InoTec InoBEAM F30 D Installation instructions

EN
Read this entire original operating manual before starting work.
Original Operating Manual
InoBEAM F30 delivery pump

EN
Page 2
Thank you for trusting INOTEC. By purchasing you have opted for a quality product.
If you have any suggestions or any issues, we would be delighted to hear your suggestions for improvement
and
your feedback. Speak to the sales representative
assigned to you or, in urgent cases, contact us directly.
We work constantly to further develop our products and reserve the right to make changes for technical reasons
relating to building legislation.
Yours faithfully
INOTEC GmbH
Legal notice
Address: INOTEC GmbH
Daimlerstraße 9-11
79761 Waldshut-Tiengen
Germany
Tel.: [phone]
Fax: [phone]
Email: [email protected]
Web: www.inotec-gmbh.com
Last updated: April 2021
Document number: 10041083-OBA-EN

Page 3
Contents
1 General information...................................................................................................... 5
1.1 Information about this manual................................................................................................................................5
1.2 Symbol explanation .................................................................................................................................................5
1.3 Information about this manual................................................................................................................................5
1.3.1 Purpose of this operating manual .......................................................................................................................5
1.3.2 Disclaimer...........................................................................................................................................................5
1.3.3 Warranty ............................................................................................................................................................5
1.3.3.1 Exercising claims.................................................................................................................................................6
1.3.3.2 Warranty claims..................................................................................................................................................6
1.3.4 Carrying out repairs............................................................................................................................................6
2 Safety ............................................................................................................................ 6
2.1 Intended use..............................................................................................................................................................6
2.2 General risk sources..................................................................................................................................................7
2.2.1 Notices in the operating manual .........................................................................................................................8
2.2.2 Performing checks before starting work..............................................................................................................8
2.2.3 Conversions and changes ...................................................................................................................................8
2.2.4 Cleaning and maintaining the machine...............................................................................................................9
2.2.5 Changing the location of the machine................................................................................................................9
2.3 Notices on the machine ...........................................................................................................................................9
2.4 Personnel qualification...........................................................................................................................................10
2.5 Responsibility of the operator...............................................................................................................................10
2.6 Personal protective equipment (PPE) ....................................................................................................................10
3 Technical data............................................................................................................... 11
3.1 Rating plate ............................................................................................................................................................11
3.2 Electric control system, mixing capacity, weight, dimensions.............................................................................11
3.3 Mortar pressure gauge...........................................................................................................................................11
3.4 Material hopper ......................................................................................................................................................11
3.5 Motor ...................................................................................................................................................................11
3.6 Pump shaft ..............................................................................................................................................................11
3.7 Rotor/stator.............................................................................................................................................................11
3.8 Noise emissions.......................................................................................................................................................11
3.9 Operating conditions..............................................................................................................................................11
4 Assembly and function ............................................................................................... 12
4.1 Scope of delivery of inoBEAM F30 ........................................................................................................................12
4.2 Functionality............................................................................................................................................................12
4.3 Components ............................................................................................................................................................12
4.3.1 Frame with material hopper incl. pump housing, pump shaft and wheels .........................................................13
4.3.2 Rotor/stator with mortar pressure gauge ..........................................................................................................13
4.3.3 Drive unit .........................................................................................................................................................13
4.3.4 Switching cabinet .............................................................................................................................................14
4.4 Displays, controls and connections .......................................................................................................................14
4.4.1 Pump shaft.......................................................................................................................................................14
4.4.2 Rotor/stator ......................................................................................................................................................15
4.5 Operating modes ....................................................................................................................................................15
4.6 Accessories ..............................................................................................................................................................16
4.7 Spare parts and diagrams ......................................................................................................................................23
4.7.1 Overview of Basic module inoBEAM F30...........................................................................................................23
4.7.2 Pump shaft.......................................................................................................................................................24
4.7.3 Rotor/stator ......................................................................................................................................................24
4.7.4.1 Pump set “D”-F30 ...........................................................................................................................................25
4.7.4.2 Pump set “R”-F30 ...........................................................................................................................................25
4.7.4.3 Pump set “HP”-F30 .........................................................................................................................................25
4.7.4.4 Assembly: Pressure flange with check valve ......................................................................................................26
4.7.5 Drive unit .........................................................................................................................................................27
4.7.6 Switching cabinet/control system......................................................................................................................27
4.7.7 Sealing unit ......................................................................................................................................................28
5 Transport and storage ................................................................................................. 29
5.1 Safety notices for transport...................................................................................................................................29

