Ingersoll-Rand Club Car VILLAGER 8 ELECTRIC User manual

VILLAGER 8 ELECTRIC
Operators Manual
APPLICABLE TO VILLAGER 8 ELECTRIC
VEHICLES WITH SERIAL PREFIX OF CI

Copyright © 2021 Club Car, LLC
This manual effective September 1, 2021

VILLAGER 8 ELECTRIC
Operators Manual
TPCC01CI00EN021 (Edition C)
Page i
INTRODUCTION
VEHICLE OWNERSHIP
Congratulations! The Club Car brand is widely recognized as the industry leader in vehicle efficiency
and long-lasting value. Read, understand, and obey the technical content in this manual to protect
your investment and provide years of reliable vehicle operation.
Read, understand, and obey all instructions and safety precautions in this manual to prevent the risk of
personal injury or property damage.
Club Car recommends owners that rent or loan vehicles make sure operators read this manual before
vehicle operation.
Club Car recommends owners register their vehicles immediately after purchase. The previous owner
must include this manual with the vehicle when sold to a new owner. Registration of the vehicle will
make sure Club Car is able to communicate necessary information directly to owners. Send your
name, address, and serial number of the vehicle to:
Club Car, LLC
Attention: Vehicle Registration
P.O. Box 204658
Augusta, Georgia 30917-4658
United States Of America
CALIFORNIA PROPOSITION 65
WARNING OPERATING, SERVICING AND MAINTAINING A
PASSENGER VEHICLE OR OFF-ROAD VEHICLE
CAN EXPOSE YOU TO CHEMICALS INCLUDING
ENGINE EXHAUST, CARBON MONOXIDE,
PHTHALATES, AND LEAD, WHICH ARE KNOWN
TO THE STATE OF CALIFORNIA TO CAUSE
CANCER AND BIRTH DEFECTS OR OTHER
REPRODUCTIVE HARM. TO MINIMIZE
EXPOSURE, AVOID BREATHING EXHAUST, DO
NOT IDLE THE ENGINE EXCEPT AS NECESSARY,
SERVICE YOUR VEHICLE IN A WELL-
VENTILATED AREA AND WEAR GLOVES OR
WASH YOUR HANDS FREQUENTLY WHEN
SERVICING YOUR VEHICLE. FOR MORE
INFORMATION GO TO WWW.P65WARNINGS.
CA.GOV/PASSENGER-VEHICLE.
APPROVED DEALERS AND DISTRIBUTORS
Club Car’s customer support system offers fast and courteous service. Speak with your dealer or
distributor for:

Page ii
VILLAGER 8 ELECTRIC
Operators Manual
TPCC01CI00EN021 (Edition C)
• Accessories
• Publications
• Replacement Parts
• Technical Advice
• Warranty Work
To find your nearest dealer or distributor:
• Visit www.clubcardealer.com
• Scan the dealer locator Quick Response (QR) code
COMPANY CONTACT INFORMATION
Send written correspondence to:
Club Car, LLC
Attention: Marketing Services
P.O. Box 204658
Augusta, Georgia 30917-4658
United States Of America
SATISFACTION AND FEEDBACK
Let your voice be heard!
Your feedback will help improve our publications. You can access the survey
through any internet-connected device with a web browser. The survey is available
in many different languages.
Scan the Quick Response (QR) code or type the web address http://bit.ly/1w9uFMh
to complete the survey.

