Meeting Room Projector
A Shared Vision
Remote
The credit card type remote is small,
functional and practical.
xS1
Attention to details
 ●LongLampLifeforalowercostofownership(4000hours)
 ●Security:Kensingtonlock,UserPIN,RemovableKeypad(byremovingthekeypadthe
projectorcannotbeoperated)
 ●Filter-FreeDesign&24/7compatible)
 ●DigitalZoom-enablesin-imagezoomtohighlightdetails during presentations
 ●CustomizableSplashscreen(todisplayyourcompanylogo,schoolmotto...)
 ●PresentationTimertoassistintrackingpresentationtime,meetingscheduleorlessontime
 ●QuickCoolingmodetopresentandgo
 ●LampAccessontop&SecondSerialNumberLabelonthebackforaneasyinstallation
 ●Solidwarrantiesforasolidproduct:2yearsProjector&6monthslampwarranty
 ●AdvancedOnScreenDisplayfunctions(Allstandardimageandpictureadjustmentsvia
onscreendisplay(OSD)/AutoSearchfunction,findingactivesourcesautomatically/18
languagesselectableforOSD)
Wireless
TheXS1is100%compatiblewiththe
InFocusLiteShowIIwirelesspresentation
adaptor,offeringfullfeaturedwireless
functionality of data, video and audio
transmission to this versatile new projector.
IntroducingtheInFocusX6andX7digitalmultimediaprojectors–designedfor
collaborativeenvironments,includingtheofce,classroomorforlarge-format
publicdisplay.Asanall-newtakeonaffordable,high-qualitydigitalprojection
theX6&X7featureadvancedDLP®chipsettechnologyinacompactsizewith
anintegratedaudiosystem,wirelessremotecontrolandsecureinstallation
options.
Beingclosehasitsadvantages.
•Theshortthrow(0.7:1ratio)reducesthedistanceofprojectortoscreento
aboutonethirdofregularprojectors.
•Inceilingmountmode,iteliminatestheshadowingofthepresenterwhen
comingclosertothescreen.
•Intabletopmode,itwillallowyoutomoveyourprojectorfromthecenterof
thetabletotheveryfront.Itwillthereforebelessobtrusivein a meeting.

Completeinteractivityandmultimedia
TheshortthrowfeatureenablestheeasyintegrationoftheXS1with
interactivewhiteboardsanditsbroadanaloganddigitalinputrangelets
youconnectanydataorvideosourcetotheprojector.Inadditiontheon-
boardserialRS232controlmakesiteasytointegratetheXS1intoasset
managementsystems.
XS1Overview
TheXS1hasXGAnativeresolution(1024x
768)whichisthemostcommonresolution
for laptop and desktop computers.The XS1
puts out 2400 Max ANSI Lumens and a 
1800:1 contrast Ratiowhich delivers bright
Theimages with lush colorsaturation and

deepblacklevels,eveninmeetingspaces
withambientlight.Itutilizesthelatest
BrilliantColor™technologytooutput
true-to-lifecolorsandshadesthroughashort
throwlens,providingbigimageexibilityto
smaller rooms.
Withthelatestinopticaltechnology,InFocusintroducestherstshort throw
projectortoitsawardwinningandindustryleadingportableproduct line.
l
TheXS1deliversbright&brilliantimages,withrichcolorsandhigh
contrastforbestinclasspicturequality.Thedigital&analogdata/
videoinputs pluseasyceiling-mountcapabilitiesmake the 
wireless-compatible XS1asimplechoiceforintegrationortabletop
use in business and educationenvironments.
Get close!