EN
Page 4
5.2 Transport inspection ...............................................................................................................................................29
5.3 Damage report........................................................................................................................................................29
5.4 Complaints...............................................................................................................................................................29
5.5 Packaging ................................................................................................................................................................29
5.6 Storage ...................................................................................................................................................................29
6 Commissioning ............................................................................................................ 30
6.1 Safety during installation.......................................................................................................................................30
6.2 Installation location requirements ........................................................................................................................30
6.3 Delivery condition of the machine ........................................................................................................................30
6.4 Assembling the pump shaft, rotor/stator and mortar pressure gauge ..............................................................30
6.5 Connecting the power supply................................................................................................................................30
7 Operation, use ............................................................................................................. 31
7.1 Safety during operation.........................................................................................................................................31
7.2 Activities before use...............................................................................................................................................31
7.2.1 Preparing the machine (pump set “D” and “R”) ...................................................................................................31
7.2.2 Preparing the machine (pump set “HP”) ...............................................................................................................31
7.2.3 Adding material to the material hopper ................................................................................................................32
7.3 Activities during operation ....................................................................................................................................32
7.3.1 Preparing and starting the conveying process (pump sets “D” and “R”)................................................................32
7.3.2 Preparing and starting the conveying process (pump set “HP”) .............................................................................33
7.3.3 Conveying process during operation.....................................................................................................................33
7.3.4 Starting the spraying process (pump sets “D” and “R”) ........................................................................................33
7.3.5 Starting the spraying process (pump set “HP”)......................................................................................................33
7.3.6 Checking operating performance..........................................................................................................................34
7.3.7 Topping up material..............................................................................................................................................34
7.3.8 Changing material................................................................................................................................................34
7.3.9 Change of location on the construction site..........................................................................................................34
7.3.10 Work break/end of work.......................................................................................................................................34
7.3.11 Cleaning the machine...........................................................................................................................................34
8 Areas of application .................................................................................................... 35
9 Cleaning........................................................................................................................ 36
9.1 Safety during cleaning ...........................................................................................................................................36
9.2 Cleaning process (pump set “D”)...........................................................................................................................36
9.3 Cleaning process (pump set “R”) ...........................................................................................................................37
9.4 Cleaning process (pump set “HP”).........................................................................................................................37
9.5 Decommissioning....................................................................................................................................................38
10 Maintenance............................................................................................................... 38
10.1 Safety during maintenance work........................................................................................................................38
10.2 Maintenance plan: Time and frequency .............................................................................................................39
10.3 Regreasing the sealing unit .................................................................................................................................39
10.4 Wear limit for pump shafts .................................................................................................................................39
10.5 Wear limit for rotor/stators ................................................................................................................................39
11 Faults, causes and solutions ..................................................................................... 40
11.1 Safety while rectifying faults...............................................................................................................................40
11.2 What to do in the event of any faults.................................................................................................................40
12 Dismantling and disposal ......................................................................................... 43
12.1 Safety while dismantling .....................................................................................................................................43
12.2 Dismantling ...........................................................................................................................................................43
12.3 Disposal .................................................................................................................................................................43
13 Systems....................................................................................................................... 44
13.1 EC declaration of conformity ...............................................................................................................................44
13.2 General Terms of Business of the company INOTEC GmbH...............................................................................45
13.3 Circuit diagram of the machine ...........................................................................................................................46
13.4 Circuit diagram of the switching cabinet............................................................................................................47
14 Order form.................................................................................................................. 48
15 Index .......................................................................................................................... 49
16 Locations .................................................................................................................... 50

Page 5
EN
Chapter 1 General information
1 General information
1.1 Information about this manual
• This manual helps to ensure safe and efficient use of
the machine.
• Operating personnel must have carefully read through
and understood this manual before starting any work.
• Compliance with all the specified safety instructions is
a basic prerequisite for working safely.
• This manual is a component of the machine and must
be stored within direct proximity of the machine, acces-
sible to operating personnel at all times.
• In addition to the notices in these instructions, the local
accident prevention guidelines and national occupa-
tional health regulations also apply.
1.2 Symbol explanation
Hazard notices feature symbols to make them easier to
identify. These indicate the severity of the hazard.
• You must observe this information.
!
DANGER DANGER indicates an immediate hazard.
Death or serious injuries may result from non-compliance.
!
WARNING WARNING indicates a potentially dangerous
situation. Death or serious injuries may result from a failure
to avoid these situations.
!
CAUTION CAUTION indicates a potentially dangerous
situation. Minor or slight injuries may result from failure to
avoid these situations or damage to the machine or some-
thing in its vicinity.
High pressure variants: inoBEAM F30 “HP”
There are three pump sets for the inoBEAM F30.
- Set “D”-F30 for spray applications
- Set “R”-F30 for floor levelling compounds
- Set “HP”-F30 for airless spray-on smoothing compounds
HIGH
PRESSURE
In these instructions, all deviating or supple-
mentary specifications for the HP variant are
shown in a box with the symbol next to it.
NOTE

NOTICE draws your attention to useful tips for
effectively handling the machine.
1.3 Information about this manual
1.3.1 Purpose of this operating manual
The operating manual is used to provide information to the
operating manager, assembly fitters and machine operators
on the construction site. It contains important instructions
for safe use, optimum results and a long service life.
!
DANGER Risk of incorrect operation
Failure to observe the operating manual could put the
operator’s life and health at risk and damage the ma-
chine.
• Read this operating manual carefully before passing it
on to your assembly fitters or operators.
• Please ensure that assembly fitters and operators read
this operating manual carefully before they start install-
ing and commissioning the machine.
• Always keep the operating manual to hand and in a leg-
ible condition.
1.3.2 Disclaimer
All technical information, data and instructions for use con-
tained in this operating manual reflect the state of the art at
the time of printing and are based on our experience thus
far and the best of our knowledge.
The manufacturer cannot be held liable for any damages as
a result of:
• Failure to comply with this manual
• Improper use
• Assignment of non-trained personnel
• Unauthorised alterations
• Technical changes
• Use of non-approved spare parts
1.3.3 Warranty
Statutory warranty periods of 12 months from the date of
purchase/the date of invoice of the industrial end customer
apply to our machinery.

