INFOCUS®LP®840/LP®850 INSTALLATION & INTEGRATION PROJECTOR
THE POWER...
—…OF PERFECT PROJECTION
Illuminate large training rooms, conference centers, classrooms, and houses of worship
with stellar brightness and image quality. Four optional user-replaceable bayonet lenses
can be changed without hassle in just three easy steps. Native XGA resolution, 750:1
contrast ratio, and 3500 lumens (LP840) or 4500 lumens (LP850) combine for images
that are powerful and captivating.
—…TO CONNECT
Experience seamless compatibility with connectivity that supports three separate PC and
three separate video sources. Control your projector via RS-232 or TCP/IP inter faces.
Connect analog and digital sources with support for HDTV and computer sources up to
UXGA resolution. BNC connectors make for secure, professional installations.
—…TO UPGRADE
The LP840 and LP850 are solutions-enabled—offering seamless integration with network
and wireless applications so you can upgrade with ease. Add them to your network right
out of the box with ProjectorNet™by InFocus®, and manage all your projector assets from
a single PC. Both projectors are also compatible with the InFocus LiteShow®wireless
solution, the first cable-free digital projection solution of its kind. Just pure performance
and wireless collaboration.
Experience the brilliant power of the InFocus LP840 and LP850 family of projectors
designed to integrate into any room—across your entire enterprise—with power ful options,
presentation flexibility, innovative ease-of-use and a price you can’t resist. Unsurpassed
flexibility and a revolutionary feature package means perfect projection in any environ-
ment—when it counts the most.
A UNIQUE, HIGH-PERFORMANCE INSTALLATION PROJECTOR
EASE, INCORPORATED
Imagine. A projector that makes your
work easier. InFocus ProjectAbility™
makes InFocus projectors so intuitive,
users are up and running all by them-
selves in no time.

THE POWER OF TOTAL CONFIDENCE
With an array of options and control features, the LP840 and LP850 family
of projectors give you exactly what you need.
—UNIQUE OPTIONS
Four optional user-replaceable bayonet lenses offer versatility in most any venue and can be
changed in just three easy steps. Just push, twist, and replace. It’s that easy.
The lamp can be replaced even while the unit is mounted allowing for simple maintenance. Power
zoom, focus and lens shift, plus horizontal and vertical keystone correction provide the highest
level of professional installation performance and control. Plus, compatibility with multiple video
and data sources ensures smooth set up and trouble-free presentations for users, resulting in a
minimum of service calls for IT and other support staff.
—EASE WITHOUT SACRIFICE
Wireless and network capabilities offer ultimate control options. Combining features and design that
benefit the installer, IT manager, and presenter, the LP840 or LP850 is a solid choice that you can
stake your reputation on.
InFocus®ProjectorNet™is a client/server based networking solution designed to allow IT and facilities
personnel to manage multiple projectors from a single PC. ProjectorNet gives corporations, universities
and other organizations the power to manage projectors just as they would other shared computing
and communication assets such as PCs and printers.
InFocus®LiteShow®delivers high-resolution, true-color clarity with fast image updates and smooth,
jitter-free images. It’s built on industry standard Wi-Fi (802.11b) technology and is compatible with
both PC and Mac operating systems. LiteShow is simple to use, requiring zero network configuration
and no cumbersome system set-up. No more plugging and unplugging between presenters, deliver-
ing unprecedented flexibility for wireless collaboration.
—INNOVATION FOR PERFORMANCE
User-focused innovations—based on years of research—enable intuitive use. Features designed
for both IT and end-users allow for trouble-free projector management. ProjectAbility, an InFocus
Corporation product design philosophy, eliminates the typical projector learning curve. Color-coded
I/O connectors let users connect in seconds. The keypad allows the most common functions to be
accessed with just one touch, while the intuitive menu system lets users simply scroll-and-select.
This approach to design for ease without sacrificing function not only reduces suppor t calls, but
results in much less presentation “down time.”
—COMPLETE CONTROL
Users gain complete control of the projector from their laptops with InFocus ProjectorManager,
™a
free application that turns any PC into an advanced projector remote control. Adjust settings, switch
sources, even access power management controls and presentation collaboration tools.
