1 Introduction
This document describes the process to configure the INGECON SUN STORAGE 1Play (TL and TL M
version) to work with LG RESU 3.3 / 6.5 / 10 batteries.
The LG RESU and ISS 1Play equipment can be used in the following type of single-phase installations:
•Stand-alone installations
•UPS installations
•Self-consumption installations
The maximum power the inverter can transfer to/from the battery depends of the hardware version:
- For ISS 1Play TL is 2400W. This is due to the fact that the inverter is limited to transfer 50A to this
48V battery.
- For ISS 1Play TL M is 3168W. This is due to the fact that the inverter is limited to transfer 66A to this
48V battery.
The minimum FW versions to work with the ISS 1Play and LG RESU are the following:
Minimum Firmware Version used in the ISS 1Play TL:
- Inverter: ABH1002_R
- Display: ABH1003_H
Minimum Firmware Version used in the ISS 1Play TL M:
•Inverter: ABH1007_
For further details, check the “List of approved lithium batteries”available on Ingeteam website.