Page 6
EN
Chapter 2 Safety
1.3.3.1 Exercising claims
In the event of a warranty claim, send the entire machine,
along with the invoice, to our headquarters in Waldshut-
Tiengen.
Contact our free INOTEC service hotline beforehand on
[phone].
1.3.3.2 Warranty claims
Claims apply only where material or manufacturing faults
exist and where machinery has been used properly. Wear
parts are not covered by the warranty. All claims shall be-
come void if third-party parts are installed, where the ma-
chinery has been improperly used or stored and in the event
of obvious non-compliance with the operating manual. In
this connection, we refer you to our General Terms of Busi-
ness.
1.3.4 Carrying out repairs
Repairs may only be carried out by employees at our
INOTEC service centres.
2 Safety
2.1 Intended use
• The inoBEAM F30 is used to convey pumpable and
paste-like materials (mineral or organic products) with
a particle size of up to a maximum of 6 mm. Feed the
delivery pump exclusively with paste-like material (e.g.
with material in buckets). The material is transported
to the rotor/stator via the pump shaft.
• The material is pumped to the processing location by
means of mortar hoses. There it is either poured onto
the floor or applied to walls or ceilings with the appro-
priate spray guns or glue guns.
• Only use the machine within its limits of application
and according to the technical data.
• Pay particular attention to the safety and warning
notices outlined in this original operating manual.
!
DANGER Failure to use the
inoBEAM F30 properly could put the user’s
life and limb at risk and damage the
inoBEAM F30 or other assets.
Safety requirements for mortar delivery machines (suction
pumps) can be found in the following standards, among
others:
• Industrial Safety Regulation, accident prevention regu-
lations “Principles of Prevention” (BetrbSichV, BGV A1)
incl. the explanations and specifications of BGR A1.
• BG 183, rule of the German Employer's Liability Insur-
ance Association for the Construction Industry, mortar
conveying and mortar spraying machines.
• DIN EN 12001, conveying, spraying and distribution
machines
• For concrete and mortar - Safety requirements; German
version EN 12007
!
WARNING Danger due to misuse!
Misuse of the inoBEAM F30 may lead to dangerous
situations.
• Never use the inoBEAM F30 delivery pump to create
other products, such as food.
• Never operate the inoBEAM F30 delivery pump using
values outside the ranges specified in the “Technical
Data”.

Page 7
EN
Chapter 2 Safety
HIGH
PRESSURE
!
DANGER Observe the following in-
structions for safe handling of the ma-
chine:
1. Only use the inoBEAM F30 “HP” with a
mortar pressure gauge.
2. Only use labelled high-pressure hoses
with at least 120 bar operating pressure.
HIGH
PRESSURE
The high-pressure variant inoBEAM F30 “HP”
is NOT designed to be used as a cleaning
device.
2.2 General risk sources
!
DANGER Electrical voltage.
Danger of death due to electric shock.
• Work on the electronic control system may only be per-
formed by a qualified electrician.
• Switch off the machine and pull out the mains plug.
• Secure the machine against unexpectedly being switched
back on.
• Only connect the pump to regulation construction site
power distribution points with type B FI circuit breakers
(30 mA).
• The connection must be fused with 16 A.
• The cross-section of the supply cable is at least 2.5 mm2
at 230 V 1 PH.
• Connect the supply cable to the 230 V / 16A “feed
supply” CEE plug.
• All operating equipment on the construction site must
generally be connected according to BGI/GUV-I 608.
!
DANGER Rotating shafts.
Danger of death due to being pulled into the ma-
chine and crushed.
When the motor is running, the pump shaft rotates
in the material hopper!
• Do not reach into the rotating shaft.
• Do not place any objects into the rotating shaft.
1. Before working on the pump shaft, interrupt the external
power supply. Loosen the screws of the protective screen
above the material hopper only when the machine is
switched off.
2. To do this, press the red push button on the switching
cabinet.
3. Pull out the mains plug.
4. Secure the machine against unexpectedly being switched
back on.
!
DANGER Pressurised conveyor hoses.
Risk of injury and risk of property damage due to
escaping and/or flying material, and/or bursting
conveyor hoses!
• Before disconnecting the conveyor hoses, make sure that
the hoses are depressurised. To do so, check the pressure
indicator on the mortar pressure gauge. The pressure in-
dicator must display 0 bar!
• Before opening the hose coupling, let the inoBEAM F30
run in reverse to reduce any pressure!
• Use only conveyor hoses which, depending on the set
used, are permissible with an operating pressure of 40
bar (set “D” and “R”) or 230 bar (set “HP”), and are in
technically perfect condition (e.g. do not have any cracks
or other external damage!).
HIGH
PRESSURE
!
DANGER Using the high-pressure hose.
• Check the high-pressure hose before
each use and replace any damaged hoses
immediately.
• Never repair defective high-pressure
hoses yourself.
• Avoid severely bending or kinking the
high-pressure hose (smallest bending
radius approx. 20 cm)
• Never pull on the high-pressure hose to
move the machine.
• Never clean high-pressure hoses with sol-
vents.
• Lay the high-pressure hose so that there
is no risk of tripping and make sure that
no one drives over the high-pressure
hose.

Page 8
EN
Chapter 2 Safety
2.2.2 Performing checks before starting work
!
WARNING Defects or damage can put the safety of
operating personnel at risk and impair the functional-
ity of the machine.
• Before commencing work, check the machine and con-
veyor hoses for any obvious external damage or defects.
• Do not commission the machine if you notice any dam-
age to or defects in the machine or to the conveyor hos-
es.
• Ensure that the damage and/or defects are rectified.
HIGH
PRESSURE
!
DANGER Observe the following points
before each commissioning:
1. Do not use faulty equipment.
2. Secure the spray gun.
3. Check the permissible operating pressure
of the high pressure hose and the spray
gun. Do not kink the high-pressure hose.
4. Check all connecting parts (e.g. union
nuts) for tightness.
5. Check the pump unit for tight fit.
2.2.3 Conversions and changes
!
DANGER Conversions or changes can put the safe-
ty of operating staff at risk and impair the functional-
ity of the machine.
• Do not make any changes, additions or conver-
sions to the machine without first consulting
Inotec GmbH and obtaining its written approval. Other-
wise, the operating license will become void.
2.2.1 Notices in the operating manual
HIGH
PRESSURE
!
WARNING ATTENTION:
Risk of injury due to injection!
The spraying pressures created by the
high-pressure pump are extremely high!
1. Never touch the spray with your fingers,
hands or other parts of your body.
2. Look for weaknesses or leaks in the high
pressure hose. Never try to seal leaking
material with your hands, shoes or with
a cloth.
3. Never point the spray gun at yourself,
other people or animals.
4. Never use the spray gun without the
spray guard.
5. Before each operation, make sure that
the trigger lock on the gun is working.
Flip the trigger safety on the gun when-
ever spraying is interrupted.
6. In case of injury, do not treat this spray
injury as a harmless cut. In the event of a
skin injury caused by coating materials or
solvents, seek medical attention imme-
diately for rapid, specialised treatment.
Inform the doctor about the coating ma-
terial or solvent used.
!
CAUTION Safety notices in the operating manual
alert the operating personnel to any immediate dan-
ger. Please observe all the technical and hazard notic-
es in this operating manual.