VILLAGER 8 ELECTRIC
Operators Manual
TPCC01CI00EN021 (Edition C)
Page iii
NOTICES
VEHICLE MODEL AND SERIAL NUMBER
The vehicle serial number is located on a bar code decal installed near the accelerator.
1. A two-letter code that identifies the vehicle
model.
2. A four-digit code that identifies the model
year and production week the vehicle was
assembled.
3. A unique six-digit number given to each
vehicle built within a specified model year.
LIABILITY AND VEHICLE DESIGN CHANGES
Club Car is not liable for errors in this manual or for incidental or consequential damages that result
from the use of the material in this manual.
Club Car reserves the right to make design changes to vehicles without obligation to make these
changes on units previously sold.
This manual is the original instructions provided by the manufacturer if in English. This manual is a
translation of the original instructions if in any language other than English.
VEHICLE MODIFICATIONS
DANGER MODIFICATIONS OR CHANGES TO THE VEHICLE THAT AFFECT
THE OCCUPANT RETENTION, ELECTRICAL SYSTEM, STABILITY
OR HANDLING OF THE VEHICLE, OR INCREASES THE MAXIMUM
VEHICLE SPEED CAN CAUSE SERIOUS PERSONAL INJURY OR
DEATH.
NOTICE MODIFICATIONS TO THE VEHICLE MUST NOT COMPROMISE
COMPLIANCE WITH STATE OR FEDERAL REGULATIONS.
Modifications made to vehicles or installation of accessories that are not approved by Club Car may
adversely affect the safe operation and performance of the vehicle. These modifications include, but
are not limited to lift kits, seating changes, increased speed and cargo capacity. Club Car does not
recommend any modification of this vehicle except kits and upgrades specifically designed and offered
by Club Car. However, if the vehicle is modified, the modifier shall:
1. arrange for the modification to be designed, tested and implemented by an engineer with expertise
in vehicles and their safety;
2. maintain a permanent record of the design, testing and implementation of the modification;
3. make appropriate changes to the capacity, plate(s), decals, and operation and maintenance
manuals; and
4. apply a permanent and readily visible label on the vehicle stating the vehicle has been modified with
the date of the modification and the name of the entity that made the modification.
The entity making any modification becomes the original equipment manufacturer of the modified
vehicle, assumes liability for the vehicle, and has the responsibilities listed above.
Modifications may void the warranty. Refer to the warranty for more details.

Page iv
VILLAGER 8 ELECTRIC
Operators Manual
TPCC01CI00EN021 (Edition C)
VEHICLE WARRANTY
Warranty information is located in the warranty section of this manual. No other expressed or implied
warranties are contained herein.
Your dealer or distributor examined the vehicle before it was delivered to you. The dealer or distributor
will also supply you a copy of the completed vehicle warranty registration form.
GOVERNMENTAL AND INDUSTRY STANDARDS
U.S.A. FEDERAL VEHICLE SAFETY STANDARDS
The configuration of this vehicle does not comply with United States Of America Federal Motor Vehicle
Safety Standards (FMVSS) for automobiles and FMVSS 500 for low-speed vehicles as it existed on the
date the vehicle was shipped from the Club Car manufacturing facility.
CANADIAN STANDARD ICES-002
This vehicle complies, when marked with an ICES decal, with CAN ICES-2 / NMB-2 as it was on the
date the vehicle was shipped from the Club Car manufacturing facility.
EUROPEAN UNION VIBRATION AND NOISE PREN 15997
European Union specification prEN 15997 was used to measure the vibration and noise levels of the
vehicle. The vibration and noise values are recorded in the vehicle specification section of this manual.
EUROPEAN UNION DIRECTIVES
This vehicle, when marked with a CE decal, complies with:
• 2014/30/EU
• 2006/42/EC
• 2006/66/EC
• 2014/35/EU
The following standards were used:
• EN ISO 12100:2010
• EN ISO 13857:2008
• EN 60204-1
• EN 61000-6-2:2005
• EN 61000-6-4:2007/A1:2011
• EN 60335-2-29:2004
PUBLICATION COPYRIGHT
This manual contains proprietary information that is protected by copyright. All rights are reserved.
Express written consent of Club Car, LLC is necessary to photocopy, replicate, or translate this manual.
The information contained in this publication is subject to change without notice.