Four optional user-replaceable
bayonet lenses - just push,
twist, and replace.
Seamless integration with
network and wireless
applications.
Simple maintenance.
Illuminate and captivate your
audience.

INSTALLATION & INTEGRATION PROJECTOR
PROJECTION DISTANCES Short Fixed Throw Ratio Range 0.8:1
Image Size
Distance Diagonal Image Image Width
Feet Meters Feet Meters Feet Meters
MIN DISTANCE 3 0.9 4.69 1.43 3.75 1.14
5 1.5 7.81 2.38 6.25 1.91
10 3.0 15.63 4.76 12.50 3.81
MAX DISTANCE 12 3.7 18.75 5.72 15.00 4.57
PROJECTION DISTANCES Standard Throw Ratio Range 1.5 –2.2:1
Minimum Image Maximum Image
Distance Diagonal Image Image Width Diagonal Image Image Width
Feet Meters Feet Meters Feet Meters Feet Meters Feet Meters
MIN DISTANCE 3 0.9 1.70 0.52 1.36 0.42 2.50 0.76 2.00 0.61
5 1.5 2.84 0.87 2.27 0.69 4.17 1.27 3.33 1.02
10 3.0 5.68 1.73 4.55 1.39 8.33 2.54 6.67 2.03
20 6.1 11.36 3.46 9.09 2.77 16.67 5.08 13.33 4.06
30 9.1 17.05 5.20 13.64 4.16 25.00 7.62 20.00 6.10
40 12.2 22.73 6.93 18.18 5.54 33.33 10.16 26.67 8.13
MAX DISTANCE 45.5 13.9 25.85 7.88 20.68 6.30 37.92 11.56 30.33 9.25
PROJECTION DISTANCES Short Zoom Throw Ratio Range 1.1 – 1.5:1
Minimum Image Maximum Image
Distance Diagonal Image Image Width Diagonal Image Image Width
Feet Meters Feet Meters Feet Meters Feet Meters Feet Meters
MIN DISTANCE 2 0.6 1.67 0.51 1.33 0.41 2.27 0.69 1.82 0.55
5 1.5 4.17 1.27 3.33 1.02 5.68 1.73 4.55 1.39
10 3.0 8.33 2.54 6.67 2.03 11.36 3.46 9.09 2.77
20 6.1 16.67 5.08 13.33 4.06 22.73 6.93 18.18 5.54
25 7.6 20.83 6.35 16.67 5.08 28.41 8.66 22.73 6.93
MAX DISTANCE 30.5 9.3 25.42 7.75 20.33 6.20 34.66 10.56 27.73 8.45
PROJECTION DISTANCES Long Zoom Throw Ratio Range 2.2 – 4.2:1
Minimum Image Maximum Image
Distance Diagonal Image Image Width Diagonal Image Image Width
Feet Meters Feet Meters Feet Meters Feet Meters Feet Meters
MIN DISTANCE 4.2 1.3 1.28 0.39 1.02 0.31 2.39 0.73 1.91 0.58
10 3.0 3.05 0.93 2.44 0.74 5.68 1.73 4.55 1.39
20 6.1 6.10 1.86 4.88 1.49 11.36 3.46 9.09 2.77
30 9.1 9.15 2.79 7.32 2.23 17.05 5.20 13.64 4.16
40 12.2 12.20 3.72 9.76 2.97 22.73 6.93 18.18 5.54
60 18.3 18.29 5.58 14.63 4.46 34.09 10.39 27.27 8.31
MAX DISTANCE 83.2 25.4 25.37 7.73 20.29 6.19 47.27 14.41 37.82 11.53
PROJECTION DISTANCES Ultra Long Zoom Throw Ratio Range 3.9 – 7.3:1
Minimum Image Maximum Image
Distance Diagonal Image Image Width Diagonal Image Image Width
Feet Meters Feet Meters Feet Meters Feet Meters Feet Meters
MIN DISTANCE 7.5 2.3 1.28 0.39 1.03 0.31 2.40 0.73 1.92 0.59
25 7.6 4.28 1.30 3.42 1.04 8.01 2.44 6.41 1.95
50 15.2 8.56 2.61 6.85 2.09 16.03 4.88 12.82 3.91
75 22.9 12.84 3.91 10.27 3.13 24.04 7.33 19.23 5.86
100 30.5 17.12 5.22 13.70 4.18 32.05 9.77 25.64 7.82
125 38.1 21.40 6.52 17.12 5.22 40.06 12.21 32.05 9.77
MAX DISTANCE 146.5 44.7 25.09 7.65 20.07 6.12 46.96 14.31 37.56 11.45
Digital Computer (M1-D)
Audio In
Audio Out
Analog Computer Composite Video
S-Video
Monitor Loop-Through
Component Video
NIC (RJ45)
RS-232
BNC (5)

THE INFOCUS COMMITMENT
Experience for yourself why InFocus Corporation is the worldwide leader in digital projection. Our dedication to quality and customer satisfaction is
reflected in service options that will bring you a greater return on your investment. InFocus projectors come with a standard 2-year limited factory
warranty, including parts and labor, and a 90-day lamp replacement warranty. Our customer support offers you premium service and convenience,
whatever your needs.