Page 9
EN
Chapter 2 Safety
2.2.4 Cleaning and maintaining the machine
!
WARNING Cleaning and maintenance work can put
the safety of operating staff at risk and impair the
functionality of the machine.
1. Switch off the machine and pull out the mains plug.
2. Secure the machine against unexpectedly being
switched back on.
3. Before cleaning with the water jet, cover all the open-
ings that water must not penetrate into for safety and
functional reasons.
4. After cleaning, remove all the covers which were at-
tached to protect against the water.
HIGH
PRESSURE
!
DANGER Be sure to follow the instruc-
tions for cleaning and maintaining the
machine:
1. Depressurise the spray gun and the
high-pressure hose.
2. Secure the spray gun.
2.2.5 Changing the location of the machine
The inoBEAM F30 is equipped with two wheels, two swiv-
el castors and an extended handle on the frame. The in-
oBEAM can, therefore, be moved on the construction site
conveniently.
!
CAUTION Changing location can put the safety of
operating staff at risk and impair the functionality of
the machine.
1. Switch off the machine and pull out the mains plug.
2. Always install the machine in such a way that it is level
and stable.
3. Secure the machine against undesirable movements.
4. Reconnect the machine to the external power supply
before restarting the machine.
2.3 Notices on the machine
!
DANGER Safety notices on the machine make oper-
ating staff aware of imminent danger.
Warning notices are affixed to the inoBEAM F30, indicat-
ing the following:
• WARNING. Do not reach into the machine (1).
• WARNING! If the machine has been switched off at the
main switch or has suffered a power failure (2), wait 60
seconds before switching it on again.
• Before opening the housing, disconnect it from the
mains (3).
• This QR code will take you to the original operating man-
ual for the delivery pump and a 3D animation of its func-
tion (4).
• WARNING! In accordance with DGUV V3, a retest is re-
quired after every electrical modification to the machine
(5).
• The device may only be operated via a connector protect-
ed with an RCD (FI) IΔn ≤ 30 mA type B (6).
• Observe all the safety and hazard notices that are at-
tached to the machine.
• Always keep the safety and hazard notices in a clearly
legible condition.
2
1
6543
The QR code (4) on the switching cabinet is linked directly
to the original operating manual and to a 3D animation of
the functioning of the delivery pump.

Page 10
EN
Chapter 3 Technical data
2.4 Personnel qualification
INOTEC offers training sessions on operating the
inoBEAM F30. Use INOTEC service for the initial commis-
sioning of the machine; this also serves as an opportunity
to provide operators with training on how to operate the
mixer.
!
DANGER If the inoBEAM F30 is operated by unqual-
ified individuals, this could put the life and health of
the operating staff at risk and cause property damage
to the inoBEAM F30 or other assets.
2.5 Responsibility of the operator
• Only task trained or instructed staff with operating the
inoBEAM F30.
• Define employees’ responsibilities for operating, setting
up, maintaining and servicing the machine clearly.
• Only task untrained staff or individuals who have not re-
ceived any instruction with operating the machine when
there is a trained or instructed specialist available to su-
pervise them.
• Work on the electronic control system may only be per-
formed by a qualified electrician.
HIGH
PRESSURE
!
DANGER At high operating pressure,
pulling the trigger of the spraying device
causes a recoil force of up to 15 N.
• Be prepared for this recoil force oth-
erwise your hand may be pushed back
or you may lose your balance. This can
cause significant injuries.
2.6 Personal protective equipment (PPE)
!
CAUTION PPE – particularly gloves, safety boots,
safety clothing, a safety helmet, safety goggles, hear-
ing protection and respiratory protection – must be
used.
HIGH
PRESSURE
!
WARNING ATTENTION:
Risk of injury due to injection!
The spraying pressures created by the
high-pressure pump are extremely high!
1. Never touch the spray with your fingers,
hands or other parts of your body.
2. Look for weaknesses or leaks in the high
pressure hose. Never try to seal leaking
material with your hands, shoes or with
a cloth.
3. Never point the spray gun at yourself,
other people or animals.
4. Never use the spray gun without the
spray guard.
5. Before each operation, make sure that
the trigger lock on the gun is working.
Flip the trigger safety on the gun when-
ever spraying is interrupted.
6. In case of injury, do not treat this spray
injury as a harmless cut. In the event of a
skin injury caused by coating materials or
solvents, seek medical attention imme-
diately for rapid, specialised treatment.
Inform the doctor about the coating ma-
terial or solvent used.