VILLAGER 8 ELECTRIC
Operators Manual
TPCC01CI00EN021 (Edition C)
Page v
CONTENTS
INTRODUCTION ........................................................................................................................................I
NOTICES ................................................................................................................................................. III
SECTION 1 – SAFETY INFORMATION ................................................................................................. 9
General Safety Information ................................................................................................................ 10
Note To The Owner ......................................................................................................................... 10
Practice Safety................................................................................................................................ 10
Safety Signal Words ....................................................................................................................... 10
Safety Committee .......................................................................................................................... 11
Vehicle Safety Information.................................................................................................................. 11
Vehicle Safety And Compliance Decals.......................................................................................... 12
Vehicle Safety Features ....................................................................................................................... 14
Battery Charging Interlock ............................................................................................................ 14
Multi-Purpose Buzzer ..................................................................................................................... 14
Regenerative Braking..................................................................................................................... 14
Walk-Away Braking ........................................................................................................................ 15
Battery Safety Information ................................................................................................................. 15
Battery International Safety Symbols ........................................................................................... 16
Lead-Acid Battery Recycling .......................................................................................................... 16
SECTION 2 – INDICATORS, GAUGES, AND DISPLAYS ..................................................................17
Indicator, Gauge, And Display Locations ............................................................................................ 18
Battery Condition Indicator................................................................................................................. 18
Charge Indicator Light......................................................................................................................... 18
SECTION 3 – VEHICLE CONTROLS.....................................................................................................21
Vehicle Controls Locator ...................................................................................................................... 22
Accelerator Pedal ................................................................................................................................. 22
Brake Pedal .......................................................................................................................................... 23
Circuit Breaker ..................................................................................................................................... 23
Forward / Neutral / Reverse Control ................................................................................................... 23
Hazard Light Switch............................................................................................................................. 24
Headlight Switch.................................................................................................................................. 24
Horn...................................................................................................................................................... 24
Key Switch............................................................................................................................................ 25
Park Brake............................................................................................................................................ 25
Run/Tow Switch ................................................................................................................................... 26
Turn Signal Lever ................................................................................................................................. 26
SECTION 4 – VEHICLE FEATURES......................................................................................................27
Vehicle Features Description ............................................................................................................... 28
Fixed Rear Seat.................................................................................................................................... 28
Fold-Down Rear Seat........................................................................................................................... 28
USB Receptacle.................................................................................................................................... 28
SECTION 5 – BATTERY CHARGER ......................................................................................................29
Introduction ......................................................................................................................................... 30
Specifications....................................................................................................................................... 31
Manufacturer Information ............................................................................................................. 31
Dimension And Weight ................................................................................................................... 31

Page vi
VILLAGER 8 ELECTRIC
Operators Manual
TPCC01CI00EN021 (Edition C)
Operational Temperature............................................................................................................... 31
AC Input.......................................................................................................................................... 31
DC Output ....................................................................................................................................... 31
Governmental And Industry Certifications ......................................................................................... 32
European Conformity ..................................................................................................................... 32
Federal Communications Commission .......................................................................................... 32
International Protection Marking................................................................................................... 32
Underwriters Laboratories And Canadian Standards Association ................................................ 32
Features ............................................................................................................................................... 32
AC Electrical Cord And Plug............................................................................................................ 32
Battery Charging Interlock ............................................................................................................ 33
Extended Storage Charge .............................................................................................................. 33
Status Indicator Lights................................................................................................................... 33
Inspection And Service........................................................................................................................ 34
Algorithm Program Number........................................................................................................... 34
Electrical Cords............................................................................................................................... 34
Electrical Plugs And Receptacles.................................................................................................... 35
Troubleshooting ................................................................................................................................... 35
Diagnostic Code.............................................................................................................................. 35
SECTION 6 – VEHICLE SPECIFICATIONS.........................................................................................37
Dimensions .......................................................................................................................................... 38
Performance......................................................................................................................................... 38
Tires ..................................................................................................................................................... 38
Electric Motor ....................................................................................................................................... 38
Batteries............................................................................................................................................... 38
Noise And Vibration ............................................................................................................................. 39
Transaxle.............................................................................................................................................. 39
Vehicle Weights And Load Capacities.................................................................................................. 39
SECTION 7 – VEHICLE OPERATION ..................................................................................................43
Daily Pre-Operational Safety And Performance Checks..................................................................... 45
Overview......................................................................................................................................... 45
Daily Pre-Operational Safety Checklist ......................................................................................... 46
Vehicle Performance Inspection .................................................................................................... 46
Vehicle Movement................................................................................................................................ 48
Overview......................................................................................................................................... 48
Motor Start ..................................................................................................................................... 48
Turn Off Motor................................................................................................................................. 49
Forward Movement ........................................................................................................................ 49
Reverse Movement......................................................................................................................... 49
Slow Or Stop The Vehicle ............................................................................................................... 50
Park The Vehicle ............................................................................................................................. 50
Driving Conditions ............................................................................................................................... 50
Unpaved Surfaces .......................................................................................................................... 50
Uphill Slope..................................................................................................................................... 50
Side Hill Slope................................................................................................................................. 51
Downhill Slope ................................................................................................................................ 52
Over Obstacles ............................................................................................................................... 52
Below Obstacles ............................................................................................................................. 53
Night Time ...................................................................................................................................... 53
Through Water................................................................................................................................ 53
SECTION 8 – VEHICLE MAINTENANCE .............................................................................................55
Disable The Vehicle .............................................................................................................................. 57
Vehicle Cleaning................................................................................................................................... 57
Windshield ...................................................................................................................................... 57
Vehicle Exterior .............................................................................................................................. 57
Vehicle Interior ............................................................................................................................... 57

