BEGINNING SHEET FOLDED SHEET
None
1. printed two sides
2. printed black
3. tolerance: ± .13
4. see sheet 2 for artwork
5. printed in country may vary
6. drawings not to scale
8.500
4.250
2.750

The RP100 Home Appliance Module works with the Nexia Home
Intelligence system as both a lighting or small appliance controller
and a signal repeater to help extend the range of the Nexia Home
Intelligence bridge.
WARNING
FOR INDOOR USE ONLY!
FAILURE TO FOLLOW THIS WARNING MAY RESULT N
PROPERTY DAMAGE, PERSONAL INJURY OR DEATH.
The device plugged into the Z-Wave™ controlled outlet on
this module must not exceed 600 watts (incandescent);
1800W (15A) Resistive or Z\x HP Motor. Total load capacity for
both outlets is 1800W Resistive.
To reduce the risk of electric shock, this product has a
grounding type plug that has a third (grounding) pin. This plug
will only fit into a grounding type power outlet. If the plug does
not fit into the outlet, contact a qualified electrician to install
the proper outlet. Do not change the plug in any way.
Any modification or use other than described may damage
the unit and will void the warranty.
For warranty details, go to nexiahome.com and click Service
& Support, or call Customer Service at 877-288-7707.
Controlling Appliances
WARNING
NOT FOR USE WITH MEDICAL OR LIFE SUPPORT EQUIPMENT
FAILURE TO FOLLOW THIS WARNING MAY RESULT IN
PERSONAL INJURY OR DEATH.
Z-Wave enabled devices should never be used to supply
power to or control the On/Off status of medical or life
support equipment.
WARNING
DO NOT USE NOT USE Z-WAVE DEVICES (Home Appliance
Module) TO CONTROL ELECTRIC HEATERS OR ANY OTHER
APPLIANCES WHICH MAY PRESENT A HAZARDOUS
CONDITION.
FAILURE TO FOLLOW THIS WARNING MAY RESULT N
PROPERTY DAMAGE, PERSONAL INJURY OR DEATH.
Exercise extreme caution when using Z-Wave devices to
control appliances. Z-Wave devices may automatically be
powered on due to timed event programming. Depending
on the appliance, an unintended or unintentional “power on”
operation may result in a hazardous condition.
Customer Service:
[phone] (U.S.A. /Canada)
Warranty information is available at www.nexiahome.com.
Specifications
Power 120VAC, 60Hz
Signal (Frequency) 908.42 MHz
Maximum load for both outlets 15 Amps, 1800W Resistive
Maximum load for the Z-Wave controlled outlet: 600W
Incandescent, ½ HP Motor or 1800W Resistive
Range: Up to 100 feet line of sight between the Wireless
Controller and the closest Z-Wave receiver module.
Operating Temperature Range: 32-104° F (0-40° C)
For indoor use only.
Specifications subject to change without notice due to continuing
product improvement
FCC NOTICE
U2Z45602-3
The Federal Communication Commission Radio Frequency Interference
Statement includes the following paragraph: The equipment has been tested
and found to comply with the limits for a Class B Digital Device, pursuant to
part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This
equipment uses, generates and can radiate radio frequency energy and, if
not installed and used in accordance with the instruction, may cause harmful
interference to radio communication. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try
to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna
• Increase the separation between the equipment and receiver
• Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected
• Consult the dealer or an experienced radio/TV technician for help
Operation is subject to the following two conditions:
• This device may not cause interference and
• This device must accept any interference, including interference that may
cause undesired operation of the device.
Important Note: To comply with the FCC RF exposure compliance
requirements, no change to the antenna or the device is permitted. Any
change to the antenna or the device could result in the device exceeding the
RF exposure requirements and void user’s authority to operate the device.
IC NOTICE
Compliance with IC Rules and Regulations
IC: 6924A-45602A3
Jasco Products Company
Model: 45603
ZW4101
This Class B digital device complies with Canadian ICES-003.
RP100
Home Appliance Module and
Home Dimmer Module
P516-364

4 Manual Operation
• Press the button once to turn the light/appliance on or off.
3 Remote Control
• Log into your account at www.mynexia.com. Click the Lighting &
Automation tab. The appliance module will be displayed.
• Optional: If using the Nexia Home Intelligence mobile
application, then click MY PHONES, EDIT PHONE, and check
the box to control the home appliance module with your mobile
device.
1 Installation
1. Plug the home appliance module into any available outlet.
• Use any indoor, three-prong, 120 volt A/C outlet.
2. (Optional) Plug a lamp (incandescent or CFL) or small
appliance into the Z-Wave™ side of the home appliance
module.
• There are two outlets on the home appliance module. One of
the outlets is labelled with a Z-Wave™ logo. A lamp or small
appliance can be controlled by the system if it is plugged into
the Z-Wave™ side of the appliance module.
• The other outlet can be used simply as a pass-through outlet
(1800 watts maximum total for both outlets). It is not controlled
by the system, and the system is not affected when it is used.
Pass-through
Side
Z-Wave™
Side
Max. 600W
Incandescent
2 Enrollment
1. Enroll the home dimmer module into the bridge.
a. Disconnect power and Ethernet from the bridge.
b. Install a fresh 9-volt battery into the bridge.
c. Hold the bridge within 6 feet (1.8 meters) of the appliance
module throughout enrollment.
d. Press and release the plus (+) button on the bridge.
e. Double-click the button on the appliance module.
f. Observe the lights on the bridge. The orange light will blink while
enrollment is taking place. Enrollment is complete when the
orange light becomes solid.
g. Reconnect power and Ethernet to the bridge.
-
+
Within 6’
(1.8 m)
-
+
Click
Double-Click
© 2012 Ingersoll Rand
Printed in U.S.A.
P516-364 Rev. 2/12-b