Page 11
EN
Chapter 3 Technical data
3 Technical data
3.1 Rating plate
1
5
4
23
Item Component Value
1 Manufacturer, address and contact
details, CE marking
-
2 Name and type of machine -
3 Machine’s year of construction -
4 Machine number -
5Technical data
- Voltage
- Current
- Output
230 V
16 A
3.0 kW
You must always state the machine number if you would
like to order spare parts, have any queries or would like
to make a complaint. You will find this information on the
rating plate or on the delivery note.
3.2 Electric control system, pump output, particle size,
weight, dimensions
Mains voltage 230 V, 50 / 60 Hz
Mains supply 1 phase N. PE 16 A
(to be supplied by
customer)
Output 3.0 kW (frequency-
controlled)
Fuse min. 16 A
Delivery rate for set “D” & “R”
Delivery rate for set “HP”
max. 2 - 50 l/min.*
max. 8 l/min.*
Delivery range for set “D” & “R”
Delivery range for set “HP”
up to 80 m*
up to 30 m*
Delivery height for set “D” & “R”
Delivery height for set “HP”
up to 25 m*
up to 15 m*
to be processed max. 6 mm
Weight approx. 85 kg
Dimensions:
Length 1,450 mm
Width 530 mm
Height 700 mm
* Depending on the consistency of the material.
Material-dependent – observe the material manufacturer’s instructions.
3.3 Mortar pressure gauge
Maximum operating pressure
Set “D” & “R” 40 bar
Set “HP” 90 bar
3.4 Material hopper
Fill quantity approx. 50 l
3.5 Motor
Output/rotation speed fre-
quency-controlled
3.0 kW, 1 - 326 rpm
Installation position Motor horizontal
Electrical data f = 50 Hz , I = 11.2 A,
U = 230 V, IP 54
Insulation class F, ED = S1
Colour unvarnished
3.6 Pump shaft
Maximum height of augur
blades:
38 mm
Minimum height of augur
blades: (wear limit)
30 mm
3.7 Rotor/stator
Set “D” - D6-3 Eco Gold
- D4-1/2 output soft
with clamping strip
- D7-2.5 Mono Plus
- D8-1.5 maintenance-
free or with clamping
strip
Set “R” - R7-1.5
Set “HP” - Rotor/stator spray
3.8 Noise emissions
Sound power level LWA < 78 dB (A)
3.9 Operating conditions
Temperature range 2 - 45 °C
Relative humidity, maximum 80 %

Page 12
EN
Chapter 4 Assembly and function
4 Assembly and function
4.1 Scope of delivery of inoBEAM F30
The scope of delivery is generated using the components
ordered and can be checked using the delivery note.
inoBEAM F30 basic module (item no. 10041083)
• Frame
• 2 running wheels
• 2 swivel castors
• Plastic material hopper
• Cover for material hopper
• Gear motor
• Switching cabinet
• 3 m connecting cable
• Pump shaft
• Stainless steel pump housing
• Tool set
• Assembly, spray lubricant
• Operating manual
Pump set “D”-F30
for spray applications (18 l / 40 bar)
Item no. 10041913*
Pump set “R”-F30
for floor levelling compounds (50 l / 15 bar)
Item no. 10043416*
Pump set “HP”-F30
for airless spray-on smoothing compounds (8 l / 90 bar)
Item no. 10041888*
________________________________
* Scope of delivery, see accessories
4.2 Functionality
The inoBEAM F30 is used to convey pumpable materials
(mineral or organics products) with a particle size of up
to a maximum of 6 mm. The pump shaft transports the
material to the rotor/stator where the necessary pressure is
built up. The material is pumped to the processing location
by means of mortar hoses. There it is either poured onto
the floor or applied to walls or ceilings with the appropri-
ate spray guns or glue guns.
HIGH
PRESSURE
NOTE

Do not use a gun filter when
applying spray-on filler and similar mate-
rials, as the filter will become blocked.
NOTE

Note the optimum assembly sequence.
1. Push the pump shaft into the pump hopper.
2. Connect the rotor/stator and the suction flange to the
pump shaft.
3. Assemble the pressure flange with the mortar pressure
gauge and hose connection to the rotor/stator and lock
the two (set “D” and “R”) or three (set “HP”) tie rods
in place with the nuts.
4. Connect the mortar hose with the quick-release cou-
pling to the hose connection of the mortar pressure
gauge by closing both cam levers.
5. Assemble the appropriate spray head or one-handed
gun to the end of the mortar hose and connect the air
hose to the spray head.
6. Connect the supply cable to the 230V / 16A “feed
supply” CEE plug.
Functionality with remote control cable
7. Take the dummy plug out of jack for the remote con-
trol cable and insert the remote control cable into the
contact.
8. Connect the remote control cable to the material hose
and the air hose of the compressor by means of adhe-
sive tape or cable ties.
4.3 Components
3
2
1
Description of components
Item Component
1 Frame with material hopper
incl. pump housing, pump shaft, swivel
castors and wheels
2 Drive unit
3 Switching cabinet

Page 13
EN
Chapter 4 Assembly and function
4.3.1 Frame with material hopper incl. pump housing,
pump shaft and wheels
The machine can be moved around the construction site by
lifting it by its frame or by transporting it using the swivel
castors and wheels. The pump shaft is connected to the
motor and rotor/stator during operation, and rotates in the
pump housing, which is fitted with a protective screen.
View of the material hopper, and the pump shaft contained
within it.
4.3.2 Rotor/stator with mortar pressure gauge
The rotor and stator (see set “D”, “R” or “HP”) together
form the rotary displacement pump. The vacuum creates
a suction flow in the rotor/stator that presses the material
which is continuously provided by the pump shaft, into the
mortar hose. The mortar pressure gauge is used to monitor
the delivery pressure.
!
DANGER Excessively high operating pressure!
Machine parts or hoses can spring open accidentally
and injure the operator.
• Do not operate the machine without mortar pressure
gauges.
• Before disconnecting the conveyor hoses, make sure that
the hoses are depressurised. To do so, check the pressure
indicator on the mortar pressure gauge. The pressure in-
dicator must display 0 bar!
• Before opening the hose coupling, let the inoBEAM F30
run in reverse to reduce any pressure!
• Use only conveyor hoses which, depending on the set
used, are permissible with an operating pressure of
40 bar (set “D” and “R”) or 230 bar (set “HP”), and
are in technically perfect condition (e.g. do not have any
cracks or other external damage!).
HIGH
PRESSURE
!
DANGER Using the high-pressure hose.
• Check the high-pressure hose before
each use and replace any damaged hoses
immediately.
• Never repair defective high-pressure hos-
es yourself.
• Avoid severely bending or kinking the
high-pressure hose (smallest bending ra-
dius approx. 20 cm)
• Never pull on the high-pressure hose to
move the machine.
• Never clean high-pressure hoses with sol-
vents.
• Lay the high-pressure hose so that there
is no risk of tripping and make sure that
no one drives over the high-pressure
hose.
4.3.3 Drive unit
The spur gear motor drives the rotor/stator via the pump
shaft.

