CMSIS-DAP -FM3) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
3.4 FPMM and FPSM connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
3.5 BOOT switches . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
3.6 WAKEUP switches and WAKEUP select header . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
3.7 GPIO switches and GPIO select headers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
3.8 SPI select headers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
3.9 UART select headers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
3.10 Expansion connector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
3.11 Current measurement header . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
3.12 Three-color LED . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
4 Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
5 Direct FPSM connection to host . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
6 Appendix A: Schematics for CYFPEVB-1100-0 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
7 Appendix B: Layout for CYFPEVB-1100-0 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
8 Appendix C: Schematics for KIT-FPG1-T2G-B-E-2M . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
9 Appendix B: Layout for KIT-FPG1-T2G-B-E-2M . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Revision history . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

User Guide 3 of 37 002-36609 Rev. **
2022-11-07
KIT-FPG1-T2G-B-E-2M automotive fingerprint evaluation kit guide
restricted
Introduction
1 Introduction
This user guide describes the evaluation board (KIT-FPG1-T2G-B-E-2M) details and other components of the kit
can be found in their respective user guides or datasheets.
Figure 1-1 shows the complete Infineon embedded fingerprint solution kit and all the hardware boards required
in the system for evaluating the Infineon embedded fingerprint solution.
Figure 1-1. Infineon fingerprint evaluation kit
Figure 1-2 shows only the evaluation board.
Table 1-1. Contents – Infineon fingerprint kit
Quantity Description Part number
1 Evaluation board (EVB) CYFPEVB-1100-0-Rev-3
1 Fingerprint match module (FPMM) KIT-FPG1_T2G-B-E-2M Rev01
1 Fingerprint sensor module (FPSM) CYFPSM-10000AAI-01
1MicroUSBcable –
1Quickstartguide –

User Guide 4 of 37 002-36609 Rev. **
2022-11-07
KIT-FPG1-T2G-B-E-2M automotive fingerprint evaluation kit guide
restricted
Introduction
Figure 1-2. EVB - Top view

User Guide 5 of 37 002-36609 Rev. **
2022-11-07
KIT-FPG1-T2G-B-E-2M automotive fingerprint evaluation kit guide
restricted
Overview
2 Overview
2.1 Functional overview
This EVB is designed for use with the FPMM and FPSM. All the modules supplied in the kit are connected to form
a complete system. The evaluation board can interface with a PC through the USB port using the built-in USB-to-
UART Bridge chip. The embedded framework FW and host interface command protocol are built into the FPMM
module. A software GUI (FPMM SW) to interact with the FPMM module is also provided. With these components,
the user can develop embedded fingerprint reader-based solutions and evaluate the Infineon embedded
fingerprint solution.
The EVB is designed to allow a host processor that is using the host communication protocol to access the FPMM
board through the following physical interfaces:
1. USB-to-UART Bridge: UART-to-USB Bridge is built into the evaluation board
2. UART: Direct UART connection is available on the expansion connector of the evaluation board
3. SPI: Direct SPI connection is available on the expansion connector of the evaluation board. Not supported in
this revision.
4. I2C: Direct I2C connection is available on the expansion connector of the evaluation board. Not supported in
this revision.
5. CAN: Direct Can connection is available on the expansion connector of the evaluation board. Not supported
in this revision.
6. Standalone GPIO mode: FPMM can be controlled using only GPIOs. The status of various phases of FPMM
operation returns through GPIOs. These GPIOs can either be connected to the push button switches on EVB
and status returned through the three-color LED on the EVB or connected to the expansion connector for any
host to use a simple GPIO-based interface to control the FPMM. Not supported in this revision.
The EVB can also be used to provide a direct connection between a host processor and the FPSM when the FPMM
is not plugged in. The EVB can be used to allow any host to directly connect to the SPI interface of the FPSM by
connecting jumper wires to the FPMM connector pins that run to the FPSM. In this mode, the host processor of
choice is running the Infineon embedded framework software to be able to communicate with the FPSM. Details
of this mode are provided in “Direct FPSM connection to host” on page 23.
Table 2-1. EVB functions
Function Specification Notes Typical UART-
USB bridge
settings
(DEFAULT)
Direct UART to
HOST
USB
CONNECTOR
Primary USB connector provides
power to the system and USB
connectivity to the USB-UART
bridge chip (FM3)
+5V0 from USB
VBUS, J13. See
“Power supply
settings” on
page 9.
––
POWER SELECT
HEADER
Select whether USB or external
connector powers the system
J5. See “Power
supply
settings” on
page 9.
Connect 2-3 Connect 1-2 for
Host powered
setup