VILLAGER 8 ELECTRIC
Operators Manual
TPCC01CI00EN021 (Edition C)
Page vii
Maintenance Schedule ........................................................................................................................ 58
Overview......................................................................................................................................... 58
Service Schedule ............................................................................................................................ 58
Maintenance Tasks............................................................................................................................... 59
Lift The Vehicle ............................................................................................................................... 59
Lower The Vehicle........................................................................................................................... 61
Tire Pressure Measurement ........................................................................................................... 63
Wheel Assembly ............................................................................................................................. 63
SECTION 9 – BATTERY MAINTENANCE ............................................................................................65
Battery Cleaning .................................................................................................................................. 66
Battery Charging ................................................................................................................................. 66
Charging With Onboard Charger ................................................................................................... 66
Battery Electrical Connection .............................................................................................................. 67
Disconnect ...................................................................................................................................... 67
Connect........................................................................................................................................... 68
Battery Hold-Down .............................................................................................................................. 68
Add Water To A Battery Without Single Point Watering System ........................................................ 68
Deionizer.............................................................................................................................................. 70
Add Water To Batteries With Single Point Watering System .............................................................. 70
Watering Intervals ............................................................................................................................... 70
Water Quality ....................................................................................................................................... 70
Overview......................................................................................................................................... 70
Preferred Sources........................................................................................................................... 71
Alternate Sources........................................................................................................................... 71
Water Impurity ............................................................................................................................... 71
SECTION 10 – TRANSPORT AND TOW ..............................................................................................73
Prepare The Vehicle To Be Towed......................................................................................................... 74
Towing A Trailer Or Vehicle .................................................................................................................. 74
Vehicle Transport Preparation ............................................................................................................. 74
Vehicle Transport Recovery ................................................................................................................. 75
SECTION 11 – EXTENDED STORAGE .................................................................................................77
Extended Storage Preparation ............................................................................................................ 78
Return To Service From Extended Storage ......................................................................................... 79
SECTION 12 – WARRANTIES ..............................................................................................................81
Limited Warranty ................................................................................................................................. 82
Warranty ......................................................................................................................................... 82
Warranty Timeframe ...................................................................................................................... 82
Exclusions....................................................................................................................................... 83
Voiding Of Warranty ....................................................................................................................... 84
Sole Remedy................................................................................................................................... 84
Disclaimer....................................................................................................................................... 84
No Consequential Damages........................................................................................................... 84
How To Make A Warranty Claim ..................................................................................................... 85

(Page intentionally left blank.)

1SAFETY INFORMATION
VILLAGER 8 ELECTRIC
Operators Manual
TPCC01CI00EN021 (Edition C)
Page 9
Safety Information
Notices 1