Page 14
EN
Chapter 4 Assembly and function
4.3.4 Switching cabinet
Connect the power supply plug on the switching cabinet (2)
to the external power supply (230 V / 50 Hz). The cross-sec-
tion of the supply cable must be at least 2.5 mm2. The in-
oBEAM F30 may only be run with an approved FI circuit
breaker (30 mA) RCD type B (30 mA).
The connection must be fused with 16 A. All the necessary
connections and controls for operating the machine are lo-
cated on the switching cabinet. It is firmly screwed to the
frame of the machine.
4.4 Displays, controls and connections
1
2
Description of the displays, controls and
connections
Item Component
1 Main and emergency stop switch
Green = ON, red = OFF
2 3-pole power supply plug
CEE 230 V / 16 A / 50 Hz.
Supply line: 230 V, 1 PH, 2.5 mm2.
3
1
2
Description of the displays, controls and
connections
Item Component
1 - Pump ON “Start”
- Pump OFF “0”
- Reverse pump “Back”
2 Pump rotation speed.
This rotary knob (potentiometer) is used to ad-
just the pump’s rotation speed
3Set “D” & “R”: Connection for remote control
Set “HP”: Connection for control cable of
mortar pressure sensor
NOTE

Working with and without remote control.
• When the remote control cable is plugged into the
switching cabinet, the machine is switched on and off
via the green push button at the end of the remote
control cable.
• When operating the machine without remote control,
the dummy plug on the switching cabinet must be
plugged into the remote control socket − otherwise,
the machine will not run.
4.4.1 Pump shaft
The pump shaft is connected to the motor via the drive
shaft and rotates during operation in the pump hopper.
The pump shaft is also connected to the rotor via a plug-in
connection. The pump shaft can be pulled out for cleaning
and maintenance work. Before removing the pump shaft,
switch off the machine and pull out the mains plug.

Page 15
EN
Chapter 4 Assembly and function
4.4.2 Rotor / stator
The choice of rotor/stator depends on the set chosen (see
scope of delivery, accessories or spare parts and diagrams)
and the planned application.
• Pump set “D”-F30
(rotor/stator D6-3 Eco Gold)
for spray applications (18 l / 40 bar)
Item no. 10041913
• Pump set “R”-F30
(rotor/stator R7-1.5)
for floor levelling compounds (50 l / 15 bar)
Item no. 10043416
• Pump set “HP”-F30
(rotor/stator spray)
for airless spray-on smoothing compounds (8 l / 90 bar)
Item no. 10041888
HIGH
PRESSURE
!
DANGER Replacing rotor/stator.
Dismantling may only be carried out by
instructed persons.
• Ensure that the machine is depressurised.
The pressure gauge must display 0 bar.
• Do not reach into the rotor when it is in
motion.
• Wear tight-fitting clothes and take pre-
cautions with long hair.
• Wear safety goggles
1. Switch off the pump via the push button
and pull out the mains plug.
2. Pull the plug out of the socket on the
switching cabinet.
3. Loosen the three nuts on the pressure
flange and set it aside.
4. Now replace the rotor/stator.
5. Replace the pressure flange and tighten
the three nuts.
6. Insert the plug into the socket on the
switching cabinet.
4.5 Operating modes
The inoBEAM F30 can be loaded with ready-mixed material
from buckets or the feed pump can be combined, for exam-
ple with the inoMIX S50 continuous mixer.