User Guide 6 of 37 002-36609 Rev. **
2022-11-07
KIT-FPG1-T2G-B-E-2M automotive fingerprint evaluation kit guide
restricted
Overview
RESET SWITCH Reset switch SW1. See
“RESET switch
and RESET
select header”
on page 10.
––
RESET SELECT
HEADER
Selects where the system Reset is
driven from
J8. See “RESET
switch and
RESET select
header” on
page 10.
Connect 2-3 Connect 1-2
USB-UART
BRIDGE
Infineon FM3 (MB9AF312KPMC-G-
JNE2) based USB-to-UART Bridge
U1. See “USB-
to-UART Bridge
(CMSIS-DAP -
FM3)” on
page 11.
– –
MODE SWITCH Mode switch for FM3 SW3. See “USB-
to-UART Bridge
(CMSIS-DAP -
FM3)” on
page 11.
FM3_MD0 = 0 FM3_MD0 = 0
FPMM
CONNECTORS
Header for the FPMM-1100Rev2
board
J18, J14. See
“FPMM and
FPSM
connections”
on page 12.
– –
FPSM
CONNECTOR
10-pin ZIF connector for the FPSM J17. See “FPMM
and FPSM
connections”
on page 12.
– –
BOOT SWITCH FPMM configuration on boot up
refer to BOOT table
SW2. See
“BOOT
switches” on
page 14.
Not used Not used
WAKEUP
SWITCH
Wakeup FPMM from low power
mode
SW4. See
“WAKEUP
switches and
WAKEUP select
header” on
page 14.
– –
Table 2-1. EVB functions (continued)
Function Specification Notes Typical UART-
USB bridge
settings
(DEFAULT)
Direct UART to
HOST

User Guide 7 of 37 002-36609 Rev. **
2022-11-07
KIT-FPG1-T2G-B-E-2M automotive fingerprint evaluation kit guide
restricted
Overview
WAKEUP
SELECT HEADER
Select the source of the Wakeup
signal
J10. See
“WAKEUP
switches and
WAKEUP select
header” on
page 14.
Connect 2-3 Connect 1-2
GPIO SWITCH Switches for General purpose GPIO,
active high
SW5, SW6, SW7.
See “GPIO
switches and
GPIO select
headers” on
page 15.
– –
GPIO SELECT
HEADERS
Selects if the GPIO is connected to
the GPIO switch or to external
connectors
J9, J11, J12. See
“GPIOswitches
andGPIOselect
headers” on
page 15.
Do not connect Do not connect
SPI SELECT
HEADER
Selects where the SPI signals are
connected
J1, J2, J3, J4.
See “SPI select
headers” on
page 17.
Do not connect Do not connect
UART SELECT
HEADER
Selects where the UART signals are
connected
J6, J7. See
“UART select
headers” on
page 18.
J6: connect 1-2
J7: connect 1-2
J6: connect 2-3
J7: connect 2-3
EXPANSION
CONNECTOR
18-pin expansion connector J16. See
“Expansion
connector” on
page 19.
Not used UART_RX,
UART_TX,
WAKEUP,
EXT_RESET,
VCONN,GND must
be connected to a
host system
POWER
MEASUREMENT
HEADER
Current measurement circuit to
measure how much power is
consumed by the FPMM/FPSM
J19. See
“Current
measurement
header” on
page 20
––
FPMM LED Three- color LED indicates the
status of fingerprint enrollment and
matches operation
D6. See “Three-
color LED” on
page 21
Not used Not used
Table 2-1. EVB functions (continued)
Function Specification Notes Typical UART-
USB bridge
settings
(DEFAULT)
Direct UART to
HOST

User Guide 8 of 37 002-36609 Rev. **
2022-11-07
KIT-FPG1-T2G-B-E-2M automotive fingerprint evaluation kit guide
restricted
Overview
2.2 Block diagram
Figure 2-1. Block diagram

