Introduction
An Inka Charcoal Oven is a ‘closed barbecue’ that delivers all the excitement,
avoursandaromasofbarbecuecooking,inthesafe,containedenvironmentof
an oven.
Cooking on the Inka is achieved through a combination of roasting and barbecuing,
and the temperature is regulated by a vent system .
By using dierent techniques and temperatures, dierent cooking eects can
beachieved.Thisproducesstunningavours,andatendernessthatcannotbe
equalled.
Charcoal ovens are regularly associated with grilling meat, particularly steak,
butwithalittleknow-howandpractice,theInkaoerstheopportunitytocook
awiderangeofdishesfrommeattosh,vegetablestoatbreadsandpizzas.
1

Inka Charcoal Ovens, The Swan Centre,
Higher Swan Lane, Bolton, Lancashire, BL3 3AQ, UK
[phone]
[email protected]
www.inka.co.uk
Information accurate at time of going to press. Revised November 2012
Adjustable Vent
Inner Shell
Insulation Layer
Grill Shelf Rails
Grill Shelves
Mild Steel Grate
Ash Collection Drawer
Smoke Vent
Thermometer
Styled Handles
Heat Proof Glass
Stainless Outer
Optional Stand
Robust Casters
Oven Diagram
2

Inka Charcoal Ovens, The Swan Centre,
Higher Swan Lane, Bolton, Lancashire, BL3 3AQ, UK
[phone]
[email protected]
www.inka.co.uk
Information accurate at time of going to press. Revised November 2012
General structure: Inka Charcoal Ovens consist of a single structure stainless
steeloutercase,withaninsulatedinner‘rebox’.Theovenisspeciallydesigned
to maintain high cooking temperatures and to avoid heat loss.
Grills: The P-600 oven comes with 1x stainless steel solid bar grill shelf, this
canbeplacedatdierentheightstovarytheintensityoftheheatandcooking
temperature.
Glass door: The specialist high temperature glass is able to withstand
temperatures upto 750oC. Use of a glass door makes it possible to observe the
coals and food being cooked whilst the door is closed. This maintains a more
constant temperature and burns less fuel.
Draft regulator: The draft system is used to regulate the amount of air in the
cooking chamber. This allows users to regulate the desired heat and burn rate
of the fuel.
3
INKA P-600

Inka Charcoal Ovens, The Swan Centre,
Higher Swan Lane, Bolton, Lancashire, BL3 3AQ, UK
[phone]
[email protected]
www.inka.co.uk
Information accurate at time of going to press. Revised November 2012
General structure: Inka Charcoal Ovens consist of a single structure stainless
steeloutercase,withaninsulatedinner‘rebox’.Theovenisspeciallydesigned
to maintain high cooking temperatures and to avoid heat loss.
Grills: The P-900 oven comes with 2x stainless steel solid bar grill shelves, these
canbeplacedatdierentheightstovarytheintensityoftheheatandcooking
temperature.
Glass door: The specialist high temperature glass is able to withstand
temperatures upto 750oC. Use of a glass door makes it possible to observe the
coals and food being cooked whilst the door is closed. This maintains a more
constant temperature and burns less fuel.
Draft regulator: The draft system is used to regulate the amount of air in the
cooking chamber. This allows users to regulate the desired heat and burn rate
of the fuel.
4
INKA P-900

Inka Charcoal Ovens, The Swan Centre,
Higher Swan Lane, Bolton, Lancashire, BL3 3AQ, UK
[phone]
[email protected]
www.inka.co.uk
Information accurate at time of going to press. Revised November 2012
Installation Requirements
Pleasenotethesearestandardrecommendations,eachsiteisdierent,itisthe
responsibility of the end-user to ensure adequate installation requirements.
FLOOR: The Inka must be installed on a non-combustible oor that extends
300mm forward of the front and 100 mm to each side/back.
SIDES: Areproofenclosureisnotrequiredifthereisaminimumgapof500mm
(sides and rear) to combustible materials and other appliances. If this distance
cannot be achieved a re/heat proof enclosure should be constructed with a
minimum gap of 50mm between the Inka and each of the internal walls (sides
and back) of the enclosure.
Recommendedconstructionofreproofenclosure:studpartitionwallcladwith
proprietaryreboard(e.g.GyprocFireline,KnaufFireboard)and2mmstainless
steel plate.
EXRACTION:Forfullinformationaboutextractionpleaseseep2
5