For service program details in your region, please visit www.infocus.com/service/service_offerings
InFocus, LP and LiteShow are registered trademarks and ProjectAbility, ProjectorNet, and ProjectorManager are trademarks of
InFocus Corporation. All other trademarks are used with permission or are for identification purposes only and are the property
of their respective companies. ©2003 InFocus Corporation. All rights reser ved. 805-0847-00. LP840_LP850_DS_E.doc. 8/03.
OPTIONAL ACCESSORIES
CA-ATA-018 ATA Case, LP840/LP850
SP-LAMP-015 Lamp, LP840
SP-LAMP-016 Lamp, LP850
SP-CEIL-010 Ceiling Mount, LP840/LP850
SP-LTMT-PLT Ceiling Plate, Litemount
SP-LTMT-EXTP LM+extension Arm 26-47"
SP-VGAEXT50-D VGA 50ft/15 m Cable/Line Amp
Extension Solution-Domestic
SP-VGAEXT50-I VGA 50ft/15 m Cable/Line Amp
Extension Solution-International
SP-AV30 Audio/Video Cable
HW-DLXSCRN Deluxe Instra-theatre Screen,
60"/152 cm
HW-WALLSCR84 Manual Wall/ceiling 84"/213 cm
Screen
HW-RF-POCKTPNT Mind Path™Pocketpoint RF
Remote (Americas Only)
HW-PRESENTER Presentation Remote
HW-CONDUCTOR+ Conductor+ Remote
OPTIONAL LENSES
LENS-022 Short-throw Fixed, FL-501 [0.8:1]
LENS-023 Short-throw Zoom, SL-502
[1.1-1.5:1]
LENS-024 Long-throw Zoom, LL-503
[2.2-4.1:1]
LENS-025 Ultra Long-throw Zoom, LL-504
[3.9-7.3:1]
Ships Standard With
• User Manual, Quick start guide and CD
• AV cable (3 x RCA)
• RGB cable
• Power cord
• M1 cable
• Remote control (batteries included)
THE FAMILY OF PERFORMANCE
Introducing the new InFocus family
of performance projectors — the
LP850, LP840, and the LP820.