User Guide 9 of 37 002-36609 Rev. **
2022-11-07
KIT-FPG1-T2G-B-E-2M automotive fingerprint evaluation kit guide
restricted
Connection and settings
3 Connection and settings
This section describes the various switches and headers available on the EVB. Confirm the settings are according
to the intended use or if using the EVB without modifications confirm the header jumpers and switches are at
default state as indicated in the following sub-sections before turning on the power supply or connecting the USB
cable.
3.1 Power supply settings
The EVB can be powered using either a 5 V DC power supply connected to the expansion connector (J16) or
through USB bus power connected to J13. Power select header J1 is used to decide whether power is to be taken
from the external expansion connector pin for USB bus power. Table 3-1 shows how to configure J13. The input
power supply voltage range is 3.3 V to 5 V and the current requirement of 500 mA. Do not exceed or go less than
the maximum and minimum voltage requirements.
Figure 3-1. Power select header
Table 3-1. Power select header
Power select header connection (J5) Function
1-2 5 V power supplied from expansion connector J16
2-3 Power supply from USB bus power

User Guide 10 of 37 002-36609 Rev. **
2022-11-07
KIT-FPG1-T2G-B-E-2M automotive fingerprint evaluation kit guide
restricted
Connection and settings
3.2 RESET switch and RESET select header
The reset switch is a push button used to RESET the FM4 device on the FPMM. This reset signal is connected to the
XINIT signal of the FPMM. The reset is an active low reset. The XINIT pin of FPMM can be driven from either the
push button reset switch SW 1 or the expansion connector J16. These selections of where the reset is driven from
are selected on the RESET select header.
Figure 3-2. RESET switch (SW1)
Figure 3-3. RESET select header
Table 3-2. RESET select header configuration
RESET SELECT header connection (J8) Function
1-2 FPMM XINIT is controlled from the RESET pin of the expansion
connector
2-3 FPMM XINIT is controlled from the RESET push button switch (SW1)

User Guide 11 of 37 002-36609 Rev. **
2022-11-07
KIT-FPG1-T2G-B-E-2M automotive fingerprint evaluation kit guide
restricted
Connection and settings
3.3 USB-to-UART Bridge (CMSIS-DAP -FM3)
The FM3 processor (U1) on the EVB performs the function of a USB-to-UART Bridge chip. The FM3 processor
comes programmed with the correct firmware to perform the UART-to-USB bridging function. The MD0 pin of the
FM3 part requires to be in the normal mode of operation when not programming this controller. Table 3-3 shows
the switch settings for the MD0 pin. The USB_UART bridge chip programming is not a user mode available option.
Table 3-3 shows the position of the switches required for the normal operation of this bridge chip.
Figure 3-4. USB-to-UART Bridge and mode switch
Table 3-3. RESET select header configuration
Mode switch (SW3.1) Description
ON The FM3 is in normal operation mode (default). Do not change this setting.
OFF The FM3 is in programming mode

User Guide 12 of 37 002-36609 Rev. **
2022-11-07
KIT-FPG1-T2G-B-E-2M automotive fingerprint evaluation kit guide
restricted
Connection and settings
3.4 FPMM and FPSM connections
The FPMM and FPSM modules are plugged into the EVB to form the embedded fingerprint system solution. The
FPMM module is a PCB with a single in-line header on each side that plugs into the 17-pin headers (J14, J18) on
the EVB. Table 3-4 shows the signals on this header.
Table 3-4. RESET select header configuration
J18 pin# Signal name
1GND
2UART_RX
3 UART_TX
4BOOT1
5GPIO0
6GPIO1
7GPIO2
8BOOT2
9WAKEUP
10 BOOT0
11 RGB_LED_B
12 V3P3_EVB
13 ZIF_EGND_CONN
14 ZIF_VDDA_CONN
15 ZIF_DGND_CONN
16 ZIF_V3P3_CONN
17 ZIF_SPI_MOSI
18 GND
19 FM4_MD0
20 SPI_CLK
21 SPI_MOSI
22 SPI_MISO
23 SPI_CS
24 XINIT
25 I2C_SCK
26 I2C_SDA
27 RGB_LED_G
28 RGB_LED_R
29 V3P3_EVB
30 ZIF_XRES
31 ZIF_INT
32 ZIF_SPI_MISO