Page 10
VILLAGER 8 ELECTRIC
Operators Manual
TPCC01CI00EN021 (Edition C)
GENERAL SAFETY INFORMATION
This vehicle is designed and intended to transport people and cargo on improved or semi-improved
surfaces for applications including commercial, industrial and resorts. Always adhere to local laws and
regulations pertaining to the use of the vehicle.
Only operate this vehicle as described in this manual. Speak with your local dealer or distributor for
changes, additions, or modifications that are necessary to comply with local laws and regulations
pertaining to the use of the vehicle.
Any vehicle can be used in a variety of usages outside of the manufacturer’s intent. Club Car cannot
anticipate and warn for every possible usage condition. Therefore, the operator must exercise good
sense and judgement and must operate the vehicle in an appropriate manner for the way in which the
vehicle is being used.
PRACTICE SAFETY
101960501
WARNING
!
ROTATING PARTS AND BURN RISK
Rotating parts can cause serious injury.
Keep body, hands, hair, and clothes away
from rotating parts.
Hot surfaces can cause serious burns.
Allow to cool before servicing.
Signal words (DANGER, WARNING, CAUTION, and NOTICE)
and safety messages are in this manual and on safety
decals. Read, understand, and obey all instructions, safety
precautions, and safety decals before vehicle operations.
Replace missing, damaged, or unreadable safety decals
immediately to prevent possible property damage, personal
injury, or death. Purchase replacement safety decals from
your dealer or distributor.
Know and understand all laws and regulations for vehicle
operation in your area.
Speak with your dealer or distributor if you have questions
about material contained in this manual or the vehicle.
SAFETY SIGNAL WORDS
Signal words (DANGER, WARNING, CAUTION, and NOTICE) and safety messages are in this manual
and on safety decals. Read, understand, and obey all instructions, safety precautions, and safety
decals before vehicle operations.
Safety messages are necessary and must be obeyed.
The safety alert symbol is used to alert you to possible personal injury hazards.
Obey all safety messages that follow this symbol to prevent possible injury or
death.
1Safety Information
General Safety Information

VILLAGER 8 ELECTRIC
Operators Manual
TPCC01CI00EN021 (Edition C)
Page 11
SAFETY SIGNAL WORD SIGNIFICANCE
DANGER
A DANGER identifies a hazardous situation which will result in
death or serious injury.
WARNING
A WARNING identifies a hazardous situation which could result
in death or serious injury.
CAUTION
A CAUTION identifies a hazardous situation which could result
in minor or moderate injury.
NOTICE
A NOTICE identifies a hazardous situation which could result in
property damage.
SAFETY COMMITTEE
If the vehicle is rented or part of a fleet, Club Car recommends a safety committee. The primary
concern of the safety committee is safe vehicle operation.
Safety committee objectives include:
• Approve vehicle operation areas.
• Identify all hazards.
• Identify who is approved to operate the vehicle.
• Keep the vehicles in a safe and serviceable condition.
• Supply instructions on safe vehicle operation.
• Visually show all hazards.
VEHICLE SAFETY INFORMATION
DANGER FAILURE TO OBEY INSTRUCTIONS IN THIS MANUAL CAN CAUSE
PROPERTY DAMAGE, SERIOUS PERSONAL INJURY, OR DEATH.
BEFORE YOU OPERATE THE VEHICLE OR DO THE SERVICING OF
THE VEHICLE, READ AND FULLY UNDERSTAND THE OWNER’S
MANUAL.
CLUB CAR VEHICLES ARE NOT RATED FOR OPERATION IN
EXPLOSIVE AREAS. THE VEHICLE OR BATTERY CHARGER CAN
CAUSE FLAMMABLE MATERIAL AND FUME IGNITION. DO NOT
OPERATE THE VEHICLE OR BATTERY CHARGER NEAR FLAMMABLE
MATERIALS AND FUMES.
Safety Information
Vehicle Safety Information 1

