Ingrasys M2210E User manual

Ver: v1.00
Quick Installation Guide
M2210(E/V)

M2210(E/V) Quick Installation Guide v1.00
Ingrasys Technology Inc.
Package Contents
1
AM2210(E/V) BC
D
Quick Installation Guide
Product CD
Warranty Card ELens adjustment tool
Hardware Pack
Torx Wrench Alignment
Sticker
Screws x 4
RJ-45 Field Installable
Feed-Through Adaptor
M12 Field Installable
Feed-Through Adaptor
Nylon Frame Anchors
M2210E M2210V
VIP Card (Optional)
F
G

Ingrasys Technology Inc.
v1.00 M2210(E/V) Quick Installation Guide v1.00
Connections
Physical Description & Connection
Connectors
2
M2210E
(RJ-45)
M2210V
(M12)
Connect the camera to a PoE switch with an Ethernet cable.
LAN
M2210E-RJ45
M2210V-M12
RJ-45 LAN Rugged
Connector
RJ-45 Field Installable
Feed-Through Adaptor
M12 Rugged
Connector
M12 Field Installable
Feed-Through Adaptor

M2210(E/V) Quick Installation Guide v1.00
Ingrasys Technology Inc.
3
Install M12 Field Installable Feed-Through Adaptor for M2210V
1.Insert a stripped Ethernet cable through the Sealing Nut and Housing of the eld
installable feed-through adaptor.
Sealing Nut Housing
Assemble M12 field installable through adaptor to achieve system waterproof and
vibration proof.
Install RJ-45 Field Installable Feed-Through Adaptor for M2210E
Assemble RJ-45 field installable through adaptor to achieve system waterproof and
vibration proof.
2. Follow the pin denition to crimp
the RJ-45 plug onto the cable.
3. Connect to M2210E RJ-45 rugged Connector
and fully seal the connector to achieve
waterproof and vibration proof completely.
1. Assemble the through the led installable
feed-through adaptor and insert a stripped
Ethernet cable.
Seals Gasket
Brown
White / Brown
Green
White / Blue
Blue
White / Green
Orange
White / Orange
8
7
6
5
4
3
2
1
Twist
Twist
Twist
Twist
Color Pin

Ingrasys Technology Inc.
v1.00 M2210(E/V) Quick Installation Guide v1.00
Mounting Camera
4
1. Alignment Sticker on drill holes 2. Loosen 2 screws and remove the top cover
3. Route the Ethernet cable through the hole and fasten camera on the surface with 4 screws
2. Follow the pin denition to weld the cable to the connector.
3.Connect to M2210V M12 rugged connector and fully seal the connector to achieve
waterproof and vibration proof completely
Connector
Sealing Nut Housing
1 2 1
4
2
3 43
Green
White / Green
Orange
White / Orange
4
3
2
1Twist
Twist
Color Pin

M2210(E/V) Quick Installation Guide v1.00
Ingrasys Technology Inc.
Assigning IP address
Launch Ingrasys Discovery Tool (IngrasysDiscovery.exe). The tool will start searching and then
displaying the cameras on the Device List after they are found.
2Check the box to select a camera device from the list.
Camera may be assigned with a valid IP address via DHCP server. It can be manually given a static
IP. To do so, click on “Set IP”, and then input the IP, Subnet Mask and Gateway. Input account info
if camera is password protected. (Default ID/Password : Admin/Admin)
3
4Click on the “Browse” button to get access to the camera web page immediately.
1
5

Ingrasys Technology Inc.
v1.00 M2210(E/V) Quick Installation Guide v1.00
2The live video of the camera can be played with a RTSP player, such as VLC or QuickTime. The
network URL is rtsp://Camera IP/stream1. The example given below is that live video is displayed
with QuickTime player.
Accessing the camera
1Launch IE browser and input the IP address of the camera, or click on “Browse” button on
Ingrasys Discovery Tool. The web page with video will then be presented as below.
6

M2210(E/V) Quick Installation Guide v1.00
Ingrasys Technology Inc.
Tuning camera Focus
7
1Fit the lens adjustment tool to the lens holder to adjust the direction of the lens.
2Pull out the lens adjustment tool, and turn it around to t the lens to adjust focus.
Replace the top cover to nish installation.
3
0 Angle
Focus
Rotate
