Inovelli Show Home ZW37 User manual

Federal Communications Commission (FCC) Statement
FCC Caution: Any changes or modifications not expressly approved by the party responsible for
compliance could void the user’s authority to operate this equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired operation.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause harmful interference
to radio or television reception, which can be determined by turning the equipment off and on,
the user is encouraged to try to correct the interference by one or more of the following measures:
Reorient or relocate the receiving antenna, increase the separation between the equipment and
receiver, connect the equipment into an outlet on a circuit different from that to which the receiver
is connected or consult the dealer or an experienced radio/TV technician for help. This equipment
should be installed and operated with minimum distance 8in (20cm) between the radiator and your body.
IC Caution: This device complies with Industry Canada licence-exempt RSS standard(s).
Operation is subject to the following two conditions: (1) this device may not cause interference, and
(2) this device must accept any interference, including interference that may cause undesired
operation of the device.
DECLARATION DE CONFORMITE D'INDUSTRIE CANADA For more information about the benefits
Ce périphérique a été testé et reconnu conforme aux limites spécifiées dans RSS-210. of Z-Wave, please visit:
Son utilisation est soumise aux deux conditions suivantes : http://z-wavealliance.org/about_z-wave_technology/
(1) il ne doit pas provoquer d'interférences gênantes et
(2) il doit tolérer les interférences re.ues, notamment cellessusceptibles d'en perturber le fonctionnement.
Show Home Products warrants this product to be free from manufacturing defects for a period of two years from the original date of consumer
purchase. This warranty is limited to the repair or replacement of this product only and does not extend to consequential or incidental damage
to other products that may be used with this product.
This warranty is in lieu of all other warranties, expressed or implied. Some states do not allow limitations on how long an implied warranty lasts or
permit the exclusion or limitation of incidental or consequential damage, so the above limitations may not apply to you.
This warranty gives you specific rights, and you may also have other rights which vary from state to state, if the unit should prove defective within the
warranty period.
Model: ZW37 (2-Channel) RISK OF FIRE
Power: 120V AC, 60Hz. RISK OF ELECTRICAL SHOCK
Signal (Frequency): 908.42 MHz. RISK OF BURNS
Maximum load for the Z-Wave controlled outlets: CONTROLLING APPLIANCES:
10Amp Max * 2-Channel (10Amp Total, not per outlet) EXERCISE EXTREME CAUTION WHEN USING Z-WAVE DEVICES TO CONTROL
Range: Up to 100 feet line of sight between the Wireless Controller APPLIANCES. OPERATION OF THE Z-WAVE DEVICE MAY BE IN A DIFFERENT
and the closest Z-Wave receiver module. ROOM THAN THE CONTROLLED APPLIANCE, ALSO AN UNINTENTIONAL ACTIVATION
Operating Temperature Range: 32-104° F (0-40° C) MAY OCCUR IF THE WRONG BUTTON ON THE REMOTE IS PRESSED. Z-WAVE DEVICES
For indoor use only. MAY AUTOMATICALLY BE POWERED ON DUETO TIMED EVENT PROGRAMMING.
Specifications subject to change without notice due to continuing DEPENDING UPON THE APPLIANCE, THESE UNINTENDED OR UNINTENTIONAL
product improvement OPERATIONS COULD POSSIBLY RESULT IN A HAZARDOUS CONDITION. FOR THESE
Dimensions: 3.19" x 2.56" x 1.30" REASONS, WE RECOMMEND DO NOT RETURN THIS PRODUCT TO THE STORE, BUT
Approval: UL/FCC/IC/NCC/Z-Wave Plus Certified RATHER CONTACT THE MANUFACTURER OF THE PRODUCT TO ARRANGE AN EXCHANGE
UL: E464831 OR REFUND IF THE PRODUCT IS DEEMED DEFECTIVE.
FCC ID: OXGZW36
Z-Wave Plus: ZC10-16010013 Disclaimer: Show Home is a separate entity from Inovelli. We have partnered to
bring unique Smart Devices to market. We hope you are happy with
your purchase and for more information, please visit:
www.inovelli.com
brought to you by:
ZW37 Smart Plug (2-Channel) Manual
Smart Plug (2-Channel)
WARRANTY
SPECIFICATIONS WARNING