SHIPS STANDARD WITH:
•WirelessRemoteControl(includingbatteries)
•ComputerCable
•PowerCord
•UserGuide(MultiLanguageCD)
•QuickStart,Safety,Warranty&RegistrationCards(printed)
OPTIONAL ACCESSORIES
•CeilingMount,Wallarm
•ProjectionScreens
•PerformanceCables&Adaptors
•InFocusLiteShowIIWirelessAdaptor
•CarryingCases
LONG TERM CUSTOMER CARE
Ifyou’rehappy,InFocusishappy.That’swhyeveryInFocusXS1
projectorcomewithastandard2-yearlimitedfactorywarranty
(includingpartsandlabor)anda6monthlimitedlamp-replacement
warranty.Extendedproduct&lampwarrantyprogramsarealso
available.
Formoreinformationaboutwarrantyandserviceprogramsinyour
region,pleasevisit:
www.infocus.com/service
©2008InFocus Corporation.Allrightsreserved.Specicationsaresubjectto changewithoutfurthernotice.InFocus
andASKProximaareeithertrademarksorregisteredtrademarksofInFocusCorporationintheUnitedStatesandother
countries.DLP,theDLPlogo,andtheDLPmedallionaretrademarksofTexasInstruments.Alltrademarksareusedwith
permissionorareforidenticationpurposesonlyandarethepropertyoftheirrespectivecompanies.
www.InFocus.com
InFocus Corporate Headquarters:27500SWParkwayAvenue
Wilsonville,Oregon97070-9215,USA•Phone:(1)503-685-8888
(1)800-294-6400•Fax:(1)503-685-8887
In Europe:InFocusInternationalBV•LouisArmstrongweg110•1311RLAlmere
TheNetherlands•Phone:(31)205792000•Fax:(31)365392999
Freephone:0080004636287(008000INFOCUS)
In Asia:19TanglinRoad•7thFloor
Singapore247909•Telephone:(65)6334-9005•Fax:(65)6333-4525
XS1
TECHNICAL SPECIFICATIONS+
NativeResolution•1024x768(XGA) 
DisplayTechnology •0.55”LVDSDLP®DMDw/BrilliantColor™from
 TexasInstruments™ 
InputSources •VGA(HD15),DVI-I,S-video,CompositeVideo,
 PCAudio(3.5mm),RS232,miniBtypeUSB
OutputSources •VGA(HD15),12Vtrigger
ComputerCompatibility •VGA(640x480),SVGA(800x600),XGA(1024x768),
 SXGA(1280x1024),SXGA+(1400x1050)
VideoCompatibility •NTSC,NTSC4.43,PAL,PAL-M,PAL-N,SECAM,
 SDTV(480i/576i),EDTV(480p/756p),
 HDTV(720p/1080i)
Brightness•2400lumens
ContrastRatio •1800:1
NumberofColors •16.7million,TrueColor
ColorWheel •5Segment(RGBYW)
BrightnessUniformity •80%
H-SynchRange •30~100kHz
V-SynchRange •50~87Hz 
DotClock •13.5MHz-140MHz 
DigitalKeystoneCorrection •+/-25deg.(vertical)
StandardProjectionLens •Fnumber:2.42
 •Focallength:7.5mm
Zoom •Fixed
ThrowRatio •0.67:1(distancetowidth)
MinimumProjectionDistance•0.9~1.6m
LensOffset •120% 
AspectRatio •4:3(native)/16:9 
ImageSize(diagonal) •1.70m~3.02m(67”~119")
ProjectionMethods •Front,Rear,Ceiling-front,Ceiling-rear
Audio •2.0Wspeaker (mono)
Control •PCcontrolthroughRS232
Lamp •200W/3000hours(Normal),4000hours(Eco)*
Security •Kensingtonslot,PINcode,removablekeypad
ProductDimensions •10.8"x5.0"x12.1"(WxHxD)
  276x127x307mm
ProductWeight •4kg / 8.75 lbs  
ProductColor •Black 
PowerConsumption •285W+/-10%@110Vac
PowerSupply •100~240Vac,50/60Hz 
OperatingTemperature •5–35°C / 41 - 35 F
MenuLanguages •English,French,German,Italian,Spanish, 
 Portuguese,Swedish,SimpliedChinese,Traditional
 Chinese,Russian,Korean,Japanese,Dutch,Thai, 
 Arabic,Czech,Polish,Turkish
AudibleNoise •30dB(A) 
Approvals •UL/cUL,FCC,CE,CCC,PSB,MIC,EK,GOST
ProductWarranty •2yearpartsandlabor
LampWarranty •6Months
* Actuallamplifemayvarybasedontheambientenvironment.Conditionsaffectinglamplifeinclude
temperature,altitudeorrapidlyswitchingtheprojectoronandoff.
+ InFocusreservestherighttoalterproductofferingsandspecicationsatanytimewithoutnotice.