—TECHNICAL SPECIFICATIONS
Native Resolution • XGA 1024 x 768
Display Technology • 0.99" polysilicon TFT with micro lens array
Input Sources • Computer Sources: Computer 1 (M1-D), Computer 2 (DSUB-15), Computer 3 (Component via BNC)
• Audio Inputs (Computer): Mini-jack x 2
• Video Sources: Video 1 (Component RCA), Video 2 (S-Video), Video 3 (Composite RCA)
• Audio Inputs (Video): Stereo RCA jack (shared)
Output Sources (standard) • Audio mini-jack, monitor loop through, wired remote
Computer Compatibility • VGA – UXGA
Video Compatibility • NTSC, NTSC 4.43, PAL, PAL-M,N, PAL60
SDTV: 525i (480i), 625i (575i)
HDTV: 750p (720p @ 60Hz), 1125i (1080i @50/60Hz, 1035i @ 60Hz)
EDTV: 525p (480p)
Brightness • LP840: 3500 max ANSI lumens (standard mode); 2800 max ANSI lumens (whisper mode)
• LP850: 4500 max ANSI lumens (standard mode); 3600 max ANSI lumens (whisper mode)
Brightness Uniformity • 85%
Contrast Ratio • 750:1 Full on/Full off
Number of Colors • 16.7 million
H-Synch Range • 15 – 91 kHz
V-Synch Range • 50 – 120 Hz
Dot Clock • 160 MHz
Lens Shift • 10:0 – 1:1 motorized vertical lens shift
Digital Keystone Correction • Horizontal: up to +/-15˚
Vertical: up to +/-15˚
• Conditions:
1024 x 768 @ 60Hz
Lens shift: 10:0
Lens: Standard lens
Projection Lens (standard) • Zoom Ratio: 1.5:1
• Throw Ratio: 1.5 – 2.2:1 (D:W)
• Minimum Projection Distance: 3'/0.9 m
• Maximum Projection Distance: 45.5'/13.9 m
• Image offset ratio (%): On axis to 100% offset
Optional • Zoom Ratio: N/A
Fixed Short Throw Lens • Throw Ratio: 0.8:1 (D:W)
• Minimum Projection Distance: 3'/0.9 m
• Maximum Projection Distance: 12'/3.7 m
• Image offset ratio (%): On axis
Optional • Zoom Ratio: 1.3:1
Short Throw Zoom Lens • Throw Ratio: 1.1 – 1.5:1 (D:W)
• Minimum Projection Distance: 2'/0.6 m
• Maximum Projection Distance: 30.5'/9.3 m
• Image offset ratio (%): On axis to 100% offset
Optional • Zoom Ratio: 1.7:1
Long Throw Zoom Lens • Throw Ratio: 2.2 – 4.1:1 (D:W)
• Minimum Projection Distance: 4.2'/1.3 m
• Maximum Projection Distance: 83.2'/25.4 m
• Image offset ratio (%): On axis to 100% offset
Optional • Zoom Ratio: 1.8:1
Ultra Long Throw • Throw Ratio: 3.9 – 7.3:1 (D:W)
Zoom Lens • Minimum Projection Distance: 7.5'/2.3 m
• Maximum Projection Distance: 146.5'/44.7 m
• Image offset ratio (%): On axis to 100% offset
Aspect Ratio • 4:3 native (supports 5:4, 16:9)
Image size (diagonal) • 30" – 300"/76.2 cm – 762.0 cm
Projection Methods • Front, rear and ceiling
Audio • 2x1-watt stereo
Mouse Control • USB via M1
Projector Control • RS-232 (9-pin DSUB), ProjectorNet™(RJ45)
Lamp • LP840: 275W UHB/2000 hours*
• LP850: 320W UHB/1500 hours* (preliminary)
Dimensions (standard) • 16.8" (W) x 12.4 " (L) x 6.4" (H); 42.7 cm (W) x 31.5 cm (L) x 16.3 cm (H)
Weight (standard) • 17 lbs/7.7 kg
Power Supply • 100 – 240V at 50 – 60 Hz; auto switching
Operating Temperature • 10˚ – 35˚ C at sea level (0' –10,000'); 50˚ – 95˚ F
Power Consumption • 430 watts
Menu Languages • English, Spanish, French, German, Japanese, Korean, Portuguese, Italian, Norwegian, Russian,
Simplified Chinese, Traditional Chinese
Audible Noise • 40dB (standard mode); 36dB (whisper mode)
Approvals • FCC A, UL/cUL, CE, TUV
Lamp Warranty • 90-days or 500 hours, whichever comes first
Product Warranty • 2 years par ts and labor
Accessory Warranty • 1 year
*Actual lamp life may var y based on the ambient environment. Conditions that may affect lamp life include temperature,
altitude, rapidly switching the projector on and off, and switching between standard and low power modes.
Contact InFocus or your dealer today.
Unique
High Performance
Innovative
Flexible
Affordable
=
Perfect Projection
E
stado da Arte - Distribuidor Autorizado
T
el.: 0800 888 9030 - www.estadodaarte.com.br