Page 12
VILLAGER 8 ELECTRIC
Operators Manual
TPCC01CI00EN021 (Edition C)
THE VEHICLE DOES NOT GIVE PROTECTION FROM LIGHTNING,
FLYING OBJECTS, OR OTHER STORM RELATED HAZARDS. DO NOT
OPERATE THE VEHICLE IN STORMS. STOP THE VEHICLE. GET OUT
OF THE VEHICLE IMMEDIATELY AND FIND A SHELTER IN
ACCORDANCE WITH APPLICABLE SAFETY GUIDELINES FOR
YOUR LOCATION IF IN A STORM.
UNINTENDED VEHICLE OPERATION CAN CAUSE SERIOUS
PERSONAL INJURY OR DEATH. MAKE SURE THAT CHILDREN ARE
ALWAYS SUPERVISED IN AND AROUND THE VEHICLE.
DO NOT OPERATE THE VEHICLE UNDER THE INFLUENCE OF
ALCOHOL, DRUGS, MEDICATIONS, OR WHILE DISTRACTED.
WARNING ELECTRICAL SHORTS CAN CAUSE A FIRE, ELECTRICAL SHOCK,
SERIOUS PERSONAL INJURY, OR DEATH. PREVENT CONTACT
BETWEEN POSITIVE VOLTAGE AND THE GROUND CIRCUIT. USE
INSULATED TOOLS.
TO HELP PREVENT BEING HIT, DO NOT STAND IN FRONT OF OR
BEHIND THE VEHICLE.
ONLY TWO PERSONS PER BENCH SEAT. ONLY RIDE ON THE
BENCH SEAT. DO NOT LET PEOPLE RIDE ON ANY PART OF THE
VEHICLE THAT IS NOT EQUIPPED WITH A SEAT. DO NOT LET A
PASSENGER HOLD A CHILD IN HIS OR HER LAP WHILE THE
VEHICLE MOVES.
ONLY TRAINED TECHNICIANS SHOULD SERVICE OR REPAIR THE
VEHICLE. ANYONE DOING EVEN SIMPLE REPAIRS OR SERVICE
SHOULD HAVE KNOWLEDGE AND EXPERIENCE IN ELECTRICAL
AND MECHANICAL REPAIR. THE APPROPRIATE INSTRUCTIONS
MUST BE USED WHEN PERFORMING MAINTENANCE, SERVICE, OR
ACCESSORY INSTALLATION.
VEHICLE SAFETY AND COMPLIANCE DECALS
WARNING MAKE SURE ALL OF THE SAFETY AND OPERATION DECALS ARE IN
THE CORRECT LOCATION ON THE VEHICLE. REPLACE THE SAFETY
AND OPERATION DECALS THAT ARE MISSING OR DAMAGED.
Understand and obey all safety decals. The instructions on these safety decals must be followed in
order to prevent the risk of dangerous personal injury or property damage.
Use a soft moist cloth to clean the decals. Do not use solvents, gasoline, or other chemicals to clean
the decals. Do not pressure wash decals.
1Safety Information
Vehicle Safety Information

VILLAGER 8 ELECTRIC
Operators Manual
TPCC01CI00EN021 (Edition C)
Page 13
200096-000105
12
3
4
5
6
6
3
3
G-
WARNING
UNINTENDED MOVEMENT, ROLLOVERS, OR FALLING OUT
CAN CAUSE SERIOUS INJURY OR DEATH.
• Vehicle to be operated by licensed and authorized persons only.
• Use in authorized area only. Do not operate on public roads.
• Two (2) persons per bench seat maximum.
• Operate from driver's seat only.
• Do not start vehicle until all occupants are fully seated.
• Drive slowly in turns and straight up and down slopes.
• Remain fully seated while moving.
• Hold on and keep entire body inside vehicle while moving.
• Do not leave children unattended in vehicle at any time.
• Children requiring a child safety seat must not ride in vehicle.
• Never operate under the influence of alcohol or drugs.
• Never attempt jumps and avoid extreme braking in reverse.
103961601
WARNING
!
Before leaving vehicle:
• Engage park brake to lock wheels.
• Set the FNR control to NEUTRAL (N).
• Turn the key to OFF and remove key.
TO OPERATE
Before using vehicle, read owner’s manual and vehicle safety warnings.
Study and understand controls.
OPERATING INSTRUCTIONS
103783001
UNINTENDED VEHICLE MOVEMENT CAN CAUSE SERIOUS
INJURY OR DEATH
• Ensure wheels are turned in desired direction of travel and path is
clear.
• Turn key to ON.
• Set the FNR control to FORWARD (F) or REVERSE (R) only when
stopped.
• Disengage the park brake.
• Vehicle will start moving when accelerator pedal is pushed.
• Slowly push the accelerator pedal to increase speed.
• During operation, a beeping alarm indicates a reduction in
regenerative braking.
• To stop, release accelerator pedal and push the brake pedal.
1. Rollover Warning Decal 2. Operating Instructions Decal
Safety Information
Vehicle Safety Information 1