User Guide 13 of 37 002-36609 Rev. **
2022-11-07
KIT-FPG1-T2G-B-E-2M automotive fingerprint evaluation kit guide
restricted
Connection and settings
The FPMM programming mode switch is located on the EVB. Because this module is not user programmable,
switching to programming mode is not supported. Therefore, keep the switch position in normal operation
mode.
Figure 3-5. FPMM and FPSM connectors
33 ZIF_SPI_CS
34 ZIF_SPI_CLK
Table 3-5. RESET select header configuration
J17 pin# Signal name
1 ZIF_XRES
2ZIF_INT
3 ZIF_SPI_MISO
4 ZIF_SPI_CS
5 ZIF_SPI_CLK
6 ZIF_SPI_MOSI
7 ZIF_V3P3_CONN
8ZIF_DGND_CONN
9ZIF_VDDA_CONN
10 ZIF_EGND_CONN
Table 3-6. RESET select header configuration
Mode switch (SW3.2) Description
ON The FM4 is in normal operation mode (default). Do not change this setting.
OFF The FM4 is in programming mode (not supported)
Table 3-4. RESET select header configuration (continued)
J18 pin# Signal name

User Guide 14 of 37 002-36609 Rev. **
2022-11-07
KIT-FPG1-T2G-B-E-2M automotive fingerprint evaluation kit guide
restricted
Connection and settings
3.5 BOOT switches
Not supported in this kit.
3.6 WAKEUP switches and WAKEUP select header
The wakeup push button switch (SW4) is used to wake up the FPMM from a low-power mode. This push button is
used to provide a wakeup signal to the VBAT_wakeup pin of the FPMM. The location of this push button switch is
shown in Figure 3-6. The wakeup signal is an active high signal.
Figure 3-6. Wakeup switch
The wakeup signal to the FPMM can be driven from either push button SW4 or the external connector J10. Jumper
J8 is used to select which circuit will drive the wakeup signal. Table 3-7 shows the wakeup select jumper
configurations.
Figure 3-7. WAKEUP select header
Table 3-7. Wakeup select
Power select header connection (J10) Function
1-2 Wakeup driven from expansion connector J16
2-3 Wakeup driven form push button switch SW4 (default)

User Guide 15 of 37 002-36609 Rev. **
2022-11-07
KIT-FPG1-T2G-B-E-2M automotive fingerprint evaluation kit guide
restricted
Connection and settings
3.7 GPIO switches and GPIO select headers
Note: GPIO functionality is not available in this revision.
Configure the GPIO switches on the EVB to perform various input/output functions according to the firmware
configuration used. Primarily these switches are used in the standalone BOOT mode of operation of the FPMM
(BOOT [2:0] = 100).
In this mode, the FPMM firmware configures these GPIOs to be used as fixed function inputs, e.g., one switch to
enter ENROLL phase, one switch to enter VERIFY phase, and the third switch to delete the ENROLLED template.
See the FPMM user guide for the firmware functionality of these switches. Table 3-8 shows the mapping of these
GPIOs to the GPIO switches.
Figure 3-8. GPIO push button switches
GPIO select headers allow the FPMM GPIO signals to connect to either the push button on the EVB or the
expansion connector J16.
Note: Currently, none of the GPIO push button switches are used.
Table 3-8. FPMM GPIO to GPIO switches mapping
FPMM GPIO GPIO push button switch on EVB
GPIO0 SW5
GPIO1 SW6
GPIO2 SW7
Table 3-9. GPIO0 select header connection
GPIO0 select header connection (J9) Function
1-2 GPIO0 connected to expansion connector J16
2-3 GPIO0 connected to push button switch SW5

User Guide 16 of 37 002-36609 Rev. **
2022-11-07
KIT-FPG1-T2G-B-E-2M automotive fingerprint evaluation kit guide
restricted
Connection and settings
Figure 3-9. GPIO select headers
Table 3-10. GPIO1 select header connection
GPIO1 select header connection (J11) Function
1-2 GPIO1 connected to expansion connector J16
2-3 GPIO1 connected to push button switch SW6
Table 3-11. GPIO2 select header connection
GPIO2 select header connection (J12) Function
1-2 GPIO2 connected to expansion connector J16
2-3 GPIO2 connected to push button switch SW7