Inka Charcoal Ovens, The Swan Centre,
Higher Swan Lane, Bolton, Lancashire, BL3 3AQ, UK
[phone]
[email protected]
www.inka.co.uk
Information accurate at time of going to press. Revised November 2012
Oven Start-Up
Beforecookingforthersttime,theovenshouldbelitandheatedto350oC for
60 minutes to allow any oil or cleaning products used during the manufacturing
processtobeburnedo.
Starting up
1. Open the door of the oven and remove the grill shelf / shelves.
2. Load charcoal fuel onto the steel grate inside the oven. The amount of charcoal
willdependonthesizeoftheoven.Seetablebelowforaverageusage.
3. To light the charcoal, rake the charcoal together into a small pile (ensure the
coalisnotspreadoutandat).Thiswillensurethecoalslightquickerand
burnmoreevenly.Youcanuserelighters,acharcoalstarteroraLooftlighter
(or similar) to start the coals. If you are using re lighters, ensure all the
articialacceleranthasburnedobeforecommencingcookingotherwiseit
will taint the food.
4. Fully open the lower and upper draft vents to allow as much air as possible
into the oven then light the coals. Then close the door and allow the coals to
catchre.
5. When the coals are red hot, spread them evenly across the desired place
on the grate. Please note, spreading coals across just half the grate is an
eectivewayofconcentratingtheheatandprovidinga‘resting’areaforfood
(in the half of the oven that does not have coals).
Model Number Lunch Service Dinner Service Total Daily Use
P-300 3-4 kgs 4-6 kgs 7-10kgs
P-600 4-6kgs 6-8 kgs 10-16kgs
P-900 6-8 kgs 8-10 kgs 14-18kgs
IMPORTANT:
• Flammableliquids(petrol,paranorsimilar)mustNOTbeusedtolightthe
charcoal.
• Food must NOT be inside the oven during the lighting process.
• Once coals have been lit and the oven is hot, insulated gloves must be used
to prevent injury. Do not touch the oven without protection for your hands.
6

Inka Charcoal Ovens, The Swan Centre,
Higher Swan Lane, Bolton, Lancashire, BL3 3AQ, UK
[phone]
[email protected]
www.inka.co.uk
Information accurate at time of going to press. Revised November 2012
Daily Operation
After lighting the oven (see page 8), wait 30-45 mins until the coals are well lit
and the oven is up to desired temperature.
Close the lower draft vent, and keep the upper draft vent open or partially
open to slow down the burn rate of the coals. This depends on your desired
temperature and type of food you plan to cook.
Replace the grill shelf / shelves in preparation for cooking. The height of the
grill shelf depends on the type of food being cooked. Please use the information
belowasaguideline:
Grill shelf position Appropriate food
Top shelf / further away from the
coals
Roasts,pizzaorbreads,dishesau
gratin
Lower shelf / closer to the coals Meat,vegetables,sh
Duringtherstfewoccasionstheovenisused,youmayndcookingtimeare
dierenttotraditionalcookingmethods.Pleasepaycloseattentiontocooking
speeds in order to achieve the best results.
IMPORTANT:
• If smoke comes out of the door when it is closed (for example when cooking
fatty foods or a high volume of food), open both draft vents until the smoke
dissipates.
• Refuelling the oven during service is not recommended as new charcoal will
lowerthetemperatureoftheoven,decreasingcookingeciency.
7