Page 14
VILLAGER 8 ELECTRIC
Operators Manual
TPCC01CI00EN021 (Edition C)
WARNING
!
FALLING OFF CAN CAUSE SERIOUS INJURY OR DEATH
• Remain seated with entire body inside vehicle and hold on to seat handle or handrail at all times.
• Two (2) persons per bench seat maximum.
• One (1) person per bucket seat maximum.
• Do not leave children unattended on vehicle at anytime. 47638920
102845101
RUN
CLOSED OPEN
TOW
BATTERY EXPLOSION CAN RESULT IN
SERIOUS INJURY.
• The battery compartment is not a storage area.
Do not keep items in battery compartment.
• Towing this vehicle
• Extended storage
SET THE RUN/TOW SWITCH TO TOW BEFORE:
WARNING
• Servicing the vehicle
• Disconnecting or connecting
battery cables
3. Falling Off Warning Decal 4. Run/Tow Warning Decal
102518301
• Do not operate the vehicle without this cover correctly installed.
• Do not direct a water stream in the area of the cover without
the cover securely in place.
• Read and understand the maintenance and service manual
before servicing.
EXPOSURE TO WATER CAN
DAMAGE ELECTRONIC COMPONENTS
!
CAUTION
WARNING
FIRE CAN CAUSE SERIOUS INJURY OR DEATH
• Replacement battery wires must be 4-gauge (AWG) with low-resistance terminals
equivalent to factory-installed wires.
• Clean and tighten battery connections. Refer to the owner’s manual.
102967601
5. Component Cover Notice Decal 6. 4 Gauge Wire Warning Decal
VEHICLE SAFETY FEATURES
BATTERY CHARGING INTERLOCK
The battery charging interlock is a safety feature that prevents possible damage to the battery charger
and vehicle. The battery charging interlock will automatically engage when the AC cord is connected to
a power source. The vehicle will not operate when the AC cord is connected.
MULTI-PURPOSE BUZZER
The vehicle comes equipped with a multi-purpose buzzer. The multi-purpose buzzer makes an audible
tone when:
• The Forward / Neutral / Reverse control (FNR) is set to R.
• The walk-away braking engages for longer than two seconds.
• The regenerative braking performance decreases because the batteries are fully charged.
• The batteries start to charge.
REGENERATIVE BRAKING
CAUTION WHEN THE BATTERIES ARE FULLY CHARGED, A WARNING
BUZZER WILL OPERATE DURING REGENERATIVE BRAKING TO
TELL THE DRIVER THAT REGENERATIVE BRAKING
PERFORMANCE WILL DECREASE. USE THE BRAKE PEDAL TO
CONTROL THE VEHICLE SPEED.
Regenerative braking helps maintain the downhill speed of the vehicle in relation to the accelerator
pedal position.
Regenerative braking performance decreases when the batteries are fully charged.
Regenerative braking cannot maintain the vehicle speed on an excessive grade (more than 20%). Use
the brake pedal to control the vehicle speed.
1Safety Information
Vehicle Safety Features

VILLAGER 8 ELECTRIC
Operators Manual
TPCC01CI00EN021 (Edition C)
Page 15
ACCELERATOR PEDAL
POSITION CONDITION
Fully Pushed Regenerative braking holds the vehicle at the programmed top speed.
Between Fully Pushed And
Released
Regenerative braking holds the vehicle at a percentage of the
programmed top speed in relation to the accelerator pedal position.
Fully Released
Regenerative braking will do one of the two based on the controller
settings:
• Factory Default - Stop the vehicle slowly.
• Optional - Let the vehicle coast freely.
Note: The regenerative braking functions are controlled by the
controller settings. Speak with your dealer or distributor for
more information.
WALK-AWAY BRAKING
WARNING WALK-AWAY BRAKING WILL NOT LIMIT VEHICLE SPEED TO 3
MPH (4.8 KM/H) ON STEEP SLOPES. DO NOT OPERATE THE
VEHICLE ON SLOPES THAT ARE MORE THAN A 20% GRADE.
Walk-away braking is a safety function that limits the roll-away speed of a vehicle when the park brake
is disengaged. The multi-purpose buzzer will make an audible tone when the walk-away braking safety
device engages for more than two seconds.
BATTERY SAFETY INFORMATION
DANGER BATTERY ACID CAN CAUSE SERIOUS BURNS. PREVENT CONTACT
WITH SKIN, EYES, AND CLOTHING. WEAR A FULL FACE SHIELD
AND RUBBER GLOVES WHEN SERVICING A BATTERY.
ANTIDOTES: EXTERNAL: FLUSH WITH WATER. CALL A
PHYSICIAN IMMEDIATELY. INTERNAL: DRINK LARGE
QUANTITIES OF MILK OR WATER FOLLOWED WITH MILK OF
MAGNESIA OR VEGETABLE OIL. CALL A PHYSICIAN
IMMEDIATELY. EYES: FLUSH WITH WATER FOR 15 MINUTES.
CALL A PHYSICIAN IMMEDIATELY.
WARNING FROZEN BATTERY ACID CAN CAUSE DAMAGE INCLUDING LEAKS
AND EXPLOSIONS. IF THE BATTERY ACID FREEZES, REPLACE THE
BATTERY BEFORE CHARGING OR USE. BATTERIES IN A LOW
STATE OF CHARGE WILL FREEZE AT LOW TEMPERATURES. KEEP
THE BATTERIES IN A HIGH STATE OF CHARGE.
FLOODED AND SUBMERGED BATTERIES CAN CAUSE DAMAGE
INCLUDING LEAKS AND EXPLOSION. IF A BATTERY IS
SUBMERGED, REPLACE THE BATTERY BEFORE CHARGING OR
USE.
LOOSE BATTERY WIRES CAN CAUSE A FIRE, PROPERTY DAMAGE,
OR SERIOUS PERSONAL INJURY. MAKE SURE THAT ALL BATTERY
WIRES AND TERMINALS ARE CLEAN AND TIGHTENED
CORRECTLY.
Safety Information
Battery Safety Information 1