User Guide 17 of 37 002-36609 Rev. **
2022-11-07
KIT-FPG1-T2G-B-E-2M automotive fingerprint evaluation kit guide
restricted
Connection and settings
3.8 SPI select headers
Note: SPI functionality is not available in this revision.
The SPI interface from the FPMM connects to the expansion connector through this header. Figure 3-10 shows
the SPI headers. The signals CAN_TX and CAN_RX share with SPI signals. Depending on the BOOT mode settings,
the FPMM can use SPI_CLKI and SPI_MOSI for either the SPI interface or the CAN interface.
Note: Do not change the default connection of the SPI headers.
Figure 3-10. SPI select headers
The following tables show how to configure the SPI headers.
Table 3-12. SPI_MOSI select header connection
SPI_MOSI select header connection (J1) Function
1-2 Not used
2-3 SPI_MISO connected to expansion connector J16 (default)
Table 3-13. SPI_CS_L select header connection
SPI_CS_L select header connection (J2) Function
1-2 Not used
2-3 SPI_CS_L connected to expansion connector J16 (default)
Table 3-14. SPI_CLK select header connection
SPI_CLK select header connection (J3) Function
1-2 Not used
2-3 SPI_CLK/CAN_TX connected to expansion connector J16 (default)

User Guide 18 of 37 002-36609 Rev. **
2022-11-07
KIT-FPG1-T2G-B-E-2M automotive fingerprint evaluation kit guide
restricted
Connection and settings
3.9 UART select headers
The UART interface from the FPMM can be connected either to the expansion header (J16) or the USB-UART
Bridge chip. The Infineon embedded fingerprint solution uses the UART interface through the USB-to-UART
Bridge to demonstrate the functionality of this solution. A PC-based software demo has been developed for this
purpose. For implementations that require UART to be connected to a HOST directly, route the UART signals to
the expansion connector (J16).
Figure 3-11. UART select headers
The following tables show the configuration of the UART RX and TX headers.
Table 3-15. SPI_MOSI select header connection
SPI_MOSI select header connection (J4) Function
1-2 Not used
2-3 SPI_MOSI/CAN_RX connected to expansion connector J16 (default)
Table 3-16. UART_RX select header connection
SPI_MOSI select header connection (J7) Function
1-2 UART_RX from FPMM connected to the USB-to-UART Bridge
(default)
2-3 UART_RX from FPMM connected to the expansion connector (J16)
Table 3-17. UART_TX select header connection
SPI_MOSI select header connection (J8) Function
1-2 UART_TX from FPMM connected to the USB-to-UART Bridge
(default)
2-3 UART_TX from FPMM connected to the expansion connector (J16)

User Guide 19 of 37 002-36609 Rev. **
2022-11-07
KIT-FPG1-T2G-B-E-2M automotive fingerprint evaluation kit guide
restricted
Connection and settings
3.10 Expansion connector
The expansion connector on the EVB exposes the communication interfaces, reset, GPIOs, and wakeup signals of
the FPMM to external hosts. The later sections describe the configuration of the various select headers to route
signals from the FPMM to the expansion connector.
Figure 3-12. Expansion connector
Table 3-18. RESET select header configuration
J16 pin# Signal name
1Externalpower(5V)
2SPI_MISO
3SPI_CS_L
4 SPI_CLK/CAN_TX
5 SPI_MOSI/CAN_RX
6UART_TX
7UART_RX
8I2C_SCLK
9I2C_SDA
10 RESET
11 External power (5 V)
12 GND
13 WAKEUP
14 GPIO0
15 GPIO1
16 GPIO2
17 Not used
18 GND

User Guide 20 of 37 002-36609 Rev. **
2022-11-07
KIT-FPG1-T2G-B-E-2M automotive fingerprint evaluation kit guide
restricted
Connection and settings
3.11 Current measurement header
The current measurement header J19 provides a way to measure the current consumed by the FPMM and FPSM
modules. The host power plane in the EVB is separated from the rest of the 3.3 V power plane by a 0-ohm resistor.
Measures the current flowing through this resistor to determine the current consumption of the two boards. J19
header Pin 1 is placed on the EVB power plane side of the 3.3 V supply and J19 header Pin 2 on the HOST_POWER
(FPMM and FPSM) side of the 3.3 V power plane.
Figure 3-13. Current measurement header
