LP630 RS-232 Command Values
The following table lists the RS-232 command value ranges for controlling the LP630.
Note: Specified commands and values apply to the LP630 with version 1.0 software or higher. Command values for LP630s with
earlier software versions may vary. If your LP630 does not have version 1.0 software or higher, go to the Software/Downloads
page to download and upgrade the projector software.
For absolute command value ranges of 0 - 1, 0 = "Off" and 1-9999 = "On" unless otherwise noted.
Function Command Type Range Read/Write
Power PWR Boolean
0 – 1 W
Lamp Hours LMP Range 0 – 9999 R
Standby STB Boolean
0 – 1 R & W
Freeze FRZ Boolean
0 – 1 R & W
Brightness BRT Range
0 – 255 R & W
Sharpness SHP Range
0 – 255 R & W
Contrast CON Range
0 – 255 R & W
Tint TNT Range
0 – 255 R & W
Color CLR Range
0 – 63 R & W
Reset RST Boolean
0 – 1 R & W
Auto Source Control ASC Boolean 0 – 1 R & W
Default Source DSC Range
0 – 5
0 = PC 2 (VESA)
1 = PC 1 - analog
2 = PC 1 - digital
3 = Video 1 (component video)
4 = Video 1 (composite video)
5 = Video 2 (S-video)
R & W
Source SRC Range
0 – 5
0 = PC 2 (VESA)
1 = PC 1 - analog
2 = PC 1 - digital
3 = Video 1 (component video)
4 = Video 1 (composite video)
5 = Video 2 (S-video)
R & W
Volume VOL Range
0 – 80 R & W
Mute MTE Boolean
0 – 1 R & W
Balance BAL Range
0 – 63 R & W
Fade FAD Range
0 – 63 R & W
Treble TRB Range
0 – 14 R & W
Bass BAS Range
0 – 14 R & W
Auto Image AIM Boolean 0 – 1 R & W
Resize ARZ Range
0 – 3
0 = standard
1 = native
2 = widescreen letterbox
3 = enhanced widescreen
R & W
Manual Sync Setting MSS Range 0 – 19 R & W
Manual Tracking Setting MTS Range 0 – 63 R & W
Horizontal Position Setting HPS Range 0 – 63 R & W
Vertical Position Setting VPS Range 0 – 63 R & W
Video Standard VSU Range
0 – 7
0 = Auto Video
1 = NTSC
2 = PAL R & W

3 = PAL-M
4 = PAL-N
5 = PAL-60
6 = SECAM
7 = NTSC4.43
Language LAN Range
0 – 6
0 = English
1 = French
2 = German
3 = Spanish
4 = Japanese
5 = Chinese
6 = Korean
R & W
Ceiling CEL Boolean
0 – 1 R & W
Rear Project REA Boolean 0 – 1 R & W
Keystone KEY Range
0 – 64 R & W
Picture-in-Picture PIP Boolean
0 – 1 R & W
Zoom ZOM Boolean
0 – 1 R & W
Magnify MAG Range
0 – 19 R & W
Demagnify DMG Range
0 – 19 R & W
Color Temperature TMP Range
0 – 6
0 = 6500
1 = 7000
2 = 7500
3 = 8000
4 = 9300
5 = 10000
6 = Bright Room
R & W
Blank Screen BSC Range
0 – 2
0 = blue
1 = black
2 = white R & W