Page 16
VILLAGER 8 ELECTRIC
Operators Manual
TPCC01CI00EN021 (Edition C)
BATTERY WIRES WITH DAMAGE OR CORROSION CAN BECOME
TOO HOT AND CAUSE A FIRE, PROPERTY DAMAGE, OR SERIOUS
PERSONAL INJURY. REPLACE BATTERY WIRES THAT HAVE
DAMAGE OR CORROSION. CLEAN CORROSION FROM THE
BATTERY TERMINALS.
BATTERY INTERNATIONAL SAFETY SYMBOLS
Understand and obey the international safety symbols on the vehicle battery before you use, repair, or
service the vehicle.
SYMBOL SIGNIFICANCE
Shield eyes
Read and obey operation and maintenance instructions
Do not smoke, No open flames, No sparks
Keep away from children
Explosive gas hazard
LEAD-ACID BATTERY RECYCLING
WARNING LEAD-ACID BATTERIES CONTAIN DANGEROUS MATERIALS THAT
CAN CONTAMINATE THE WATER AND SOIL, CAUSE
ENVIRONMENTAL DAMAGE, CAUSE PROPERTY DAMAGE, AND
CAUSE SERIOUS PERSONAL INJURY. SPEAK WITH YOUR DEALER
OR DISTRIBUTOR FOR INFORMATION ON HOW TO DISCARD A
BATTERY CORRECTLY.
Lead-acid batteries and other components which have the Waste Electrical and Electronic Equipment
(WEEE) symbol printed on them must be collected and recycled separately from other waste. Do not
discard lead-acid batteries as municipal waste.
Speak with your dealer or distributor on how to correctly recycle lead-acid batteries.
1Safety Information
Battery Safety Information

2INDICATORS, GAUGES, AND
DISPLAYS
VILLAGER 8 ELECTRIC
Operators Manual
TPCC01CI00EN021 (Edition C)
Page 17
Indicators, Gauges, And Displays
Battery Safety Information 2

Page 18
VILLAGER 8 ELECTRIC
Operators Manual
TPCC01CI00EN021 (Edition C)
INDICATOR, GAUGE, AND DISPLAY LOCATIONS
130596-000037
BATTERY CONDITION
EF
2
1
G-
1. Charge Indicator Light 2. Battery Condition Indicator
(Optional Equipment)
BATTERY CONDITION INDICATOR
BATTERY CONDITION
EF
-+
The battery condition indicator gives a visual indication of the batteries state of
charge (SOC). The battery condition indicator has a 10-bar LED display.
CHARGE INDICATOR LIGHT
NOTICE WHEN THE CHARGE INDICATOR LIGHT IS ON, CHARGE
BATTERIES AS QUICKLY AS POSSIBLE.
The charge indicator lamp gives a visual indication when:
• The battery state of charge (SOC) is less than 20%. Charge the batteries as
quickly as possible.
• The batteries start to charge.
Note: The multi-purpose buzzer will operate three times.
2Indicators, Gauges, And Displays
Indicator, Gauge, And Display Locations