Must not exceed 600 watts (Incandescent): 1200W (10A) Resistive or ½ HP
Motor. Total load capacity for both outlets is 1200W (10A) Resistive.
• Two Z-Wave controlled AC outlet for standard incandescent lighting, CFL/LED,
fans or small appliances
• Remote ON/OFF control via a Z-Wave controller (2-Channels)
• Manual ON/OFF control with the front panel push button
• Space efficient design
• Does not block the lower outlet when plugged into the upper outlet of a duplex wall receptacle
(This assumes that the duplex receptacle is mounted with the ground pin down).
• Plugs and cords for connected devices route to the side allowing close placement of furniture
• Grounded 3-wire power connection for safety
2
A. Manual/Program button (Toggle)
Single press — turn the lamp On/Off
Single press (while setting up) — include or exclude in Z-Wave network
B. Z-Wave controlled outlet (Channel 1)
This outlet can be remotely turned On/Off on the connected device
C. Z-Wave controlled outlet (Channel 2)
This outlet can be remotely turned On/Off on the connected device
1. Plug the light or appliance you want to control into the Z-Wave controlled smart
plug (B or C) on the wireless switch as shown in Step 3.
NOTE: Plug directly into outlet, do not use with extension cords
2. Plug the wireless smart switch directly into an available grounded outlet
(Top outlet recommend if possible).
1. If plugged in, unplug the smart switch from the receptacle.
2. Press and hold the top button for at least 3 seconds while you plug the
switch into a recepticle
3. Use this procedure only in the event that the network primary controller
is missing or otherwise inoperable.
1. Follow the instructions for your Z-Wave certified controller to include a
device to the Z-Wave network.
2. Once the controller is ready to include your device, press in and release the
toggle (A) 3-5 times within 3 seconds to include it in the network.
3. Once your controller has confirmed that the device has been included, refresh
the Z-Wave network to optimize performance (may vary based on controller).
4. Now your device should be fully operational and able to be used as normal
1. Follow the instructions for your Z-Wave certified controller to exclude a
device from the Z-Wave network.
2. Once the controller is ready to exclude your device, press in and release
the toggle (A) 3-5 times within 3 seconds to exclude it from the network.
Our product can be included and operated in Z-Wave network with other
certified devices and/or other applications.
Note: All non-battery nodes within Z-Wave network will act as repeater
1. Follow the instructions for your Z-Wave certified controller to include the device
to the Z-Wave network.
2. Once the controller is ready to include your device, single press and release
the toggle (A) 3-5 times within 3 seconds on the device to include it in the network.
3. Once your controller has confirmed that the device has been included, refresh
the Z-Wave network to optimize performance.
4. The association group supports two nodes and life line function.
Note: Your device may need to be within 10 feet of the controller to be included. If so, include the device to the network within 10 feet
of the controller and relocate it to the desired position in your home. Besure to refresh the network if the device is included in this manner.
Please reference the controller/gateway’s manual for instructions.
Now you have complete control to turn your lamp ON/OFF according to groups, scenes, schedules and interactive automations programmed
by your controller.If your Z-Wave certified controller features Remote Access,you can now control your lighting from your mobile phone devices.
For information on the "Command Classes", please visit: www.inovelli.com/NZW37-manual.pdf
GETTING TO KNOW YOUR Z-WAVE SMART PLUG
IMPORTANT INFORMATION ABOUT YOUR Z-WAVE SMART PLUG
INCLUDING YOUR DEVICE
EXCLUDING AND RESETTING YOUR DEVICE
ADDING YOUR DEVICE TO YOUR Z-WAVE NETWORK
TO RETURN YOUR DEVICE TO FACTORY DEFAULT
GETTING STARTED | PLUGGING IN YOUR MODULE
For a quick setup guide,
please scan the QR Code
below or go to:
www.inovelli.com/NZW37-setup
please see our tutorials on
common troubleshooting issues as
well as to submit a question if you
are having issues.
www.inovelli.com/nzw37-help
1
2
3
4
5
FOR TROUBLESHOOTING HELP

Generic Device Class GENERIC_TYPE_SWITCH_BINARY
Specific Device Class SPECIFIC_TYPE_POWER_SWITCH_BINARY
Command Classes COMMAND_CLASS_ZWAVEPLUS_INFO
COMMAND_CLASS_ASSOCIATION
COMMAND_CLASS_ASSOCIATEION_CRP_INFO
COMMAND_CLASS_DEVICE_RESET_LOCALLY
COMMAND_CLASS_MANUFACTURER_SPECIFIC
COMMAND_CLASS_MULTI_CHANNEL
COMMAND_CLASS_MULTI_CHANNEL_ASSOCIATION
COMMAND_CLASS_POWERLEVEL
COMMAND_CLASS_SWITCH_ALL
COMMAND_CLASS_SWITCH_BINARY
COMMAND_CLASS_VERSION
COMMAND CLASS INFORMATION