Page 16
EN
Chapter 4 Assembly and function
inoBEAM F30 set “HP”
inoBEAM F30 set “R”
inoBEAM F30 set “D”
4.6 Accessories
The following accessories can be supplied for the inoBEAM F30.
Water/air hose
• For universal use, e.g. air, water
• GEKA couplings crimped with sleeves on both sides
Technical data:
Max. operating pressure: 20 bar
Temperature range: -20 up to +90°C
Ø
1/2”
1/2”
1/2”
Length:
10 m
15 m
20 m
Item no.
10022000
10022001
10022002
P
P
P
P
P
P
—
—
—
Ultralight hose
- with mortar coupling
Ø
25 mm
Length
10 m
Item no.
10043874 P P —
Inotec mortar hose
• Abrasion-resistant special hose for pumping highly pressurised
wet mortar; largely kink-proof
• For an operating pressure of 40 bar with 3 times the reliability
• Yellow on the outside: less heat builds up in the event of sun
exposure
• With mortar hose couplings, M-piece and rotating V-piece
(only with diameters of 25 mm)
• With cam levers on the M-piece
Technical data:
Operating pressure: 40 bar / bursting pressure: 120 bar
Ø
25 mm
25 mm
25 mm
35 mm
35 mm
Length
10 m
15 m
20 m
10 m
20 m
Item no.
10008346-001
10008346-002
10008346-003
10022032
10008346-007
P
P
P
P
P
P
P
P
P
P
—
—
—
—
—
Inotec mortar hose
• Abrasion-resistant special hose for pumping highly pressurised
wet mortar; largely kink-proof
• For an operating pressure of 40 bar with 3 times the reliability
• Black on the outside
• With mortar hose, M-piece couplings and
rotating V-piece (only at Ø 25 mm)
• With cam levers on the M-piece
Technical data:
Operating pressure: 40 bar / bursting pressure: 120 bar
Ø
40 mm
40 mm
Length
13.3 m
20 m
Item no.
10041544
10041545
P
P
P
P
—
—
Reprofiling spraying device
• Reprofiling spraying device, 35 V with nozzle pipe 12 mm, connection 35 V piece
• Nozzle pipe 12 mm
• Nozzle pipe 15 mm
Item no.
10023309
10022789
10022790
P
P
P
—
—
—
—
—
—
Flushing hose
• For clearing blockages in mortar hoses
Length
10 m
Item no.
10024385 P P —
230 V / 3 x 2.5 mm2connecting cable
• 16 A Schuko plug and CEE coupling
Length
15 m
Item no.
10015126 P P P
3 x 2.5 mm2cable reel made from impact-resistant plastic
• Plastic cable reel with 33 m H07BQ-F3G2.5 cable
• Robust impact-resistant design, all-round rollover protection
• 4 European Schuko sockets (splashproof, with self-closing covers)
• Protection class: IP44
Length
33 m
Item no.
10044024 P P P
Wireless remote control
• Wireless remote control, 3-channels, with handheld transmitter, integrated antenna,
4-pole Harting plug with LED display
• Only for devices with a control voltage of 24 - 42 V
• Function: ON / OFF/ TEST
Item no.
10044303 P P —

Page 17
EN
Chapter 4 Assembly and function
Remote control cable with remote control switch Length
16 m
32 m
Item no.
10042464
10042465
P
P
P
P
—
—
Remote control extension cable without remote control switch
• For remote control cable
• For remote control switch
• For inoCOLL / inoCOLL Pro one-handed gun
Length
16 m
32 m
Item no.
10015210
10042463
P
P
P
P
—
—
Adapter for remote control cable
• m-tec plug – Harting socket
• m-tec socket – Harting plug
Item no.
10015121
10015120
P
P
P
P
—
—
Remote control switch
• With 0.2 m cable, indicator light and
4-pole Harting plug
Item no.
10015134 P P —
Hose holder
• For rapidly fixing hoses to the scaffold
Item no.
10018503 P P —
inoCOLL one-handed gun
• For bonding and basecoat mortars
• Whip hose 2 m, Ø 19 mm with an LW 24 mortar connection coupling
suitable for a 25 mm mortar hose
• For particle sizes up to 1.5 mm
Item no.
10024144 P— —
inoCOLL PRO one-handed gun
• For applying reinforcing mortar and finishing plaster up to 4 mm particle size
• Operating pressure: up to 40 bar
Item no.
10041950 P— —
Spray attachment for inoCOLL / PRO one-handed gun with GEKA air connection
• For spraying mineral and paste-like products
• With 10 mm nozzle
Item no.
10039322 P— —
Short spray pipe with mortar coupling 25 mm
Short, lightweight spray pipe with L24 coupling for spraying paste-like materials. Thanks to
the special nozzle geometry, a small compressor (air flow rate from 200 l/min.) is sufficient
to achieve a very good spray pattern. The air quantity can be regulated using the integrated
mini ball valve.
• For particle sizes up to 3 mm / • Suitable for a 25 mm mortar hose
Scope of delivery: Short spray pipe with 2 m whip hose (diameter 19 mm), with mortar
coupling 25 mm and 2 m air hose with GEKA coupling, without nozzles
Item no.
10039887 P— —
inoBEAM F30 set “HP”
inoBEAM F30 set “R”
inoBEAM F30 set “D”

Page 18
EN
Chapter 4 Assembly and function
Nozzles for:
- Spray attachment for inoCOLL / PRO one-handed gun
(10039322)
- Short spray pipe with mortar coupling 25 (10039887)
- Angled spray head with GEKA coupling (10039457)
- Short spray pipe as a set (10039886)
• Made from stainless steel
* For particle sizes up to 6 mm
Ø
4 mm
5 mm
6 mm
8 mm
10 mm
13 mm*
Item no.
10039271
10042461
10039220
10039221
10039222
10040941
P
P
P
P
P
P
—
—
—
—
—
—
—
—
—
—
—
—
MAI finishing coat device, straight
• With 25 mm M-piece coupling
• Including a 14 mm jet nozzle
Item no.
10024362 P— —
Jet nozzle
• For MAI finishing coat device
Ø
10 mm
12 mm
14 mm
16 mm
Item no.
10024378
10024379
10024380
10024381
P
P
P
P
—
—
—
—
—
—
—
—
Straight finishing coat device
• With 25 mm M-piece coupling
• incl. 14 mm finishing coat nozzle
Item no.
10024098 P— —
Finishing coat nozzles
• For finishing coat device, item no.: 10024098
Ø
10 mm
12 mm
14 mm
16 mm
Item no.
10024089
10024090
10024091
10024093
P
P
P
P
—
—
—
—
—
—
—
—
Plastic material hopper
Material container hopper as an optional attachment for the pump hopper for
increasing the container volume from 10 to 50 litres.
Item no.
10044178 P P P
Cover for material hopper
• For protecting the contents of the hopper against impurities
• Made from black plastic
Item no.
10041816 P P P
Bag mangle
• For emptying plastic bags with paste-like materials
Item no.
10041971 P P P
Straight decorative plaster spraying device
• Not including nozzle with 25 mm M-piece coupling
• For particle sizes up to 6.0 mm
Item no.
10024246 P— —
Nozzle for straight decorative plaster spraying device
• Made from stainless steel
Ø
8 mm
10 mm
12 mm
Item no.
10024071
10024065
10024066
P
P
P
—
—
—
—
—
—
Air quantity controller with EWO couplings
• For precisely adjusting the air quantity when spraying.
• Is connected between the air hose and spraying device.
Item no.
10017793 P— —
inoBEAM F30 set “HP”
inoBEAM F30 set “R”
inoBEAM F30 set “D”