Inka Charcoal Ovens, The Swan Centre,
Higher Swan Lane, Bolton, Lancashire, BL3 3AQ, UK
[phone]
[email protected]
www.inka.co.uk
Information accurate at time of going to press. Revised November 2012
Extraction
AllInkaCharcoalOvensmustbeextractedusingeither:
(a) An appropriate 150mm diameter extraction pipe securely connected to the top of the
ovenueandventeddirectlyintotheopenair
O r,
(b) Overhead extraction canopy capable of extracting 0.5m2per second, where the canopy
hood extends at least >300mm further than the oven door when open
It is the users responsibility to ensure all fuel is selected, burned and disposed
of in accordance with DEFRA and Environment Agency (UK) or relevant local
country controls and legislation regarding the burning of solid fuels.
WARNING: When charcoal, wood and other solid fuels are
burned, they can produce noxious gas (carbon monoxide
besides others). It is the responsibility of the user to ensure
all extraction systems and procedures are adequately
installed and maintained to ensure smoke & fumes are
removedaseectivelyaspossible.Failuretodosocould
result in personal injury or death.
8

Inka Charcoal Ovens, The Swan Centre,
Higher Swan Lane, Bolton, Lancashire, BL3 3AQ, UK
[phone]
[email protected]
www.inka.co.uk
Information accurate at time of going to press. Revised November 2012
Fuel Usage
InkaCharcoalOvensshouldbeonlybepoweredbyapprovedsolidfuels,including:
• Restaurant grade wood charcoal
• Coconut charcoal
Inka Charcoal Ovens recommends Big K Products Limited in the UK. For countries
outside the UK, we recommend users ensure their supplier is able to supply
charcoal grades of a similar level and conformance.
BIG K Products U.K. Limited
Whittington Hill
Stoke Ferry, Norfolk PE33 9TE
SalesDirectTel:01366501604
SalesDirectFax:01366500395
E.Mail:[email protected]
Website:www.bigk.co.uk
WARNING: Use of non-approved fuel could lead to the
warranty becoming invalid. Use of wood, seasoned logs,
compressed wood logs, coal or any solid fuel (other than
charcoal) is not recommended.
9

Inka Charcoal Ovens, The Swan Centre,
Higher Swan Lane, Bolton, Lancashire, BL3 3AQ, UK
[phone]
[email protected]
www.inka.co.uk
Information accurate at time of going to press. Revised November 2012
CAUTION: To reduce the risk of re, please read and
follow this handbook and recommendations carefully. The
appliance is an indoor barbeque fuelled by charcoal, the
proximity of combustible materials needs to be carefully
managedtoreducetheriskofre.
WARNING: Improper installation, adjustment, alteration,
service or maintenance may result in damage to property,
personal injury or death. Read the installation, operation
and maintenance instructions thoroughly before installing,
using or servicing this equipment.
It is recommended that this oven be maintained and
serviced only by authorised professionals.
10

Inka Charcoal Ovens, The Swan Centre,
Higher Swan Lane, Bolton, Lancashire, BL3 3AQ, UK
[phone]
[email protected]
www.inka.co.uk
Information accurate at time of going to press. Revised November 2012
11
Warranty Information & Serial Number
Manufacturer’sWarranty:TermsandConditions
1. The 1 year manufacturer’s warranty covers all manufacturing defects as
veriedbyourServiceTeam.Thewarrantystartdateisthedateofpurchase
(please see below).
2. The manufacturer’s warranty does not cover damage, defects or mechanical
breakdown due to inappropriate use, the unit being dropped or knocked, or
damage due to inappropriate or excessive fuel.
3. The manufacturer’s warranty does not cover normal wear and tear of parts or
damage caused during maintenance of the unit.
4. The manufacturer’s warranty is invalid if work or maintenance is undertaken
by engineers or service personnel other than those approved by DelSpin Ltd
(Inka Charcoal Ovens).
5. The manufacturer’s warranty does not cover labour or expenses, and is only
valid for the mainland UK.
Model:
SerialNumber:
DateofPurchase:
NameofPurchaser:
Location:
DespatchDate:
QualityCheckedby:
Thank you for your custom.

Inka Charcoal Ovens
The Swan Centre,
Higher Swan Lane,
Bolton, Lancashire,
BL3 3AQ, UK
[phone]
[email protected]
www.inka.co.uk