Page 19
EN
Chapter 4 Assembly and function
Connecting coupling for compressors
EWO V-piece on GEKA
Item no.
10022353 P— —
Reducer coupling
• For connecting two mortar hoses or
reducing the machine outlet.
35 V-piece -> 25 V-piece
42 M-piece -> 35 M-piece
50 V-piece -> 35 M-piece
Item no.
10022101
10022097
10022100
P
P
—
P
P
P
—
—
—
Plaster piece with GEKA coupling
• For cleaning mortar hoses 25 V-piece
35 M-piece
25 M-piece
42 V-piece
50 M-piece
Item no.
10022113
10022114
10022112
10042213
10022116
P
P
P
P
P
P
P
P
P
P
—
—
—
—
—
Sponge balls (soft version)
• For cleaning material / mortar hoses
Ball
Ø
14 mm
20 mm
30 mm
45 mm
60 mm
Hose
Ø
13 mm
19 mm
25 mm
35 mm
40/50 mm
Item no.
10008116-001
10008116-003
10008116-004
10008116-005
10008116-006
—
P
P
P
P
—
P
P
P
P
P
P
—
—
—
Sponge balls (firm version)
• For cleaning material / mortar hoses
Ball
Ø
30 mm
45 mm
Hose
Ø
25 mm
35 mm
Item no.
10008116-007
10008116-008
P
P
P
P
—
—
230 V INOTEC Compact 330 compressor
The compact 230-volt compressor is ideal for many applications, such as spraying decora-
tive coatings, plaster or bitumen, for operating compressed air tools, and for painting, etc.
Technical data:
Operating pressure: 10 bar
Suction capacity: 330 l/min
Output: 2.05 kW
Dimensions (L x W x H): 396 x 473 x 598 mm
Weight: 32 kg
Item no.
10034389 P— —
Connection unit for 2 INOTEC Compact 330 compressors
consisting of check valve and EWO coupling
- 2 x V parts
- 1 x M-piece
Item no.
10019060 P— —
KAESER 230 V Compressor Premium Car 450/30W
The compact 230-volt compressor is ideal for many applications, such as spraying decora-
tive coatings, plaster or bitumen, for operating compressed air tools, and for painting, etc.
Technical data:
Operating pressure: 10 bar
Suction capacity: 450 l/min
Output: 2.2 kW
Dimensions (L x W x H): 870 x 560 x 590 mm
Weight: 86 kg
Item no.
10039227 P— —
inoBEAM F30 set “HP”
inoBEAM F30 set “R”
inoBEAM F30 set “D”

Page 20
EN
Chapter 4 Assembly and function
Set “HP”-F30
The inoBEAM F30 delivery pump can be converted into a high-performance 230 V air-
less spraying device using an optional set and just a few, easy steps. A delivery rate of 7-8
l/min is achieved with
3.0 kW when processing spray-on filler.
Scope of delivery: High pressure pump SPRAY, high pressure hose, airless
gun, pressure and suction flange “HP”, pressure control and tie rod “HP”, nozzle holder,
and nozzle
Item no.
10044242 — — P
Set “R”-F30 (Rotor/Stator R7-1.5)
Ø 115 mm, 50 l/min, 15 bar, e.g., for floor levelling compounds
Scope of delivery: Suction flange, pressure flange, mortar pressure gauge, rotor/stator R7-
1.5, coupling M part 50 (2” IT), 2 x M16 nuts, 2 x M16 threaded rods (330 mm), 2 x M16
double nuts
Item no.
10043416 —P—
Set “D”-F30 (Rotor/stator D6-3 Eco gold)
Ø 89 mm, 18 l/min, 40 bar, e.g., for spray applications
Scope of delivery: Pressure and suction flange with tension rods, mortar pressure gauge,
rotor/stator D6-3 Eco gold
Item no.
10041913 P— —
Static mixers
• Prevents/destroys lumps in mortar
• Diameter: 35 mm
• Length: 200 mm
• Including M-piece coupling 35 mm, and V-piece 35 mm
Item no.
10042362 —P—
Rotor D4-½ output
• Head marked in green
Stator D4-½ output, soft with clamping strip
Item no.
10022543
10022503
P
P
—
—
—
—
Rotor D6-3 “Eco Gold”
• Head marked in gold
Stator D6-3 “Eco Gold”
• Without twist protection, colour: gold
Item no.
10022552
10022509
P
P
—
—
—
—
Rotor R7-1.5
Stator R7-1.5 (maintenance-free)
Stator R7-1.5 with clamping strip
Item no.
10022887
10022522
10023395
—
—
—
P
P
P
—
—
—
Rotor D7-2.5 “S”
Stator D7-2.5 “Mono Plus” (maintenance-free)
Item no.
10022556
10042506
P
P
—
—
—
—
Rotor D8-1.5
• Head marked in yellow
Stator yellow D8-1.5 (maintenance-free)
Stator yellow D8-1.5 with clamping strip
Item no.
10022562
10022517
10022519
P
P
P
—
—
—
—
—
—
inoBEAM F30 set “HP”
inoBEAM F30 set “R”
inoBEAM F30 set “D”
